Introduction Harmonic Harmonic filter design for impact study Filter design electrified railways EMT study Conclusion DIgSILENT USER GROUP Sydney 5 September 2013 M Jansen, S Hagaman, T George Introduction Introduction Harmonic


slide-1
SLIDE 1

Introduction Harmonic impact study Filter design EMT study Conclusion

Harmonic filter design for electrified railways

DIgSILENT USER GROUP

Sydney — 5 September 2013

M Jansen, S Hagaman, T George

slide-2
SLIDE 2

Introduction Harmonic impact study Filter design EMT study Conclusion

Introduction

◮ Railway electrification project ◮ Adds significant unbalanced non-linear load to the grid ◮ PowerFactory used for

◮ Harmonic emission/compliance ◮ Filter design/rating ◮ EMT review ◮ Protection design

slide-3
SLIDE 3

Introduction Harmonic impact study Filter design EMT study Conclusion

Feeder station topology

TNSP Network 132 kV RL1 RL2 RL3 HF1 RL4 RL5 RL6 HF2 50 kV (AB) (BC) T1 T2

Note: (AB)/(BC) phasing is typical

◮ Requires single phase compensation ◮ Limited output power

slide-4
SLIDE 4

Introduction Harmonic impact study Filter design EMT study Conclusion

Emission limits

Emission limit (% of V1) 0.5 1.0 1.5 Harmonic order THD 7 13 19 25 31 37 43 49

slide-5
SLIDE 5

Introduction Harmonic impact study Filter design EMT study Conclusion

Range of network conditions

Network impedance (Ω) 10 100 1000 Frequency (× 50 Hz) 5 10 15 20 25 30 35 40 45 50

slide-6
SLIDE 6

Introduction Harmonic impact study Filter design EMT study Conclusion

Current spectra

Measured Expanded Used Current emission (% of V1) 0.001 0.01 0.1 1 10 Harmonic order THD 7 13 19 25 31 37 43 49

slide-7
SLIDE 7

Introduction Harmonic impact study Filter design EMT study Conclusion

Voltage distortion without filters

PoC voltage distortion (% of V1) 0.001 0.01 0.1 1 10 Harmonic order THD 7 13 19 25 31 37 43 49

slide-8
SLIDE 8

Introduction Harmonic impact study Filter design EMT study Conclusion

Filter configuration

Shunt Third Fifth Ninth Phase A Phase B From 50 kV switchroom

slide-9
SLIDE 9

Introduction Harmonic impact study Filter design EMT study Conclusion

Voltage distortion with filters

PoC voltage distortion (% of V1) 0.001 0.01 0.1 1 Harmonic order THD 7 13 19 25 31 37 43 49

slide-10
SLIDE 10

Introduction Harmonic impact study Filter design EMT study Conclusion

Filter parameters

Rating C L Rp Tuned to Branch Type (Mvar) (µF) (mH) (Ω) (Hz) Shunt — 20 — 398 — — Third Single tuned 7 7.92 142 — 150 Fifth Damped 5 6.11 66.3 800 250 Ninth Damped 18 22.6 5.53 50 450

slide-11
SLIDE 11

Introduction Harmonic impact study Filter design EMT study Conclusion

Component ratings

Capacitor VN Reactor IRMS Resistor PR (kV) (A) (kW) Third 78.2 178.78 – Fifth 64.8 117.21 16 Ninth 61.0 414.45 80

slide-12
SLIDE 12

Introduction Harmonic impact study Filter design EMT study Conclusion

Electromagnetic study

◮ Design for electromagnetic transient (EMT) phenomena

◮ Peak voltage across capacitor banks ◮ Peak currents ◮ Protection setting stability

◮ Studies for switching transients and lightning surges ◮ Specification of mitigation measures

slide-13
SLIDE 13

Introduction Harmonic impact study Filter design EMT study Conclusion

Model augmentation for EMT study

TNSP Network 132 kV RL1 RL2 RL3 HF1 RL4 RL5 RL6 HF2 50 kV T1 T2 Stray capacitance Surge arrester

slide-14
SLIDE 14

Introduction Harmonic impact study Filter design EMT study Conclusion

PowerFactory simulation

◮ Operational scenarios to define different switching

arrangements

◮ 1 or 2 transformers online ◮ 1 or 2 filters online ◮ Several different track feeder arrangements ◮ Lightning strike points

◮ Study cases for each switching/lightning case ◮ Analysis of different point on wave switching ◮ DPL scripts to automate study cases, print plots and

analyse waveforms

slide-15
SLIDE 15

Introduction Harmonic impact study Filter design EMT study Conclusion

Switching study

VC3 VC5 VC9 Capacitor voltage (kV) 200 Time (s) 0.02 0.04 0.06 0.08 0.10 I3 I5 I9 Branch current (kA) −1 1 Time (s) 0.02 0.04 0.06 0.08 0.10

slide-16
SLIDE 16

Introduction Harmonic impact study Filter design EMT study Conclusion

Mitigation measures

◮ Switching transient

◮ Surge arresters specified across the 3rd tuned branch

capacitor bank (approaching IEC 60871-1 peak limit)

◮ Overcurrent protection graded to avoid spurious trips on

filter energisation

◮ Lightning surge

◮ Surge arresters specified for the filter busbars

slide-17
SLIDE 17

Introduction Harmonic impact study Filter design EMT study Conclusion

Capacitor bank voltages with surge arresters

175.4 kV

  • 205.9 kV

IEC 60871 voltage withstand limit VC3 (kV) −200 200 Time (s) 0.005 0.010 0.015 0.020

slide-18
SLIDE 18

Introduction Harmonic impact study Filter design EMT study Conclusion

Surge arrester current — PoW switching

PoW time 6 ms, Ipeak = -380 A IMOV (kA) −0.4 −0.2 Time (s) 0.005 0.010 0.015 0.020 0.025 0.030

slide-19
SLIDE 19

Introduction Harmonic impact study Filter design EMT study Conclusion

Surge arrester current — Lightning

Current (kA) 10 Time (ms) −0.1 0.1 0.2 Energy (kJ) 20 Time (ms) −0.1 0.1 0.2

slide-20
SLIDE 20

Introduction Harmonic impact study Filter design EMT study Conclusion

Conclusion

Thank you for your time Questions?
