Hadronic showers / missing energy in protoDUNE Pawel Guzowski Outline Particle gun MC of pions and protons Studying the MC true energy deposited in protodune Quantifying energy associated to primary, and to neutral secondaries

slide-1
SLIDE 1

Hadronic showers / missing energy in protoDUNE

Pawel Guzowski

slide-2
SLIDE 2

Outline

  • Particle gun MC of pions and protons
  • Studying the MC true energy deposited in

protodune

  • Quantifying energy associated to primary,

and to neutral secondaries (photons, neutrons)

  • Examining how much of the true energy ends

up as a reconstructed hit, and reconstructed clusters by 4 reconstruction modules

– lineclusterdc, linecluster, pandoradc, pandora

31 Oct 2016 2 Pawel Guzowski

slide-3
SLIDE 3

larsoft workflow

  • Using dunetpc v05_13_00

– protodune_v2 geometry

  • protoDUNE_gensingle.fcl

– Pion or proton, 0.1 – 3.0 GeV – x: 118.106 cm, y: 395.649 cm, z: 0 cm

  • protoDUNE_g4single.fcl
  • protoDUNE_detsim_single.fcl

– Optical simulation is off, to save time

  • protoDUNE_reco.fcl
  • No cosmics / multiparticle events

31 Oct 2016 Pawel Guzowski 3

slide-4
SLIDE 4

Analysis

  • For now, only looking at the true energy

deposits

  • Associating each energy deposit to

– Primary – Neutrons – and subsequent daughters – Photons – and subsequent daughters

  • Calculating the fraction of energy deposited

into those three categories

  • Calculating how much of this true energy

ends up in a reconstructed hit

31 Oct 2016 Pawel Guzowski 4

slide-5
SLIDE 5

1.2 GeV pion

31 Oct 2016 Pawel Guzowski 5

99% of energy associated to primary

photon-associated deposits primary-associated deposits

p i

  • n

positron

Points are true G4 energy deposits

slide-6
SLIDE 6

1.2 GeV pion

31 Oct 2016 Pawel Guzowski 6

74% of energy associated to photons

Neutron-associated deposits

pi-zero

slide-7
SLIDE 7

1.2 GeV pion

31 Oct 2016 Pawel Guzowski 7

73% of energy associated to neutrons

slide-8
SLIDE 8

MC True particles

31 Oct 2016 Pawel Guzowski 8

Soft neutrons scattering around everywhere

Green lines = photons

slide-9
SLIDE 9

3.0 GeV proton

31 Oct 2016 Pawel Guzowski 9

Hard neutron

slide-10
SLIDE 10

PIONS

31 Oct 2016 Pawel Guzowski 10

slide-11
SLIDE 11

Pion energy deposit

31 Oct 2016 Pawel Guzowski 11

Total Primary Neutrons Photons Line = mean Area = RMS

slide-12
SLIDE 12

Fractional components

31 Oct 2016 Pawel Guzowski 12

Primary Neutrons Photons

slide-13
SLIDE 13

Reconstructed hits

31 Oct 2016 Pawel Guzowski 13

Total Primary Neutrons Photons Energy ending up in a recob::Hit

slide-14
SLIDE 14

Reconstructed fraction

31 Oct 2016 Pawel Guzowski 14

Total Primary Neutrons Photons ~100% ~85% ~80% ~60%

slide-15
SLIDE 15

lineclusterdc Clusters

31 Oct 2016 Pawel Guzowski 15

Total Primary Neutrons Photons

slide-16
SLIDE 16

linecluster Clusters

31 Oct 2016 Pawel Guzowski 16

~90% ~70% ~55% ~30%

slide-17
SLIDE 17

pandoradc Clusters

31 Oct 2016 Pawel Guzowski 17

Total Primary Neutrons Photons

slide-18
SLIDE 18

pandora Clusters

31 Oct 2016 Pawel Guzowski 18

~90% ~60% ~50% ~20%

slide-19
SLIDE 19

PROTONS

31 Oct 2016 Pawel Guzowski 19

slide-20
SLIDE 20

Proton energy deposit

31 Oct 2016 Pawel Guzowski 20

Total Primary Neutrons Photons

slide-21
SLIDE 21

Fractional components

31 Oct 2016 Pawel Guzowski 21

Primary Neutrons Photons

slide-22
SLIDE 22

Reconstructed hits

31 Oct 2016 Pawel Guzowski 22

Total Primary Neutrons Photons Energy ending up in a recob::Hit

slide-23
SLIDE 23

Reconstructed fraction

31 Oct 2016 Pawel Guzowski 23

Total Primary Neutrons Photons ~100% ~85% ~70% ~65%

slide-24
SLIDE 24

lineclusterdc Clusters

31 Oct 2016 Pawel Guzowski 24

Total Primary Neutrons Photons

(statistical fluctuation,

  • ne entry)
slide-25
SLIDE 25

linecluster Clusters

31 Oct 2016 Pawel Guzowski 25

~90% ~70% ~40% ~30%

slide-26
SLIDE 26

pandoradc Clusters

31 Oct 2016 Pawel Guzowski 26

Total Primary Neutrons Photons

slide-27
SLIDE 27

pandora Clusters

31 Oct 2016 Pawel Guzowski 27

~90% ~60% ~30% ~20%

slide-28
SLIDE 28

Summary

  • ~100% of primary energy deposit is

reconstructed in hits

  • ~40% of neutron energy is lost
  • ~30% of photon energy is lost
  • Even more energy is unclustered
  • Pandora doing worse than linecluster
  • No difference between ‘dc’ and non-‘dc’

31 Oct 2016 Pawel Guzowski 28

slide-29
SLIDE 29

BACKUPS

31 Oct 2016 Pawel Guzowski 29

slide-30
SLIDE 30

Total E deposit for 1.0 GeV pion

31 Oct 2016 Pawel Guzowski 30

Mean = 0.8 RMS = 0.1
