H0K03a : Advanced Process Control Model-based Predictive Control 2 : - - PowerPoint PPT Presentation

▶
h0k03a advanced process control
SMART_READER_LITE
LIVE PREVIEW

H0K03a : Advanced Process Control Model-based Predictive Control 2 : - - PowerPoint PPT Presentation

Jan 06, 2024 34 likes •547 views

H0K03a : Advanced Process Control Model-based Predictive Control 2 : Dynamic Optimization Bert Pluymers Prof. Bart De Moor Katholieke Universiteit Leuven, Belgium Faculty of Engineering Sciences Department of Electrical Engineering (ESAT)

slide-1
SLIDE 1

Bert Pluymers

  • Prof. Bart De Moor

Katholieke Universiteit Leuven, Belgium Faculty of Engineering Sciences Department of Electrical Engineering (ESAT) Research Group SCD-SISTA

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

H0K03a : Advanced Process Control

Model-based Predictive Control 2 : Dynamic Optimization

slide-2
SLIDE 2

1

Overview

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Lesson 2 : Dynamic Optimization

  • Optimization basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-3
SLIDE 3

2

General form : Legend :

  • : vector of optimization variables
  • : objective function / cost function
  • : equality constraints
  • : inequality constraints
  • : solution to optimization problem
  • : optimal function value

Notation

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-4
SLIDE 4

3

Gradient : (points in direction of steepest ascent) Hessian : (gives information about local curvature of )

Gradient & Hessian

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-5
SLIDE 5

4

Gradient & Hessian

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Example : Gradients for different Eigenvectors of hessian at the origin ( )

slide-6
SLIDE 6

5

Unconstrained Optimality Conditions

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Necessary condition for optimality of Sufficient conditions for minimum positive definite Classification of optima : positive definite minimum indefinite saddle point negative definite maximum

slide-7
SLIDE 7

6

Introduction of Lagrange multipliers leads to Lagrangian : with Lagrange multipliers of the ineq. constraints Lagrange multipliers of the eq. constriants Constrained optimum can be found as Minimization over but Maximization over !!!!

Lagrange Multipliers

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-8
SLIDE 8

7

Constrained optimum can be found as First-order optimality conditions in

Lagrange Multipliers

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Gradient of Gradient of ineq. Gradient of eq.

Interpretation ???

slide-9
SLIDE 9

8

Lagrange Multipliers

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-10
SLIDE 10

9

Lagrange Multipliers

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-11
SLIDE 11

10

Lagrange Multipliers

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-12
SLIDE 12

11

Lagrange Duality

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-13
SLIDE 13

12

Karush-Kuhn-Tucker Conditions

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

From previous considerations we can now state necessary conditions for constrained optimality : These are called the KKT conditions.

slide-14
SLIDE 14

13

Optimization Tree

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Optimization discrete continuous unconstrained constrained convex

  • ptimization

non-convex

  • ptimization

NLP LP QP SOCP SDP

slide-15
SLIDE 15

14

Convex Optimization

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

An optimization problem of the form is convex iff for any two feasible points :

  • is feasible
  • This is satisfied iff
  • `the cost function is a convex function
  • the equality constraints or linear or absent
  • the inequality constraints define a convex region
slide-16
SLIDE 16

15

Convex Optimization

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Importance of convexity :

  • no local minima, one global optimum
  • under certain conditions, primal and dual have

same solution

  • efficient solvers exist
  • polynomial worst-case execution time
  • guaranteed precision
slide-17
SLIDE 17

16

From LP to SDP

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

SDP SOCP QP LP

Semi-Definite Programming Second Order Cone Progr. Quadratic Programming Linear Programming

computational efficiency generality

slide-18
SLIDE 18

17

General form : Remarks :

  • always convex
  • optimal solution always at a corner of ineq. constraints
  • typically used in finance / economics / management

Linear Programming (LP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

slide-19
SLIDE 19

18

Linear Programming (LP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Eliminating equality constraints : Reparametrize optimization vector : Leading to

slide-20
SLIDE 20

19

Quadratic Programming (QP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

General form : Remarks :

  • convex iff
  • LP is a special case of QP (imagine )
  • Used in all domains of engineering
slide-21
SLIDE 21

20

Second-Order Cone Programming (SOCP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

General form : Remarks :

  • Always convex
  • Second-Order, Ice-Cream, Lorentz cone :
  • Engineering applications with sum-of-squares,

robust LP, robust QP

SOC constraint

slide-22
SLIDE 22

21

Second-Order Cone Programming (SOCP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

QP as special case of SOCP : Rewrite this as which is equivalent to By introducing an additional variable we get the SOCP

slide-23
SLIDE 23

22

Semi-Definite Programming (SDP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

General form : with Remarks :

  • means that should be positive semi-definite
  • means that should be pos. semi-def.
  • always convex :
  • ineq. constraints called LMI’s : Linear Matrix Ineq.
  • LMI’s arise in many applications of

Systems & Control Theory

slide-24
SLIDE 24

23

Semi-Definite Programming (SDP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

convexity : Easily verified : hence and therefore which means that LMI’s are convex constraints.

slide-25
SLIDE 25

24

Semi-Definite Programming (SDP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Schur Complement : is equivalent with More general : Remarks :

  • Originally developed in a statistical framework
  • Today widely used in S&C in order to reformulate

problems involving eigenvalues as an LMI.

slide-26
SLIDE 26

25

Semi-Definite Programming (SDP)

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

SOCP as special case of SDP : is equivalent with (by using Schur complement) : (exercise : apply Schur complement to LMI and reconstruct SOC constraint)

slide-27
SLIDE 27

26

Convexity = SDP ?

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Formulated as SDP Convex optimization Convex optimization formulatable as SDP Example :

slide-28
SLIDE 28

27

Convexity ≠ SDP !

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

SDP SOCP QP LP convex optimization

structure easily exploitable (many toolboxes available) → significant efficiency gains ! convexity difficult to exploit (computationally)

slide-29
SLIDE 29

28

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

MPC Paradigm

  • At every discrete time instant , given information about

the current system state , calculate an ‘optimal’ input sequence over a finite time horizon :

  • Apply the first input to the real system
  • Repeat at the next time instant , using new state

measurements / estimates.

N N

slide-30
SLIDE 30

29

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Dynamic Programming

  • Finding the optimal input sequence is done by means
  • f Dynamic Programming
  • Definition* :

“DP is a class of solution methods for solving sequential decision problems with a compositional cost structure”

  • Invented by Richard Bellman (1920-1984) in 1953
slide-31
SLIDE 31

30

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Example 1 : The darts problem* : “Obtain a score of 301 as fast as possible while beginning and ending in a double.”

  • Decision : next area towards which to throw the dart
  • Cost : time

http://plus.maths.org/issue3/dynamic/

* D. Kohler, Journal of the Operational Research Society, 1982.

Dynamic Programming

slide-32
SLIDE 32

31

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Example 2 : DNA sequence allignment : G A A T T C A G T T A (sequence #1) G G A T C G A (sequence #2)

  • Decisions : which nucleotides to match
  • Cost : e.g. based on substitution / insertion prob.
  • Algorithms : Baum/Welch, Waterman/Smith, …

Dynamic Programming

slide-33
SLIDE 33

32

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

“Series of sequential decisions” :

Dynamic Programming in MPC

Typical optimization problem :

measured Optimization variables

→ standard QP formulation ?

slide-34
SLIDE 34

33

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Optimization vector : Cost function : For convexity hence .

Linear MPC as standard QP

slide-35
SLIDE 35

34

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Equality constraints with Sparsity : many entries in equal to 0

Linear MPC as standard QP

slide-36
SLIDE 36

35

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Inequality constraints with Sparsity : many entries in equal to 0

Linear MPC as standard QP

slide-37
SLIDE 37

36

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Alternatives

  • slightly faster to solve
  • ‘chattering’ : optimal solution jumps around
slide-38
SLIDE 38

37

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Alternatives

Non-convex optimization in general : to be avoided !!!

slide-39
SLIDE 39

38

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

MPC and optimization

slide-40
SLIDE 40

39

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

MPC and optimization

slide-41
SLIDE 41

40

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Active Set Methods

slide-42
SLIDE 42

41

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Active Set Methods

slide-43
SLIDE 43

42

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Interior Point Methods

  • 1. Choose initial point
  • 2. Linearize KKT conditions around current point
  • 3. Solve Linearized KKT system to obtain search

direction

  • 4. Calculate step length such that
  • 5. Repeat from step 2, until convergence
slide-44
SLIDE 44

43

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Interior Point Methods

slide-45
SLIDE 45

44

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Comparison

  • ASM allow hot start
  • reuse of active set, factorizations, …
  • ASM has feasible intermediate results
  • by construction
  • IPM can exploit sparsity
  • solution of KKT system by sparse solver

In industry currently mostly ASM due to first two advantages, but IPM under consideration…

slide-46
SLIDE 46

45

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Comparison

slide-47
SLIDE 47

46

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Comparison

slide-48
SLIDE 48

47

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Comparison

slide-49
SLIDE 49

48

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Comparison

slide-50
SLIDE 50

49

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

Conclusion

  • convex optimization powerful tool !!!
  • different optimization algorithm have pro’s and con’s
  • try to avoid NLP’s !!!!
slide-51
SLIDE 51

50

  • Overview
  • Optimization Basics
  • Convex Optimization
  • Dynamic Optimization
  • Optimization Algorithms

Signal processing

Identification System Theory Automation

H0k03a : Advanced Process Control – Model-based Predictive Control 2 : Dynamic Optimization bert.pluymers@esat.kuleuven.be

References
