East Sligh Avenue Segment 1 Group 4 University of South Florida CGN6933 Sustainable Transportation Spring 2019 Juan Medina, Wyatt Burttschell, Aman Kansagara, Indrajeet Shah, Harshavardhan Reddy, shanumukaeswara April 18, 2019 1 Goals and

slide-1
SLIDE 1

East Sligh Avenue Segment 1 Group 4

University of South Florida CGN6933 Sustainable Transportation Spring 2019 Juan Medina, Wyatt Burttschell, Aman Kansagara, Indrajeet Shah, Harshavardhan Reddy, shanumukaeswara April 18, 2019

1

slide-2
SLIDE 2

Goals and Objectives

  • Goal 1: Enhance safety and travel behaviors.
  • Objectives
  • Reduce the number of collisions involving property damage,

serious injury, fatality and pedestrians by 30 percent.

  • Reduce the number of crashes caused by distracted or impaired

behavior by 30 percent.

2

slide-3
SLIDE 3

Goals and Objectives

  • Goal 2: Increase the viability of non-motorized travel
  • ptions.
  • Objectives
  • Eliminate all redundant driveways and improve overall sidewalk

conditions and width by 1 foot.

  • Reduce vehicle miles travel by 20 percent.

3

slide-4
SLIDE 4

Goals and Objectives

  • Goals 3: Enhance aesthetics, social inclusion, economic

activity and environmental quality.

  • Objectives
  • Introduce a series of five landscaping, art and stormwater

management elements.

  • Identify address and redevelop all sites of potential

contamination, with emphasis on low density abandoned parcels.

4

slide-5
SLIDE 5
  • E. Sligh From N. Florida Ave To N. Nebraska Ave

5

slide-6
SLIDE 6

Existing Conditions Almanac

  • East Sligh From N. Florida to N. Nebraska, 0.5 miles.
  • No Transit Stations on E. Sligh.
  • Extensive bus routes are found on N. Florida and N. Nebraska.
  • Limited, to no, amenities offered at surrounding bus stops.
  • No active buffered or non-buffered bicycle lanes
  • 5 Pedestrian Crossings
  • Improvements are aimed at achieving ADA standards and applying

NACTO guidelines for curbside and crosswalk design.

6

slide-7
SLIDE 7

Existing Conditions

7

  • Right of way varies 53 ft-66 ft.
  • 10-11 feet travel lanes
  • 4.5 foot sidewalk w/ grass buffer and gutter
  • 4 lane undivided
slide-8
SLIDE 8

Existing Conditions

8

Narrow, steep and unaccommodating sidewalks. Overgrown shrubs intruding on sidewalk with redundant driveways

slide-9
SLIDE 9

Existing Conditions

9

Faded Markings. Poor Sidewalk Conditions Poor road conditions on side streets

slide-10
SLIDE 10

Crash Data

  • 2015-2019 (5-Year Period)

118 107 1 20 40 60 80 100 120 140

Property Damage Injury Fatality

226 Total Crashes 448 Total Vehicles Involved

10

Property Damage Injury Fatality

slide-11
SLIDE 11

Crash Data

Bike and Pedestrian Data

  • 06/07/2013 to 05/07/2018
  • 13 Incidents involving cyclists and

pedestrians 10 resulting injuries.

  • No report of aggressive or

intoxicated behavior 11

Crash Injuries Peds Bike Intersection Straight Ahead 3 2 3 1 Turning Left 6 6 6 1 2 Unknown 2 2 2 1 Vehicle Motion

slide-12
SLIDE 12

Map of Activity Centers

12

Owner: City of Tampa Type: Fitness Center Acres: 7.97

Owner: Tampa Baptist Church Property Type: Church Acres: 4.13 Owner: Huracan Realty LLC Property Type: Supermarket Acres: 0.67

Off Street Parking Areas

Source: https://gis.hcpafl.org/gissearch/

slide-13
SLIDE 13

Zoning

RO Residential Office: Primarily for low density residential development and low intensity office uses compatible with residential neighborhoods. Minimum lot size is 5000 square feet, 1 unit per 5000 sq. ft. Maximum height is 35 feet. CG Commercial-general: Variety of retail and commercial service activities can be conducted compatible with surrounding uses and residential districts. Minimum lot size is 10000 square feet. Maximum height is 45 feet. RS Residential Single Family: Provides areas primarily for low density single-family detached dwellings. Maximum height is 35 feet. CN Commercial-neighborhood: This district provides areas for limited retail and personal services in residential neighborhoods. CI Commercial-intensive: This district provides areas for intense commercial activity, permitting heavy commercial and service uses. Minimum lot size is 10000 square feet. Maximum height is 45 feet.

13

slide-14
SLIDE 14

Traffic Count

14

2014: 26,249 2018: 29,280 2018: 18,669 2014: 16,944

2014: 22,000 2015: 22,500 2016: 22,500 2017: 23,500

  • Traffic counts by FDOT stations

indicate slightly higher traffic volumes

  • Traffic volumes east of I-275

indicate the corridor could be a potential candidate for a road diet.

  • To accommodate a road diet, future

travel demands will needed to be shifted to other forms of transportation.

Based on County Count Stations

Source: The Federal Highway Administration’s Road Diet Informational Guide (FHWA-SA-14-028).

slide-15
SLIDE 15

Bicycle Connections

15

https://www.strava.com/onboarding

  • No bicycle paths on East Sligh

segment

  • Limited connectivity to activity

centers.

  • A connected bike network

would be consistent with Hillsborough County’s Imagine 2040 Long Range Transportation Plan

  • Included in TBARTA’s Regional

Multi Use Trail Network as a “Conceptual Trail”

slide-16
SLIDE 16

Functional Classification

16

Sligh Avenue: Hillsborough, Arterial

  • N. Nebraska and I-275:

State, Principal Arterial North Florida: State, Arterial

slide-17
SLIDE 17

Speed Limits

17

35 MPH 40 MPH 55-65 MPG

Legend

  • Speed reduction mechanisms to

consider include; landscaped median (with pedestrian refuge), lane shifts, roundabouts, street trees and

  • n-street parking.
  • Passive vs. protective street

design

slide-18
SLIDE 18

2025 Improvements

  • 2025
  • Enhancement to all side street crosswalks applying PROWAG

and NACTO standards.

  • Left turn lane elimination at N. Florida intersection, bike lane

and increased sidewalk width.

  • All improvements fit within the existing right of way

18

slide-19
SLIDE 19

Crosswalk 2025

19

Proposed flashing beacon crosswalk to connect residential side streets with recreational area

slide-20
SLIDE 20

2025 Crosswalks and Surface Enhancements

20 Improved crosswalks for non- signalized streets

N Wellington

N Branch N Dixon N Navin

  • E. Sligh Ave
slide-21
SLIDE 21

Crosswalk design guidelines (NACTO Urban street design Guide)

  • Stripe all signalized crossings to reinforce yielding of vehicles

turning during a green signal phase.

  • Street lighting should be provided at all intersections, with

additional care and emphasis taken at and near crosswalks.

  • Accessible curb ramps are required by the Americans with

Disabilities Act (ADA) at all crosswalks.

21

slide-22
SLIDE 22
  • N. Florida Ave. Intersection Curb Ramps

22

slide-23
SLIDE 23

Bike Lanes

  • Bike lanes will be included

throughout the entire segment, approximately 0.5 miles.

  • Combining both bike lanes

and buffered bike lanes for some portions.

23

slide-24
SLIDE 24

2025 Design Improvements N. Florida Intersection

24

slide-25
SLIDE 25

2040 Improvements

  • All improvements take place within the existing right of way, no

acquisition for additional right of way required.

  • Channelized off ramp
  • Implementing bike lanes and wider sidewalks
  • Solar flashing crosswalk lights
  • Underpass lighting and art
  • Additional landscaping and stormwater management
  • Additional recreational and transit amenities

25

slide-26
SLIDE 26

2040 Channelized Right-turning Lane (off-ramp)

26

slide-27
SLIDE 27

Asymmetrical three-lane road/ lane elimination

27

slide-28
SLIDE 28

2040 N. Nebraska Right Turn Lane Elimination

28

slide-29
SLIDE 29

2040 Road Diet From I-275 to N. Nebraska

29

East Sligh From I-275 Heading East to N. Nebraska Integrate pervious strips into median

  • section. Using native landscaping and

maximum 2% gentle side slope to direct flow into the facility. Future and current traffic projections support a road diet for Sligh Ave East of I-

  • 275. Grid network and enhanced non

motorized travel options will allow for successfully diversion of traffic flow, if needed.

Source: NACTO Urban Street Design Guide

slide-30
SLIDE 30

Stormwater Drain Relocation - N Dixon Ave Intersection

30

slide-31
SLIDE 31

Stormwater Drain Relocation - N Dixon Ave Intersection

31

slide-32
SLIDE 32

Stormwater Drain Relocation - N Central Ave Intersection

32

slide-33
SLIDE 33

Stormwater Management

  • Integrated into the landscaping of design improvements will be

stormwater management elements; including bioswales and pervious strips

  • NACTO Urban Street Design

33

slide-34
SLIDE 34

2040 Safety and Art Improvement For I-275

34

Light Emitting Metallic Palm Trees And Landscaped Median Will Enhance Aesthetics and Safety For the Corridor

slide-35
SLIDE 35

2040 MPO Green ARTery/ Walk Bike Plan

  • The City of Tampa and the MPO plan a

loop trail linking downtown Tampa to Palmetto Beach, Ybor City, Rowlett Park, Sulphur Springs, Lowry Park and along the Hillsborough River back to downtown Tampa.

  • E. Sligh and The Hillsborough River play

a central role

http://www.greenartery.org/wp-content/uploads/2016/05/Walk- Bike-Phase-V-Draft_051716.pdf

35

slide-36
SLIDE 36

American Legion Park

36

slide-37
SLIDE 37

TDM Measure to further reduce VMT

  • In addition to protected bike lanes further TDM measures

can include;

  • Congestion pricing
  • Carsharing/ Bike sharing
  • Telework
  • Standardized wayfinding
  • Unlimited transit passes or transit subsides

37

slide-38
SLIDE 38

Solar roads

France China

slide-39
SLIDE 39

Why Solar Roads?

  • Illuminated lighting
  • Renewable energy
  • Safer driving condition
  • High durability (20 to 40years)
  • Less pollution
  • Pay for itself
slide-40
SLIDE 40

Solar Road

slide-41
SLIDE 41

Future Plug in Charging Stations

  • Electric cars sale has

increased to 81% in 2018.

  • USA is second large country

in usage of electric vehicles

  • By 2030 there are 130

million electric vehicles on the road*

  • 90% of passenger cars will be

electric in USA by 2040#

*http://fortune.com/2018/05/31/electric-vehicles- international-energy-agency/ https://news.nationalgeographic.com/2017/09/electric- cars-replace-gasoline-engines-2040/

slide-42
SLIDE 42

Charging Plug-in points

slide-43
SLIDE 43

Thank You!

Any Questions? www.cutr.usf.edu

43
