Constructed nstructed We Wetla tland nd Grou Gr oup p Ree eed Bed ed Sy System ems for Bio iosolid solids s Trea eatm tment ent An Innovative and Cost Effective Approach to Wastewater and Sludge Treatment Constructed Wetlands


slide-1
SLIDE 1

An Innovative and Cost Effective Approach to Wastewater and Sludge Treatment

Constructed nstructed We Wetla tland nd Gr Grou

  • up

p

Ree eed Bed ed Sy System ems for Bio iosolid solids s Trea eatm tment ent

slide-2
SLIDE 2

Aiken, MN Aliquippa, PA Amity Township, PA Ancora State Hospital, Ancora, NJ Appomattox, VA Belgium, WI Bethel, ME Beverly, NJ Birdsboro, PA Blairsville, PA Bowmanstown, PA Brillion, WI Burgettstown, PA Caribou, ME Central Carbon, PA Culver, IN Deer Lake, PA Delano, MN Denton, MD Elizabethville, PA Falls City, NE Fleetwood, PA Friendship, NY Greencastle, IN Green Lane, PA Harrison Township, PA Hawley Area Authority, PA Indian Head, MD Kasson, MN

Constructed Wetlands Group, Inc.

Reed Beds in Operation

Maiden Creek, PA Marion, WI Marlboro Developmental Ctr., Marlboro, NJ Morysville, PA Myerstown, PA Mercersburg, PA New Jersey School Of Conservation, Branchville, NJ New Paris, IN Northern Lancaster County Authority, Denver, PA North Warren, PA Oley, PA Oneida Tribe of Wisconsin Orbissonia Rockhill , PA Orwigsburg, PA Penn Yan, NY Pine River, MN Red Cliff Band of Chippewa, WI Robeson, PA Robesonia Wernersville, PA Royersford, PA Saint Michael, MN Salem, MO Schuylkill County MUA, Gordon, PA Shade Gap, PA Sherwood, WI Shickshinny, PA Sinking Spring, PA

slide-3
SLIDE 3

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

On-Site Water and Wastewater Treatment

An effective, cost-saving approach to dewatering sludge

slide-4
SLIDE 4

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

History of Reed Beds

  • Original research and

seminal work conducted by the Max-Plank Institute, Ustersbach, Germany.

  • Research began in the

late 1950’s - early 1960’s.

slide-5
SLIDE 5

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

  • Dr. Kaethe Seidel
  • A pioneer in the study of

the sewage treatment plant

  • Dr. Seidel’s

experiments showed the ability to metabolize and uptake various organic as well as inorganic substances

slide-6
SLIDE 6

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Metabolizing Plants

  • Macrophytes grown

hydroponically, and plants such as

  • Phragmites (common reed),
  • Scirpus (soft stemmed bulrush),
  • Juncus (bulrush), and
  • Typha (cattail)
slide-7
SLIDE 7

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Design Considerations for Reed Bed Biosolid Treatment

  • Volume of sludge
  • Sludge characteristics
  • including use of polymers
  • flocculent such as alum
  • Climatic conditions
  • Volatile solids concentration
  • f waste activated sludge
  • Stabilization process

(aerobic vs. anaerobic)

slide-8
SLIDE 8

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Design Considerations continued

  • Most aerobic biosolids systems have further

stabilization of WAS

  • Efficacy of system dramatically diminished when

volatile solids are consistently above 70 percent

  • Provide biosolids retention

to comply with seasonal application cycles

  • winter application

intervals may be 3-4 weeks

  • Land availability
slide-9
SLIDE 9

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Sludge Quality

  • Metal concentration
  • Oil and grease content
  • pH
slide-10
SLIDE 10

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Biodynamics and Mechanisms

  • f the Reed Bed Process
  • Based on previously discussed

design considerations

  • application rates will vary from

20 to 50 gal./sq. ft./yr.

  • Application rates and intervals will

depend on (est. 12-22 applications a year)

  • severity of winter as it relates to

freeze and thaw conditions

  • amount of precipitation
slide-11
SLIDE 11

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Root System Phragmites (common reed)

  • Extensive root structure

creates an environment for diverse and active micro flora

  • microorganisms continually

help to degrade the volatile solids

  • reduction in volatile

solids documented as low as 20 percent

  • Root structure enhances

hydraulic conductivity and drainage of supernatant and water from the biosolids

slide-12
SLIDE 12

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Root System Phragmites continued

  • Voracious demand for water

by the plants results in uptake and release of water by the leaf structure (evapotransporation)

  • Mature monoculture of reeds

can effectively assimilate up to the equivalent of 40 inches

  • f annual precipitation
  • Mature plants can

transfer oxygen to its root system even against the pressure

  • f six feet of water
slide-13
SLIDE 13

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Physical Characteristics of Phragmites

  • Rhizome and emergent stalk

has a system of nodes

  • When nodes are engulfed

by biosolids, they form adventitious secondary root system

  • Secondary root system

provides enhanced attachment sites for microorganisms and aids in dewatering

slide-14
SLIDE 14

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Propagation of Phragmites

  • Phragmites are one of the

world’s most opportunistic plant species

  • Found in over 40 states
  • Can survive in up to six feet
  • f standing water for long

periods of time

  • Can also be found in desert

climates

  • Phragmites is native in many
  • f the states in which it is

found

  • Phragmites has been

documented historically in almost all mid-western states

slide-15
SLIDE 15

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Propagation Issues

  • Phragmites is viewed as an

invasive species

  • It has been shown that

Phragmites propagates almost exclusively by vegetative means

  • Scientists have proven in the

laboratory that 30 - 70% of the seeds produced are viable

  • However, conditions necessary

for germination of the seed make it extremely difficult to propagate via seed.

slide-16
SLIDE 16

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Safeguards to Prevent Inadvertent Spread of Phragmites

  • Special care of harvested plant material
  • Use of rigid structural barriers

(concrete and treated timber)

  • Ultimate disposal of the biosolids together with the

plant material should be carefully monitored

slide-17
SLIDE 17

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Advantages of the Reed Bed System

  • Although there are significant capital costs in new

construction, there are minimal operation and maintenance costs

  • Existing drying beds can be inexpensively

converted to accommodate reed beds

  • Requires no removal of biosolids

for six to ten years

  • Final bi-product may meet

Class A limitations for final disposal

slide-18
SLIDE 18

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

More Advantages

  • Significant volume and volatile solids reduction
  • Long term dewatering and biosolids degradation
slide-19
SLIDE 19

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Construction of the Reed Beds

  • Typically Reed Beds

are constructed with concrete side walls

slide-20
SLIDE 20

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Construction of Reed Beds (continued)

  • PVC liner is used to

make the beds impermeable

slide-21
SLIDE 21

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Construction of Reed Beds (continued)

  • Perforated underdrain

system usually connected to the head of the plant

slide-22
SLIDE 22

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Construction of Reed Beds (continued)

  • Less than two feet of

gravel and sand required

  • 3.5 - 4 feet wall of

freeboard or cement

  • Biosolids distribution system
  • Eight foot tongue and

groove pretreated side panels

slide-23
SLIDE 23

The Process

Wastewater Treatment Plant

slide-24
SLIDE 24

The Process

Clearing the Site

slide-25
SLIDE 25

The Process

Clearing and Preparing the Site

slide-26
SLIDE 26

The Process

Clearing and Preparing the Site

slide-27
SLIDE 27

The Process

Preparing the Site

slide-28
SLIDE 28

The Process

Adding Watering System and Walls

slide-29
SLIDE 29

The Process

Adding Walls

slide-30
SLIDE 30

The Process

Adding Walls

slide-31
SLIDE 31

The Process

Adding Walls

slide-32
SLIDE 32

The Process

Adding Entrance/Exit

slide-33
SLIDE 33

The Process

At Entrance/Exit

slide-34
SLIDE 34

The Process

Construction

slide-35
SLIDE 35

The Process

Watering System

slide-36
SLIDE 36

The Process

Inspecting and Preparing for PVC Liner

slide-37
SLIDE 37

The Process

Laying Out PVC Liner

slide-38
SLIDE 38

The Process

Installing PVC Liner

slide-39
SLIDE 39

The Process

Installing PVC Liner

slide-40
SLIDE 40

The Process

Installing PVC Liner

slide-41
SLIDE 41

The Process

Adding Gavel Layer over PVC Liner

slide-42
SLIDE 42

The Process

Adding Sand Layer over Gravel Layer

slide-43
SLIDE 43

The Process

Planting of Rhizomes in Sand

slide-44
SLIDE 44

The Process

Watering Rhizomes

slide-45
SLIDE 45

The Process

Watering Rhizomes

slide-46
SLIDE 46

The Process

Flooding Bed

slide-47
SLIDE 47

The Process

Flooding Bed

slide-48
SLIDE 48

The Process

Early Phragmites/Reed Growth

slide-49
SLIDE 49

The Process

Grown Mature Phragmites

slide-50
SLIDE 50

The Process

Grown Mature Phragmites

slide-51
SLIDE 51

The Process

Grown Mature Phragmites

slide-52
SLIDE 52

The Process

Grown Mature Phragmites

slide-53
SLIDE 53

The Process

Harvesting Phragmites/Reeds

slide-54
SLIDE 54

The Process

Harvested Reed Piles – Ready for Mulching or Baling

slide-55
SLIDE 55

The Process

Harvested Reed Piles – Mulched

slide-56
SLIDE 56

The Process

Harvested Reed Piles – Mulched

slide-57
SLIDE 57

The Process

Seasonal Burning of Unneeded Phragmites/Reeds

slide-58
SLIDE 58

The Process

Dormant Winter Tubular Reeds Allow Air Flow

slide-59
SLIDE 59

The Process

Solids Prior to Screening of Rhizomes – with Topsoil Consistency

slide-60
SLIDE 60

The Process

Removal of Solids Built-up over 8 to 10 years

slide-61
SLIDE 61

The Process

Removal of Solids After 8 to 10 years

slide-62
SLIDE 62

The Process

Applying to Agricultural Land – Consistency of Nutrient-Rich Topsoil

slide-63
SLIDE 63

The Process

Reworking the Bed Bottom

slide-64
SLIDE 64

The Process

Flooding for New Season

slide-65
SLIDE 65

The Process

New Season Growth

slide-66
SLIDE 66

The Process

Grown Mature Phragmites

slide-67
SLIDE 67

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Preparing for Planting

  • Spacing of rhizomes

12 inches apart

  • Watering new roots
slide-68
SLIDE 68

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Preparing for Planting

  • Watering covered rhizomes
  • Flooding of bed
slide-69
SLIDE 69

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Planting of Phragmites

  • Planting season from mid

April to November

  • Vegetative root stock is

planted on one foot centers

  • Watering is required for a

period of 4-8 weeks after planting depending on the season

  • Application of biosolids

within 4-6 weeks after planting

slide-70
SLIDE 70

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Operational Concerns & Common Problems

  • Over loading or application
  • f poorly digested biosolids
  • may cause plant stress or

plant mortality

  • formation of anaerobic slime

layers and potential for

  • dor problems
  • diminished drainage resulting

in significant downtime

  • Immature reeds can be

susceptible to nitrogen burn, heat stress, ammonia toxicity and damage by aphids

slide-71
SLIDE 71

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Solution to Common Problems

  • Early recognition and prompt re-mediation
  • increased levels of DO in biosolids stabilization process
  • longer retention time
  • conservative application rates
  • avoidance of loading on hot sunny days (causes burn)
  • taking beds out of service for extended periods of time
slide-72
SLIDE 72

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Control of Biological Pests (Aphids)

  • During the first year of plant growth,

aphids can cause serious damage

  • Aphids can be managed with

chemical and biological controls

  • During the first year it is often

necessary to use systemic insecticides such as Cygon

  • With established plants aphids can be

controlled by the release of ladybugs

slide-73
SLIDE 73

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Harvesting of Reed Beds

  • Harvesting is normally done in the winter when the

biosolid layer is frozen

  • provides firm footing
  • plants are dormant
  • Harvesting can be completed by several methods
  • use of sickle bar mower
  • weed trimmer with metal blade
  • burning
slide-74
SLIDE 74

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Why Do We Harvest the Reeds?

  • Significant biomass (10-13 foot high plants) will

dramatically add to the sludge blanket if not removed

  • Although metal uptake by plants is not significant,

removal of the reeds helps to lower metal levels in the accumulated biosolids layer over time

  • reeds have the greatest

affinity for copper and zinc

slide-75
SLIDE 75

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Harvesting continued

  • Nine to twelve inches of plant stalk

should be left after harvesting

  • Remaining stalk is dead

plant material, which will not renew itself

  • important conduit for air to

the rhizome which promotes new growth the following season

  • creates hydraulic

conductivity promoting drainage during the winter

slide-76
SLIDE 76

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Disposal of Harvested Material

  • Disposal methods for

reed stalks

  • composting on-site
  • chipping/mulching
  • burning
  • disposal to landfill
  • baling
slide-77
SLIDE 77

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Evacuation of Reed Beds

  • Eventually biosolids will

accumulate to 3 – 3.5 depths

  • Beds are taken out of

service for six months, beginning in the fall

  • Allowing time for the

biosolids to dry and degrade

  • Following six month down

time, water content becomes as low as 50%

  • Beds can be walked

upon, biosolids are friable

slide-78
SLIDE 78

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Evacuation continued

  • Volatile solids are as low as 20 - 25%
  • Metal values in the accumulated biosolids have

consistently been lower or equivalent to the liquid that has been applied

  • Pathogen and Helminth ova alues at a number of

facilities are well within Class A limits

slide-79
SLIDE 79

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Removal of the Biosolids

  • Removal can be accomplished by excavation

equipment set up outside the bed

  • Use of floatation type vehicles within the bed
  • Care should be taken to drag biosolids, avoiding

disturbance of underlying sand and gravel layer

  • Facilities often leave 3 or 4 inches of residual

biosolids

slide-80
SLIDE 80

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Reeds after Evacuation

  • Reeds will regenerate as a

result of the undisturbed underlying root structure

  • Beds need to be watered

following biosolids removal

slide-81
SLIDE 81

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Disposal of Biosolids

  • Land fill
  • Beneficial Use
  • cover for solid waste land fill
  • used to stabilize mine land reclamation sites
  • Agricultural application
  • provided that biosolids have been screened for

vegetative matter

slide-82
SLIDE 82

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Costs

  • Construction costs of reed beds will vary from

$20.00 per square foot to $40.00 per square foot

  • Constructed Wetland Group, Inc.

costs for reed beds will vary from $1.00 per square foot to $5.00 per square foot

slide-83
SLIDE 83

www ww.re .reedb dbed. d.com com

Email:info@reedbed.com

Constructed Wetlands Group, Inc. Scope of Services

  • Technical support to engineer

during feasibility and cost studies

  • Provides design criteria and

assistance during design phase

  • Site inspection during

construction

  • Provide botanical material,

planting supervision, and guarantee

  • Create site specific written
  • peration and maintenance

guidelines

  • Regular on site support during

the first two years of start-up
