GreenTouch Consortium:

Overview and Green Meter Research Study

Thierry E. Klein, PhD

t hierry.klein@ alcat el-lucent .com

Chair, GreenTouch Technical Commit t ee Head of Green Research, Bell Labs / Alcat el-Lucent

2 GreenTouch Proprietary

Energy Efficiency is a Necessity for the ICT Industry

Fundamental question: Support the traffic growth in a sustainable and economically viable way throughout the world

Deliver by 2015 Architectures, S pecifications and S

• lutions and

Demonstrate Key Technologies to Increase Network Energy Efficiency by a Factor 1000 Compared to 2010

GreenTouch™ (www.greentouch.org)

• Bell Labs Initiated Global Research Consortium representing

industry, government and academic organizations

• Launched in May 2010 with focus on energy efficiency,

sustainability and growth

• Holistic and ambitious goal of 1000x
• 53 member organizations with 350+ leading scientists
• New innovation model for sustainability
• Recognized by the World Economic Forum as an industry-led best

practice toward sustainability

• Leading Green ICT: cooperation with other NGOs such as GeS

I, ITU-T , GreenGrid, Carbon Trust, ITRS

3 GreenTouch Proprietary

GreenTouch Overview Video

Makes both Environmental and Economic S ense

GROWTH INCREASE REDUCE

Revenue from Services Costs Green Services Carbon Footprint

Byt es Wat t - hours

Why Network Energy Efficiency?

Network by Consumed Energy Total Network by Delivered Traffic Total Efficiency Network =

4 GreenTouch Proprietary

Fixed Access IP/ MPLS Edge/ Core Services Network Optical Transport Converged Service Control

Enterprise Data center

Wireless Access Alternative Energy Eco-Sustainable Services

End to End Network Perspective

Thermal Management and Cooling

5 GreenTouch Proprietary

New Approaches Focused on Energy

Network Architecture

RN

eNB

Proc essi ng Unit

IP layer WDM layer

Management and Control Components and Hardware Thermal Management

6 GreenTouch Proprietary

Large Scale Antenna System

• Use many more service-antennas than terminals

with data beams directed towards the terminals

• Increased spectral efficiency (bits/ s/ Hz) and

radiated energy efficiency (bits/ Joule)

• Technological advantages:
• Only needs cheap, single-antenna terminals
• All complexity at the base station
• Expensive power amplifier amplifiers replaced by many

low-power low-precision units

• Important to consider total system energy

consumption and energy efficiency:

• Radiated power
• LS

AS-critical computing processing power

• Internal per-antenna power consumption

(RF chains, analog blocks, A/ D)

Proce ssing Unit

7 GreenTouch Proprietary

Beyond Cellular Green Generation

8

Signaling Data sleep sleep sleep sleep sleep

Separate

Beyond “cellular” coverage with data capacity on demand

Opportunities for sustainability:

• System designed for energy efficiency
• Separate capacity from coverage
• Optimise signalling transmission
• Lean access to system
• Cope with massive amount of low

data rate services Challenges:

• New system architecture
• Re-invent mobility management
• Agile management, context aware,

network with memory

• Hardware for fast reconfiguration

GreenTouch Proprietary

10 Gb/s ~10 Mb/s

Standard Transmission Protocol in FTTH Networks (XG-PON)

9 GreenTouch Proprietary

Bit-Interleaved Passive Optical Networks

10

10 Gb/s ~10 Mb/s

Bit-Interleaved Passive Optical Networks (Bi-PON) provides better than 10x energy efficiency improvement

GreenTouch Proprietary

Research st udy shows net energy consumpt ion in net works can be reduced by up t o 90% by 2020 while t aking int o account t raffic growt h

• S

ignificant impact for service provider

• Technology asset s for fut ure

net works

• Economic impact
• Environment al sust ainabilit y
• Live webcast on May 13 wit h

announcement of result s and green met er research st udy

Real Overall Progress and Results

Green Meter Webcast: http://www.mediaserver.com/m/p/jcczhxay.

11 GreenTouch Proprietary

Some Key Technologies

• Mobile:
• S

mall cells deployment in dense urban environments

• Infrastructure sharing across operators
• Discontinuous transmissions during periods without traffic
• Base station power models
• All-optical backhaul
• Wireline:
• Bit interleaved passive optical networking (Bi-PON)
• Power shedding and sleep modes
• Energy efficient hardware
• Core:
• Optical bypass and optimum use of mixed line rates
• Dynamic allocation of resources to diurnal traffic

fluctuations

• Low power electronics and photonics

20 40 60 80 100 120 140 160 180 200 2 4 6 8 10 12 14 16 18 20 22 Power Consumption (kW) Time of The Day (Hours) Compression Processors Regenarators Optical Switches EFDAs Transponders Routers

12 GreenTouch Proprietary

0.0 2.0 4.0 6.0 8.0 10.0 12.0 14.0 2010 2012 2013 2014 2015 2016 2017 2018 2019 2020 2022 W/subscriber Wireless LAN OLT(/subscriber) HGW processor Wireline LAN (Eth.) PON digital OE PON GPON XGPON EE HW design Long reach Virtual HGW BI PON Low power electronics Transparent CPE Low power Optics S leepmode 2 S leepmode Short Term Long Term Medium Term 0.0 2.0 4.0 6.0 8.0 10.0 12.0 14.0 2010 2012 2013 2014 2015 2016 2017 2018 2019 2020 2022 W/subscriber Wireless LAN OLT(/subscriber) HGW processor Wireline LAN (Eth.) PON digital OE PON GPON XGPON EE HW design Long reach Virtual HGW BI PON Low power electronics Transparent CPE Low power Optics S leepmode 2 S leepmode Short Term Long Term Medium Term

16 RESEARCH PROGRAMS and PROJECTS NEW APPROACHES BEING TAKEN TWO MAJOR PUBLIC DEMONSTRATIONS COMMON REFERENCE ARCHITECTURE & ROADMAP

Conclusion: Where Do We Go From Here?

13 GreenTouch Proprietary

ADDITIONAL DEMOS TO VALIDATE KEY TECHNOLOGIES ONGOING RESEARCH ACTIVITIES AND UPDATES TO GREEN METER BRAINSTORMING ON NEW IDEAS

@ Green_Touch www.greentouch.org @ Thierry_Klein
