GREEN VEINS

a proposal for a regional ecological corridor network for Metro Vancouver Jamie Vala

GREEN VEINS

Landscape Ecology

Patch Corridor Matrix

GREEN VEINS

Further Local Extinction Time Disconnected Habitat Patches Local Extinction

Current Condition

GREEN VEINS

Species at risk by habitat type in Metro Vancouver

Birds Plants Fish Other Insects Mammals Estuary Lake Marine River Terrestrial Wetland

GREEN VEINS

Connected Habitat Patches Local Extinction Local Recolonization Time

Proposed Condition

GREEN VEINS

Open water

Great Blue Heron Ardea herodias Skunk Cabbage Lysichiton americanus Black Bellied Plover Pluvialis squatarola Coho Salmon Oncorhynchus kisutch

Indicators of Healthy Habitats

Forest

Great Blue Heron Ardea herodias Douglas Squirrel Tamiasciurus douglasii Red Breasted Nuthatch Sitta canadensis Northwest Salamander Ambystoma gracile

Wetland

Great Blue Heron Ardea herodias Red Legged Frog Rana aurora Marsh Wren Cistothorus palustris Skunk Cabbage Lysichiton americanus

GREEN VEINS

Ecosystem Services

Pollination Food Cleansing of Water Aesthetic and Cultural Decomposition Soil Generation Distribution of Water Recreation Habitat Seed Dispersal Flood Mitigation Medicinal Resources Climate Regulation Infiltration of Water

GREEN VEINS

Network Delineation Network Refinement Selection of Corridor Swath Corridor Delineation Corridor Refinement Identification of Critical Constraints Mitigation of Critical Constraints stage 1 stage 2 stage 3

GREEN VEINS

P S Existing C (Existing Existing Habita

Corridor Swath Selection Process

Critical Corridor Swaths Species at risk Waterways Connectivity Habitat types

GREEN VEINS

Complete Corridor Swath Network

Proposed Corridors

N

GREEN VEINS

Network Delineation Network Refinement Selection of Corridor Swath Corridor Delineation Corridor Refinement Identification of Critical Constraints Mitigation of Critical Constraints stage 1 stage 2 stage 3

GREEN VEINS

Criterion for Critical Corridor Swath Network

Critical Habitat Types largest patches most productive patches representative habitat types

GREEN VEINS

Critical Corridor Swath Network

Riverine Coastal Terrestrial

N

GREEN VEINS

Network Delineation Network Refinement Selection of Corridor Swath Corridor Delineation Corridor Refinement Identification of Critical Constraints Mitigation of Critical Constraints stage 1 stage 2 stage 3

GREEN VEINS

Criteria for Single Corridor Swath Selection

Variety of land uses Habitat types Important patches

GREEN VEINS

Single Corridor Swath Selection

Selected Terrestrial Corridor

N

Westwood Plateau - Old growth forest Central Valley - Burnaby Lake Agricultural Land Fraser River Estuary Burnaby Mountain - Forest

GREEN VEINS

Network Delineation Network Refinement Selection of Corridor Swath Corridor Delineation Corridor Refinement Identification of Critical Constraints Mitigation of Critical Constraints stage 1 stage 2 stage 3

GREEN VEINS

Criteria for Corridor Placement

Presence of existing vegetation Fewest barriers to movement Ownership

GREEN VEINS Corridor Options Barriers Zoning (% Public) A 6 ~ 20% B 2 ~ 80% C 3 ~ 60 %

Decision process for corridor placement

Option A Option B Option C Option B

GREEN VEINS

Placement of the Corridor within the Swath

Richmond Burnaby Coquitlam

South Arm of the Fraser River North Arm of the Fraser River Burnaby Lake Westwood Plateau Burrard Inlet Fraser River Estuary

Corridor Swath (1000 m) Corridor (100 m)

GREEN VEINS

Network Delineation Network Refinement Selection of Corridor Swath Corridor Delineation Corridor Refinement Identification of Critical Constraints Mitigation of Critical Constraints stage 1 stage 2 stage 3

GREEN VEINS

Corridor Analysis - Vegetation

Designated park land Other greenspace

GREEN VEINS

Corridor Analysis - Barriers

Minor Barrier Major Barrier

GREEN VEINS

Corridor Analysis - Habitat Types

Agricultural Shrub Open space Young forest Old forest Fresh water

GREEN VEINS

Corridor Analysis - Zoning

Park Agricultural Residential Commercial Industrial

GREEN VEINS

Habitat types (%) 31.5 agricultural 13 shrub 9

• pen space

12 young forest 23

• ld forest

1.5 freshwater 9 built

Corridor Statistics

~ 90% vegetated 13 major barriers 20 minor barriers ~50% publicly owned

GREEN VEINS

Critical Constraints

Barriers Intactness

GREEN VEINS

Network Delineation Network Refinement Selection of Corridor Swath Corridor Delineation Corridor Refinement Identification of Critical Constraints Mitigation of Critical Constraints stage 1 stage 2 stage 3

GREEN VEINS

Solutions to Barriers

Two lane road with small animal tunnel

Precedent of amphibian tunnel

Four lane road - at grade crossing

GREEN VEINS

Solutions to Barriers

Precedent of large animal tunnel

Four lane or greater road with large mammal tunnel

GREEN VEINS

Solutions to Barriers

Precedent of large animal overpass

Wildlife overpass over large highways

GREEN VEINS

Agricultural Site Residential Site Industrial Site

GREEN VEINS

Agricultural Site

Existing Shell Trail

GREEN VEINS

Proposed

A A’ Trail Railway New access point

GREEN VEINS

Fraser River Estuary Richmond Nature Park Agricultural Land

S E E E

Major Transit Lines

E

Elementary School

S

Secondary School Nodes along the corridor Nodes adjacent to the corridor Length of line connecting each node represents relative distance between nodes. Designated Bike Route

Corridor Adjacencies

GREEN VEINS

Section A-A’ Existing Section A-A’ Lower Cost Proposal Section A-A’ Higher Cost Proposal

Sections

Grassland set aside Existing Trail and Vegetation Trail enhancements and increased plant diversity Perch trees for raptors Grassland set aside

GREEN VEINS

Existing Trail

GREEN VEINS

Proposed Trail Enhancements

GREEN VEINS

Residential

Existing Site Oakland Avenue Stanley Street Empress Avenue Deer Lake Park Brantford Park

GREEN VEINS

Proposed Site

A A’ B B’

Deer Lake Park Brantford Park Street rights of way used for habitat enhancement and pedestrian improvements Backyard habitat enhancements provide stop

• ver point for native wildlife

Streets are narrower, curbless, have tree canopy, and swales to allow for easier wildlife crossings Creating a multi-storied canopy in the park adds plant diversity and creates more habitat for wildlife

GREEN VEINS

Single House Lot

Single Lot Section C-C’ C C’

GREEN VEINS

Section A-A’ Existing Section A-A’ Proposed

Sections

Wide streets without trees or sidewalks Reduced lanes, permeable parking strip, street trees, swales, and planted public land allow for movement through the corridor to adjacent habitat patches Backyards planted with native shrubs and trees can support a variety of other species

GREEN VEINS

Section B-B’ Existing

Habitat enhancement in the park creates a multi-storied canopy

Section B-B’ Proposed

Sections

Unmown grassy areas reduce maintenance costs and provide habitat Park is composed of mown lawn and a few large trees

GREEN VEINS

Existing Condition

GREEN VEINS

Proposed Condition

GREEN VEINS

Industrial

Existing Barnet Highway Runnel Drive Dewdney Trunk Road

GREEN VEINS

Proposed

Detention pond collects water from surrounding parking lots Bosque of crab apple trees provide seasonal interest, habitat value and a formal park setting Corridor trail could connect from Colony Farm to Westwood Plateau Re-organization of industrial lot allows for a narrow corridor

GREEN VEINS

Section A-A’ Existing Section A-A’ Proposed

Sections

Under utilized industrial lot Part of the lot is transformed into a hedgerow and shrub area. This land could be donated by the owner in exchange for a tax break

GREEN VEINS

Section B-B’ Existing Section B-B’ Proposed

Under utilized parking lot Stormwater detention pond collects water from surrounding parking lots. This artificial wetland creates habitat for birds and insects.

GREEN VEINS

Existing Conditions

GREEN VEINS

Proposed Conditions
