GRAVITATIONAL LENSING LECTURE 11 Docente: Massimo Meneghetti AA 2015-2016 TODAYS LECTURE Lensing by multiple point masses Binary lenses COMPLEX LENS EQUATION N For a system of N-lenses we obtained: m i X z s = z z z

slide-1
SLIDE 1

GRAVITATIONAL LENSING

LECTURE 11

Docente: Massimo Meneghetti AA 2015-2016

slide-2
SLIDE 2

TODAY’S LECTURE

➤ Lensing by multiple point masses ➤ Binary lenses

slide-3
SLIDE 3

COMPLEX LENS EQUATION

➤ For a system of N-lenses we obtained: ➤ Taking the conjugate: ➤ We obtain z* and substitute it back

into the original equation, which results in a (N2+1)th order complex polynomial equation

➤ This equation can be solved only

numerically, even in the case of a binary lens

zs = z −

N

X

i=1

mi z∗ − z∗

i

z∗

s = z∗ − N

X

i=1

mi z − zi

p(z) =

N

X

i=0

cizi

slide-4
SLIDE 4

COMPLEX LENS EQUATION

➤ Note that the solutions are not necessarily solutions of the

lens equations (spurious solutions)

➤ One has to check if the solutions are solutions of the lens

equation

➤ Rhie 2001,2003: maximum number of images is 5(N-1) for

N>2

slide-5
SLIDE 5

MAGNIFICATION

➤ In the complex form, the magnification can still be derived

from the lensing Jacobian:

det A = ✓∂zs ∂z ◆2 − ∂zs ∂z∗ ✓ ∂zs ∂z∗ ◆∗ = 1 − ∂zs ∂z∗ ✓ ∂zs ∂z∗ ◆∗ ∂zs ∂z∗ =

N

X

i=1

mi (z∗ − z∗

i )2

det A = 1 −

  • N

X

i=1

mi (z∗ − z∗

i )2

  • 2
slide-6
SLIDE 6

CRITICAL LINES AND CAUSTICS

➤ Therefore the critical lines form where

  • N

X

i=1

mi (z∗ − z∗

i )2

  • 2

= 1

➤ Thus, to find the critical points we solve

N

X

i=1

mi (z∗ − z∗

i )2 = eiφ

φ ∈ [0, 2π]

➤ Again, this can be turned into a complex polynomial of order

2N: for N lenses, there are 2N critical lines and caustics. The solutions can be found numerically.

slide-7
SLIDE 7

CRITICAL LINES AND CAUSTICS

Witt, 1990, A&A, 236, 311 critical lines and caustics originated by 400 stars

slide-8
SLIDE 8

BINARY LENSES

➤ determinant of the Jacobian: ➤ condition for critical points: ➤ resulting fourth grade polynomial: ➤ Lens equation:

slide-9
SLIDE 9

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-10
SLIDE 10

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-11
SLIDE 11

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-12
SLIDE 12

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-13
SLIDE 13

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-14
SLIDE 14

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-15
SLIDE 15

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-16
SLIDE 16

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-17
SLIDE 17

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-18
SLIDE 18

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-19
SLIDE 19

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-20
SLIDE 20

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-21
SLIDE 21

BINARY LENSES: TWO LENSES WITH THE SAME MASS (Q=1) AND VARYING DISTANCE

critical lines caustics

slide-22
SLIDE 22

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-23
SLIDE 23

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-24
SLIDE 24

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-25
SLIDE 25

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-26
SLIDE 26

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-27
SLIDE 27

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-28
SLIDE 28

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-29
SLIDE 29

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-30
SLIDE 30

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-31
SLIDE 31

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-32
SLIDE 32

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-33
SLIDE 33

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-34
SLIDE 34

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-35
SLIDE 35

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-36
SLIDE 36

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-37
SLIDE 37

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-38
SLIDE 38

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-39
SLIDE 39

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-40
SLIDE 40

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-41
SLIDE 41

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-42
SLIDE 42

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-43
SLIDE 43

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-44
SLIDE 44

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-45
SLIDE 45

BINARY LENSES: TWO LENSES WITH THE VARYING MASS AND FIXED DISTANCE

critical lines caustics

slide-46
SLIDE 46

BINARY LENSES: TOPOLOGY CLASSIFICATION

wide

separate 4- cusp caustics

slide-47
SLIDE 47

BINARY LENSES: TOPOLOGY CLASSIFICATION

intermediate

single 6-cusp caustic

slide-48
SLIDE 48

BINARY LENSES: TOPOLOGY CLASSIFICATION

close

single 4-cusp caustic two triangular caustics

slide-49
SLIDE 49

TRANSITIONS

Touching critical lines

slide-50
SLIDE 50

MULTIPLE IMAGES

➤ Lens equation: ➤ complex polynomial:

p5(z) =

5

X

i=0

cizi

➤ 3 or 5 images

Witt & Mao, 1995, ApJ, 447, L105

slide-51
SLIDE 51

MULTIPLE IMAGES

Mollerach & Roulet, “Gravitational Lensing and Microlensing”

slide-52
SLIDE 52

IMAGE MAGNIFICATION

➤ magnification at the

image position:

➤ total magnification: ➤ of course, the magnification varies as a function of z…
