Granola: LowOverhead Distributed Transac9on Coordina9on James Cowling and Barbara Liskov MIT CSAIL Granola An infrastructure for building distributed storage applica<ons. A distributed transac9on coordina9on protocol, that provides strong
SLIDE 2
SLIDE 3
Repository 1 Client 1
Distributed Storage
Repository 2 Repository 3
…
Client 2
…
SLIDE 4
Why Transac9ons?
Atomic opera9ons allow users and developers to ignore concurrency Distributed atomic opera<ons allow data to span mul9ple repositories
avoids inconsistency between repositories
SLIDE 5
Distributed transac9ons are hard
Tension between consistency and performance
SLIDE 6
Op9ng for Consistency
Two‐phase commit with strict two‐ phase locking
Distributed databases, Sinfonia, etc.
SLIDE 7
Op9ng for Consistency
Two‐phase commit with strict two‐ phase locking
Distributed databases, Sinfonia, etc.
High transac9on cost: mul<ple message delays, forced log writes, locking/logging overhead (≈30‐40%*)
* OLTP through the looking glass, and what we found there Harizopoulos et al, SIGMOD ‘08
SLIDE 8
Op9ng for Performance
No distributed transac<ons
SimpleDB, Bigtable, CRAQ, etc.
Weak consistency models
Dynamo, Cassandra, MongoDB, Hbase, PNUTS, etc.
SLIDE 9
Op9ng for Performance
No distributed transac<ons
SimpleDB, Bigtable, CRAQ, etc.
Weak consistency models
Dynamo, Cassandra, MongoDB, Hbase, PNUTS, etc.
Place the burden of consistency
- n the applica9on developer
SLIDE 10
Where we come in…
Strong Consistency and High Performance (for a large class of transac<ons)
SLIDE 11
Introduce a new transac9on class which lets us provide consistency without locking
SLIDE 12
MOTIVATION TRANSACTION MODEL PROTOCOL EVALUATION
SLIDE 13
One‐Round Transac9ons
Expressed in one round of communica9on between clients and repositories Execute to comple9on at each par<cipant
SLIDE 14
General Opera9ons
Transac<ons are uninterpreted by Granola, and can execute arbitrary
- pera9ons
SLIDE 15
Transac9on Classes
Single‐Repository
execute en<rely on one repository
Distributed Transac<ons
- Coordinated
- Independent
SLIDE 16
Coordinated Transac9ons
Commit only if all par<cipants vote to commit Example:
- Transfer $50 between accounts
SLIDE 17
Independent Transac9ons
Transac<ons where all par<cipants will make the same commit/abort decision Examples:
- Add 1% interest to each bank balance.
- Compute total amount of money in the
bank.
SLIDE 18
Independent Transac9ons
Evidence these are common in OLTP workloads
- Any read‐only distributed transac<on
- Transac<ons that always commit
- Atomically update replicated data
- Where commit decision is
determinis9c func9on of shared state
SLIDE 19
Example: TPC‐C
TPC‐C benchmark can be expressed en<rely using single repository and independent transac9ons
e.g., new_order transac<on only aborts if invalid item number
can be computed locally if we replicate Item table
SLIDE 20
MOTIVATION TRANSACTION MODEL PROTOCOL EVALUATION
SLIDE 21
Server Applica<on Granola Repository Library Granola Client Library Client Applica<on
invoke transac<on coordina<on run
Repository Client
result result
SLIDE 22
Replica9on
Repository
Primary Backup Backup
Implemented as
SLIDE 23
Repository Modes
Primarily in Timestamp Mode
- Single‐repository, Independent
Occasionally in Locking Mode
- When coordinated transac<ons are
required
SLIDE 24
Timestamps
Each transac<on is assigned a <mestamp Each repository executes transac<ons in 9mestamp order Timestamps define global serial order
SLIDE 25
Key Ques9ons
How do we assign <mestamps in a scalable, fault‐tolerant way? How do we make sure we always execute in 9mestamp order?
SLIDE 26
Single‐Repository Protocol
Clients present the highest 9mestamp they have observed Repository chooses <mestamp higher than the client 9mestamp, any previous transac<on, and its clock value Repository executes in 9mestamp order, sends response and <mestamp to client
SLIDE 27
Assign <mestamp
Log Transac<on Run
Choose <mestamp higher than previous transac<ons
SLIDE 28
Assign <mestamp
Log Transac<on Run
Run replica<on protocol to record <mestamp Choose <mestamp higher than previous transac<ons
SLIDE 29
Assign <mestamp
Log Transac<on Run
Run replica<on protocol to record <mestamp Execute in <mestamp order Send result and <mestamp to the client Choose <mestamp higher than previous transac<ons
SLIDE 30
Independent Protocol
Clients present highest <mestamp they observed Repository chooses proposed 9mestamp higher than clock value and previous transac<ons Repositories vote to determine highest 9mestamp Repository executes in <mestamp order, sends <mestamp to client
SLIDE 31
Propose <mestamp Log Transac<on Vote Run replica<on protocol to record proposed <mestamp Send proposed 9mestamp to the other par9cipants Choose proposed 9mestamp higher than previous transac<ons Pick final <mestamp Highest 9mestamp from among votes Run Execute in <mestamp order Send result and final <mestamp to client
SLIDE 32
Timestamp Constraint
Won’t execute transac<on un<l it has the lowest 9mestamp of all concurrent transac<ons Guarantees a global serial execu9on
- rder
SLIDE 33
Repository 1 Repository 2
Queue: History: Queue: History:
Alice Bob
Example 1:
SLIDE 34
Queue: History: Queue: History: T1 T1
Repository 1 Repository 2 Alice Bob
SLIDE 35
Queue: History: Queue: History: T1 [prop. ts: 9] T1 [prop. ts: 3] T1 T1
Repository 1 Repository 2 Alice Bob
SLIDE 36
Queue: History: Queue: History: Vote T1 [9] T1 [prop. ts: 9] T1 [prop. ts: 3] Vote T1 [3]
…
Repository 1 Repository 2 Alice Bob
SLIDE 37
Queue: History: Queue: History: T1 [final ts: 9] T1 [prop. ts: 3] Vote T1 [9] … T1 [final ts: 9]
Repository 1 Repository 2 Alice Bob
SLIDE 38
Queue: History: Queue: History: T1 [final ts: 9] T1 [prop. ts: 3] T2 Vote T1 [9] …
Repository 1 Repository 2 Alice Bob
SLIDE 39
Queue: History: Queue: History: T1 [final ts: 9] T1 [prop. ts: 3], T2 [ts: 5] Vote T1 [9] … T2
Repository 1 Repository 2 Alice Bob
SLIDE 40
Queue: History: Queue: History: T1 [final ts: 9] T1 [prop. ts: 3], T2 [ts: 5] Vote T1 [9] …
Repository 1 Repository 2 Alice Bob
SLIDE 41
Queue: History: Queue: History: T1 [final ts: 9] T1 [prop. ts: 3], T2 [ts: 5] Vote T1 [9]
Repository 1 Repository 2 Alice Bob
SLIDE 42
Queue: History: Queue: History: Vote T1 [9] T1 [final ts: 9] T2 [ts: 5], T1 [final ts: 9]
Repository 1 Repository 2 Alice Bob
SLIDE 43
Queue: History: Queue: History: T1 [final ts: 9] T1 [final ts: 9] T2 [ts: 5] T2 [ts: 5]
Repository 1 Repository 2 Alice Bob
SLIDE 44
Queue: History: Queue: History: T1 [final ts: 9] T2 [ts: 5], T1 [final ts: 9] T1 [final ts: 9]
Repository 1 Repository 2 Alice Bob
SLIDE 45
Queue: History: Queue: History: T1 [final ts: 9] T2 [ts: 5], T1 [final ts: 9]
Global serial order: T2 ‐> T1 Repository 1 Repository 2 Alice Bob
SLIDE 46
Choosing 9mestamps
Client‐provided <mestamp guarantees transac<on will be serialized aYer any transac9on it observed
SLIDE 47
Queue: History: Queue: History: T1 [final ts: 9] T1 [prop. ts: 3] Vote T1 [9] …
Example 2:
Repository 1 Repository 2 Alice Bob
SLIDE 48
Queue: History: Queue: History: T1 [final ts: 9] T1 [prop. ts: 3] Vote T1 [9] … T2
Repository 1 Repository 2 Alice Bob
SLIDE 49
Queue: History: Queue: History: T1 [final ts: 9], T2 [ts: 10] T1 [prop. ts: 3] Vote T1 [9] … T2 [ts: 10]
Repository 1 Repository 2 Alice Bob
SLIDE 50
Queue: History: Queue: History: T1 [final ts: 9] , T2 [ts: 10] T1 [prop. ts: 3] Vote T1 [9] … T3 [latest ts: 10]
Repository 1 Repository 2 Alice Bob
SLIDE 51
Queue: History: Queue: History: T1 [final ts: 9] , T2 [ts: 10] T1 [prop. ts: 3], T3 [ts: 11] Vote T1 [9] … T3 [latest ts: 10]
Repository 1 Repository 2 Alice Bob
SLIDE 52
Queue: History: Queue: History: T1 [final ts: 9] , T2 [ts: 10] T1 [final. ts: 9], T3 [ts: 11] Vote T1 [9]
Repository 1 Repository 2 Alice Bob
SLIDE 53
Queue: History: Queue: History: T1 [final ts: 9] , T2 [ts: 10] T1 [final ts: 9], T3 [ts: 11]
Global serial order: T1 ‐> T2 ‐> T3 Repository 1 Repository 2 Alice Bob
SLIDE 54
Where are we now?
Timestamp‐based transac<on coordina<on
- Interoperability with coordinated
transac9ons
- Recovery from failures
SLIDE 55
Coordinated Transac9ons
Applica<on determines commit/abort vote Requires locking to ensure vote isn’t invalidated
SLIDE 56
Protocol changes
Prepare phase
applica<on acquires locks and determines vote Timestamp vo<ng
Repository can commit transac<ons
- ut of 9mestamp order
SLIDE 57
Protocol changes
Prepare phase where applica<on acquires locks and determines vote Repository can commit transac<ons
- ut of <mestamp order
Timestamp Constraint: Timestamps s&ll match the serial order, even if execu<on happens out of <mestamp order
SLIDE 58
Repository 1 Repository 3
Client 1 Client 2
Repository 2
coordinated transac<on independent transac<on Locking Mode Timestamp Mode Locking Mode
SLIDE 59
Effect on other Transac9ons
Independent transac<ons processed using locking‐mode protocol No locks held for single‐repository transac<ons
SLIDE 60
MOTIVATION TRANSACTION MODEL PROTOCOL EVALUATION
SLIDE 61
Experimental Setup
Implemented as a Java library Deployed on 20 servers
2005‐vintage Xeon machines colocated on same LAN
SLIDE 62
Experimental Setup
Throughput was CPU bound
> 65,000 tps on microbenchmarks latency kept around 1‐2 ms
We compare against extended version
- f Sinfonia
SLIDE 63
TPC‐C
Implemented distributed TPC‐C benchmark using a non‐distributed codebase Par<<oned such that all transac<ons single‐repository or independent
SLIDE 64
Scalability
SLIDE 65
Distributed transac9ons
SLIDE 66
Performance Gains
No locking or undo logging
40% lower CPU overhead no aborts or retries
3 one‐way message delays (vs 4) 1 forced log write
