Hendricks County Surveyor s Office Speaker Name: Beth Neilson/ Aaron Lasley Williams Creek PHASE 1 Nash Trucksess/ Wilson Lateral North of Sycamore Street Work started in Fall 2009 Planted in Spring 2010 Maintenance 2010- Current Title

SLIDE 1

SLIDE 2

Hendricks County Surveyor’s Office

Speaker Name: Beth Neilson/Aaron Lasley – Williams Creek

SLIDE 3

PHASE 1 Nash Trucksess/Wilson Lateral

North of Sycamore Street

Work started in Fall 2009 Planted in Spring 2010 Maintenance 2010-Current

SLIDE 4

Title

Click to edit

2011 OUTSTANDING STORMWATER

PROJECT AWARD

INDIANA ASSOCIATION FOR FLOODPLAIN AND STORMWATER MANAGEMENT

Established in 1998, this award recognizes an

utstanding stormwater project studied,

designed, or constructed by a firm for a local

unit of government or a private entity.

SLIDE 5

PHASE 1

Stream Restoration Included: Combined Length – 3025 LF Channel and Buffer Width – 39 LF

Maplebrook Drive

Gr

a

n

t

S

t

r

e e

t

Sycamore Street

SLIDE 6

STREAM NATURALIZATION

Constructed in existing Right of Way Provides habitat, groundwater recharge, and passive recreation Existing channel carries storm events, no structural changes Increased vegetation on banks provides a buffer Improves water quality as a flow through best management practice

SLIDE 7

BEFORE PHOTOS

Click to edit

SLIDE 8

BEFORE PHOTOS

Water Quality

SLIDE 9

THE NATURAL BALANCE

Develop native vegetation

Water tolerant plants in the water and at waters edge Native grasses and forbs on the higher elevations going up the bank

Create mini ecosystem Flora and fauna to reduce the number of mosquitoes

SLIDE 10

DESIGN

Stream Restoration Rendering

SLIDE 11

PLAN IMPLEMENTATION

Stream Restoration

SLIDE 12

PLAN IMPLEMENTATION

Stream Restoration

SLIDE 13

Title

Click to edit

Index of Biotic Integrity showed that the stream became healthier as it

flowed through the riparian restoration area.

SLIDE 14

WATER QUALITY (PHASE 1)

2013 Water Quality Testing Orthophosphorus - most common form of phosphorus in water mg/l) Nitrate – nitrogen from fertilizer (farm/yard), leaking septic tanks and animal wastes (mg/l) Turbidity – measurement of suspended material in water (NTU) Chlorophyll A - measurement of the concentration of suspended Phytoplankton (ug/l) Algal Count – measurement of algae cells per milliliter (per ml) Samples collected on six dates at Maplebrook and Grant Streets (upstream) then at Sycamore Street (downstream).

SLIDE 15

WATER QUALITY AVERAGES

Maplebrook Grant

Sycamore

Orthophosphorus (mg/l)

0.36 0.24 0.21

Nitrate (mg/l)

1.27 0.58 0.62

Turbidity (NTU)

11.1

6.3 5.7

Chlorophyll A (ug/l)

19 30 26

Algal Count (per ml)

45,183 51,883 22,167

Both phosphorus and nitrate values were reduced by roughly 50% as the water flowed through the riparian restoration area. Similar results were observed for turbidity and chlorophyll concentrations, which were also reduced as the water flowed through the project area.

SLIDE 16

MOSQUITO PREDITORS

Dragonfly:

Normally, the dragonfly’s prey is caught in the air and eaten in flight. It consumes large numbers of mosquitoes.

Birds:

Several specific species of birds eat mosquitoes. Birds adapt their diet when there is a higher concentration of mosquitoes. Water fowl consume mosquito larvae in their normal diets.

Bats:

Most bat species feed after dark or at dusk. Some experts estimated that one bat can eat between 600 to 1000 insects, mosquitoes included, within a period of one hour.

SLIDE 17

THE NEXT STEP

Phase 2 South of Sycamore Street to State Road 267

SLIDE 18

PHASE 2 LAYOUT

Planned area Length 2450’ Channel and buffer width 38-44’

SLIDE 19

PHASE 2 – CURRENT CONDITION

Click to edit

SLIDE 20

PHASE 2 – CURRENT CONDITION

Click to edit

SLIDE 21

PHASE 2 – CROSS SECTION A

SLIDE 22

PHASE 2 – CROSS SECTION B

SLIDE 23

PHASE 2 - IMPLEMENTATION

Scope of Work

1.96 Acres – Native Seed Installation 8,300 SY – Erosion Control Blanket 10,800 – Native Plugs (Live Material) 440 Lineal Feet – 12” Coir Logs

115 – 1 Gallon Shrubs

25 – Do Not Mow, Do Not Spray Signs

SLIDE 24

PHASE 2 - SCHEDULE

Current Schedule

May 2014

Herbicide Application (Existing Turf) Seed Bed Preparation Native Seed Installation Erosion Control Materials Native Shrub Installation Restoration Signage

July/August 2014

Native Plant Installation (Channel Bottom) 12” Coir Log Installation

SLIDE 25

PLANTS

Click to edit

SLIDE 26

CONTINUED DRAINAGE BENEFITS

No structural changes Plants in channel will serve as a flow through Best Management Practice BMP) Plantings on banks will serve as buffer for stormwater from mowed areas

SLIDE 27

THANK YOU

Aaron Lasley

alasley@williamscreekmgt.net

Beth Neilson bneilson@williamscreek.net
