Fault Tolerance and the MPI standard meet at the Ultra-Scale Richard L. Graham Computer Science and Mathematics Division National Center for Computational Sciences 1 1 Managed by UT-Battelle Managed by UT-Battelle for the Department of

slide-1
SLIDE 1

1 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08 Graham_OpenMPI_SC08

1 Managed by UT-Battelle for the Department of Energy

Richard L. Graham Computer Science and Mathematics Division National Center for Computational Sciences

Fault Tolerance and the MPI standard meet at the Ultra-Scale

2 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Outline

  • Problem definition

– General – MPI Specific

  • General approach for making MPI fault

tolerant

  • Current status
  • Is this all ?

Goal: Let MPI survive partial system failure

slide-2
SLIDE 2

3 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Problem definition

Disk B Node 2 Disk A Node 1 Network

4 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Problem definition – A bit more realistic

Disk B Node 2 Node 1 Network

slide-3
SLIDE 3

5 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Failure example – node failure

Disk B Node 2 Node 1 Network

6 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

  • Problem: A component affecting a running

MPI job is compromised (H/W or S/W)

  • Question: Can the MPI application continue

to run correctly ?

– Does the job have to abort ? – If not, can the job continue to communicate ? – Can there be a change in resources available to the job ?

slide-4
SLIDE 4

7 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Related Work*

MPICH-V/CL Starfish Enrichment of MPI AF99 Clip Semi-trasparant Ckpt Clp97 Cocheck Independent of MPI Ste96 LAM/MPI Optimistic recovery in distributed systems N faults with coherent Ckpt - FY85 Egida Rav99 2 faults sender based Pruitt 98 Sender based Msg Log 1 fault sender based JZ87 Manetho n faults EZ92 MPI/FT Redundance of Tasks BNC01 MPICH-V N faults Distributed logging MPI-FT N faults Centralized Sever LNLE00 LA-MPI RG03 FT-MPI

Framework API Comm Layer

Optimistic Log Casual Log Pessimistic Log Ckpt Based Log Based Automatic Non Automatic

  • ther

*Borrowed from Jack Dongarra

8 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Why address this problem now ? Why address this problem now ?

  • There have been quite a few predictions over

the last decade that we would reach a scale at which hardware and software failure rates would be so high, we would not be able to make effective use of these systems.

slide-5
SLIDE 5

9 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Why address this problem now ? – Why address this problem now ? – cont’d

  • nt’d
  • This has not happened (?)

Why should we believe it will happen this time ?

Actually, we have adjusted Wasting resources Automating simple forms of recovery (restart – John Daly)

10 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Why address this problem now ? – Why address this problem now ? – cont’d

  • nt’d
  • Systems are getting much larger
  • NCCS ~15000 (‘07) -> ~30,000 cores(‘08) ->

~150,000 cores (end ’08)

  • Impact on the applications is increasing
  • As we go to 1,000,000+ processes being

used in a single job, application MTBF will suffer greatly

slide-6
SLIDE 6

11 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Why is Coordinated Checkpoint Restart not Sufficient ?*

Ron Oldfield, et al. – Modeling the Impact of Checkpoints on Next- Generation Systems

12 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

The Challenge

  • We need approaches to dealing with fault-

tolerance at scale that will:

– Allow applications to harness full system capabilities – Work well at scale

slide-7
SLIDE 7

13 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Technical Guiding Principles

  • End goal: Increase application MTBF

– Applications must be willing to use the solution

  • No One-Solution-Fits-All

– Hardware characteristics – Software characteristics – System complexity – System resources available for fault recovery – Performance impact on application – Fault characteristics of application

  • Standard should not be constrained by

current practice

14 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Why MPI ?

  • The Ubiquitous standard parallel

programming model used in scientific computing today

  • Minimize disruption of the running

application

slide-8
SLIDE 8

15 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

What role should MPI play in recovery ?

  • MPI does NOT provide fault-tolerance
  • MPI should enable the survivability of MPI

upon failure.

16 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

What role should MPI play in recovery ? – Cont’d

  • MPI provides:

– Communication primitives – Management of groups of processes – Access to the file system

slide-9
SLIDE 9

17 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

What role should MPI play in recovery ? – Cont’d

  • Therefore upon failure MPI should: (limited

by system state)

– Restore MPI communication infrastructure to correct and consistent state – Restore process groups to a well defined state – Able to reconnect to file system – Provide hooks related to MPI communications needed by other protocols building on top of MPI, such as

  • Flush the message system
  • Quiesce the network
  • Send “piggyback” data
  • ?

18 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

What role should MPI play in recovery ? – Cont’d

  • MPI is responsible for making the internal

state of MPI consistent and usable by the application

  • The “application” is responsible for restoring

application state

Layered Approach

slide-10
SLIDE 10

19 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

CURRENT WORK CURRENT WORK

19

20 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Active Members in the Current MPI Forum

Argonne NL, Bull, Cisco, Cray, Fujitsu, HDF Group, HLRS, HP, IBM, INRIA, Indiana U., Intel, Lawrence Berkeley NL, Livermore NL, Los Alamos NL, Mathworks, Microsoft, NCSA/UIUC, NEC, Oak Ridge NL , Ohio State U., Pacific NW NL, Qlogic, Sandia NL, SiCortex, Sun Microsystems, Tokyo Institute of Technology,

  • U. Alabama Birmingham,
  • U. Houston,
  • U. Tennessee Knoxville,
  • U. Tokyo

20

slide-11
SLIDE 11

21 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Motivating Examples

22 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Collecting specific use case scenarios

  • Process failure – Client/Server, with client

member of inter-communicator

– Client process fails – Server is notified of failure – Server disconnects from Client inter- communicator, and continues to run – Client processes are terminated

22

slide-12
SLIDE 12

23 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Collecting specific use case scenarios

  • Process failure – Client/Server, with client

member of intra-communicator

– Client process fails – Processes communicating with failed process are notified of failure – Application specifies response to failure

  • Abort
  • Continue with reduced process count, with the

missing process being labled MPI_Proc_null in the communicator

  • Replace the failed process (why not allow to increase

the size of the communicator ?)

23

24 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Collecting specific use case scenarios

  • Process failure – Tightly coupled

simulation, with independent layered libraries

– Process fails

  • Example application: POP (ocean simulation code)

using conjugate gradient solver

– Application specifies MPI’s response to failure

24

slide-13
SLIDE 13

25 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Design Details

  • Allow for local recovery, when global

recovery is not needed (scalability)

– Collective communications are global in nature, therefore global recovery is required for continued use of collective communications

  • Delay recovery response as much as

possible

  • Allow for rapid and fully coordinated

recovery

26 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Design Details – Cont’d

  • Key component: Communicator

– A functioning communicator is required to continue MPI communications after failure

  • Disposition of active communicators:

– Application specified – MPI_COMM_WORLD must be functional to continue

  • Handling of surviving processes

– MPI_comm_rank does not change – MPI_Comm_size does not change

slide-14
SLIDE 14

27 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Design Details – Cont’d

  • Handling of failed processes

– Replace – Discard (MPI_PROC_NULL)

  • Disposition of active communications:

– With failed process: discard – With other surviving processes – application defined on a per communicator basis

28 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Error Reporting Mechanisms – current status

– Errors are associated with communicators – By default errors are returned from the affected MPI calls, are are returned synchronously

Example: Ret1=MPI_Isend(comm=MPI_Comm_world, dest=3, …request=request3) Link to 3 fails Ret2=MPI_Isend(comm=MPI_Comm_world, dest=4, …request=request4) Ret3=Wait(request=request4) // success Ret4=Wait(request=request3) // error returned in Ret Can ask for more information about the failure

28

slide-15
SLIDE 15

29 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

  • May request global event notification

– Several open questions remain here

29

30 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

  • A collective call has been proposed to check
  • n the status of the communicator
  • No extra cost is incurred for consistency checks,

unless requested (may be relevant for collective

  • perations)
  • Provides global communicator state just before

the call is made

30

slide-16
SLIDE 16

31 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Examples of proposed API modifications Surviving Processes

  • MPI_COMM_IRECOVER(ranks_to_restore,

request, return_code)

– IN ranks_to_restore array of ranks to restore (struct) – OUT request request object (handle) – OUT return_code return error code(integer)

  • MPI_COMM_IRECOVER_COLLECTIVE(ranks

_to_restore, request, return_code)

– IN ranks_to_restore array of ranks to restore (struct) – OUT request request ob ject (handle) – OUT return_code return error code(integer)

32 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Examples of proposed API modifications Restored Processes

  • MPI_RESTORED_PROCESS(generation,

return_code)

  • OUT generation Process generation (integer)
  • OUT return_code return error code (integer)
  • MPI_GET_LOST_COMMUNICATORS(comm_names,

count, return_code)

  • OUT comm_names Array of communicators that may be

restored (strings)

  • OUT count Number of Communicators that may

be restored (in- teger)

  • OUT return_code return error code(integer)
slide-17
SLIDE 17

33 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Examples of proposed API modifications Restored Processes – Cont’d

  • MPI_COMM_REJOIN(comm_names, comm,

return_code)

  • IN comm_names Communicator name (string)
  • OUT comm communicator (handle)
  • OUT return_code return error code(integer)

34 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Open Questions

  • How heavy handed do we need to be at the

standard specification level to recover from failure in the middle of a collective operation ? Is this more than an implementation issue ? (Performance is the fly in the ointment)

  • What is the impact of “repairing” a

communicator on implementation of collective algorithms (do we have to pay the cost all the time?)

34

slide-18
SLIDE 18

35 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Is this All ?

  • Other aspects of fault tolerance

– Network – Checkpoint/Restart – File I/O

  • End-to-end solution

36 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

For involvement in the process see:

meetings.mpi-forum.org

36

slide-19
SLIDE 19

37 Managed by UT-Battelle for the Department of Energy

Graham_OpenMPI_SC08

Backup slides
