MPI-IO: A Retrospective

Rajeev Thakur

25th Anniversary of MPI Workshop Argonne, IL, Sept 25, 2017

Outline

§ Origins of MPI-IO § How it became part of MPI-2 § What is in MPI-IO § Which features of MPI-IO turned out to be useful, and which were less useful § Current status and future

2

The Origins (1)

§ MPI-IO originated in an effort at IBM Research in 1994 to explore the use of the (then) new MPI concepts to define an interface for parallel I/O [1] § At that time, there was a need for a standard parallel I/O interface, just as a few years earlier there was a need for a standard message-passing interface

– There were many I/O interfaces in existence: Each vendor, parallel file system, or research I/O library had its own interface

1. Jean-Pierre Prost, Marc Snir, Peter Corbett, and Dror Feitelson, “MPI-IO, a message-passing interface for concurrent I/O,” Tech. Rep. RC 19712 (87394), IBM T.J. Watson Research Center, August 1994

3

The Origins (2)

§ MPI seemed like a good basis to build an I/O interface because of similarities between message passing and I/O

– Writing to a file is like sending a message; reading is like receiving – Any parallel I/O API would need

• collective operations
• nonblocking operations
• ability to describe noncontiguous layouts in memory and file
• separation of application-level messages from I/O-related messages
• i.e., features that MPI already had

.

4

The Origins (3)

§ The IBM effort expanded to a collaboration with NASA Ames § A revised version of the technical report was prepared and distributed at a BoF at SC’94 in Washington DC

– Peter Corbett, Dror Feitelson, Yarsun Hsu, Jean-Pierre Prost, Marc Snir, Sam Fineberg, Bill Nitzberg, Bernard Traversat, and Parkson Wong, “MPI-IO: A parallel file I/O interface for MPI,” Technical Report RC 19841 (87784), IBM T.J. Watson Research Center, November 1994

§ At this point, a large email discussion group was formed, with participation from many institutions § This group, calling itself the “MPI-IO Committee”, pushed the idea further in a series of proposals, culminating in the version 0.5 release of the MPI-IO specification

– The MPI-IO Committee, “MPI-IO: A parallel file I/O interface for MPI,” Version 0.5, April 1996.

5

The Origins (4)

§ In the meanwhile, the MPI Forum had resumed meeting to define new features that would be part of MPI-2 § The MPI-IO Committee eventually merged with the MPI Forum, and, from the summer of 1996, the MPI-IO activities took place in the context of the MPI Forum meetings § The MPI Forum used the latest version of the existing MPI-IO specification as a starting point for the I/O chapter in MPI-2 § The I/O chapter evolved over many meetings of the Forum and was released along with the rest of MPI-2 in July 1997

6

The Origins (5)

§ Bill Nitzberg was the chair of the I/O chapter in MPI-2. He navigated the MPI Forum process very skillfully. § I joined Argonne as a postdoc in May 1995, working with Bill Gropp and Rusty Lusk, and participated in the MPI-IO definition in the MPI-2 Forum § I also developed the ROMIO implementation of MPI-IO, which tracked the evolving MPI-IO spec (similar to the way MPICH tracked the MPI spec)

7

8

ROMIO Implementation of MPI-IO

MPI-IO

GPFS PVFS UFS New File System

ADIO

NTFS XFS Portable Implementation File-system-specific Implementations

ADIO

remote site Wide-area network NFS

ROMIO is available as part of all MPI implementations

Basic MPI-IO

§ MPI-IO provided a familiar file I/O interface (open, close, read, write, seek) and some additional features § To MPI users, it was like MPI § To I/O developers, it was a file I/O interface with an MPI flavor

9

Using MPI-IO

MPI_File fh; MPI_Status status; MPI_Comm_rank(MPI_COMM_WORLD, &rank); MPI_Comm_size(MPI_COMM_WORLD, &nprocs); bufsize = FILESIZE/nprocs; nints = bufsize/sizeof(int); MPI_File_open(MPI_COMM_WORLD, "/pfs/datafile", MPI_MODE_RDONLY, MPI_INFO_NULL, &fh); MPI_File_seek(fh, rank * bufsize, MPI_SEEK_SET); MPI_File_read(fh, buf, nints, MPI_INT, &status); MPI_File_close(&fh);

FILE P0 P1 P2 P(n-1)

11

New Feature: File views for noncontiguous data

etype = MPI_INT filetype = two MPI_INTs followed by a gap of four MPI_INTs displacement filetype filetype and so on... FILE

head of file

What turned out to be useful or widely used

§ Collective reads/writes (MPI_File_read_all / write_all) § Nonblocking reads/writes (MPI_File_iread / iwrite) § Explicit offset reads/writes (MPI_File_read_at / write_at) and their collective and nonblocking versions § MPI_Info hints § Well defined set of consistency semantics

12

Features that are not widely used

§ File interoperability

– Internal, external32 data representations – User-defined data representations – Not used because higher-level libraries that use MPI-IO have their

• wn file format (HDF, PnetCDF)

§ Shared file pointers § Split collective I/O (MPI_File_read_all_begin / end)

– Restricted form of nonblocking collective I/O – MPI 3.1 has added regular nonblocking collective I/O functions (MPI_File_iread_all, etc.)

13

Current Status

§ MPI-IO is still widely used by applications for parallel I/O, either directly or indirectly through high-level I/O libraries (such as HDF-5, PnetCDF, ADIOS) that use MPI-IO § Many file systems are supported (GPFS, Lustre, …) § Others contribute code for new file systems § Many papers have been written (by many people) on

• ptimizations that can be done within an MPI-IO

implementation

14

Future

§ Work is always needed in tuning an implementation for the specific I/O configurations of large supercomputing systems § Giving users too many options (in the form of hints they can pass) is not useful – they don’t use them

– The implementation must figure out as many of the best values it can

§ The presence of burst buffers (NVRAM) on a system changes the economics of small v/s large I/O operations

– There is less need to aggregate small I/O operations into large ones, or the cutoff point is different – The implementation needs more smarts to know what is the best approach

15

Summary

§ Twenty years have flown by since the MPI-2 days § It has been my privilege to be involved in many aspects of MPI (in addition to MPI-IO)

– MPICH implementation – MPI-2.1, 2.2, and 3.0 standardization – RMA and collectives

§ Thanks to many colleagues and friends whom I have worked with over the years
