SLIDE 1
GLENOVER RARE EARTHS
ALEX ANDERSSON - MD - GLENOVER
GLENOVER RARE EARTHS
INTRODUCTION & PROJECT BACKGROUND GLENOVER PROJECT INFRASTRUCTURE METALLURGY DEVELOPMENT VALUE DERIVED SUMMARY
GLENOVER RARE EARTHS ALEX ANDERSSON - MD - GLENOVER Glenover - - PowerPoint PPT Presentation
GLENOVER RARE EARTHS ALEX ANDERSSON - MD - GLENOVER Glenover - - PowerPoint PPT Presentation
GLENOVER RARE EARTHS ALEX ANDERSSON - MD - GLENOVER Glenover Rare Earth Project Agenda INTRODUCTION & PROJECT BACKGROUND GLENOVER PROJECT INFRASTRUCTURE METALLURGY DEVELOPMENT VALUE DERIVED SUMMARY GLENOVER RARE EARTHS GLENOVER
SLIDE 2
SLIDE 3
GLENOVER PROJECT BACKGROUND
SLIDE 4
GLENOVER RARE EARTHS
Location
Glenover
Glenover Rare Earth Project
SLIDE 5
Glenover Rare Earth Project
LOCATION
SLIDE 6
Breccia Body “hill” Late Stage Carbonatite Pyroxenite
Source: Dr. W J Verwoerd
GEOLOGY
Glenover Rare Earth Project
ORIGINAL BROAD GEOLOGICAL MODEL
SLIDE 7
Pyroxenite/Glimmerite Pyroxenite cross cut by Carbonatite Veins Coarse Grained Dolomitic Carbonatite
Apatite Martite Breccia
Glenover Rare Earth Project
ROCK TYPES
SLIDE 8
GEOPHYSICS – AEROMAGNETIC SIGNATURE
Glenover Rare Earth Project
SLIDE 9
GEOPHYSICS – RADIOMETRIC SIGNATURE
Glenover Rare Earth Project
SLIDE 10
Glenover Rare Earth Project
1958 - 1982
HISTORY – GOLDFIELDS OPERATION
SLIDE 11
Glenover Rare Earth Project
1999 - 2011
HISTORY – FERMINORE OPERATION
SLIDE 12
GLENOVER PROJECT INFRASTRUCTURE
SLIDE 13
Glenover Rare Earth Project
TAR ROAD TO SITE RAIL SERVICES WITHIN 20KM 2 REGIONAL POWER STATIONS
PROJECT INFRASTRUCTURE
SLIDE 14
Glenover Rare Earth Project
BOOMING LOCAL MINING INDUSTRY
SLIDE 15
Glenover Rare Earth Project
BOREHOLE WATER ELECTRICAL SUPPLY WORKSHOPS/OFFICE ABLUTION FACILITIES
PROJECT INFRASTRUCTURE ON SITE
SLIDE 16
INFRASTRUCTURE
Glenover Rare Earth Project
3.5MT of fines and ROM stockpiles ready for processing
SLIDE 17
GLENOVER GETTING TO METALLURGY
SLIDE 18
GEOCHEMISTRY – 3000M DRILL PROGRAMME
Glenover Rare Earth Project
SLIDE 19
GEOCHEMISTRY – 3000M DRILL PROGRAMME
Glenover Rare Earth Project
SLIDE 20
GEOCHEMISTRY
Glenover Rare Earth Project
SLIDE 21
RESOURCE
Glenover Rare Earth Project
SLIDE 22
RESOURCE
Glenover Rare Earth Project
SLIDE 23
RESOURCE STATEMENT – APATITE BRECCIA ONLY
Cut-off Grade Tonnes Average Grade Contained TREO % TREO Mt % TREO kt Indicated Resource In Situ 1 7.4 2.2 163 Inferred Resource (Stockpiles) 1 3.1 1.9 59 TOTAL 10.5 222
Glenover Rare Earth Project
SLIDE 24
APATITE BRECCIA MINERALOGY HIGHLIGHTS
Grade Summary: TREO HREO HREO/ TREO Nb2O5 Sc2O3 ThO2 P2O5 Fe2O3 % % % % ppm ppm % % Apatite Breccia 2.22 0.14 6.31 0.81 143 540 18.21 23.67
Glenover Rare Earth Project
Main REE Bearing Minerals: Apatite (Primary + Secondary); Monazite; Synchysite; Bastnaesite; Aeschynite Potential Co-products
SLIDE 25
APATITE BRECCIA MINERALOGY HIGHLIGHTS
Liberation: Iron: 75%-80% at 120μm P2O5: +90% at 120μm REE: 30-40% at 120μm
10 20 30 40 50 60 70 80 90 100 10 100 1000 Cu mulative mass % mineral passing size Grain Size (µm)
Grain Size Distribution LG Apatite Breccia
REE Phosphates REE Carbonates Zr Oxides and Silicates REE Nb-rich Apatite Fe Oxide Fe Oxide with Goethite
Glenover Rare Earth Project
SLIDE 26
Glenover Rare Earth Project Flow Sheet
SLIDE 27
Glenover Rare Earth Project
PROPOSED PLANT EXPANSION AND PIT ENLARGEMENT
SLIDE 28
GLENOVER DEVELOPMENT VALUE DERIVED
SLIDE 29
- June 2011:
Mineralogy study on Apatite Breccia completed by SGS
- Jan 2012:
Initial 3000m Drill Programme completed
- March 2012:
6-hole Step Out Drill Programme completed
- June 2012:
Updated SAMREC Resource published
- To Aug 2012:
Stockpiles sampled and 16T of ROM crushed and homogenized for mineralogy and metallurgy
- August 2012:
Mineralogy studies on Breccia, Carbonatite and Pyroxenite core completed by Xstrata Process Support
DEVELOPMENT SUMMARY - GEOLOGY
Glenover Rare Earth Project
SLIDE 30
- June 2010:
Fer-Min-Ore magnetic separation testwork
- April 2012:
Completion of Maelgwyn apatite flotation testwork
- August 2012:
PEA scope awarded to process consultant GBM, UK
- September 2012:
PFS metallurgy contract awarded to lab, China
DEVELOPMENT SUMMARY – METALLURGY
Glenover Rare Earth Project
SLIDE 31
BENCHMARKING – Nd RICH REE PACKAGE
Galileo Frontier Montero GWMG Arafura Lynas Rare Element Quest RE Oxide Glenover Zandkopsdrift Wigu Hill Steenkampskraal Nolans Bore Mt Weld Bear Lodge Strange Lake Lanthanum 16.71% 25.37% 37.07% 21.05% 19.13% 23.88% 26.56% 13.76% Cerium 45.04% 44.05% 49.03% 45.36% 48.72% 47.54% 43.81% 29.13% Praseodymium 5.78% 4.62% 3.86% 5.13% 5.93% 5.16% 5.01% 3.24% Neodymium 22.16% 15.88% 9.27% 17.83% 20.59% 18.13% 17.95% 12.14% Samarium 3.51% 2.27% 0.77% 2.80% 2.29% 2.44% 2.83% 2.70% Europium 0.89% 0.59% 0.00% 0.06% 0.39% 0.53% 0.62% 0.11% Gadolinium 2.03% 1.42% 0.00% 1.91% 0.99% 1.09% 1.44% 2.65% Terbium 0.21% 0.17% 0.00% 0.23% 0.08% 0.09% 0.12% 0.55% Dysprosium 0.76% 0.78% 0.00% 1.00% 0.32% 0.25% 0.37% 3.60% Holmium 0.10% 0.13% 0.00% 0.12% 0.04% 0.03% 0.04% 0.83% Erbium 0.19% 0.32% 0.00% 0.31% 0.09% 0.06% 0.08% 2.54% Thulium 0.02% 0.04% 0.00% 0.02% 0.01% 0.01% 0.01% 0.40% Ytterbium 0.09% 0.22% 0.00% 0.12% 0.06% 0.03% 0.04% 2.61% Lutetium 0.01% 0.03% 0.00% 0.01% 0.01% 0.00% 0.01% 0.40% Yttrium 2.50% 4.12% 0.00% 4.05% 1.35% 0.76% 1.11% 25.34% Total 100% 100% 100% 100% 100% 100% 100% 100%
2 1 1 3 4
PEER RATING OF CREO DISTRIBUTION
Glenover Rare Earth Project
SLIDE 32
BENCHMARKING
Glenover Rare Earth Project
SLIDE 33
PROJECT DEVELOPMENT PLANS – SYNCHYSITE TARGET – VALUE POTENTIAL
Glenover Rare Earth Project
SLIDE 34
PROJECT DEVELOPMENT PLANS – 2012/2013
- Metallurgy – Complete Open and Closed Circuit PFS Met by Q4 2012
- Feasibility Studies - Complete PEA Q1 2013 and PFS Q4 2013
- Exploration Drilling – Investigate Synchysite Target
Glenover Rare Earth Project
SLIDE 35
GLENOVER - SUMMARY
- Low Cost Project that Competes with World Class Peers
- Potentially Low Cost Producer with Zero Mining Costs for 1st 3 Years
- Potential Co-Product Credits
- Significant Available Infrastructure
- Excellent Further Target Potential in 7km Diameter Intrusive
SLIDE 36
