SLIDE 1
ggplot and the GRAMMAR OF GRAPHICS MAPPING vs SETTING AESTHETICS - - PowerPoint PPT Presentation
ggplot and the GRAMMAR OF GRAPHICS MAPPING vs SETTING AESTHETICS - - PowerPoint PPT Presentation
ggplot and the GRAMMAR OF GRAPHICS MAPPING vs SETTING AESTHETICS p <- ggplot (data = gapminder, mapping = aes (x = gdpPercap, y = lifeExp, color = "purple")) p + geom_point () + geom_smooth (method = "loess") +
SLIDE 2
SLIDE 3
p <- ggplot(data = gapminder, mapping = aes(x = gdpPercap, y = lifeExp, color = "purple")) p + geom_point() + geom_smooth(method = "loess") + scale_x_log10()
SLIDE 4
What has gone wrong here?
SLIDE 5
p <- ggplot(data = gapminder, mapping = aes(x = gdpPercap, y = lifeExp) p + geom_point(color = "purple") + geom_smooth(method = "loess")) + scale_x_log10()
SLIDE 6
SLIDE 7
p <- ggplot(data = gapminder, mapping = aes(x = gdpPercap, y = lifeExp)) p + geom_point(alpha = 0.3) + geom_smooth(color = "orange", se = FALSE, size = 2, method = "lm") + scale_x_log10()
Here, some elements are mapped to variables, while others are set to values geom functions can take many different arguments
SLIDE 8
SLIDE 9
p <- ggplot(data = gapminder, mapping = aes(x = gdpPercap, y = lifeExp, color = continent, fill = continent)) p + geom_point() + geom_smooth(method = "loess") + scale_x_log10()
SLIDE 10
SLIDE 11
MAP or SET AESTHETICS per geom
SLIDE 12
p <- ggplot(data = gapminder, mapping = aes(x = gdpPercap, y = lifeExp)) p + geom_point(mapping = aes(color = continent)) + geom_smooth(method = "loess") + scale_x_log10()
SLIDE 13
SLIDE 14
PAY CLOSE ATTENTION TO WHICH SCALES AND GUIDES ARE DRAWN, AND WHY THAT HAPPENS
SLIDE 15
p <- ggplot(data = gapminder, mapping = aes(x = gdpPercap, y = lifeExp, color = continent, fill = continent)) p + geom_point() + geom_smooth(method = "loess") + scale_x_log10()
SLIDE 16
p <- ggplot(data = gapminder, mapping = aes(x = gdpPercap, y = lifeExp)) p + geom_point(mapping = aes(color = continent)) + geom_smooth(method = "loess") + scale_x_log10()
SLIDE 17
REMEMBER: EVERY MAPPED VARIABLE HAS A SCALE
SLIDE 18
SLIDE 19
IMPLEMENTS A GRAMMAR OF GRAPHICS ggplot
SLIDE 20
The grammar is a set of rules for how produce graphics from data, taking pieces of data and mapping them to geometric objects (like points and lines) that have aesthetic attributes (like position, color and size), together with further rules for transforming the data if needed, adjusting scales, or projecting the results onto a coordinate system.
SLIDE 21
Like other rules of syntax, the grammar limits what you can validly say, but it doesn’t make what you say sensible or meaningful.
SLIDE 22
Grouped Data and the group aesthetic
SLIDE 23
p <- ggplot(data = gapminder, mapping = aes(x = year, y = gdpPercap)) p + geom_line()
SLIDE 24
SLIDE 25
SLIDE 26
p <- ggplot(data = gapminder, mapping = aes(x = year, y = gdpPercap)) p + geom_line(mapping = aes(group = country))
SLIDE 27
SLIDE 28
p <- ggplot(data = gapminder, mapping = aes(x = year, y = gdpPercap)) p + geom_line(mapping = aes(group = country)) + facet_wrap(~ continent)
A facet is not a
- geom. It’s a way
- f arranging geoms.
Facets use R’s ‘formula’ syntax. Read the ~ as “on” or “by”.
SLIDE 29
SLIDE 30
p + geom_line(color = "gray70", mapping = aes(group = country)) + geom_smooth(size = 1.1, method = "loess", se = FALSE) + scale_y_log10(labels=scales::dollar) + facet_wrap(~ continent, ncol = 5) + labs(x = "Year", y = "GDP per capita", title = "GDP per capita on Five Continents")
The labs() function lets you name labels, title, subtitle, etc.
