SLIDE 1
Euclid of Alexandria
The Founder of Geometry. He was a Greek mathematician, often referred to as the "Father
- f Geometry". He was active in Alexandria
during the reign of Ptolemy I (323–283 BC)
Geometry Euclid of Alexandria The Founder of Geometry. He was a - - PowerPoint PPT Presentation
Geometry Euclid of Alexandria The Founder of Geometry. He was a - - PowerPoint PPT Presentation
Geometry Euclid of Alexandria The Founder of Geometry. He was a Greek mathematician, often referred to as the "Father of Geometry". He was active in Alexandria during the reign of Ptolemy I (323283 BC) Pythagorean theorem Geometry
SLIDE 2
SLIDE 3
Pythagorean theorem
SLIDE 4
Geometry
SLIDE 5
LEGOMETRY
SLIDE 6
3 Plates = 1 Brick
SLIDE 7
Ldraw Unit (LDU)
SLIDE 8
SLIDE 9
Bricks are 8mm wide by 9.6mm high How do you make widths and heights match?
SLIDE 10
LDU makes the math easy.... How many plates = how many studs?
2 studs = 2x20 = 40 LDU 5 plates = 5x8 = 40 LDU
2 studs = 2x20 = 40 LDU 5 plates = 5x8 = 40 LDU
SLIDE 11
How many bricks = how many studs? 6 studs = 6x20 = 120 LDU 5 bricks = 5x24 = 120 LDU
SLIDE 12
6 studs = 5 bricks = 120 LDU (or 15 plates) 4 studs = 3 1/3 bricks = 80 LDU (or 10 plates) 2 studs = 1 2/3 bricks = 40 LDU (or 5 plates)
SLIDE 13
Since 1 stud = 2 ½ plates, no combination of plates adds up to exactly one stud
SLIDE 14
One answer: brackets. The thin vertical plate is ½ the thickness of a normal plate, or 4 LDU
SLIDE 15
Bracket vertical part is ½ plate thick ½ plate from bracket + 1 plate + 1 tile = 2 ½ plates, same as 1 stud
SLIDE 16
Exception
SLIDE 17
Technic pin hole placement is just a little higher (about 0.2mm) than stud-on-side placement. Some models may have alignment problems due to this. Reason: early Technic brick molds needed thicker plastic between pinhole and bottom of brick.
SLIDE 18
Use bricks with studs on sides to attach assemblies at 90 degrees. To mount them flush, remember that 5 plates = 2 studs = 40 LDU.
SLIDE 19
Use half-plate offsets to add texture to an otherwise flat wall
SLIDE 20
SLIDE 21
Studs not on Top
SLIDE 22
How do you make a gentle slope? What if these are too steep?
SLIDE 23
For a more gradual slope, we'd like to mount every other one ½ plate higher But, we have a half-plate hole to fill! How to attach these?
SLIDE 24
Alternate rotations for headlight bricks to take advantage of ½ plate offset in “foot”
SLIDE 25
The 1x1 “cheese slope” is a very useful part but doesn't combine well with others of its kind to make a smooth slope. This notch is needed for it to fit a stud inside, but is ugly.
SLIDE 26
Turns out that “notch” is ½ plate thick. 2 plates (height of cheese slope) + ½ plate = 1 stud
SLIDE 27
Mount the center slope ½ plate lower for a smooth surface!
SLIDE 28
Passing through Whole parts
SLIDE 29
SLIDE 30
SLIDE 31
Other Ways to flip 180 degrees
SLIDE 32
Hinges
SLIDE 33
SLIDE 34
With Technics
SLIDE 35
Axles
This building work only for bricks bigger than 1xn bricks.
SLIDE 36
Half pins
SLIDE 37
Other Ways
SLIDE 38
34 LDU height.
SLIDE 39
28 LDU height
SLIDE 40
50 LDU height
SLIDE 41
Smallest Way
SLIDE 42
It can also be improved using cut Technic tubing.
SLIDE 43
OFFSETS
SLIDE 44
Jumper Plates
SLIDE 45
Other Offsets
SLIDE 46
Stud-to-tube trick
SLIDE 47
Tube to hollow stud trick
SLIDE 48
Technic bricks
SLIDE 49
bar/arm and clip
SLIDE 50
SLIDE 51
LETTERING
SLIDE 52
SLIDE 53
SLIDE 54
SLIDE 55
SLIDE 56
Diagonals and Striping
SLIDE 57
SLIDE 58
SLIDE 59
SLIDE 60
MicroStriping
SLIDE 61
SLIDE 62
Top hinges brick micro-striping
SLIDE 63
SNOT mounted 1x2-1x4 bracket micro-striping
SLIDE 64
Making things Skeef
SLIDE 65
SLIDE 66
