SLIDE 1
GENERAL PRESENTATION ACS GROUP BUSINESS LINES Infrastructures - - PowerPoint PPT Presentation
GENERAL PRESENTATION ACS GROUP BUSINESS LINES Infrastructures - - PowerPoint PPT Presentation
GENERAL PRESENTATION ACS GROUP BUSINESS LINES Infrastructures Control - Infrastructure Management - Project Monitoring - Technical Tunnel Control - Project Control and Surveillance - Q&C Laboratory - Radiochemistry and radiometry
SLIDE 2
SLIDE 3
Infrastructures Control
- Infrastructure Management
- Project Monitoring
- Technical Tunnel Control
- Project Control and Surveillance
- Q&C Laboratory
- Radiochemistry and radiometry laboratory
Works
- Foundations
- Ground treatments
- Monument and infrastructure
restoration
BUSINESS LINES
Engineering
- Geotechnical and technical assistance
- Structures
- Environmental protection
- IT Software developments.
R+D+i
- R&D&I projects
- Technological developments
GEOTECNIA Y CIMIENTOS, S.A, Spanish company leader in its field was incorporated in 1968. Also uses GEOCISA like its trade name .
SLIDE 4
ACTIVITIES
INFRASTRUCTURES CONTROL
Q.C. Laboratory Radiochemistry and radiometry laboratory Environment laboratory. Project control and surveillance:
- Design and installation of instrumentation systems
- Instrumentation control and data analysis
Technical tunnel control Infrastructure management:
- Road conservation
- A.D.A.R. control
- Road security
SLIDE 5
ENGINEERING
IT Software developments. Structures
- Structure instrumentation
- Structure management system
- Durability studies
- Structural test
Environmental protection
- Environment performance
- Hydrogeology and soil characterization
- Soil remediation (in situ y ex situ)
Geotechnical and technical assistance
- Geological and geotechnical studies
- Slope stabilization
ACTIVITIES
SLIDE 6
WORKS
FOUNDATIONS Monument and infrastructure restoration
- Cathedrals and other religious buildings
- Castles and walls
- Palaces
- Singular buildings
- Rehabilitation of Civil Structures
GROUND TREATMENTS
- Injections:
- Compensation
- Compaction
- Jet grouting
- Drains
- Micropiles
- Dynamic compaction
- Stone columns
- Anchors & bolts
- Drillings and boreholes
ACTIVITIES
Diaphram Walls:
- Reinforced diaphram walls
Hydro milling (to depths of 71 m, a record in Spain) Continuous reinforced concrete walls CSM walls Secant pile walls Discontinuous pile walls Cement-bentonite walls with bar reinforcements Cement-bentonite walls with pile reinforcements Micropile walls Sheet piling walls
- Waterproofing walls
Continuous cement-bentonite walls for hydraulic works (k=10^-6 cm/s) Continuous cement-bentonite walls for contaminated enclosures (k=10^-8 cm/s) Discontinuous plastic concrete walls Piles: Piles with parameter readings. Continuous propeller Piles with joinable pipes Piped piles with vibrating driver Piles with mud Mixed piles Percussion-driven piles Pile piers with concrete shaft Pile piers with metal shaft
SLIDE 7
GEOCISA carries out Research & Development activities in its different Areas within the field of Engineering, Site Construction and lastly, supervision and Testing of Quality or Environment related aspects.
R+D+i
GEOCISA has had its R+D+i MANAGEMENT system registered with AENOR since 2010, in compliance with the model stipulated under the UNE-EN ISO 16002 Standard.
SLIDE 8
HEALTH & SAFETY MANAGEMENT SYSTEM
SAFETY AT WORK INDUSTRIAL HIGENE APPLIED PSYCHO-SOCIOLOGY & ERGONOMICS MEDICINE GEOCISA has the four specialisations required by law : GEOCISA considers Safety to be an essential factor in carrying out its work. GEOCISA is also certified by FLC (Spanish Construction Labour Foundation) as Authorised Company to give training
- n Ocupational Prevention Risks since 2009
GEOCISA has its H & S Management System registered with AENOR since 2011, in compliance with the model stipulated under the OHSAS 18001:2007 Standard
SLIDE 9
GEOCISA is the First Spanish company in its Field to have been awarded the AENOR QUALITY CERTIFICATION in compliance with the UNE-EN ISO 9002:94 Standard GEOCISA has had its ENVIRONMENTAL MANAGEMENT system registered with AENOR since 2001, in compliance with the model stipulated under the UNE-EN ISO 14001 Standard. GEOCISA considers Quality to be absolutely essential to ensuring Competitiveness, Sucess and Leadership in its field both in Spain and abroad and this, the Management and all others with the Organization are committed to Total Quality Management.
QUALITY CONTROL AND ENVIROMENTAL MANAGEMENT SYSTEM
SLIDE 10
In the last 5 years GEOCISA has carried out :
GEOCISA MAIN WORKS
WORKS:
- Foundations and Ground Treatment Works: More than 600 contracts (320 M €)
- Monument and Civil structure restoration: More than 90 contracts (65 M €)
INFRASTRUCTURE CONTROL:
- Tunnel Technical Control and Instrumentation and Monitoring: More than 330
contracts (70 M €)
- Infrastructure management: More than 490 contracts (41 M €)
- Site Technical Assistance and Q&C Laboratories: More than 860 contracts (65 M €)
ENGINEERING
- Technical Assistance and Enviromental Restoration: More than 615 contracts (26 M €)
SLIDE 11
