Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion Ganeti The Cluster Virtualization Management Software Helga Velroyen (helgav@google.com) Klaus Aehlig (aehlig@google.com) August 24, 2014 Introduction

slide-1
SLIDE 1

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti

The Cluster Virtualization Management Software Helga Velroyen (helgav@google.com) Klaus Aehlig (aehlig@google.com) August 24, 2014

slide-2
SLIDE 2

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Cluster

instance instance node instance node instance node

For Ganeti, a cluster is

  • virtual machines (“instances”)
  • on physical machines (“nodes”)

using some hypervisor (Xen, kvm, . . . )

  • and some storage solution

(DRBD, shared storage, . . . ).

slide-3
SLIDE 3

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Cluster Management

instance instance node instance node instance node

Ganeti helps

  • to get there
  • uniform interface

hypervisors/storage/. . .

  • policies, balanced allocation
slide-4
SLIDE 4

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Cluster Management

instance instance node instance node instance node

Ganeti helps

  • to get there
  • uniform interface

hypervisors/storage/. . .

  • policies, balanced allocation
  • and to stay there
slide-5
SLIDE 5

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Cluster Management

instance instance node instance node instance node instance instance

Ganeti helps

  • to get there
  • uniform interface

hypervisors/storage/. . .

  • policies, balanced allocation

keeping N + 1 redundancy

  • and to stay there
  • failover instances
  • rebalance
  • Restart instances after power
  • utage
  • . . .
slide-6
SLIDE 6

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Cluster creation

  • gnt-cluster init -s 192.0.2.1

clusterA.example.com

slide-7
SLIDE 7

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Cluster creation

  • gnt-cluster init -s 192.0.2.1

clusterA.example.com

  • gnt-node add -s 192.0.2.2 node2.example.com
slide-8
SLIDE 8

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Cluster creation

  • gnt-cluster init -s 192.0.2.1

clusterA.example.com

  • gnt-node add -s 192.0.2.2 node2.example.com
  • . . .
slide-9
SLIDE 9

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Cluster creation

  • gnt-cluster init -s 192.0.2.1

clusterA.example.com

  • gnt-node add -s 192.0.2.2 node2.example.com
  • . . .
  • gnt-instance add -t drbd -o debootstrap -s 2G
  • -tags=foo,bar instance1.example.com
slide-10
SLIDE 10

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Cluster creation

  • gnt-cluster init -s 192.0.2.1

clusterA.example.com

  • gnt-node add -s 192.0.2.2 node2.example.com
  • . . .
  • gnt-instance add -t drbd -o debootstrap -s 2G
  • -tags=foo,bar instance1.example.com

The -o debootstrap references the OS definition to be used. An OS definition essentially is a collection of scripts to create, import, export, . . . an instance.

slide-11
SLIDE 11

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Planned Node maintenance

Evacutating a node

  • gnt-node modify --drained=yes node2.example.com
slide-12
SLIDE 12

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Planned Node maintenance

Evacutating a node

  • gnt-node modify --drained=yes node2.example.com
  • hbal -L -X
slide-13
SLIDE 13

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Planned Node maintenance

Evacutating a node

  • gnt-node modify --drained=yes node2.example.com
  • hbal -L -X
  • gnt-node modify --offline=yes node2.example.com
slide-14
SLIDE 14

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Planned Node maintenance

Evacutating a node

  • gnt-node modify --drained=yes node2.example.com
  • hbal -L -X
  • gnt-node modify --offline=yes node2.example.com

Using the node again

  • gnt-node modify --online=yes node2.example.com
slide-15
SLIDE 15

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Basic Interaction—Planned Node maintenance

Evacutating a node

  • gnt-node modify --drained=yes node2.example.com
  • hbal -L -X
  • gnt-node modify --offline=yes node2.example.com

Using the node again

  • gnt-node modify --online=yes node2.example.com
  • hbal -L -X
slide-16
SLIDE 16

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

slide-17
SLIDE 17

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node gnt-* luxid

  • gnt-* don’t execute tasks

they just submit jobs

slide-18
SLIDE 18

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node gnt-* luxid

  • gnt-* don’t execute tasks

they just submit jobs

  • CLI does not have to wait; --submit
  • can be queried with gnt-job info
slide-19
SLIDE 19

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node gnt-* luxid

  • gnt-* don’t execute tasks

they just submit jobs

slide-20
SLIDE 20

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node gnt-* luxid noded job file job file

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • written to disk
  • replicated to some other nodes

(the “master candidates”)

slide-21
SLIDE 21

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
slide-22
SLIDE 22

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • limit on jobs running simultaneously

(NEW: run-time tunable)

slide-23
SLIDE 23

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • limit on jobs running simultaneously

(NEW: run-time tunable)

  • job dependency

(NEW: honored at queuing stage)

slide-24
SLIDE 24

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • limit on jobs running simultaneously

(NEW: run-time tunable)

  • job dependency

(NEW: honored at queuing stage)

  • ad-hoc rate limiting

(NEW in Ganeti 2.13; more later)

slide-25
SLIDE 25

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
slide-26
SLIDE 26

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file job

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
  • forked off, but still waiting for locks

(instances, nodes, . . . )

slide-27
SLIDE 27

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file job wconfd

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
  • forked off, but still waiting for locks

(instances, nodes, . . . )

  • Reading configuration
slide-28
SLIDE 28

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file job wconfd

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
  • forked off, but still waiting for locks

(instances, nodes, . . . )

  • Reading configuration
  • Already responsible for its own job file
slide-29
SLIDE 29

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node luxid noded job file job file job wconfd

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
slide-30
SLIDE 30

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node node luxid noded job file job file job wconfd noded

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
  • running
  • Actual manipulation of the world

via noded

slide-31
SLIDE 31

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node node luxid noded job file job file job wconfd noded conf conf

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
  • running
  • Actual manipulation of the world

via noded

  • Updates the configuration
slide-32
SLIDE 32

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node node luxid noded job file job file job wconfd noded conf conf

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
  • running
slide-33
SLIDE 33

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Jobs

master node MC node node luxid noded job file job file wconfd noded conf conf

  • gnt-* don’t execute tasks

they just submit jobs

  • luxid recieves job
  • queued
  • waiting
  • running
  • success

(hopefully; or error, canceled)

slide-34
SLIDE 34

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
slide-35
SLIDE 35

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • cluster verification (parallel verification of node groups)
slide-36
SLIDE 36

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • cluster verification (parallel verification of node groups)
  • node evacuation (parallel instance moves)
  • . . .
slide-37
SLIDE 37

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
slide-38
SLIDE 38

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
slide-39
SLIDE 39

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • hbal -L -X
slide-40
SLIDE 40

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • hbal -L -X
  • External tools on top of Ganeti
slide-41
SLIDE 41

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
slide-42
SLIDE 42

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

slide-43
SLIDE 43

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

  • List of (source, reason, time) triples
slide-44
SLIDE 44

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

  • List of (source, reason, time) triples
  • Every entity touching can (and usually does) extend
slide-45
SLIDE 45

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

  • List of (source, reason, time) triples
  • Every entity touching can (and usually does) extend
  • Inherited on job expansion
slide-46
SLIDE 46

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

  • List of (source, reason, time) triples
  • Every entity touching can (and usually does) extend
  • Inherited on job expansion
  • The “reason trail” is also used for rate limiting (Ganeti 2.13+)
slide-47
SLIDE 47

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

  • List of (source, reason, time) triples
  • Every entity touching can (and usually does) extend
  • Inherited on job expansion
  • The “reason trail” is also used for rate limiting (Ganeti 2.13+)
  • Reasons starting with rate-limit:n: are rate-limit buckets
slide-48
SLIDE 48

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

  • List of (source, reason, time) triples
  • Every entity touching can (and usually does) extend
  • Inherited on job expansion
  • The “reason trail” is also used for rate limiting (Ganeti 2.13+)
  • Reasons starting with rate-limit:n: are rate-limit buckets
  • At most n such jobs run in parallel
slide-49
SLIDE 49

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Reason Trail

  • Instead of running, jobs can also expand to other jobs
  • High-level commands can submit many Ganeti jobs
  • To keep track why a particular job is run,

parts are annotated with a “reason trail”

  • List of (source, reason, time) triples
  • Every entity touching can (and usually does) extend
  • Inherited on job expansion
  • The “reason trail” is also used for rate limiting (Ganeti 2.13+)
  • Reasons starting with rate-limit:n: are rate-limit buckets
  • At most n such jobs run in parallel

gnt-group evacuate

  • -reason="rate-limit:7:maintenance 123" groupA
slide-50
SLIDE 50

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Instance placement

slide-51
SLIDE 51

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Instance placement

  • Ganeti tries to keep utilization equal at all nodes
slide-52
SLIDE 52

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Instance placement

  • Ganeti tries to keep utilization equal at all nodes
  • Especially do so when creating new instances!

(Saves later moves)

slide-53
SLIDE 53

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Instance placement

  • Ganeti tries to keep utilization equal at all nodes
  • Especially do so when creating new instances!

(Saves later moves)

  • IAllocator protocol
  • delegate decission where to place to external program
  • Given: cluster description and needed resources
  • Answer: node(s) to place instance(s)
  • Most popular allocator hail

Same algorithm as hbal

slide-54
SLIDE 54

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Instance placement

  • Ganeti tries to keep utilization equal at all nodes
  • Especially do so when creating new instances!

(Saves later moves)

  • IAllocator protocol
  • delegate decission where to place to external program
  • Given: cluster description and needed resources
  • Answer: node(s) to place instance(s)
  • Most popular allocator hail

Same algorithm as hbal

  • Locking
  • need to guarantee that resources are still available
  • nce nodes are chosen
  • lock all nodes, release remaining after choice
slide-55
SLIDE 55

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Instance placement

  • Ganeti tries to keep utilization equal at all nodes
  • Especially do so when creating new instances!

(Saves later moves)

  • IAllocator protocol
  • delegate decission where to place to external program
  • Given: cluster description and needed resources
  • Answer: node(s) to place instance(s)
  • Most popular allocator hail

Same algorithm as hbal

  • Locking
  • need to guarantee that resources are still available
  • nce nodes are chosen
  • lock all nodes, release remaining after choice

Instance creation sequential Even if other nodes will eventually be chosen!

slide-56
SLIDE 56

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Opportunistic Locking

Parallel instance creation with --opportunistic-locking

slide-57
SLIDE 57

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Opportunistic Locking

Parallel instance creation with --opportunistic-locking

  • Grab just the available node locks
slide-58
SLIDE 58

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Opportunistic Locking

Parallel instance creation with --opportunistic-locking

  • Grab just the available node locks
  • Choose among those nodes

and release the remaining

slide-59
SLIDE 59

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Opportunistic Locking

Parallel instance creation with --opportunistic-locking

  • Grab just the available node locks
  • Choose among those nodes

and release the remaining New error type (“try again”) if not enough resources

  • n the available nodes
slide-60
SLIDE 60

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Opportunistic Locking

Parallel instance creation with --opportunistic-locking

  • Grab just the available node locks

NEW: but at least one (two for DRBD)

  • Choose among those nodes

and release the remaining New error type (“try again”) if not enough resources

  • n the available nodes
slide-61
SLIDE 61

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Opportunistic Locking

Parallel instance creation with --opportunistic-locking

  • Grab just the available node locks

NEW: but at least one (two for DRBD)

  • Choose among those nodes

and release the remaining New error type (“try again”) if not enough resources

  • n the available nodes

Planned: internal retry

slide-62
SLIDE 62

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Deployment at Scale

  • RAPI
  • Hspace
  • Dedicated
  • ExtStorage
slide-63
SLIDE 63

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

RAPI

  • RAPI = remote API
  • RESTful
  • Client library hides all the details
  • You need the cluster name and credentials (for writing)
  • Virtual IP for cluster master failover
slide-64
SLIDE 64

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

RAPI - Python Client

Example usage of the Python client:

import ganeti_rapi_client as grc import pprint rapi = grc. GanetiRapiClient (’cluster1.example.com ’) print rapi.GetInfo () pp = pprint. PrettyPrinter (indent =4). pprint instances = rapi.GetInstances (bulk=True) pp(instances)

slide-65
SLIDE 65

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

RAPI - Python Client

Read/Write requires credentials:

import ganeti_rapi_client as grc rapi = grc. GanetiRapiClient (’cluster1.example.com ’) rapi = grc. GanetiRapiClient ( ’cluster1 ’, username=’USERNAME ’, password=’PASSWORD ’)

  • rapi. AddClusterTags (tags=[’dns ’])
slide-66
SLIDE 66

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

RAPI - Curl

Of course, you can just use with curl on the commandline:

> curl -k https :// mycluster.example.com :5080/2/ nodes [{"id": "mynode1.example.com", "uri ":: "/2/ nodes/mynode1.example.com"}, {"id": "mynode2.example.com", "uri": "/2/ nodes/mynode2.example.com"}, curl -k -X POST -H "Content -Type: application/json"

  • -insecure -d ’{ " master_candidate ": false }’

https :// username: password@mycluster .example.com :5080 \ /2/ nodes/mynode3.example.com/modify

slide-67
SLIDE 67

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Hspace - Capacity Planning

Running clusters, you might want to know:

  • How many more instances can I put on my cluster?
  • Which resource will I run out first?
  • How many new machines should I buy for demand X?

Hspace simulates resource consumption:

  • It simulates to add new instances till we run out of resources
  • Allocation done like with hail
  • Start with maximal size of instance (according to ipolicy)
  • Reduce size if we hit the limit for one resource
slide-68
SLIDE 68

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Hspace - on a live cluster

> hspace -L The cluster has 3 nodes and the following resources: MEM 196569 , DSK 10215744 , CPU 72, VCPU 288. There are 2 initial instances on the cluster. Tiered (initial size) instance spec is: MEM 1024 , DSK 1048576 , CPU 8, using disk template ’drbd ’. Tiered allocation results:

  • 4 instances of spec MEM 1024 , DSK 1048576 , CPU 8
  • 2 instances of spec MEM 1024 , DSK 258304 , CPU 8
  • most

likely failure reason: FailDisk

  • initial

cluster score: 1.92199260

  • final

cluster score: 2.03107472

  • memory

usage efficiency: 3.26%

  • disk

usage efficiency: 92.27%

  • vcpu

usage efficiency: 18.40% [...]

slide-69
SLIDE 69

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Hspace - Simulation Backend

Planning a cluster that does not exist yet

  • Simulates an empty cluster with given data
  • Format:
  • allocation policy (p=preferred, a=last resort, u=unallocatable)
  • number of nodes (in this group)
  • disk space per node (in MiB)
  • RAM (in MiB)
  • number of physical CPUs
  • use --simulate several times for more node groups
slide-70
SLIDE 70

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Hspace - Cluster Simulation

> hspace

  • -simulate=p ,3 ,34052480 ,65523 ,24 \
  • -disk -template=drbd --tiered -alloc =1048576 ,1024 ,8

The cluster has 3 nodes and the following resources: MEM 196569 , DSK 102157440 , CPU 72, VCPU 288. There are no initial instances on the cluster. Tiered (initial size) instance spec is: MEM 1024 , DSK 1048576 , CPU 8, using disk template ’drbd ’. Tiered allocation results:

  • 33 instances of spec MEM 1024 , DSK 1048576 , CPU 8
  • 3 instances of spec MEM 1024 , DSK 1048576 , CPU 7
  • most

likely failure reason: FailCPU

  • initial

cluster score: 0.00000000

  • final

cluster score: 0.00000000

  • memory

usage efficiency: 18.75%

  • disk

usage efficiency: 73.90%

  • vcpu

usage efficiency: 100.00% [...]

slide-71
SLIDE 71

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Dedicated - Use Case

Use case:

  • Offer machines to customers which require exclusive disk

resources

  • No two instances using the same disks
  • Solution could be to use bare metal, but ...

You still want the benefits of virtualization:

  • A different OS than the standard host OS
  • Easy migration if hardware fails

Ganeti Dedicated offers exactly that.

slide-72
SLIDE 72

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti Dedicated - Realisation

Setup:

  • Use Ganeti nodes with LVM storage (plain or DRBD)
  • Make sure no two physical volumes share the same physical

disk

  • Flag nodes in a node group with exclusive storage

Ganeti will:

  • Not place more than one instance on the same physical

volume

  • Respect this restriction in operations like cluster balancing

(hbal) and capacity planning (hspace)

slide-73
SLIDE 73

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

ExtStorage - Setup

Ganeti’s integration of shared / distributed / networked storage

  • All nodes have access to an external storage (SAN/NAS

appliance etc.)

  • Instance disks reside inside that storage
  • Instances are able to migrate/failover to any other node
  • The ExtStorage interface is a generic way to access external

storage

slide-74
SLIDE 74

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

ExtStorage - Implementation

  • For each type of appliance, Ganeti expected an ’ExtStorage

provider’

  • A bunch of scripts to do carry out these operations:
  • Create / grow / remove an instance disk on the applicance
  • Attach / detach a disk to / from a Ganeti node
  • SetInfo on a disk (add metadata)
  • Verify the provider’s supported parameters
  • Parameters transmitted via environment variables
slide-75
SLIDE 75

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

ExtStorage - Examples

Assume you have two appliance of different vendors:

  • /usr/share/ganeti/extstorage/emc/*
  • /usr/share/ganeti/extstorage/ibm/*

Some example usages:

  • gnt-instance add -t ext
  • -disk=0:size=2G,provider=emc
  • -disk=2:size=10G,provider=ibm
  • gnt-instance modify --disk

3:add,size=20G,provider=ibm

  • gnt-instance migrate [-n nodeX.example.com]

testvm1

  • gnt-instance modify --disk

2:add,size=3G,provider=emc,param5=value5

slide-76
SLIDE 76

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Current Development - 2.10

  • 2.10.7, available in debian wheezy backports
  • KVM:
  • hotplug support
  • direct access to RBD storage
  • Cross-cluster instance moves:
  • automatic node allocation on destination cluster
  • convert disk templates on the fly
  • Cluster balancing based on CPU load
  • Ganeti upgrades
slide-77
SLIDE 77

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti upgrades

Before:

  • On all nodes:
  • /etc/init.d/ganeti stop
  • apt-get install ganeti2=2.7.1-1

ganeti-htools=2.7.1-1

  • On the master node:
  • /usr/lib/ganeti/tools/cfgupgrade
  • On all nodes:
  • /etc/init.d/ganeti start
  • On the master node:
  • gnt-cluster redist-conf
  • ... lots of other steps, depending on the version
  • If something goes wrong, fix the mess manually.
slide-78
SLIDE 78

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Ganeti upgrades

From 2.10 on, Ganeti comes with a built-in upgrade mechanism:

  • On all nodes:
  • apt-get install ganeti-2.11
  • On the master node:
  • gnt-cluster upgrade --to 2.11
  • To roll back:
  • gnt-cluster upgrade --to 2.10

Note that you still have to install the new and deinstall the old packages manually.

slide-79
SLIDE 79

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Current Development - 2.11

  • Current stable version, available in Debian Jessie
  • RPC security: individual node certificates
  • Compression for instance moves / backups / imports
  • Configurable SSH ports per node group
  • Gluster support (experimental)
  • hsqueeze
slide-80
SLIDE 80

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

hsqueeze

Huddle your instances during a cold cold night!

  • Instances with shared storage (= live migration cheap)
  • High load during peak times, low utilization otherwise
  • Goal: During low utilization times, squeeze as many instances

together as possible and shutdown unused nodes

  • Use: Hsqueeze!
  • Calculates migration plan for instances
  • Aims to drain as many nodes as possible
  • But not too many to not cause resource congestion
  • Uses hbal to calculate balanced load
  • In 2.11, only planning; in 2.13 including execution
slide-81
SLIDE 81

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

LXC

  • LXC = Linux Containers
  • Was experimental for a looong time (because nobody got

time for it)

  • Now: Google Summer of Code Project
  • Goal: make it production ready, including a proper test chain
  • Status: Going well, probably to be released in 2.13
  • Works with LXC 1.0
  • Live-migration still experimental
slide-82
SLIDE 82

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Disk Template Conversions

  • Ganeti offers various disk templates for instances:
  • file, lvm, drbd, sharedfile, external storage
  • So far, converting between those is only partially fun
  • Google Summer of Code Project to make conversions smooth
  • Status: Going well, probably release in 2.13
slide-83
SLIDE 83

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

The Future

No guarantees!

  • Improved Jobqueue management
  • Network improvements (IPv6, more flexibility)
  • Storage: more work on shared storage
  • Heterogeneous clusters
  • Improvements on cross-cluster instance moves
  • Improvements on SSH key handling
slide-84
SLIDE 84

Introduction Jobs Locking Deployment at Scale Current and Future Development Conclusion

Conclusion

  • Check us out at

https://code.google.com/p/ganeti/

  • Or just search for ”Ganeti”

Questions? Feedback? Ideas? Flames? Upcoming Events:

  • Ganeticon, Portland, Oregon, Sep 2nd - 4th

c 2010-2014 Google Use under GPLv2+ or CC-by-SA
