Fruit Juice Solutions

1

LiquA is an industrial packaging and logistics group with an extensive network throughout the world. The company is incorporated in Spain and its factory is located in Istanbul, Turkey. Liqua team has been in the industry since 1997 as a packaging manufacturer. The starting product has been big bags. In 2007, the group started producing flexitanks and developing solutions for bulk liquids. In 2011, LiquA Logistics LTD was established to provide service to its clients through Liqua

• network. Customers are provided high

quality of bulk liquid logistics services as well as the most innovative packaging solutions.

2

Who we are...

3

Who we are...

Liqua proudly holds; PAS 1008 : 2016 Flexitank Production Managment System ISO 9001 : 2008 Quality Management System ISO 14001 : 2004 Environmental Management System ISO 22000 : 2005 HACCP Food Management System FSSC 22000 : 2010 Food Safety System Certificate OHSAS 18001 : 2007 Occupational Health and Safety Management System Kosher : Kosher Pareve Including Passover Halal : 22:2011 Halal Product Management System

4

Quality Assurance...

• Clean Room
• Ultrasonic Cutter

5

Production...

6

R-Flex Reefer Solutions…

7

Flexitanks designed for commodities that require temperature control. Flexitanks for; Reefer 20ft Containers Reefer 40ft Containers Reefer Trucks 22% more payload compared to drums and IBCs

Aseptic,

Food grade,

Gamma Irradiation

Dual Flexitank, possibility to load two different products with two separate compartments in a single flexitank Applicable for all kinds of containers and trucks Low Residue, Environmental Friendly, Easy recycling Less Carbon Foot Print than tankers and ISO tanks

R-Flex Reefer Solutions…

Org rganizatio ion…

Due to delicate nature of the commodities to be transported in reefer containers and also relatively fragile nature of 40ft reefer container boxes, CM CMA CGM, , Teconja &Liq LiquA joined their forces exclusively to provide door to door service to the customers worldwide.

R-Flex 40f 40ft is an easy and cost effective way of transporting bulk commodities. A safe flexitank design for 40ft Reefer Containers. It is the one and ONLY Monobloc (one piece) flexitank with anti – wave technology that stabilizes the liquid. R-Flex 40ft does NOT allow liquid to generate any hydro dynamic forces/sloshing.

What is is R-Fle lex 40ft ft?…

What is is R-Fle lex 40ft ft?…

Wave breakers integrated in the R-Flex design minimizes the flow of the liquid within chambers to keep the hydro dynamic energy and surge at minimum level.

How sa safe is is R-Flex 40ft?…

Tested and certified by Dekra Germany according to European Norm EN12642 & Railroad Impact Tested and Certified by TTCI, USA & Fully compliant with USDOT road and rail requirements

R-Fl Flex, Easy Easy Fl Flexi exitank for for 20ft ft re reefer con

• ntain

iners is a harnessed design that, thanks to its anti- wave technology, does not require any bulkhead and does not exert any pressure to the side walls of the containers. R-flex, stabilizes the liquid and does NOT allow liquid to generate any hydro dynamic forces/sloshing.

What is is R-Fle lex 20ft ft?…

What is is R-Fle lex 20ft ft?…

It is made out of two tanks standing on each other and incorporated with 6 big interconnections.

How sa safe is is R-Flex 20ft?…

Railroad Impact Tested in USA according to both AAR and PAS 1008:2016 Approved by Container Owners Association Approved by All Major Shipping Lines Approved by Railroads in USA and Russia

Reefer Trucks / Trailers

15

What is is R-Fle lex Tru ruck?…

R-Flex Truck is basically «T-Flex flexitank for trucks» applied in reefer trucks.

Features & & Advantages…

• The first and only Monobloc (one

piece) flexitank available for 40’ reefer containers.

• No need to go inside the

container to load or discharge, in line with health and safety standards.

• Patented robust wave breaking

designs providing a stabilized journey.

• No pressure on the side walls.
• Anti-wave feature.
• High chilled air circulation.
• Up to 22,000lt capacity in 20ft

and 24,000lt capacity in 40ft.

Features & & Advantages…

• Direct filling from stevedore tanks into R-Flex 40ft. No Re-loading.
• Less packaging tara, more cargo…



Up to

11% 11%

(21 2100kg) more cargo in a container compared to metal drums.



Up to

3.5 .5% (70

700kg) more cargo in a container compared to plastic drums.



Up to

6% 6% (12

1250kg) more cargo in a container compared to IBCs.

• No inventory for empty packaging (Drums/Bins/IBCs)
• Extreme labor cost saving from packaging, filling, handling, empty packaging storage.
• Capital saving from packaging.
• Less loading time.

• Single use hygienic transportation, eliminating contamination risk.
• Production in clean room under FSCC 22000 Food Safety System.
• Positive air pressure condition in the clean room with capability of less

than 0.54mg particle per m3.

• Food approved raw materials according to Regulation (EU) 10/2011.
• 15kGy Gamma Irradiation.
• Dairy connection, thermo plastic valve for aseptic loading & discharge.
• EVOH Oxygen barrier.

Aseptic Flexitank.. ...

18

Aseptic Flexitank.. ...

19

3’’ Dairy connection EN 11851

What is is Gamma Ir Irradiation…

Sterilization with gamma rays is one of the most reliable, effective and common alternative sterilization methods used

• today. Irradiation facility makes use of

gamma rays released from Co-60 source. Gamma rays are ionizing rays. Ionizing rays can remove electrons from the atoms when they react with

• substances. This process is called “ionization”. Free electrons can participate

in chemical reactions or detach DNA molecules from living organisms. This reaction is the basis of terminating microorganisms such as bacteria, parasites, mold, yeasts or fungus. Gamma rays are electromagnetic energy just like radio, TV waves or microwaves, visible lights or x-rays.

Gamma Ir Irradiation Features…

• It is an ionizing ray. It can remove electrons from the atoms or molecules when it

penetrates through a substance. That causes charged particles called "ions".

• Its penetration capacity to materials is high because it is more energetic than
• ther types of rays.
• It is on the shortest wave length of the electromagnetic spectrum and the highest

energy level.

• Gamma rays don’t have any mass or charge and they travel with light speed.

The QR Code application is another innovative initiative by LiquA that

• perators can use through their smart phones.

Our QR code application is specially developed for;

• Guiding Liqua flexitank fitting operations
• Getting instant information about your flexitank fittings
• Ensuring that the operators follow all the instructions in order to complete

insurance procedures.

22

QR Code Application…

LiquA flexitank boxes have QR Codes on all labels. Scanning the QR Code diverts the user to the LiquA site.

Through the serial number of the flexitank, LiquA provides up to date written and video manuals for the specific product.

23

QR Code Application…

Photographs showing the condition of the container and fitting operation must be uploaded to our server prior to the flexitank filling.

Give it a try…

Download a free QR Code reader to your smart phone and give it a try with the QR Code on the right… Username : demo Password : demo We recommend the below applications as QR Code readers

As being a flexitank and container liner manufacturer, the dynamics of the industry led us to the expected conclusion for customer satisfaction. Liqua Logistics… We aim to integrate secure transportation with custom made packaging under one roof. Through the joint work of extensive network of agents/distributers and the logistics partners, Liqua provides door to door service. Depending on the conditions of the route, geography and the qualities of the cargo, Liqua team;

25

Designs the right packaging Determines the right mode of transportation Organizes just in time delivery

Network…

Thank You…

26
