Flexible Networking at Large Mega-Scale

Exploring issues and solutions

What is “Mega-Scale”?

One or more of:

• > 10,000 compute nodes
• > 100,000 IP addresses
• > 1 Tb/s aggregate bandwidth
• Massive East/West traffic between tenants

Yahoo is “Mega-Scale”

What are our goals?

• Mega-Scale, with

○ Reliability

■ Yahoo supports ~200 million users/day -- it must be reliable

○ Flexibility

■ Yahoo has 100s of internal and user-facing services

○ Simplicity

■ Undue complexity is the enemy of scale!

Our Strategy

Leverage high-performance network design with:

➢ OpenStack ➢ Augmented with additional automation ➢ Hosting applications designed to be “disposable”

• Fortunately, we already had many of the needed pieces

Traditional network design

• Large layer 2 domains
• Cheap to build and manage
• Allows great flexibility of solutions
• Leverage pre-existing network design
• IP mobility across the entire domain

It’s Simple. But...

L2 Networks Have Limits

• The L2 Domain can only be extended so far

○ Hardware TCAM limitations (size and update rate) ○ STP scaling/stability issues

• But an L3 network can

○ scale larger ○ at less cost ○ but limits flexibility

Potential Solutions

• Why not use a Software Defined Network?

○ Overlay allows IP mobility but

■ Control plane limits scale and reliability ■ Overhead at on-ramp boundaries ○ OpenFlow-based solutions ■ Not ready for mega-scale yet w/ L3 support ■ Control plane complexities

Not Ready for Mega-Scale

Our Solution

• Use Clos design network backplane
• Each cabinet has a Top-Of-Rack router

○ Cabinet is a separate L2 domain ○ Cabinets “own” one or more subnets (CIDRs) ○ OpenStack is patched to “know” which subnet to use

• Network backplane supports East-West and North-

South traffic equally Well

• Structure is ideal if we decide to deploy SDN overlay

A solution for scale: Layer 3 to the rack

Compute Racks

L2 L3

Compute + Admin

Admin= API, DB, MQ, etc

...

• Clos-based L3 network
• TOR (Top Of Rack) routers

Adding Robustness With Availability Zones

Problems

• No IP Mobility Between Cabinets

○ Moving a VM between cabinets requires a re-IP ○ Many small subnets rather than one or more large

• nes

○ Scheduling complexities: ■ Availability zones, rack-awareness

• Other issues

○ Coordination between clusters ○ Integration with existing infrastructure

You call that “flexible?”

(re-)Adding Flexibility

• Leverage Load Balancing

○ Allows VMs to be added and removed

(remember, our VMs are mostly “disposable”)

○ Conceals IP changes (such as rack/rack movement) ○ Facilitates high-availability ○ Is the key to flexibility in what would otherwise be a constrained architecture

(re-)Adding Flexibility (cont’d)

• Automate it:

○ Load Balancer Management ■ Device selection based on capacity & quotas ■ Association between service groups and VIPs ■ Assignment of VMs to VIPs ○ Availability Zone selection & balancing ○ Multiple cluster integration

• Implement “Service Groups”

○ (external to OpenStack -- for now)

Service Groups

• Consists of groups of VMs running the same

application

• Can be a layer of an application stack, an

implementation of an internal service, or a user-facing server

• Present an API that functions behind a VIP

○ Web services everywhere!

Service Group Creation

Integrating With Openstack

Putting It Together

• Registration of hosts and services

○ A VM is associated with a service group at creation ○ A tag associated with the service group is accessible to resource allocation

• Control of load balancers

○ Allocates and controls hardware ○ Manages VMs for each service group ○ Provides elasticity and robustness

Putting It Together (cont’d)

• OpenStack Extensions and Patches

○ Three points of integration:

• 1. Intercept request before issue
• 2a. Select network based on hypervisor
• 2b. Transmit new instance information to external automation
• 3. Transmit deleted instance information to external automation

Wither OpenStack?

• Our Goals:

○ Minimize patching code ○ Minimize points of integration with external systems ○ Contribute back patches of general use ○ Replace custom code with community code: ■ Use Heat for automation ■ Use LBaaS to control load balancers ○ Share our experiences

Complications

• OpenStack clusters don’t exist in a vacuum
• - this makes scaling them harder

○ Existing physical infrastructure ○ Existing management infrastructure ○ Interaction with off-cluster resources ○ Security and organizational policies ○ Requirements of existing software stack ○ Stateful application introduce complexities

Conclusion

• Mega-Scale has unique issues

○ Many potential solutions don’t scale sufficiently ○ Some flexibility must be sacrificed

*BUT*

○ Mega-Scale also admits solutions that aren’t practical or cost-effective at smaller scale ○ Automation and integration with external infrastructure is key

Questions

?

email: edhall@yahoo-inc.com
