Flexible Cache Error Protection using an ECC FIFO Doe Hyun Yoon and - - PowerPoint PPT Presentation

SC’09

Flexible Cache Error Protection using an ECC FIFO

Doe Hyun Yoon and Mattan Erez

• Dept. Electrical and Computer Engineering

The University of Texas at Austin

1

SC’09

ECC FIFO

• Goal: to reduce on-chip ECC overhead

– Two-tiered error protection

• T1EC: light-weight on-chip error code
• T2EC: strong error correcting code

– Off-load T2EC overhead to FIFO in DRAM

• Why FIFO? It’s simple to manage
• 15-25% LLC area reduction
• 10-17% LLC power saving
• Just 1% performance penalty

2

SC’09

BACKGROUND

3

SC’09

Error Correcting Codes

• 1-bit parity for error detection
• SEC-DED (Hamming) codes

– Single-bit Error Correction and Double-bit Error Detection – 8bit ECC for 64bit data

• DEC-TED

– Double-bit Error Correction and Triple-bit Error Detection – 15bit ECC for 64bit data

4

SC’09

Interleaving

• To detect and correct burst errors

– N-way interleaving converts an N-bit burst error to N single-bit errors

5

. . . … … … N

Error code 0

2N 1 N+1 2N+1

Error code 1

2 N+2 2N+2

Error code 2

N-1 2N-1

Error code N-1

SC’09

Interleaving

• To detect and correct burst errors

– N-way interleaving converts an N-bit burst error to N single-bit errors

6

. . . . . . … … … N

Error code 0

2N 1 N+1 2N+1

Error code 1

2 N+2 2N+2

Error code 2

N-1 2N-1

Error code N-1

SC’09

Interleaving

• To detect and correct burst errors

– N-way interleaving converts an N-bit burst error to N single-bit errors

• Baseline cache error protection

– 8 way interleaved SEC-DED

• Can correct up to 8-bit burst errors
• 8B ECC per 64B cache line

7

SC’09

Uniform Error Protection

8

. . .

. . . . . . . . . Data ECC ... ... 211 sets 8 ways 64B 8B . . . Tag

ECC increases area AND leakage/dynamic power

SC’09

RELATED WORK

9

SC’09

Soft Errors: Observations

• Still, Soft Error Rate (SER) is low

– Every cache access tries to detect errors, but finds no error in most cases

• Error Detection – Common case

– Need a low cost, low overhead error detection mechanism

• Error Correction – Uncommon case

– Correction can be slow – But, still need to maintain error correction info somewhere

• Memory hierarchy provides redundancy

inherently for clean data

– Only dirty lines need error correcting codes

10

SC’09

PERC [Sorin’06] / Energy Efficient [Li’04]

11

. . .

... 211 sets 8 ways . . . Tag . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Data EDC ... 64B 1B . . . . . . . . . 7B ECC

Read only Data and EDC – saves dynamic power Power gate ECC of clean lines – saves static power

SC’09

Area Efficient [Kim’06]

12

212 sets 4 ways . . . Tag

. . . . . . . . .

. . . . . . Data EDC . . . ECC 212 sets 64B 1B 8B

Allow only 1 dirty line per set

SC’09

MAXn scheme

13

. . .

... 211 sets 8 ways . . . Tag

. . .

. . . . . .

. . . . . . . . .

. . . . . . Data EDC ... . . . ECC 211 sets n ways ... 64B 1B 8B (n<8)

. . .

. . . ... Tag

Allow only n dirty lines per set May cause detrimental cleaning traffic

SC’09

Two-tiered error protection

• Tier-1 Error Code (T1EC)

– On-chip light-weight error code – Uniform error protection

• Tier-2 Error Code (T2EC)

– Strong error codes only for dirty lines – Corrects Detected but Uncorrected Errors (DUE)

• f T1EC

14

SC’09

Memory Mapped ECC [Yoon’09]

15

. . .

... 8 ways . . . Tag . . . . . .

. . . . . . . . . . . . . . . . . .

Data ... 64B . . . . . . . . . 1B 8B ... T1EC T2EC On-Chip DRAM 211 sets

T2EC is memory mapped AND cached

SC’09

ECC FIFO

16

SC’09

ECC FIFO

• Use Two-tiered error protection
• T2EC is off-loaded to FIFO in DRAM

– LLC caching behavior is unaffected

• FIFO

– Simple to manage

• Coalesce buffer

– To better utilize DRAM channel

17

SC’09 18

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . . . . . . . . . . . . . .

. . . T2EC encoder Coalesce Buffer

SC’09 19

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . . . . . . . . . . . . . .

. . . T2EC encoder Dirty line eviction to LLC Coalesce Buffer

SC’09 20

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . . . . . . . . . . . . . .

. . . T2EC encoder TAG T2EC Encode T2EC and TAG Coalesce Buffer

SC’09 21

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . . . . . . . . . . . . . .

. . . T2EC encoder TAG T2EC Push to Coalesce Buffer Coalesce Buffer

SC’09 22

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . . . . . . . . . . . . . .

. . . T2EC encoder TAG T2EC Next dirty line comes TAG T2EC Tag/T2EC buffered in Coalesce Buffer Coalesce Buffer

SC’09 23

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . .

. . . T2EC encoder TAG T2EC TAG T2EC Coalesce Buffer is now FULL TAG T2EC TAG T2EC TAG T2EC TAG T2EC

. . . . . . . . . . . .

Coalesce Buffer

SC’09 24

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . .

. . . T2EC encoder Coalesce Buffer TAG T2EC TAG T2EC Write the coalesced T2EC into ECC FIFO TAG T2EC TAG T2EC TAG T2EC TAG T2EC

. . . . . . . . . . . .

T2EC T2EC write size matches to DRAM burst size

SC’09 25

Last Level Cache DRAM Rest of cache hierarchy

. . .

ECC FIFO . . . Data T1EC

. . . . . .

. . . T2EC encoder Coalesce Buffer

. . . . . . . . . . . .

T2EC Coalesce Buffer becomes empty

SC’09

More on ECC FIFO

• Write-back data, but write-through ECC
• Potential performance degradation

– Increased DRAM traffic due to T2EC writes

• Error correction

– Search the matching TAG in coalesce buffer AND ECC FIFO

• May take a long time

– Not a problem since SER is low

• Sometimes, may not find the matching TAG

– ECC FIFO is finite – Potentially unprotected dirty lines – discussed later

26

SC’09

EVALUATION

27

SC’09

Performance Evaluation

• GEMS + DRAMsim

– An out-of-order SPARC V9 core – Exclusive two-level cache hierarchy – DDR2 667MHz – 5.33GB/s – Eager write-back

• Clean dirty lines periodically
• Workloads

– 16 data intensive applications – SPEC CPU 2006, PARSEC, and SPLASH2

28

SC’09

Performance Penalty

29 0.9 0.95 1 1.05 1.1 CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006 Normalized Execution Time

1.2% 6.0% DRAM – 5.33 GB/s

SC’09

Performance Penalty

30 0.9 0.95 1 1.05 1.1 CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006 Normalized Execution Time

DRAM – 2.67 GB/s 2.3% 6.3% 6.8%

0.9 0.95 1 1.05 1.1 CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006 Normalized Execution Time

1.2% 6.0% DRAM – 5.33 GB/s

SC’09

Comparison to MAXn and MME

31

0.9 1 1.1 1.2 1.3 1.4

CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006

Normalized Execution Time

Max1 Max2 Max4 MME ECC FIFO

1%

SC’09

Comparison to MAXn and MME

32

0.9 1 1.1 1.2 1.3 1.4

CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006

Normalized Execution Time

Max1 Max2 Max4 MME ECC FIFO

1%

SC’09

Comparison to MAXn and MME

33

0.9 1 1.1 1.2 1.3 1.4

CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006

Normalized Execution Time

Max1 Max2 Max4 MME ECC FIFO

1%

SC’09

Comparison to MAXn and MME

34

0.9 1 1.1 1.2 1.3 1.4

CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006

Normalized Execution Time

Max1 Max2 Max4 MME ECC FIFO

4% 1%

SC’09

Comparison to MAXn and MME

35

0.9 1 1.1 1.2 1.3 1.4

CHOLESKY FFT OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

milc lbm sphinx3 Average SPLASH2 PARSEC SPEC2006

Normalized Execution Time

Max1 Max2 Max4 MME ECC FIFO

8% 11% 23% 36% 11% 4% 1%

SC’09

Comparison to MME

36

1.40E+09 1.60E+09 1.80E+09 2.00E+09 2.20E+09 2.40E+09 2.60E+09 256KB 512KB 1MB 2MB

Execution Time [cycle]

LLC size

Baseline MME ECC FIFO

OCEAN 258x258

10.4%

SC’09

LLC Area and Power

• CACTI 5 model of a 45nm process
• Parity T1EC + SEC-DED T2EC

– 15% area and 9% power saving

• Compared to SEC-DED baseline
• SEC-DED T1EC + DEC-TED T2EC

– 15% area and 10% power saving

• Compared to DEC-TED baseline
• More error code examples in the paper

37

SC’09

FIFO OVERWRITE

38

SC’09

ECC FIFO is Finite

• ECC FIFO is implemented

as a circular buffer

– Each T2EC push overwrites the oldest entry in the FIFO

• If the associated data is still valid

even after T2EC is overwritten

– The cache line is no longer protected – Errors on this line cannot be corrected using T2EC

39

SC’09

40

ECC FIFO LLC t . . .

A small LLC and an ECC FIFO with k entries (no coalesce buffer for the simplicity)

k

SC’09

41

. . . dirty line eviction to LLC TAG/T2EC to ECC FIFO ECC FIFO LLC t k

SC’09

42 1 1

1 ECC FIFO LLC t k dirty line eviction to LLC TAG/T2EC to ECC FIFO . . .

SC’09

. . .

43 1 1 2 2

1 2 ECC FIFO LLC t k dirty line eviction to LLC TAG/T2EC to ECC FIFO

SC’09

. . .

44 1 1 2 3 4 k-1 k-1 k-2 k-3 k-2 k-3

1 2 … k-3 k-2 k-1 ECC FIFO LLC t k

SC’09

. . .

45 1 1 2 3 4 k-1 k-1 k-2 k-2 k-3 k 3 k

T2EC 0 is evicted from the FIFO dirty line 0 is no longer protected

ECC FIFO LLC t k dirty line eviction to LLC TAG/T2EC to ECC FIFO 1 2 k-3 k-2 k-1 k …

SC’09 46

1 2 k-3 k-2 k-1 k t T2EC overwrite-time T2EC valid-time

T2EC valid-time > T2EC overwrite-time The cache line becomes T2EC unprotected

Window of vulnerability

Reuse or evict

…

SC’09 47

t T2EC overwrite-time T2EC valid-time

T2EC valid-time < T2EC overwrite-time No window of vulnerability

1 2 k-3 k-2 k-1 k t T2EC overwrite-time T2EC valid-time

T2EC valid-time > T2EC overwrite-time The cache line becomes T2EC unprotected

Window of vulnerability

Reuse or evict Reuse or evict

1 2 k-3 k-2 k-1 k … …

SC’09

How to Avoid (or Mitigate) It?

• T2EC overwrite-time

– Make the FIFO bigger

• The bigger the FIFO, the longer T2EC lifetime
• Not sure how big it has to be
• T2EC valid-time

– Inherent memory access pattern

• A dirty line is re-used or evicted
• Make the T2EC obsolete before it gets overwritten

– Eager write-back

• Limit the lifetime of dirty lines

48

SC’09

Eager Write-Back

• Scan LLC lines periodically

– Eagerly write-back dirty lines

• lder than the period
• It’s cleaning, so it doesn’t affect hit-rate
• 1M cycle period

– Limit the T2EC valid-time (max: 2xEWB period)

• More T2ECs become obsolete

before it gets overwritten

• Eager write-back improves performance

– 6-10% in general, 26% in libquantum

49

SC’09

1.00E-10 1.00E-09 1.00E-08 1.00E-07 1.00E-06 1.00E-05 1.00E-04 1.00E-03 1.00E-02 1.00E-01 1.00E+00 20 40 60 80 100

Probability of T2EC unprotected FIFO size [thousand entries]

FFT CHOLESKY OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

lbm milc sphinx3

SC’09

1.00E-10 1.00E-09 1.00E-08 1.00E-07 1.00E-06 1.00E-05 1.00E-04 1.00E-03 1.00E-02 1.00E-01 1.00E+00 20 40 60 80 100

Probability of T2EC unprotected FIFO size [thousand entries]

FFT CHOLESKY OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

lbm milc sphinx3

SC’09

1.00E-10 1.00E-09 1.00E-08 1.00E-07 1.00E-06 1.00E-05 1.00E-04 1.00E-03 1.00E-02 1.00E-01 1.00E+00 20 40 60 80 100

Probability of T2EC unprotected FIFO size [thousand entries]

FFT CHOLESKY OCEAN RADIX canneal dedup fluidanimate freqmine bzip2 mcf hmmer libquantum

• mnetpp

lbm milc sphinx3

SC’09

Required FIFO size

• 100k entry FIFO, the worst case

– 1MB of storage in DRAM

• More in the paper

– A simple analytic model on Probability of unprotected – Required FIFO size with regards to eager write-back period – how to guarantee zero probability of unprotected

53

SC’09

Conclusion

• ECC FIFO is an efficient low cost

error protection mechanism

– A simple FIFO off-loads the overhead of strong T2EC

• 15-25% LLC area reduction
• 10-17% LLC power saving

– Does not affect LLC caching behavior – Choosing error code for T1EC/T2EC is flexible

• See more error code examples in the paper
• Penalties

– Average 1% performance degradation – negligible – Increased error correction latency – but SER is low – Potentially unprotected cache lines

• Can make this quite low or even guarantee not to occur

54

SC’09

Flexible Cache Error Protection using an ECC FIFO

Doe Hyun Yoon and Mattan Erez

• Dept. Electrical and Computer Engineering

The University of Texas at Austin

55
