Flatbed applicator Developed, produced and tested on a real time advertising production Creation We operate since 2004 as an advertising production The Vroller was born. Creating wide format prints and printing house Vipline. every day, we

SLIDE 1

Developed, produced and tested

n a real time advertising production

Flatbed applicator

SLIDE 2

We operate since 2004 as an advertising production and printing house Vipline. In 2009 we understood existing machines don’t fulfill our needs, so we decided to create our own flatbed applicator.

Creation

The Vroller was born. Creating wide format prints every day, we know from inside of the business what applicator must have to operate simply, productively and last long. Before each new model comes out, we test it on our advertising production. Also, every day we use our machines in daily work to be sure that clients are getting high quality product. As a result we have created robust and functional machines for multi shift work. All components are made in EU either by us or purchased from well known world brands. Schaeffler Germany (INA, LuK and FAG brands) is doing the linear rail and SMC Pneumatics Japan is making pneumatics. Detailed info www.vroller.eu Vipline printing house www.vipline.ee

SLIDE 3

Pro Series

Extra precise real-time roll pressure display System pressure control Pneumatica made by SMC Pneumatics Japan Table storage slots Side roll holders High-hardness tool steel Linear rail made by Schaeffler Germany (INA, LuK and FAG brands) Aluminium roll vulcanized with high-quality HD rubber 10mm thick, all rolls are 140mm in diameter HD rubber mat LED-illuminated working area Tempered glass table or HDF board

SLIDE 4

High-hardness tool steel

Regular Series

System pressure control HD rubber mat LED-illuminated working area Tempered glass table or HDF board Linear rail made by Schaeffler Germany (INA, LuK and FAG brands) Pneumatica made by SMC Pneumatics Japan Aluminium roll vulcanized with high-quality HD rubber 10mm thick, all rolls are 140mm in diameter Side roll holders

SLIDE 5

Base model options

Vroller high-hardness tool steel frame with robust metal coating HD rubber mat HDF white table System pressure control

SLIDE 6

Base model options

Carriage with roll Side roll holders Pneumatics made by SMC Pneumatics Japan Linear rail made by Schaeffler Germany (INA, LuK and FAG brands)

SLIDE 7

Additional options

Glass table Table roll unwinder Table LED illumination Extra precise real-time roll pressure display

SLIDE 8

Additional options

Table storage slots Silent 45db air compressor Standard 85db air compressor Carriage roll holder Second roll carriage

SLIDE 9

Base models and prices

All applicators fully made, tested and assembled in Estonia (EU) Corresponding to standards EVS-EN 60598, EVS-EN 55015

700S 1200S 1500M 1700M 1700L 1700XL 2200M 2200XL 700x2000 1200x2000 1500x3300 1700x3300 1700x3700 1700x6000 2200x3300 2200x6000 Table Size (mm) Model

PRO Series

640x1750 1140x1750 1440x3050 1640x3050 1640x3500 1640x5750 2140x3300 2140x5750 Work Area (mm) 640 1140 1440 1640 1640 1640 2140 2140 Roll width (mm) 136 136 136 136 136 136 136 136 Electric Electric Electric Electric Electric Electric Electric Electric Roll Ø (mm) Valve 50/60 50/60 50/60 50/60 50/60 50/60 50/60 50/60 Work Height (mm) 150 250 450 520 590 850 750 990 Net Weight (kg) 5 900 6 900 7 900 8 500 8 900 12 500 13 500 14 900 Price (€) 1200SM 1500M 1700L 1200x2400 1500x3500 1700x3700 Table Size (mm) Model

REGULAR Series

1140x2000 1440x3100 1640x3300 Work Area (mm) 640 1140 1440 Roll width (mm) 116 116 116 Pneumatic Pneumatic Pneumatic Roll Ø (mm) Valve 50/60 50/60 50/60 Work Height (mm) 150 250 350 Net Weight (kg) 6 500 7 500 7 900 Price (€)

For extra information please contact your local distributor

r www.vroller.eu

export@vroller.eu +372 5822 7183 (24/7) Skype: elegantsolution ZBLP LTD., Tartu rd. 80J, 10112 Tallinn, Estonia

SLIDE 10

Additional options prices

All applicators fully made, tested and assembled in Estonia (EU) Corresponding to standards EVS-EN 60598, EVS-EN 55015 For extra information please contact your local distributor

r www.vroller.eu

export@vroller.eu +372 5822 7183 (24/7) Skype: elegantsolution ZBLP LTD., Tartu rd. 80J, 10112 Tallinn, Estonia

PRO Series

1200SM 1500M 1700L 1200x2400 1500x3500 1700x3700 Table Size (mm) Model

REGULAR Series

1140x2000 1440x3100 1640x3300 Work Area (mm) 300 450 850 Glass table (€) 700S 1200S 1500M 1700M 1700L 1700XL 2200M 2200XL 700x2000 1200x2000 1500x3300 1700x3300 1700x3700 1700x6000 2200x3300 2200x6000 Table Size (mm) Model 640x1750 1140x1750 1440x3050 1640x3050 1640x3500 1640x5750 2140x3300 2140x5750 Work Area (mm) 300 450 800 900 990 1 500 1 200 1 950 Glass table (€) 200 300 500 550 650 900 1 200 1 400 Table LED illumination (€) 300 500 650 Table LED illumination (€)

SLIDE 11

Additional options prices

All applicators fully made, tested and assembled in Estonia (EU) Corresponding to standards EVS-EN 60598, EVS-EN 55015

For all models

Carriage roll holder Table roll unwinder Extra precise real-time roll pressure display Table storage slots S, M models Table storage slots L, XL models Second roll carriage for 1500 models Second roll carriage for 1700 models Second roll carriage for 2200 models Vroller silent 45db air compressor Vroller standard 85db air compressor Option 250 290 390 350 490 3 900 4 300 4 900 1 650 750 Price (€)

For extra information please contact your local distributor

r www.vroller.eu

export@vroller.eu +372 5822 7183 (24/7) Skype: elegantsolution ZBLP LTD., Tartu rd. 80J, 10112 Tallinn, Estonia

SLIDE 12

Contact

For any questions please contact us anytime ZBLP LTD., Tartu rd. 80J, 10112 Tallinn, Estonia export@vroller.eu / +372 5822 7183 (24/7) Skype: elegantsolution www.vroller.eu / www.vipline.ee
