FIRST FLOOR PLAN ELEVATION A PORCH 18'-0"x5'-0" FIRST - - PDF document

STUDY

12'-0"x10'-0"

FOYER

5'-5"x10'-0"

GARAGE

21'-4"x22'-6"

LAU.

11'-0"x6'-10"

KITCHEN

11'-0"x12'-1"

DINING

12'-6"x14'-1"

FAMILY ROOM

17'-8"x15'-9" PWD.

PATIO/DECK

12'-0"x14'-0"

COATS COATS PANTRY

PORCH

18'-0"x5'-0"

FIRST FLOOR PLAN ELEVATION A

PORCH

18'-0"x5'-0"

FIRST FLOOR PLAN

• ELEVS. B, D

PORCH

18'-0"x5'-0"

FIRST FLOOR PLAN

• ELEV. C

FAMILY ROOM

17'-8"x15'-9"

• OPT. REAR FIREPLACE

W.I.C.

• OPT. BEDROOM 4

13'-0"x10'-0"

LOFT/ OWNER'S SUITE

15'-9"x15'-1"

W.I.C. BEDROOM 2

11'-0"x12'-0"

BEDROOM 3

12'-0"x12'-0"

LINEN

O. BATH B2

LINEN

W.I.C. W.I.C.

SECOND FLOOR PLAN ELEVATIONS A & B

W.I.C.

• OPT. BEDROOM 4

13'-0"x10'-0"

LOFT/

SECOND FLOOR PLAN

• ELEV. D

W.I.C.

• OPT. BEDROOM 4

13'-0"x10'-0"

LOFT/

SECOND FLOOR PLAN

• ELEV. C

DINING

12'-6"x14'-1"

• COV. PORCH

14'-0"x12'-0"

FLOOR PLAN REAR ELEVATION LEFT ELEVATION RIGHT ELEVATION

DINING

12'-6"x14'-1"

SCREEN PORCH

14'-0"x12'-0"

FLOOR PLAN REAR ELEVATION LEFT ELEVATION RIGHT ELEVATION

KITCHEN

11'-0"x12'-1"

DINING

12'-6"x14'-1"

PATIO/DECK

10'-0"x12'-0"

SUNROOM

13'-4"x9'-8"

SUNROOM

REAR ELEVATION LEFT ELEVATION RIGHT ELEVATION

FRONT ELEVATION A

FRONT ELEVATION B

FRONT ELEVATION B W/ BRICK

FRONT ELEVATION C

FRONT ELEVATION D

FRONT ELEVATION D W/ BRICK
