Fingerprint-based detection of DNS hijacks using RIPE Atlas MAPRG Meeting, IETF 99 20 th July 2017, Prague Pawe Foremski Maciej Andziski Farsight Security, Inc. NASK IITiS PAN DNS hijacks? DNS hijack: you think Google answers your

slide-1
SLIDE 1

Fingerprint-based detection

  • f DNS hijacks using RIPE Atlas

MAPRG Meeting, IETF 99

20th July 2017, Prague

Paweł Foremski

Farsight Security, Inc. IITiS PAN

Maciej Andziński

NASK

slide-2
SLIDE 2

DNS hijacks?

2

DNS hijack: you think Google answers your queries

slide-3
SLIDE 3

RIPE Atlas?

3

An Internet measurement platform, ~10,000 probes

slide-4
SLIDE 4

Research idea & goals

4

1. Send select DNS queries to the target IP

  • > RIPE Atlas

2. Rewrite replies as a feature vector

  • > fingerprinting

3. Check if the fingerprint matches the model

  • > detection
  • Target: Google DNS & OpenDNS (*)
  • How prevalent hijacking is - globally, per-country, per-AS?
  • Which are the most risky ASes?
  • What does it all mean to the Internet?
slide-5
SLIDE 5

Features

1. RIPE Atlas provides a restricted API for DNS queries

a. Allows specifying the target server & some query parameters b. Provides low-level access to DNS replies (wire format) c. Measures timing

2. CHAOS TXT queries

a. CH TXT hostname.bind -> e.g. “cdns011.ovh.net” or... “who know” b. CH TXT version.bind -> e.g. “dnsmasq-2.76” or... “[SECURED]” c. CH TXT id.server -> e.g. “unbound.t72.ru” or… “go away” (RFC 4892) d. For each reply, store: i. response time & size ii. DNS header flags & rcode iii. rdata of first answer

5

slide-6
SLIDE 6

Features #2

3. DNSSEC support (RFC4033 - RFC4035)

a. IN A dnssec-failed.org -> should fail b. IN DNSKEY pl. -> must not fail

4. IPv6 support

a. Query for a zone hosted on an IPv6-only auth NS b. IN AAAA ds.v6ns.test-ipv6.ams.vr.org -> should not fail

5. TCP support

a. IN A facebook.com / TCP -> should not fail

6. Replies to non-existent domains

a. IN A <timestamp>.<probe-id>.surely1does2not3exist4.com b. If successful, store IP, ASN, network name

7. Qname letter case (in-)sensitivity

a. IN A FaCeBoOk.cOm b. Should return the same letter case

6

slide-7
SLIDE 7

Features #3

8. Round-trip time

a. Measure the minimum ICMP ping RTT to the resolver

9. Traceroute

a. Send an ICMP traceroute to the resolver b. Filter out private IP addr space c. Store: hop count, ASPATH length, parameters of the exit AS (RTT, ASN, network)

10. Two independent “who am I?” services:

a. IN A whoami.akamai.com

b.

IN TXT test.ipv4.google-pdns-info.andzinski.pl c. An auth server that replies with the resolver IP address d. Store: returned IP address, it’s ASN and network name

7

slide-8
SLIDE 8

Measurements & tools

  • Run in June 2017 using 9,790 RIPE Atlas probes (3K ASes)

○ ...burned a few million RIPE Atlas credits - thanks Vesna & Stephen! ;-) ○ tools published at https://github.com/recdnsfp/measurements

○

parsers at https://github.com/recdnsfp/parsejson

  • Google (8.8.8.8)

○ Raw: https://github.com/recdnsfp/measurements/tree/master/datasets/google

○

Spreadsheet: https://goo.gl/LSXSjW

  • OpenDNS (208.67.222.222)

○ https://github.com/recdnsfp/measurements/tree/master/datasets/opendns

○

Spreadsheet: https://goo.gl/9MEhnx

8

slide-9
SLIDE 9

Measurements: Google Public DNS

9

Median: 17.8 msec

Latency (ICMP ping)

Median: 9 hops

Hop count (traceroute)

slide-10
SLIDE 10

Measurements: Cisco OpenDNS

10

Median: 22.6 msec

Latency (ICMP ping)

Median: 7 hops

Hop count (traceroute)

slide-11
SLIDE 11

Ground-truth

11

  • No way to obtain from network operators
  • Assume the most common fingerprint as “legitimate”
  • Assume some deviations in the fingerprint as “hijacked” (7 features)
  • ML classifier will use all of the features (40+)
slide-12
SLIDE 12

Machine Learning Classification

1. Randomly sample 50 “legitimate” vs. 50 “hijacked” probes

a. Randomly split into training/testing 30 times -> evaluate

2. Evaluate the classification performance:

12

Google OpenDNS

Accuracy %FP %FN Accuracy %FP %FN k-NN (n = 3) 78.11% 6.29% 15.60% 81.44% 0.60% 17.97% Decision Tree (CART) 92.82% 0.97% 6.22% 93.56% 1.14% 5.30% Random Forest (n = 10) 93.84% 0.00% 6.16% 93.50% 0.25% 6.25%

3. Classify the rest of data using Random Forest classifier

a. Implementation at https://github.com/recdnsfp/classify

slide-13
SLIDE 13

Results: Google DNS hijacks (120 = 1.54% globally)

13

slide-14
SLIDE 14

Results: Google DNS hijacks (%)

14

Madagascar Iraq Indonesia China

slide-15
SLIDE 15

Results: Google DNS hijacks (% for >10 probes)

15

Indonesia India Russia Canada Austria Norway

slide-16
SLIDE 16

Results: OpenDNS hijacks (94 = 1.22% globally)

16

slide-17
SLIDE 17

Results: OpenDNS hijacks (%)

17

Samoa Iraq Indonesia Mexico

slide-18
SLIDE 18

Results: OpenDNS hijacks (% for >10 probes)

18

Indonesia India Iran Canada Belgium Austria

slide-19
SLIDE 19

Results: Google hijacks per AS

19

# Network ASN Count % Total % in ASN 1 BRITISH_TELECOMMUNICATIONS_PLC AS2856 6 5.00% 8.96% 2 VODAFONE_ITALIA_SPA AS30722 5 4.17% 62.50% 3 COMCAST_CABLE_COMMUNICATIONS_LLC AS7922 4 3.33% 1.35% 4 LIBERTY_GLOBAL_OPERATIONS_BV AS6830 4 3.33% 1.63% 5 UNARTEL_SRO AS198977 4 3.33% 80.00% 6 PT_TELEKOMUNIKASI_INDONESIA AS17974 4 3.33% 80.00% 7 CLOSED_JOINT_STOCK_COMPANY_TRANSTELECOM AS47313 2 1.67% 100.00% 8 IRENALA AS37608 2 1.67% 100.00% 9 ABSOLIGHT AS29608 2 1.67% 100.00% 10 BREDBAND2_AB AS29518 2 1.67% 40.00% Other 85 70.83%

slide-20
SLIDE 20

# Network ASN Count % Total % in AS 1 BRITISH_TELECOMMUNICATIONS_PLC AS2856 6 6.38% 9.52% 2 VODAFONE_ITALIA_SPA AS30722 5 5.32% 62.50% 3 PT_TELEKOMUNIKASI_INDONESIA AS17974 4 4.26% 80.00% 4 COMCAST_CABLE_COMMUNICATIONS_LLC AS7922 3 3.19% 1.02% 5 LIBERTY_GLOBAL_OPERATIONS_BV AS6830 2 2.13% 0.82% 6 TELECOMMUNICATION_INFRASTRUCTURE_COMPANY AS48159 2 2.13% 100.00% 7 SKYLOGIC_SPA AS29286 2 2.13% 100.00% 8 FREE_SAS AS12322 2 2.13% 1.36% 9 JASA_TERPADU_TELEMATIKA_JASATEL AS9785 1 1.06% 100.00% 10 TOKYO_INSTITUTE_OF_TECHNOLOGY AS9367 1 1.06% 100.00% Other 66 70.21%

Results: OpenDNS hijacks per AS

20

slide-21
SLIDE 21

Results: Google vs OpenDNS

21

Google Public DNS Cisco OpenDNS

52

probes

26

probes

68

probes

slide-22
SLIDE 22

Results: the most risky ASes

22

1. Take probes with both Google & OpenDNS hijacked 2. Drop ASes with less than 3 probes with hijacked DNS Results: 1. AS 17974, Telkom Indonesia: 4 out of 6 2. AS 30722, Vodafone Italy: 5 out of 9 3. AS 2856, British Telecommunications: 5 out of 88

slide-23
SLIDE 23

Conclusions

  • DNS hijacking is a real thing happening on the Internet

○ We found several RIPE Atlas probes with hijacked DNS resolver (120/94) ○ Some countries have >25% chances of DNS being hijacked (>1% avg)

  • The risk does not necessarily come from a government

○ Some ASes seem to have a policy of DNS hijacking ○ Many hijacks in developed countries (e.g. US, UK, Italy)

○

Probably many motivations - not only “censorship”

  • No big difference for Google DNS vs. OpenDNS

○ Just switching the resolver IP will not help

  • The Internet absolutely needs more secure DNS

○ Hijacking opens endless possibilities for manipulation & surveillance ○ We need to secure the stub vs. recursive resolver path

23

slide-24
SLIDE 24

Future Work

  • IPv6
  • Better ground-truth method
  • Analyze data returned by hijacked resolvers
  • Publish a paper :)

24

slide-25
SLIDE 25

Thank You!

Acknowledgements & Thanks:

○ Mateusz Kaczanowski (Facebook) ○ Vesna Manojlovic (RIPE NCC) ○ Stephen D. Strowes (RIPE NCC) ○ RIPE NCC DNS Hackathon (2017)

25

Paweł Foremski

pjf@fsi.io @pforemski

Maciej Andziński

maciej.andzinski@nask.pl @MaciejAndzinski

https://github.com/recdnsfp

slide-26
SLIDE 26

26

Backup slides

slide-27
SLIDE 27

recdnsfp vs. fpdns

27

  • Uses all RIPE Atlas probes vs. a single machine
  • Uses Machine Learning vs. static rules
  • Targets recursive DNS servers only
  • Different purpose: detect hijacks vs. server software version
slide-28
SLIDE 28

Results: Google DNS hijacks (% for >20 probes)

28

Indonesia India Russia

slide-29
SLIDE 29

Results: OpenDNS hijacks (% for >20 probes)

29

Indonesia Iran India

slide-30
SLIDE 30

Measurements: default probe resolvers

30

# Network Count Percentage

1 GOOGLE 1,857 21.63% 2 OPENDNS 351 4.09% + DIRECT_MEDIA 31 0.36% 3 LIBERTY_GLOBAL_OPERATIONS 234 2.73% 4 DEUTSCHE_TELEKOM 222 2.59% 5 COMCAST_CABLE_COMMUNICATIONS 212 2.47% 6 ORANGE 147 1.71% 7 FREE_SAS 115 1.34% 8 XS4ALL_INTERNET_BV 65 0.76% 9 BRITISH_TELECOMMUNICATIONS_PLC 65 0.76% 10 MCI_COMMUNICATIONS 61 0.71% Other / N/A: 5,224 60.86%

Resolver network, as seen by whoami.akamai.com
