FileWall : Implementing File Access Policies Using Dynamic Access Context Stephen Smaldone, Aniruddha Bohra, and Liviu Iftode DiscoLab Department of Computer Science Rutgers University Workshop on Spontaneous Networking May 12, 2006
SLIDE 2
SLIDE 3
Workshop on Spontaneous Networking
Organization:
Too many files, directories, servers
Protection:
Left to the discretion of the owner
Dynamism:
Cannot be incorporated without file system extension
Administrator has little control over file access policies Administrator has little control over file access policies
SLIDE 4
Workshop on Spontaneous Networking
File names are powerful
Can be used to implement access policies
All file system access are performed through messages
Message transformations can be used to enforce policies File system state can be constructed using information contained in messages
SLIDE 5
Workshop on Spontaneous Networking
File names are powerful
Can be used to implement access policies
All file system access are performed through messages
Message transformations can be used to enforce policies File system state can be constructed using information contained in messages Access policies can be implemented by interposition and message transformation Access policies can be implemented by interposition and message transformation
SLIDE 6
Workshop on Spontaneous Networking
Interposes on the client- server path Stores network flow history Evaluates each message against the firewall policies Passes-through, drops, or transforms network packets
SLIDE 7
Workshop on Spontaneous Networking
Interposes on client-server path Stores file access history Evaluates each message against FileWall policies Transforms file system messages
SLIDE 8
Workshop on Spontaneous Networking
Interposes on client-server path Stores file access history Evaluates each message against FileWall policies Transforms file system messages FileWall constructs virtual namespaces using file system namespaces and access policies through message transformation FileWall constructs virtual namespaces using file system namespaces and access policies through message transformation
SLIDE 9
Workshop on Spontaneous Networking
Access control Quality of Service (QoS) File system organization Intrusion detection Information Lifecycle Management (ILM) Data transformations
SLIDE 10
Workshop on Spontaneous Networking
Motivation Design
Access Context FileWall Policies
Implementation Evaluation Related Work Conclusions
SLIDE 11
Workshop on Spontaneous Networking
Access history
Access statistics Sequence of accesses
Describes user behavior
Environment
Time, available disk space, CPU load, etc.
SLIDE 12
Workshop on Spontaneous Networking
Requirements
Compact representation Contain semantic information which describes user behavior Easy to understand and specify Soft state
SLIDE 13
Workshop on Spontaneous Networking
Node = file run
Groups of accesses performed by same application Open to close or approximate using clustered accesses
Attributes
File name Type of run (READ, WRITE, etc.) Operation count
Edge
Run started after and ended before parent
Depth-first traversal defines sequence of runs in an access tree
SLIDE 14
Workshop on Spontaneous Networking
Root
SLIDE 15
Workshop on Spontaneous Networking
Read 1
Root 1
SLIDE 16
Workshop on Spontaneous Networking
Read 1, Create/Delete 2
Root 1 2
SLIDE 17
Workshop on Spontaneous Networking
Read 1, Create/Delete 2, Read/Write 3
Root 1 2 3
SLIDE 18
Workshop on Spontaneous Networking
Read 1, Create/Delete 2, Read/Write 3, Write 1
Root 1 2 3 1
SLIDE 19
Workshop on Spontaneous Networking
Motivation Design
Access Context FileWall Policies
Implementation Evaluation Related Work Conclusions
SLIDE 20
Workshop on Spontaneous Networking
Transform messages (requests and replies)
Sequence of rules INPUT and OUTPUT
Use:
Access context File attributes contained in messages
SLIDE 21
Workshop on Spontaneous Networking
Policy: Show files accessed today For each client-visible file:
Access Time = TODAY
Transform directory listing messages
READDIR and READDIRPLUS
SLIDE 22
Workshop on Spontaneous Networking
Access Context Policies
FileWall
SLIDE 23
Workshop on Spontaneous Networking
Access Context Policies
M
READDIR
FileWall
SLIDE 24
Workshop on Spontaneous Networking
Access Context Policies
READDIR
FileWall
SLIDE 25
Workshop on Spontaneous Networking
Access Context Policies
READDIR
FileWall
SLIDE 26
Workshop on Spontaneous Networking
Access Context Policies
READDIR READDIRPLUS
FileWall
SLIDE 27
Workshop on Spontaneous Networking
Access Context Policies
READDIRPLUS
FileWall
SLIDE 28
Workshop on Spontaneous Networking
Access Context Policies
READDIRPLUS
FileWall
SLIDE 29
Workshop on Spontaneous Networking
Access Context Policies
READDIRPLUS
FileWall
SLIDE 30
Workshop on Spontaneous Networking
Access Context Policies
READDIRPLUS READDIR
FileWall
SLIDE 31
Workshop on Spontaneous Networking
INPUT Rule:
int fwin(rpc_msg request) { if (request.proc == READDIR) { request.proc = READDIRPLUS; return FORWARD; } }
OUTPUT Rule:
int fwout(rpc_msg reply) { if (reply.proc == READDIRPLUS) { FOREACH entp in reply { if (entp.atime == TODAY) copy_entry(resp_entp, entp) } reply.entries = res_entp; reply.proc = READDIR; return FORWARD; } }
Specified as C programs and compiled as loadable shared modules Specified as C programs and compiled as loadable shared modules
SLIDE 32
Workshop on Spontaneous Networking
Motivation Design
Access Context FileWall Policies
Implementation Evaluation Related Work Conclusions
SLIDE 33
Workshop on Spontaneous Networking
FileWall:
Click Modular Router NFS over UDP
SLIDE 34
Workshop on Spontaneous Networking
FileWall
Click Modular Router NFS over UDP
FileWall Client
SFS toolkit Session establishment Bootstrapping
Identify list of available file systems
SLIDE 35
Workshop on Spontaneous Networking
Motivation Design
Access Context FileWall Policies
Implementation Evaluation Related Work Conclusions
SLIDE 36
Workshop on Spontaneous Networking
SLIDE 37
Workshop on Spontaneous Networking
General purpose server
Email, user homes, web server Files mounted over NFS
Web servers are prone to flash crowds Current policies
Rate limit number of requests Disable web server
SLIDE 38
Workshop on Spontaneous Networking
Access context
Rate of sequential file reads, directory listings, etc.
Policy
Hide files with rate greater than a threshold Show files again when rate falls below threshold
Only the source of the flash crowd disappears from the namespace
SLIDE 39
Workshop on Spontaneous Networking
SLIDE 40
Workshop on Spontaneous Networking
Infokernel [Arpaci-Dusseau 03], firewall/NAT Access Context
Desktop search [Soules 03] File system prefetching [Amer 02, Lei 97] Enforcing enterprise-wide policies [He 05]
Semantic file systems [Sheldon 91, Pike 93, Neuman 92, Rao 93] Extensible file systems [Zadok 00, Tewari 05]
SLIDE 41
Workshop on Spontaneous Networking
User study
Real deployment Behavior models
SLIDE 42
Workshop on Spontaneous Networking
User study
Real deployment Behavior models
Policy language
Constraints Debugging and logging
SLIDE 43
Workshop on Spontaneous Networking
User study
Real deployment Behavior models
Policy language
Constraints Debugging and logging
Data transformations
Censorship Protocol translations
NFS -> CIFS Recipe-based file system (CASPER) IP -> RDMA
Video encoding Content adaptation
SLIDE 44
Workshop on Spontaneous Networking
Per-file access policies can be enforced using virtual namespaces
No client or server modification required Soft state maintenance required
SLIDE 45
Workshop on Spontaneous Networking
Per-file access policies can be enforced using virtual namespaces
No client or server modification required Soft state maintenance required
Provides administrators the ability to define a wide variety of access policies
Protect file systems Provide quality of service
SLIDE 46
SLIDE 47
Workshop on Spontaneous Networking
Dell Poweredge 2600 systems
Dual 2.4GHz Intel Xeon processors 1GB RAM 36GB 15000 RPM SCSI disk
Linux Gigabit Ethernet switch
