FDS-100 Fever Detection System

Optimal fever detection system to to prevent the spread of

  • f viruses(COVID-19, MERS, SARS etc.)

Ver 1.3

slide-2
SLIDE 2
  • 1. Necessities of Fever detection system for COVID-19

Efficiency Convenience Safety Technology

Real-time Fever Detection System for COVID-19 ➢ Reduce measurement time ➢ Reduce monitoring manpower ➢ Simultaneous monitoring is available ➢ Simple installation ➢ Simple monitoring ➢ Automatic warning alert ➢ Non-contact method → very small risk for a secondary infection ➢ Auto recording function ➢ Auto e-mail transmission function (Remote monitoring is available) ➢ Temperature history function ➢ Temperature display function

Ver 1.3

slide-3
SLIDE 3
  • 2. Features of Fever detection system for COVID-19

Thermometer Thermal Camera

Device Image Measurement type Manual Automatic Contact type Contact Non-contact Risk for a secondary infection High Very low Requirement of time Large Small Requirement of manpower Large(manual measurement) Small(automatic measurement) Simultaneous measurement Unavailable Available

Remote Monitoring

Unavailable (excluding wireless thermometer)

Available

[ Comparison of temperature measurement methods]

Ver 1.3

slide-4
SLIDE 4

Fever Detecton System for COVID-19

°, 50°)

  • 2. Features of Fever detection system for COVID-19

Ver 1.3

slide-5
SLIDE 5
  • 3. FDS-100 System Figuration

[System Configuration]

  • Thermal + Optical Camera
  • Tripod

+

  • Laptop /Desktop
  • CMSSoftware

Ver 1.3

slide-6
SLIDE 6
  • 4. Thermal Camera Features

Sensitivity (NETD) 50mK

  • Temp. Accuracy

± 0.5℃

  • Temp. Stability

< 0.5℃ Detector Type FPA,Uncooled Microbiometer Image Resolution 160 x 120 Frame Rate 9Hz Distance (Meter) 1 ~ 1.5M Field of View 56°(H) X 71°(V) Power & Interface IP Network Temp.Range 0℃ ~ 50℃ Dual Camera – Thermal + Optical

Ver 1.3

slide-7
SLIDE 7
  • 5. CMS Software

<Alert Line Blue: Lower than setting Temp.> <Alert Line Red: Higher than setting Temp.>

* Each channel can be selected by each display type

Ver 1.3

slide-8
SLIDE 8
  • 6. Features of CMS Software

Normal Temp. range setting Max / Min / Selected Temp. information display Digital image signal

[Setting display] [Rec. method and path setting]

Ver 1.3

slide-9
SLIDE 9

Real-time check by smart-phone and Web

#1 MIN N : 27 27 MAX: X:43 43 #2 MIN N : 27 27 MAX: X:43 43 #3 MIN N : 27 27 MAX: X:43 43

  • 2020/0

/02/29 18:20 Problem detected

  • 2020/0

/02/29 19:00 Problemdetected

Send E-mail when abnormal Temp.

TCP/IP Network

Send status to pre-set E-Mail Detect abnormal temp. Auto recording Event Control Check history by thumbnails Smart Phone / PC Web Observation

  • 6. Features of CMS Software

Ver 1.3

slide-10
SLIDE 10
  • 7. System Configuration

Local System Unit

Thermal Camera #1~#N Ethernet (TCP/IP)

Control Center

S/W Hub

Analysis and Monitoring Sever

TCP/IP Network

Power PLC (or level2)

Power

TCP/IP(FTP Cable)

Remark

Alert Event!!

Smart phone Smart Phone Event S/W Hub

Dual Camera Laptop CMSSoftware

Ethernet

Ver 1.3

slide-11
SLIDE 11
  • 8. Target Markets

Can be installed at any place where quarantine is necessary (Densely populated area such as school, army base, convention and concert hall /

  • r small businesses, private residences etc.)

Target Markets for FDS-100

+

  • 1. Airport
  • 2. Hospital
  • 4. Public Institution
  • 5. Building Entrance
  • 3. Terminal

Contact

Ver 1.3
