F- 35A Lightning II Australias Next Generation Air Combat Aircraft UNCLASSIFIED New Air Combat Capability Australian Business Defence Industry Unit Lunch Air Vice-Marshal Kym Osley Program Manager New Air Combat Capability February

SLIDE 1

UNCLASSIFIED New Air Combat Capability

F-35A ‘Lightning II’

Australia’s Next Generation Air Combat Aircraft

Air Vice-Marshal Kym Osley Program Manager New Air Combat Capability February 2013 Australian Business Defence Industry Unit Lunch

SLIDE 2

UNCLASSIFIED New Air Combat Capability

First Australian F-35As are being produced at this time

SLIDE 3

UNCLASSIFIED New Air Combat Capability

AU-1 is on the production line!

SLIDE 4

UNCLASSIFIED New Air Combat Capability

Short Take-Off Vertical Landing (STOVL) Carrier Variant (CV)

Lift Fan Roll Nozzle 3-Bearing Swivel Duct

Conventional Take-Off and Landing (CTOL)

F-35 Family of Aircraft

SLIDE 5

UNCLASSIFIED New Air Combat Capability

Ground Moving Target Missile Warning Electro-Optical Radar

Day Night

Multi-Spectral Sensors

Situational Awareness

SLIDE 6

UNCLASSIFIED New Air Combat Capability

All 8 non-US partners remain with the Program

– US – still after 2443 aircraft – Italians – first three aircraft LRIP 6 (2014), FACO by early 2013. Recently reduced to 90 total. – Dutch – first two aircraft 2012, then rest to start later in decade. – Norwegian Parliament agreed four aircraft – and brought forward buy – Turkey has agreed first two aircraft and confirmed 100 reqd. – UK – has first two and third soon. Back to STOVL – Canadians – 65 aircraft and . Need to extend CF-18

– Israel’s - 19 JSF (media reports of additional SQN) – Japan’s - confirmed order for 42 – first two to be delivered in around 2016 – South Korea - FX-III competition (60) – Singapore – very interested

JSF Partner/FMS Update

SLIDE 7

UNCLASSIFIED New Air Combat Capability

Air Force Annual Fighter Buy Fiscal Year

F-35A 50 100 150 200 250 300 350 400 80 83 86 89 92 95 98 1 4 7 10 F-15C/D F-15E F-16A/D F-117 FY80-90 average - 227

FY91-10 average - 25 A-10 F-22

USAF Fighter Procurement

SLIDE 8

UNCLASSIFIED New Air Combat Capability

F-35 to be Predominant Aircraft in USAF Combat Air Forces

Fiscal Year Fighter Inventory

11 13 15 17 19 21 23 25 27 29 31 33 35

F-35 F-22 F-15C F-16 F-15E A-10A

SLIDE 9

UNCLASSIFIED New Air Combat Capability

We are contractually committed to two and they will be

delivered in 2014-2015 in the United States for testing and training purposes.

We have previously announced a commitment to purchase

another 12 and that commitment will occur but it will occur two years after the previously anticipated timetable.

We remain committed to the Joint Strike Fighter project

Stephen Smith MP, Minister for Defence, 3rd May 2012

SLIDE 10

UNCLASSIFIED New Air Combat Capability

Will develop three options for consideration in the context
f the 2013-14 Budget
In the course of 2013, Government will make decisions

with respect to those various options.

Stephen Smith MP, Minister for Defence, 13th December 2012

SLIDE 11

UNCLASSIFIED New Air Combat Capability

Production – approx 3-4 months behind (mainly

due to recent strike)

Flight test – overall slightly ahead of schedule

(approx 35% complete for CTOL) – but CTOL slightly behind

Development Phase – still adequately funded
Software development – better – but some delay,

and migration of capability – Block 1 delivered – Block 2A – four months late – Block 3I – through dev flight test April 2015 – Block 3F – through dev flight test August 2017 – A developmental program and there is still risk in the software schedule

International JSF Program

SLIDE 12

UNCLASSIFIED New Air Combat Capability

1 2009 2 2010 3 2011 4 2012 5 2013 6 2014 7 2014 8 2015 9 2016 10 2017 11 2018 12 2019 13 2020 14 2021 Production LOT (LRIP) Number and Delivery Year

Affordability

SLIDE 13

UNCLASSIFIED New Air Combat Capability

F-35 Production Outlook

LRIP 1 LRIP 2 LRIP 3 LRIP 4 LRIP 5 LRIP 6 LRIP 7 LRIP 8 LRIP 9 LRIP 10 LRIP 11 Buy Year 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 Del Year (+2) 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 Total 2 12 17 32 32 36 37 54 85 124 139

Currently in build

SLIDE 14

UNCLASSIFIED New Air Combat Capability

50 100 150 200 250 300 350 Dec-06 Jun-07 Dec-07 Jun-08 Dec-08 Jun-09 Dec-09 Jun-10 Dec-10 Jun-11 Dec-11 Jun-12 Dec-12 Date US$M Miscellaneous Propulsion LM (LRIP) LM (SDD)

Total US$127M Total US$138M Total US$213M Total US$286M Total US$195M

Industry Participation

SLIDE 15

New Air Combat Capability

UNCLASSIFIED

Centre Fuselage Composites QuickStep Vertical Tails Marand, BAES & Quickstep Actuators (Landing Gear, Bay Doors & Utility) Goodrich Control Systems & Rosebank Engineering Handling Fixtures Varley, Broens Shipping Containers Trimcast Engine Trailer Marand Training Courseware Design Kellogg, Brown & Root Airframe & System Component Machining Lovitt, Ferra, Levett, Aerostaff & Production Parts Radar, TPS & EW Components Cablex, BAES, Micreo, Partech Systems & CSC Flares Chemring JSF Studies Calytrix, BAES & Marand Voice Recognition Software Adacel Airframe Design & Stress Analysis GKN & Vipac Weapon Adapters Ferra Composite Tooling Marand, Broens & Hofmann Metaltec Engine component Production Parts, Broens, Hofmann Metaltec & Levett Ejection seat wiring Cablex CNI Chassis TAE Engineering support - ITC Design Thales Corrosion Sensors BAES Aust

F-35 Australian Suppliers

as at August 2012

SLIDE 16

New Air Combat Capability

UNCLASSIFIED

Work is only won on ‘international best value’
JSF partners all manoeuvring for a good industry outcome
Reduced early production numbers (slip to right)
All companies cutting margins due Global Financial Crisis
Strong AUS dollar

Industry challenges

SLIDE 17

New Air Combat Capability

UNCLASSIFIED

Why Seek JSF Work?

Only the JSF Partner nations can bid for JSF work on the 3000

planned Partner aircraft

The work is very much high value added
L-M and other primes tend to provide access to training and

accreditation that allow companies to bid for other high tech work.

JSF – once at full production – will be a significant source of business

for involved industry

JSF sustainment offers some businesses ongoing opportunities for the

period out to 2040+

SLIDE 18

New Air Combat Capability

UNCLASSIFIED

JSF Industry – ‘Ferra’

“…The staff within the Defence Industry Innovation Centre were able to provide us with a detailed understanding…subsequently assisted Ferra Engineering to secure F35 Joint Strike Fighter adaptor contracts ….valued at approximately $340m…will ensure Ferra Engineering remains an active member

f the Australian Aerospace industry for many years to come.”
Queensland-based company
Making weapons adapters for F-35
But diversified into other military and commercial aerospace
Also renewable energy and medical devices

SLIDE 19

New Air Combat Capability

UNCLASSIFIED

JSF Industry – ‘Quickstep’

Quickstep recently won the 2011 Manufacturer of the Year (Manufacturer’s Monthly Magazine) as well as the Global Integration Award - “…Quickstep highlighted how Australian manufacturers can successfully compete against the best in the

world. As part of the F-35 program, Quickstep has successfully
vercome the many entry barriers faced by new participants in the

defence manufacturing sector, possibly the highest of any industry in the world….”

West Australia (soon NSW) based company
Making composite panels for F-35
Diversifying into other military aerospace (eg C-130J flaps)

SLIDE 20

New Air Combat Capability

UNCLASSIFIED

JSF Industry – ‘Marand’

On 3rd May 2012, Marand was awarded the prestigious Manufacturer of the Year award (Large Business). Marand is the inaugural winner of the award and was selected by industry experts against a criteria including export performance, enabling technologies utilised, innovation in manufacturing, quality management and sustainable practices amongst others.

Melbourne based company
Making engine trailers for F-35, and working with

BAES and Quickstep on 722 shipsets of F-35 vertical tails.

Diversified into rail, automotive, aerospace and

general engineering

SLIDE 21

UNCLASSIFIED New Air Combat Capability

FMS vs Partner

Bidding for the manufacture of parts for partner aircraft limited to

Partner nation industry

FMS can make parts for their own aircraft and other FMS customers
However, FMS can negotiate with US companies to get some of their

‘strategic’ business

Japan:

– They will have a FACO for their aircraft, and perhaps other FMS aircraft.

Israel:

– In media that Israel will make some wing sets on behalf of L-M

SLIDE 22

New Air Combat Capability

UNCLASSIFIED

How can NACC Help Industry?

Director JSF Industry Support Team – John Wilshire – Canberra - (02)

6144 1535 – Two staff members in the US

Establish contacts
Get you through the (right) door
Strong ‘customer’ voice to the US primes (L-M/P&W)

– Australian JSF Industry Group

Two types of work:

– Strategic – for Australian companies to lose – Global supply chain competitive

NACC Industry Support Program

SLIDE 23

New Air Combat Capability

UNCLASSIFIED

NACC Industry Support Program

Aim – provide Australian companies/research with seed

funding to develop new or improved capabilities to allow Australian industry to be more competitive. – Have a total of $8.2m in grants available. – Six grants to date

What grants are available:

– <$1m for improved technologies that offer savings to JSF supply chain. – <$250K to enhance a company’s competitiveness to win work. – <$300k for Australian research centres to do research that leads to improvements in the JSF supply chain.

SLIDE 24

UNCLASSIFIED New Air Combat Capability

Operating maintenance:

– Canopy – WLM – Battery – WLM – Wheels and Tyres – WLM – Support Equip – probably mainly local industry – Propulsion – WLM and TDL – possible regional repair centre in Australia – Pilot equip fitting facility – WLM – SOAP – WLM – Avionics test – probable at WLM – Gun - WLM

Contractor In-Country Support

SLIDE 25

UNCLASSIFIED New Air Combat Capability

Deeper maintenance:

– Scheduled and unscheduled DM - WLM – Modification incorporation – WLM – Phased inspection – WLM (TBA but could be 300 hrs) – LO acceptance test – GOCO – contractor and DSTO – LO paintshop – GOCO

Supply Chain

– Off base regional holdings – Potential on base contractor facility for on-delivery to SQNs

Training

– Turn-key contractor operation – excluding pilot flying instruction and maintenance of training jets. – Maintenance instruction contractor provided

Contractor support of ALIS hardware and software

support

Contractor In-Country Support

SLIDE 26
