Extending Rails: Understanding and Building Plugins

Clinton R. Nixon

Welcome!

Welcoming robin by Ian-S (http://flickr.com/photos/ian-s/2301022466/)

What are we going to talk about?

The short

• How plugins work with Ruby on Rails
• How to find and install plugins

The long

• Types of plugins
• How to build plugins

Ruby on Rails and plugins

History of plugins:

• Introduced with Rails 1.0 as a way to extract functionality
• Made it easy to distribute functionality
• In Rails 2.0, some core features were pulled into plugins and

some plugins pulled into core

• In Rails 2.1, gem dependencies introduced

Gem dependencies

Fulfills same role as a plugin

• Major disadvantage of plugins: no dependencies
• Your app can now depend on a gem
• That depends on other gems

Same techniques apply as a standard plugin

• Differences will be pointed out

Where do you find plugins?

Unfortunately, no simple answer

• Rails wiki
• Giant list of plugins
• Used by script/plugin
discover
• Lots of out of date information

Where do you find plugins?

My recommendations

• Agile Web Development
• Core Rails Plugins
• Technoweenie (Rick Olson)

How do you install plugins?

Install from a URL:

• script/plugin
install
http://example.com/

plugins/make_foo

• script/plugin
install
svn://code.mondu.org/

svn/atom_fu/trunk

• script/plugin
install
git://github.com/bnl/

acts_as_replicator.git

How do you install plugins?

Install by name:

• script/plugin
source
http://example.com/

plugins/

• script/plugin
install
make_foo

Plugin installation sources

See list of sources:

• script/plugin
sources

Remove source:

• script/plugin
unsource
http://example.com/

plugins/

Autodiscovering plugin sources

Scrape Rails wiki for sources:

• script/plugin
discover

vendor/plugins trivia

Plugins are installed, by default, in vendor/

• plugins. However:
• “plugins can be nested arbitrarily deep within an unspecified

number of intermediary directories” - railties/lib/ rails/plugin/locator.rb

• So, vendor/plugins/my_organization/acts_as/

acts_as_long_dir_name/ is fine.

Additional plugin paths

More plugin paths can be defined as configuration.plugin_paths
in
 environment.rb

• Overwrites default plugin paths

How do you install gem plugins?

Installing gem dependencies

• Add config.gem
'gemname' to environment.rb
• rake
gems:install makes sure gems are installed locally
• rake
gems:unpack puts gems in vendor/gems
• Even better: rake
gems:unpack:dependencies
• Recompilation: rake
gems:build

Questions

Baby monkey (http://flickr.com/photos/7971389@N03/504227772/)

What types of plugins are there?

• acts_as...
• ...fu
• controller and view helpers
• testing helpers
• resourceful plugins
• piggyback plugins

acts_as... plugins

Adds capabilities to ActiveRecord models

• acts_as_versioned
• acts_as_paranoid
• acts_as_state_machine
• acts_as_taggable_on

...fu plugins

Adds new controller capabilities and back-end processing

• attachment_fu
• GeoKit
• BackgrounDRb
• Active Merchant
• Exception Notification

Helper plugins

Automate frequently repeated or complicated tasks; some crossover with ...fu plugins

• will_paginate
• Stickies
• jRails
• ssl_requirement
• TinyMCE for Rails
• permalink_fu

Testing plugins

Adds capabilities to testing in Rails

• Shoulda
• Factory Girl
• Test::Spec on Rails
• RSpec on Rails

Resourceful plugins

Plugins which contain a mini-app

• Savage Beast
• Comatose
• RESTful Authentication
• Bloget
• Sandstone

Piggyback plugins

Plugins that alter the behavior of other plugins

• Also known as “evil twin plugin”
• Usually not published
• But increasingly found
• n GitHub

Questions

Shinji the Hedgehog by Narisa (http://flickr.com/photos/narisa/508277874/)

What are the parts of a plugin?

• README
• about.yml
• install.rb
• uninstall.rb
• init.rb
• lib/
• Rakefile
• tasks/
• generators/
• test/
• anything else you want to add

README and about.yml

about.yml:

author: Clinton R. Nixon summary: Adds ability to set foreign key constraints. description: "Adds ability to set foreign key constraints in the database through ActiveRecord migrations. Only works currently with MySQL, PostgreSQL, and SQLite." homepage: http://www.extendviget.com/ plugin: git://github.com/vigetlabs/foreign_key_migrations.git license: MIT version: 0.9 rails_version: 2.0+

You can see this information with: script/plugin
info
PLUGIN.

install.rb & uninstall.rb

Run automatically

• script/plugin
install
• script/plugin
uninstall

Usually contains code to display instructions

• r move files

Often not found

puts IO.read(File.join(File.dirname(__FILE__), 'README'))

init.rb

Always run at Rails startup Arbitrary Ruby code Usually injects plugin code

ActionView::Helpers::AssetTagHelper::JAVASCRIPT_DEFAULT_SOURCES = \ ['jquery','jquery-ui','jrails'] ActionView::Helpers::AssetTagHelper::reset_javascript_include_default require 'jrails'

lib/

Arbitrary Ruby code to be loaded

• models
• controllers
• modules

Added to require path Because of Rails’ autoloading, all properly named files here will be available without require statements

Rakefile and tasks/

Rakefile contains tasks internal to the plugin

• Only executed from plugin directory

tasks/ contains tasks external to the plugin

• Available throughout the Rails environment
• in .rake files

generators/

Contains new generators that can be run in Rails

• script/generate and script/destroy

Both generator definitions and generator assets Used to automate creation of models, controllers, views, migrations, and tests

test/

Tests for plugin

• rake
test:plugins
• rake
test:plugins
PLUGIN=plugin_name
• plugin Rakefile test task

Anything else you want to add

License files Further instructions Changelog Contribution guidelines Gemspecs Todo lists Asset files (JavaScript, images)

Questions

Baby Hippo by phalinn (http://flickr.com/photos/phalinn)

How do you create a plugin?

script/generate
plugin create

vendor/plugins/test_plugin/lib





create

vendor/plugins/test_plugin/tasks



create

vendor/plugins/test_plugin/test



create

vendor/plugins/test_plugin/README



create

vendor/plugins/test_plugin/MIT‐LICENSE



create

vendor/plugins/test_plugin/Rakefile



create

vendor/plugins/test_plugin/init.rb



create

vendor/plugins/test_plugin/install.rb



create

vendor/plugins/test_plugin/uninstall.rb



create

vendor/plugins/test_plugin/lib/test_plugin.rb



create

vendor/plugins/test_plugin/tasks/test_plugin_tasks.rake



create

vendor/plugins/test_plugin/test/test_plugin_test.rb

Plugins and metaprogramming

Modules

• include
• extend

alias_method and alias_method_chain

Using modules

Allows you to namespace your code

• Common idiom: YourName::YourPlugin::ModuleName

include
YourModule

• adds methods to class instances

extend
YourModule

• adds methods to class

Common module inclusion idiom

module YourName::YourPlugin::YourModule def self.included(base) base.extend ClassMethods end def foo ... end module ClassMethods def bar ... end end end User.send(:include, YourName::YourPlugin::YourModule) >> user = User.new >> user.foo >> User.bar

Aliasing methods

Hook onto any method using this technique

def awesome_find ...

• ld_find(params)

end alias_method :old_find, :find alias_method :find, :awesome_find

Kind of messy and unsustainable

alias_method_chain

def find_with_awesome(params) ... find_without_awesome(params) end alias_method_chain :find, :awesome # Equivalent to: # alias_method :find_without_awesome, :find # alias_method :find, :find_with_awesome

Multiple aliasing

class Finder def find puts "found" end def find_with_awesome puts "AWESOME" find_without_awesome end def find_with_humility find_without_humility puts "nothing, really" end alias_method :find_without_awesome, :find alias_method :find, :find_with_awesome alias_method :find_without_humility, :find alias_method :find, :find_with_humility end >>> Finder.new.find AWESOME found nothing, really

Multiple aliasing

class Finder def find puts "found" end def find_with_awesome puts "AWESOME" find_without_awesome end def find_with_humility find_without_humility puts "nothing, really" end alias_method_chain :find, :awesome alias_method_chain :find, :humility end >>> Finder.new.find AWESOME found nothing, really

Plugin initialization order

• Framework is initializated (This typo was too great to leave out)
• Environment is loaded
• Gem dependencies are loaded
• Plugins are loaded
• config/initializers/*.rb (application initializers)

loaded

• after_initialize callback executed
• Routes and observers loaded

Plugin best practices

• Namespace your code
• Enhance, not override
• Leave choices to plugin users
• Do as little as possible
• Don’t do anything unexpected

Questions

Chloe’s Baby #2 by mdprovost (http://flickr.com/photos/anderani/2617606614/)

How do you setup a plugin?

install.rb - on installation

• nly works when script/plugin
install used

init.rb - on application load

init.rb

Run every time the Rails environment is loaded

• script/server
• script/console
• script/runner

init.rb

For a small plugin, may be all you need Should kick off most of your metaprogramming Sometimes used to copy assets

• Don’t do this unless absolutely necessary

Should only do things you need to do every time your plugin is loaded

init.rb binding

def evaluate_init_rb(initializer) if has_init_file? silence_warnings do # Allow plugins to reference the current configuration object config = initializer.configuration eval(IO.read(init_path), binding, init_path) end end end

Gem plugins and init.rb

init.rb found under rails/ directory in a gem plugin lib/ still added to load path

How do you work with models?

New models dropped in lib/ will automatically get picked up and be accessible - but are not reloaded in development. Downside: user cannot easily extend model.

Model behavior in lib/

A solution:

• Put a module in lib/ to be included in a model class in

app/models/

We can get assistance from generators if we require a class for our plugin to work.

• Example: acts_as_taggable_on vs. Bloget

Single table inheritance as a solution

You can drop a model in lib/ intended to be inherited from.

• DB table will need a type column
• STI has its own downsides

Adding behavior to multiple models

To affect all models automatically, include code in ActiveRecord::Base.

• Not very common usage

Granting ability to add behavior

AKA acts_as... Include module in ActiveRecord::Base, but

• nly add one method to trigger behavior

module ActiveRecord::Acts::Versioned def self.included(base) base.extend ClassMethods end module ClassMethods def acts_as_versioned(options = {}, &extension) ... end end end ActiveRecord::Base.send :include, ActiveRecord::Acts::Versioned

acts_as_paranoid walkthrough

Baby croc by marcelgermain (http://flickr.com/photos/marcelgermain/1472148914/)

How do you work with controllers?

Like models, you can drop a controller in lib/ and it will work. Again, this has the drawback that the user cannot easily edit it. Wrapping behavior in a module and including it is smart. Inheritance also works well.

Classes involved with controllers

ActionController::Base and ActionView::Base are the two classes to change.

ActionController::Base.send(:include, Stickies::ControllerActions) ActionController::Base.send(:include, Stickies::AccessHelpers) ActionView::Base.send(:include, Stickies::AccessHelpers) ActionView::Base.send(:include, Stickies::RenderHelpers)

A better way to handle helpers

Since Rails 0.8.5, there’s been a better way to add helpers to controllers and views.

ActionController::Base.send(:include, Stickies::AccessHelpers) ActionController::Base.helper(Stickies::AccessHelpers) ActionController::Base.helper(Stickies::RenderHelpers)

Adding behavior to controllers

Included modules are the most common way to add controller behavior.

resource_this walkthrough

You can use a setup method to add parameters to your behavior, allowing for complex controller manipulation.

How do you work with views?

Working with views is much like working with controllers. Use ActionController::Base.helper to add new helpers.

Changing template root

class FooController < ActionController::Base self.template_root = \ File.join(File.dirname(__FILE__), '..', 'views') end

One problem with this: the controller will expect all views - including templates and partials - to be found under this directory.

Questions

Baby tiger (http://flickr.com/photos/modu_li/1788817738/)

How do you work with generators?

Generators can let you make models, controllers,

• r anything else to stick directly into the user’s

Rails app. Put assets and generation script in generators/.

Thanks to Brian Landau

Structure of generators/ directory

• generators/
• plugin_name/
• plugin_name_generator.rb
• templates/
• a_model.rb
• a_controller.rb
• some_views/
• view_file.html.erb
• USAGE

Two types of generators

Rails::Generator::Base

• No required argument
• More basic

Rails::Generator::NamedBase

• First argument is a class name
• Extra attributes available in generation
• Use when you're creating a specific named object

Generator class structure

Should inherit from Base or NamedBase Must define a manifest method Can have a banner method Can have an add_options! method

NamedBase attributes

name Blog::Comment
or
blog/comment class_nesting class_nesting_depth class_path file_path class_name plural_name singular_name table_name Blog 1 ['blog'] blog/comment Blog::Comment comments comment blog_comments

Manifest directives

• class_collisions
• directory
• file
• template
• migration_template
• route_resources
• readme
• dependency

USAGE

Description:

The
comatose
generator
creates
a
migration
for
the
comatose
model.

The
generator
takes
a
migration
name
as
its
argument.
The

migration
name
may
be
given
in
CamelCase
or
under_score.


'add_comatose_support'
is
the
default.

The
generator
creates
a
migration
class
in
db/migrate
prefixed
by


its
number
in
the
queue. Example:

./script/generate
comatose
add_comatose_support

With
4
existing
migrations,
this
will
create
an
Comatose
migration


in
the
file
db/migrate/005_add_comatose_support.rb

Generator templates

Use ERB to customize

• For ERB generating ERB: <%%=
@post.name
%>
• Generator methods available
• Unlike Rails’ views, generator instance variable not available

Programmatically running generators

Rails::Generator::Scripts::Generate.new.run( ['authenticated', 'user', 'sessions'])

How do you add new tasks?

No different from Rails

• Place Rake files in tasks/ named whatever.rake

The plugin Rakefile is only for Rake tasks run in the plugin directory.

• rake
test
• rake
rdoc
• rake
rerdoc
• rake
clobber_rdoc

How do you deal with other plugins?

Simple trick: all plugins in vendor/plugins are loaded in alphabetical order.

How do you test a plugin?

One way: require that your plugin is in a Rails app

• Easy
• Ugly
• Cannot specify Rails version
• May interfere with app classes
• Requires your plugin’s setup to be run

Running plugin tests

From plugin dir: rake
test

• Does not automatically load Rails environment
• To load Rails env:
• require File.join(File.dirname(__FILE__),

'../../../../test/test_helper')

Running plugin tests

From Rails app dir

• rake
test:plugins
• rake
test:plugins
PLUGIN=plugin_name

Running from Rails app dir does not run plugin’s Rakefile, so dependencies in there are not executed.

Standalone testing of plugins

Helper plugins may not need a Rails app For other plugins, you can mock out a Rails app

• Generators may need a full directory
• Model plugins can get by with a test database
• Controller plugins may need very little
• But mocking out routing can be very hard

How do you package your plugin?

A public Subversion or Git repository lets users install with script/plugin. To make a gem plugin, try Mr Bones.

PROJ.name = 'friend-feed' PROJ.authors = 'Clinton R. Nixon' PROJ.email = 'crnixon@gmail.com' PROJ.url = 'friend-feed.rubyforge.org' PROJ.dependencies = ['json'] PROJ.version = FriendFeed::VERSION

Bloget walkthrough

Baby tapir (http://flickr.com/photos/su-lin/2087767962/)

Foreign Key Migrations walkthrough

Baby duck (http://flickr.com/photos/dizzygirl/437988363/)

RESTful Authentication walkthrough

Uganda Mbeya (http://flickr.com/photos/youngrobv/2347565498/)

Resources

• Peepcode’s Plugin Patterns by Andrew Stewart
• Addison-Wesley’s Shortcut Rails Plugins by James Adam
• Rick Olson: techno-weenie.net - tons of plugins and plugin

building blog posts

• This talk: http://crnixon.org/talks/rails-plugins
