Simon Simon Schiff Schiff, zgr zgr L. L. zep zep Exploiting Exploiting Back-End Back-End APIs APIs fo for Feasible easible Ontology-Based Ontology-Based Stream Stream Access cess Fourth Stream Reasoning Workshop,

slide-1
SLIDE 1

Simon Simon Schiff Schiff, Özgür Özgür L.

  • L. Özçep

Özçep

Exploiting Exploiting Back-End Back-End APIs APIs fo for Feasible easible Ontology-Based Ontology-Based Stream Stream Access cess

Fourth Stream Reasoning Workshop, Linköping, 17th April Institute of Information Systems University of Lübeck

slide-2
SLIDE 2

QSQL historic data OBDA on huge datasets (w/o optimization) ⇒ Long processing times QSTARQL

2 / 6

slide-3
SLIDE 3

QSQL historic data OBDA on huge datasets (w/o optimization) ⇒ Long processing times Idea Processing times are reducible using additional hardware and parallelisation ⇒ Short processing times historic data QSparkSQL

. . .

Horizontal scaling QSTARQL

2 / 6

slide-4
SLIDE 4

STARQL Query Example

Measurements

Time/min Temp/C◦ 0.0 1.0 2.0 3.0 4.0 5.0 6.0 90.0 91.0 92.0 93.0 94.0

Information need for monotonicity

Tell every minute whether the temperature measured by a sensor increased monotonically in the last 5 minutes.

3 / 6

slide-5
SLIDE 5

STARQL Query Example

Measurements

Time/min Temp/C◦ 0.0 1.0 2.0 3.0 4.0 5.0 6.0 90.0 91.0 92.0 93.0 94.0

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

3 / 6

slide-6
SLIDE 6

STARQL Query Example

Measurements

Time/min Temp/C◦ 0.0 1.0 2.0 3.0 4.0 5.0 6.0 90.0 91.0 92.0 93.0 94.0

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

3 / 6

slide-7
SLIDE 7

STARQL Query Example

Measurements

Time/min Temp/C◦ 0.0 1.0 2.0 3.0 4.0 5.0 6.0 90.0 91.0 92.0 93.0 94.0

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

3 / 6

slide-8
SLIDE 8

STARQL Query Example

Measurements

Time/min Temp/C◦ 0.0 1.0 2.0 3.0 4.0 5.0 6.0 90.0 91.0 92.0 93.0 94.0

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

3 / 6

slide-9
SLIDE 9

STARQL Query Example

Measurements

Time/min Temp/C◦ 0.0 1.0 2.0 3.0 4.0 5.0 6.0 90.0 91.0 92.0 93.0 94.0 y1 at t1 y2 at t3

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

3 / 6

slide-10
SLIDE 10

STARQL Query Example

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

The FOL template language is domain independent1: STARQL HAVING clause can be unfolded into languages such as SQL. ⇒ Process historic (e.g. timestamped datasets)

1Serge Abiteboul, Richard Hull, and Victor Vianu.

Foundations of Databases: The Logical Level. Addison-Wesley Longman Publishing Co., Inc., 1995.

3 / 6

slide-11
SLIDE 11

STARQL Query Example

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

No function exists for executing the unfolded query per window! ◮ First idea: Create table with window intervals and join with historic dataset. ◮ Too slow?

3 / 6

slide-12
SLIDE 12

STARQL Query Example

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

No function exists for executing the unfolded query per window! ◮ Second idea: Create a function for executing the unfolded query per window using PL/pgSQL. ◮ Sufficient?

3 / 6

slide-13
SLIDE 13

STARQL Query Example

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

No function exists for executing the unfolded query per window! ◮ Second idea: Create a function for executing the unfolded query per window using PL/pgSQL. ◮ Sufficient? ◮

3 / 6

slide-14
SLIDE 14

STARQL Query Example

1

CREATE TYPE window_state AS (memory measurements [], wid bigint , start timestamp , stop timestamp , pulse timestamp);

2 3

CREATE TABLE measurements_data AS SELECT NULL :: bigint AS wid , NULL :: timestamp AS timestamp , NULL :: integer AS sensor , NULL :: numeric (12 ,3) AS value WHERE false;

4 5

CREATE OR REPLACE FUNCTION moving_window (source text , pulse interval , range interval , slide interval) RETURNS SETOF measurements_data AS $$

6

DECLARE

7

win window_state ;

8 9

cnt bigint;

10 11

line_cursor refcursor;

12

line measurements ;

13

BEGIN

14

OPEN line_cursor FOR EXECUTE ’SELECT * FROM ’ format (’%1$s ’, source) ’ ORDER BY timestamp ASC ’;

15

FETCH line_cursor INTO line;

16 17

win.start := line.timestamp;

3 / 6

slide-15
SLIDE 15

STARQL Query Example

18

win.stop := line.timestamp + range;

19

win.pulse := line.timestamp;

20 21

WHILE line.timestamp < win.stop LOOP

22

win.memory := array_append (win.memory , line);

23

FETCH line_cursor INTO line;

24

END LOOP;

25 26

win.wid := 0;

27

RETURN QUERY SELECT win.wid , (unnest(win.memory :: measurements [])).*;

28 29

win.pulse := win.pulse + pulse;

30

WHILE line.timestamp IS NOT NULL LOOP

31

IF win.pulse < win.stop AND win.pulse < win.start + slide THEN

32

win.wid := win.wid + 1;

33

RETURN QUERY SELECT win.wid , (unnest(win.memory :: measurements [])).*;

34

win.pulse := win.pulse + pulse;

35

ELSIF win.pulse >= win.stop AND win.pulse < win. start + slide THEN

36

win.pulse := win.pulse + pulse;

37 38

win.start := win.start + slide;

3 / 6

slide-16
SLIDE 16

STARQL Query Example

39

win.stop := win.stop + slide;

40

WHILE line.timestamp < win.stop LOOP

41

win.memory := array_append (win.memory , line);

42

FETCH line_cursor INTO line;

43

END LOOP;

44

cnt := 1;

45

FOR i IN coalesce( array_lower (win.memory , 1), 1) .. coalesce( array_upper (win.memory , 1), 1) LOOP

46

IF win.memory[i]. timestamp < win.start THEN

47

cnt := cnt + 1;

48

ELSE

49

EXIT;

50

END IF;

51

END LOOP;

52

win.memory := win.memory[cnt :];

53

ELSIF win.pulse >= win.start + slide THEN

54

win.start := win.start + slide;

55

win.stop := win.stop + slide;

56

WHILE line.timestamp < win.stop LOOP

57

win.memory := array_append (win.memory , line);

58

FETCH line_cursor INTO line;

59

END LOOP;

60

cnt := 1;

3 / 6

slide-17
SLIDE 17

STARQL Query Example

61

FOR i IN coalesce( array_lower (win.memory , 1), 1) .. coalesce( array_upper (win.memory , 1), 1) LOOP

62

IF win.memory[i]. timestamp < win.start THEN

63

cnt := cnt + 1;

64

ELSE

65

EXIT;

66

END IF;

67

END LOOP;

68

win.memory := win.memory[cnt :];

69

END IF;

70

END LOOP;

71

win.wid := win.wid + 1;

72

RETURN QUERY SELECT win.wid , (unnest(win.memory :: measurements [])).*;

73

CLOSE line_cursor ;

74

END

75

$$ language plpgsql;

3 / 6

slide-18
SLIDE 18

STARQL Query Example

STARQL Representation of monotonicity

SELECT x FROM measurements [NOW - PT5M, NOW] -> PT1M WHERE Sensor(x) HAVING FORALL ti, tj, y1, y2 IF hasVal(x,y1)<ti> AND hasVal(x,y2)<tj> AND ti < tj THEN y1 <= y2

. . .

Horizontal scaling

Function exists for executing the unfolded query per window! ◮ Apache Spark SQL scales horizontally and vertically. ◮ Scalable?

3 / 6

slide-19
SLIDE 19

Processing times using different back ends

2 4 6 8 10 12 2 4 6 8 10 12 14 16 Processing time in minutes Measurement duration in days PostgreSQL PL/pgSQL Apache Spark SQL

4 / 6

slide-20
SLIDE 20

Processing times using different back ends

2 4 6 8 10 12 20 40 60 80 100 120 140 160 Processing time in minutes Measurement duration in days PL/pgSQL Apache Spark SQL

5 / 6

slide-21
SLIDE 21

Conclusion and Future Work

Conclusion: ◮ Window function can be realized by using PL/pgSQL ◮ Speed gain by using Apache Spark SQL1 ◮ Complexity hidden by STARQL Future Work: ◮ Incremental stream processing (Not possible for every STARQL query)

1Simon Schiff, Özgür L. Özçep, and Ralf Möller. “Ontology-based Data

Access to Big Data”. In: Open Journal of Databases (OJDB) 6 (1 2018). Postproceeding of Hidest’18, pp. 21–32.

6 / 6

slide-22
SLIDE 22

Processing times using distributed Apache Spark SQL

0.5 1 1.5 2 2.5 3 3.5 4 10 20 30 40 50 60 Processing time in hours Measurement duration in years 1 Node 2 Nodes 3 Nodes 4 Nodes

7 / 6
