Expanders via Local Edge Flips

Big Data & Sublinear Algorithms Workshop, DIMACS

Zeyuan Allen-Zhu Princeton University Aditya Bhaskara Google Lorenzo Orecchia Boston Univesity Silvio Lattanzi Google Vahab Mirrokni Google

Outline

Big Data and Sublinear Algorithms Workshop, DIMACS

How can we construct an expander locally?
 Problem motivation and related works A simple distributed protocol
 The switch and the flip protocols
 A new analysis for the two protocols
 Obstacles in the analysis and new approach for the problem Conclusions and future directions
 Open problems

How can we construct an expander locally?

Big Data and Sublinear Algorithms Workshop, DIMACS

Distributed system
 P2P networks
 Sensor networks Asynchronous system Benefits Efficient Robust New challenges Important to construct quickly good network structure Only local communication

Why is it interesting?

Big Data and Sublinear Algorithms Workshop, DIMACS

Local algorithms
 Algorithms based on local message passing among nodes

Local graph algorithms

Big Data and Sublinear Algorithms Workshop, DIMACS

Local algorithms
 Algorithms based on local message passing among nodes Advantages Applicable to large scale graphs Fast, easy to implement in parallel (MapReduce, Hadoop, Pregel...)

Local graph algorithms

Big Data and Sublinear Algorithms Workshop, DIMACS

Starting from any connected graph is it possible to construct an expander locally?


Problem

Big Data and Sublinear Algorithms Workshop, DIMACS

SKIP+: A Self-Stabilizing Skip Graph.

• R. Jacob, A. W. Richa, C. Scheideler, S. Schmid and H. Täubig.
• J. ACM 61(6): 36:1-36:26 (2014)

In the Local model it is possible to build an expander locally in

Previous work

Big Data and Sublinear Algorithms Workshop, DIMACS

O(log2 n)

Previous work

Big Data and Sublinear Algorithms Workshop, DIMACS

O(log2 n)

Construct Skip+ locally Skip+ has constant edge expansion and degree log n

SKIP+: A Self-Stabilizing Skip Graph.

• R. Jacob, A. W. Richa, C. Scheideler, S. Schmid and H. Täubig.
• J. ACM 61(6): 36:1-36:26 (2014)

In the Local model it is possible to build an expander locally in

SKIP+: A Self-Stabilizing Skip Graph.

• R. Jacob, A. W. Richa, C. Scheideler, S. Schmid and H. Täubig.
• J. ACM 61(6): 36:1-36:26 (2014)

In the Local model it is possible to build an expander locally in

Limitations:

• Using this technique it is not possible to obtain an algebraic expander
• In any round nodes can exchange arbitrary large messages
• Memory needed by a single node in any round is not bounded
• Synchronous model, complex algorithm

Previous work

Big Data and Sublinear Algorithms Workshop, DIMACS

O(log2 n)

Construct Skip+ locally Skip+ has constant edge expansion and degree log n

Starting from any connected graph is it possible to define a simple rule to construct an expander locally?


Problem

Big Data and Sublinear Algorithms Workshop, DIMACS

A simple distributed protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

Switch protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[McKay, Congressus Numerantium 1981]

A simple protocol: Pick two edges at random and invert their endpoints

Switch protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[McKay, Congressus Numerantium 1981]

A simple protocol: Pick two edges at random and invert their endpoints

Switch protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[McKay, Congressus Numerantium 1981]

A simple protocol: Pick two edges at random and invert their endpoints

Switch protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[McKay, Congressus Numerantium 1981]

A simple protocol: Pick two edges at random and invert their endpoints

Creation of parallel edges/self-loops is allowed

Switch protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[McKay, Congressus Numerantium 1981]

A simple protocol: Pick two edges at random and invert their endpoints

Creation of parallel edges/self-loops is allowed Limitation It is not local

It may disconnect the graph

Flip protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[Mahlmann and Schindelhauer, SPAA 2005]

Pick a random length 3 path and invert its endpoints

Flip protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[Mahlmann and Schindelhauer, SPAA 2005]

Pick a random length 3 path and invert its endpoints

Flip protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[Mahlmann and Schindelhauer, SPAA 2005]

Pick a random length 3 path and invert its endpoints

Flip protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[Mahlmann and Schindelhauer, SPAA 2005]

Pick a random length 3 path and invert its endpoints

Creation of parallel edges/self-loops is allowed

Flip protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

[Mahlmann and Schindelhauer, SPAA 2005]

Pick a random length 3 path and invert its endpoints

Creation of parallel edges/self-loops is allowed

Experimentally it seems to be really fast

What is known about them?

Big Data and Sublinear Algorithms Workshop, DIMACS

[Cooper, Dyer and Greenhill, SODA 2005]

For d-regular graph the switch protocol converges to the
 configuration model in steps.

[Greenhill, SODA 2015]

For non regular graph with max degree in the switch protocol converges to the configuration model in
 steps. ˜ O

• n8d15

O √m

• ˜

O

• m10d14

max

What is known about them?

Big Data and Sublinear Algorithms Workshop, DIMACS

[Cooper, Dyer and Greenhill, SODA 2005]

For d-regular graph the switch protocol converges to the
 configuration model in steps.

[Greenhill, SODA 2015]

For non regular graph with max degree in the switch protocol converges to the configuration model in
 steps.

[Mahlmann and Schindelhauer, SPAA 2005]

For d-regular graph the flip protocol converges to the configuration model.

[Feder, Guetz, Mihail, and Saberi, FOCS 2006]

For d-regular graph the flip protocol converges to the configuration model in steps.

[Cooper and Dyer, PODC 2009]

For d-regular graph the flip protocol converges to the configuration model in steps. ˜ O

• n8d15

O √m

• ˜

O

• m10d14

max

• ˜

O

• d34n36

˜ O

• d23n17

How do they perform in practice?

Big Data and Sublinear Algorithms Workshop, DIMACS

[Mahlmann and Schindelhauer, SPAA 2005]

Experimentally switch and flips protocol transform any graph in an expander very quickly. Conjectures:

Switch converges on d-regular graph in steps.
 Flip converges on d-regular graph in steps.

O (nd log n) O (nd)

A new analysis for the two protocols

Big Data and Sublinear Algorithms Workshop, DIMACS

Results

Big Data and Sublinear Algorithms Workshop, DIMACS

Starting from any d-regular graph, with , the switch protocol transforms the graph in an algebraic expander in steps. the flip protocol transforms the graph in an algebraic expander in steps.

O (nd) O ⇣ n2d2p log n ⌘ d ∈ Ω(log n)

Results

Big Data and Sublinear Algorithms Workshop, DIMACS

Starting from any d-regular graph, with , the switch protocol transforms the graph in an algebraic expander in steps. the flip protocol transforms the graph in an algebraic expander in steps.

O (nd) O ⇣ n2d2p log n ⌘ d ∈ Ω(log n)

Obstacles

Big Data and Sublinear Algorithms Workshop, DIMACS

Dependencies. Small cuts may first become smaller and only later increase.

Obstacles

Big Data and Sublinear Algorithms Workshop, DIMACS

Dependencies. Small cuts may first become smaller and only later increase.

Pick a random edge.

Flip definition

Big Data and Sublinear Algorithms Workshop, DIMACS

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort).

Flip definition

Big Data and Sublinear Algorithms Workshop, DIMACS

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort).

Flip definition

Big Data and Sublinear Algorithms Workshop, DIMACS

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort).

Flip definition

Big Data and Sublinear Algorithms Workshop, DIMACS

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort). The other endpoint picks a random
 neighbor(if in common, picks a new one).

Flip definition

Big Data and Sublinear Algorithms Workshop, DIMACS

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort). The other endpoint picks a random
 neighbor(if in common, picks a new one).

Flip definition

Big Data and Sublinear Algorithms Workshop, DIMACS

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort). The other endpoint picks a random
 neighbor(if in common, picks a new one). Perform swap.

Flip definition

Big Data and Sublinear Algorithms Workshop, DIMACS

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort). The other endpoint picks a random
 neighbor(if in common, picks a new one). Perform swap. Let

Expected change of laplacian

Big Data and Sublinear Algorithms Workshop, DIMACS

∆(t) = L ⇣ G(t+1)⌘ − L ⇣ G(t)⌘ E h ∆(t)|G(t)i = 4 d2n ✓ (d + 1)L(t) − ⇣ L(t)⌘2◆

Pick a random edge. One of the endpoints picks a neighbor
 at random(if in common, abort). The other endpoint picks a random
 neighbor(if in common, picks a new one). Perform swap. Let

Expected change of laplacian

Big Data and Sublinear Algorithms Workshop, DIMACS

∆(t) = L ⇣ G(t+1)⌘ − L ⇣ G(t)⌘ E h ∆(t)|G(t)i = 4 d2n ✓ (d + 1)L(t) − ⇣ L(t)⌘2◆

Nice term.

has


better
 expansion.

⇣ G(t)⌘2

Unfortunately we cannot argue directly on the expectation of the matrix
 after t step.

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

E h ∆(t)|G(t)i = 4 d2n ✓ (d + 1)L(t) − ⇣ L(t)⌘2◆

Unfortunately we cannot argue directly on the expectation of the matrix
 after t step. We use a classic potential used for matrix concentration: where

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

E h ∆(t)|G(t)i = 4 d2n ✓ (d + 1)L(t) − ⇣ L(t)⌘2◆ Φ(t) = ˆ tr ⇣ e− 20 log n

d

L(t)⌘

ˆ tr

• eA

= eλ1 + eλ2 + ...

Unfortunately we cannot argue directly on the expectation of the matrix
 after t step. We use a classic potential used for matrix concentration: where Note that in order to have very small all the eigenvalues need
 to be large.

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

E h ∆(t)|G(t)i = 4 d2n ✓ (d + 1)L(t) − ⇣ L(t)⌘2◆ Φ(t) = ˆ tr ⇣ e− 20 log n

d

L(t)⌘

ˆ tr

• eA

= eλ1 + eλ2 + ... Φ(t)

We want to show that the potential decreases

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

Φ(t+1) = ˆ tr ⇣ e− 20 log n

d

(L(t)+∆(t))⌘

We want to show that the potential decreases

by Golden-Thompson inequality

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

Φ(t+1) = ˆ tr ⇣ e− 20 log n

d

(L(t)+∆(t))⌘

= ˆ tr ⇣ e− 20 log n

d

L(t)e− 20 log n

d

∆(t)⌘

We want to show that the potential decreases

by Golden-Thompson inequality

by

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

Φ(t+1) = ˆ tr ⇣ e− 20 log n

d

(L(t)+∆(t))⌘

= ˆ tr ⇣ e− 20 log n

d

L(t)e− 20 log n

d

∆(t)⌘

= ˆ tr e− 20 log n

d

L(t)

I − 20 log n d ∆(t) + ✓20 log n d ∆(t) ◆2!!

e−A = I − A + A2

We want to show that the potential decreases

by Golden-Thompson inequality

by

Taking expectation:

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

Φ(t+1) = ˆ tr ⇣ e− 20 log n

d

(L(t)+∆(t))⌘

= ˆ tr ⇣ e− 20 log n

d

L(t)e− 20 log n

d

∆(t)⌘

= ˆ tr e− 20 log n

d

L(t)

I − 20 log n d ∆(t) + ✓20 log n d ∆(t) ◆2!!

e−A = I − A + A2

E h Φ(t+1)|Gti = Φ(t) − 4 log n d3n ˆ tr ✓ e− 20 log n

d

L(t) ✓

L(t) ✓d 2 ˆ I − L(t) ◆◆◆

We want to show that the potential decreases

by Golden-Thompson inequality

by

Taking expectation:

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

Φ(t+1) = ˆ tr ⇣ e− 20 log n

d

(L(t)+∆(t))⌘

= ˆ tr ⇣ e− 20 log n

d

L(t)e− 20 log n

d

∆(t)⌘

= ˆ tr e− 20 log n

d

L(t)

I − 20 log n d ∆(t) + ✓20 log n d ∆(t) ◆2!!

e−A = I − A + A2

E h Φ(t+1)|Gti = Φ(t) − 4 log n d3n ˆ tr ✓ e− 20 log n

d

L(t) ✓

L(t) ✓d 2 ˆ I − L(t) ◆◆◆

Using common diagonalization

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

X

1≤i≤n

e− 20 log n

d

λiλi(d/2 − λi)

Using common diagonalization Two interesting cases:

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

∀i : λi ≥ d 4 X

1≤i≤n

e− 20 log n

d

λiλi(d/2 − λi) ∈ O(n−3)

X

1≤i≤n

e− 20 log n

d

λiλi(d/2 − λi)

Using common diagonalization Two interesting cases: We look at:

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

X

1≤i≤n

e− 20 log n

d

λiλi(d/2 − λi)

∃i : λi < d 4

P

1≤i≤n e− 20 log n

d

λiλi(d/2 − λi)

Φ(t) = P

1≤i≤n e− 20 log n

d

λiλi(d/2 − λi)

P

1≤i≤n e− 20 log n

d

λi

Using common diagonalization Two interesting cases: We look at:

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

X

1≤i≤n

e− 20 log n

d

λiλi(d/2 − λi)

∃i : λi < d 4

P

1≤i≤n e− 20 log n

d

λiλi(d/2 − λi)

Φ(t) = P

1≤i≤n e− 20 log n

d

λiλi(d/2 − λi)

P

1≤i≤n e− 20 log n

d

λi

≈ P

1≤i≤k e− 20 log n

d

λiλi

P

1≤i≤k e− 20 log n

d

λi

∈ Ω ✓ 1 n√log n ◆

Using common diagonalization Two interesting cases: We look at:

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

X

1≤i≤n

e− 20 log n

d

λiλi(d/2 − λi)

∃i : λi < d 4

P

1≤i≤n e− 20 log n

d

λiλi(d/2 − λi)

Φ(t) = P

1≤i≤n e− 20 log n

d

λiλi(d/2 − λi)

P

1≤i≤n e− 20 log n

d

λi

≈ P

1≤i≤k e− 20 log n

d

λiλi

P

1≤i≤k e− 20 log n

d

λi

∈ Ω ✓ 1 n√log n ◆

∈ Ω ✓ d n√log n ◆

Thus: So in expectation is in after steps, hence using Markov inequality we get the result.

Potential

Big Data and Sublinear Algorithms Workshop, DIMACS

Φ(t) O(n−3) O(n2d2 log n)

E h Φ(t+1)|G(t)i = ✓ 1 − Ω ✓√log n n2d2 ◆◆ Φ(t) + O(n−3)

Limit of our analysis

Big Data and Sublinear Algorithms Workshop, DIMACS

Expected additive improvement in a round can be O ✓ 1 n2d2 ◆

Conclusions and future directions

Big Data and Sublinear Algorithms Workshop, DIMACS

Conclusions

New technique to analyze distribute protocol New convergence time analysis for flip and switch
 protocol

Big Data and Sublinear Algorithms Workshop, DIMACS

Future works

Improve analysis of the flip Study parallelized version of the protocol Study node addition or deletion

Big Data and Sublinear Algorithms Workshop, DIMACS

Thanks!

Big Data and Sublinear Algorithms Workshop, DIMACS
