Erik Van Buggenhout Royal Holloway, University of London Distance Learning Conference 2014 Information Security Consultant Instructor Incident Response, Penetration Testing SEC 560 & 542 Royal Holloway, University of London Project: ATM

slide-1
SLIDE 1

Erik Van Buggenhout Royal Holloway, University of London Distance Learning Conference 2014

slide-2
SLIDE 2

Information Security Consultant Incident Response, Penetration Testing Instructor SEC 560 & 542 Royal Holloway, University of London Project: ATM Security assessment framework

slide-3
SLIDE 3

§ About the project § ATM Introduction § Attacking the ATM § Common ATM system design § Assessing a sample ATM § Conclusion

slide-4
SLIDE 4

§ About the project § ATM Introduction § Attacking the ATM § Common ATM system design § Assessing a sample ATM § Conclusion

slide-5
SLIDE 5

§ “A security assessment framework for Automated

Teller Machines”

§ Finished it this year (2014) § Supervisor: Frederik Mennes

slide-6
SLIDE 6
slide-7
SLIDE 7

§ About the project § ATM Introduction § Attacking the ATM § Common ATM system design § Assessing a sample ATM § Conclusion

slide-8
SLIDE 8

§ Automated Teller Machine § Cash disposing & dispensing § 2.2 million devices worldwide § Different hardware & software vendors

slide-9
SLIDE 9

The first ATM was installed in 1939 in New York City, known as “Bankograph”. Removed after 6 months because it was not used J It was reintroduced in Ohio in 1959, with huge success. There are currently more then 2.2 million ATM’s worldwide.

slide-10
SLIDE 10

PIN validation Account balance Transfer / withdrawal authorization ...

The ATM is a “stupid” device, part of the bank’s overall architecture. It relies on back-end services for “important” decisions.

slide-11
SLIDE 11
  • 1. ATM computer
  • 2. (Touch)screen
  • 3. Card-reader
  • 4. PIN pad
  • 5. Cash dispenser
  • 6. Cash cassettes

Typical lay-out of a modern ATM

slide-12
SLIDE 12
  • 1. ATM computer
  • 2. (Touch)screen
  • 3. Card-reader
  • 4. PIN pad
  • 5. Cash dispenser
  • 6. Cash cassettes
slide-13
SLIDE 13
  • 1. ATM computer
  • 2. (Touch)screen
  • 3. Card-reader
  • 4. PIN pad
  • 5. Cash dispenser
  • 6. Cash cassettes
slide-14
SLIDE 14
  • 1. ATM computer
  • 2. (Touch)screen
  • 3. Card-reader
  • 4. PIN pad
  • 5. Cash dispenser
  • 6. Cash cassettes

CD / DVD CD / DVD Disk bays Disk bays Auxiliary ports USB

slide-15
SLIDE 15

§ About the project § ATM Introduction § Attacking the ATM § Common ATM system design § Assessing a sample ATM § Conclusion

slide-16
SLIDE 16
slide-17
SLIDE 17

It stores MONEY

Handles interesting customer data as well, which could be abused to get MORE MONEY

slide-18
SLIDE 18

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-19
SLIDE 19

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-20
SLIDE 20

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-21
SLIDE 21

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-22
SLIDE 22

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-23
SLIDE 23

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-24
SLIDE 24
slide-25
SLIDE 25

Safe certification standards, bolts, video surveillance...

slide-26
SLIDE 26

Ink cartridges that stain money upon breach

slide-27
SLIDE 27

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-28
SLIDE 28

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-29
SLIDE 29

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-30
SLIDE 30

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-31
SLIDE 31

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-32
SLIDE 32

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-33
SLIDE 33

Anti-skimming devices

slide-34
SLIDE 34

Security awareness campaigns

slide-35
SLIDE 35

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-36
SLIDE 36

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-37
SLIDE 37

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-38
SLIDE 38

Awareness + force change of default passwords

slide-39
SLIDE 39

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-40
SLIDE 40

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-41
SLIDE 41

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ...

slide-42
SLIDE 42

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ... Barnaby Jack “Jackpotting ATMs” - 2010

slide-43
SLIDE 43

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ... Network access?

slide-44
SLIDE 44

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ... Network access? Shodan HQ (Internet search engine) lists 800+ ATMs available on the Internet

slide-45
SLIDE 45

Blow up the safe Copy cards & steal PIN codes Steal the entire thing Attack back-end communication Attack the OS Access “operator” mode ... CCC 2013 “Electronic bank robberies” Boot ATMs from USB

slide-46
SLIDE 46

§ About the project § ATM Introduction § Attacking the ATM § Common ATM system design § Assessing a sample ATM § Conclusion

slide-47
SLIDE 47

CEN/XFS (eXtensions for Financial Services) provides a standard set

  • f APIs that can be

used by Windows applications to operate the ATM peripherals

slide-48
SLIDE 48

XFS Manager Windows-based application XFS APIs XFS SPIs XFS Service Providers ATM peripheral Vendor Dependent Vendor Independent Operating System

CEN/XFS (eXtensions for Financial Services) provides a standard set

  • f APIs that can be

used by Windows applications to operate the ATM peripherals

slide-49
SLIDE 49

95% of ATMs was running Windows XP in January 2014

(NCR, 2014)

slide-50
SLIDE 50

“How will you approach the Windows XP end-of-support?”

(KAL 2013 – ATM Software Trends & Analysis)

slide-51
SLIDE 51

§ About the project § ATM Introduction § Attacking the ATM § Common ATM system design § Assessing a sample ATM § Conclusion

slide-52
SLIDE 52
slide-53
SLIDE 53
slide-54
SLIDE 54
slide-55
SLIDE 55
slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61
slide-62
SLIDE 62

Attack failed

slide-63
SLIDE 63

Using openly available forensic toolkits we managed to recover the majority of the original hard disk content.

slide-64
SLIDE 64

Sweet... But I don’t have a bank back-end (yet)

slide-65
SLIDE 65
slide-66
SLIDE 66
slide-67
SLIDE 67
slide-68
SLIDE 68

WFSOpen("CurrencyDispenser1", WFS_DEFAULT_HAPP , "NVISOSPIT", WFS_TRACE_NONE, WFS_INDEFINITE_WAIT , 0x0000FFFF , &serviceVersion, &spiVersion, &service); WFSCDMDISPENSE tDispense; WFSCDMDENOMINATION tDenomination; Set up XFS session with the “CurrencyDispenser1”, no logging is required J Create a dispense object “tDispense” Create a denomination

  • bject “tDenomination”
slide-69
SLIDE 69

tDispense.fwPosition =WFS_CDM_POSNULL; tDenomination.cCurrencyID[0]='E'; tDenomination.cCurrencyID[1]='U'; tDenomination.cCurrencyID[2]='R'; tDenomination.ulAmount=nviso_amount; tDenomination.usCount=5; tDenomination.ulCashBox=0; ulaValues[0] =nviso_cassette1; ulaValues[1] =nviso_cassette2; ulaValues[2] =0; ulaValues[3] =0; ulaValues[4] =0; €€€ I want “EUR” J The amount is specified dynamically by a command line argument Specify how many notes you want per cassette

slide-70
SLIDE 70

tDenomination.lpulValues = ulaValues; tDispense.lpDenomination= &tDenomination; HRESULT hResult = WFSExecute(service,WFS_CMD_CDM_DISPENSE,&tDispense,WFS_INDEFINIT E_WAIT ,&lpResult); Load the dispense with the specified denomination & execute the dispense operation

slide-71
SLIDE 71
slide-72
SLIDE 72

TODO: Make it generic for different ATM devices (read custom config from registry J)

slide-73
SLIDE 73

DEMONSTRATION

slide-74
SLIDE 74

§ About the project § ATM Introduction § Attacking the ATM § Common ATM system design § Assessing a sample ATM § Conclusion

slide-75
SLIDE 75

Modern ATMs are standard, Windows-based, computers full of money ATM software is developed according to open standards Highly interesting target, protection is required! Application whitelisting Network segmentation Disk encryption Protect the BIOS Patch management
