Entwurfsmuster und Frameworks – Proxy

Oliver Haase

Oliver Haase Emfra — Proxy 1/14

Description I

◮ Classification: Object-based structural pattern ◮ Also known as: Surrogate ◮ Purpose: Control access to a subject through indirection, i.e.

a placeholder object (proxy) that provides the same interface and that delegates operation calls to the actual subject.

◮ Applicability: Common reasons to hide a subject behind a

proxy are:

◮ local placeholder for remote communication; basic idea behind

Remote Procecure Call (RPC), Remote Method Invocation (RMI) → Remote Proxy

◮ create expensive objects only on demand → Virtual Proxy

Example: high resolution graphic in text document, virtual proxy might only know size (bounding box) and position.

Oliver Haase Emfra — Proxy 2/14

Description II

◮ control access to original proxy → Protection Proxy

access control can only mean to filter out interfaces that shall not be usable, or a full-fledged authentication and authorization mechanism.

◮ need for an “inteligent” reference that e.g. counts number of

existing references to subject (needed for automatic garbage collection) → Smart Reference

Oliver Haase Emfra — Proxy 3/14

Structure

Oliver Haase Emfra — Proxy 4/14

Participants

◮ Proxy:

◮ has reference to real subject (might see real subject only as an

instance of type Subject)

◮ implements type Subject ◮ controls access to real subject; might be responsible for

creating real subject on demand

◮ further functionality depends on proxy kind

◮ Subject: Common interface for RealSubject and Proxy

→ allows a proxy to substitute for a real subject.

◮ RealSubject: implements the real thing.

Oliver Haase Emfra — Proxy 5/14

Implementation

Example: A service interface that contains methods for usage, for administration, and methods to get a usage or administration proxy:

public i n t e r f a c e ServiceUsage { void use ( ) ; } public i n t e r f a c e S e r v i c e A d m i n i s t r a t i o n { void a d m i n i s t r a t e ( i n t s t a t e ) ; } public i n t e r f a c e S e r v i c e extends S e r v i c e A d m i n i s t r a t i o n , ServiceUsage { S e r v i c e A d m i n i s t r a t i o n getAdministrationProxy ( ) ; ServiceUsage getUsageProxy ( ) ; }

Oliver Haase Emfra — Proxy 6/14

Implementation

Simple Service implementation:

public c l a s s C o n c r e t e S e r v i c e implements S e r v i c e { private i n t s t a t e = 0; public void a d m i n i s t r a t e ( i n t s t a t e ) { t h i s . s t a t e = s t a t e ; } public void use () { System . out . p r i n t l n ( ” s t a t e : ” + s t a t e ) ; } public S e r v i c e A d m i n i s t r a t i o n getAdministrationProxy () { return new AdministrationProxy ( t h i s ) ; } public ServiceUsage getUsageProxy () { return new UsageProxy ( t h i s ) ; } }

Oliver Haase Emfra — Proxy 7/14

Implementation

Proxy classes:

p u b l i c c l a s s A d m i n i s t r a t i o n P r o x y implements S e r v i c e A d m i n i s t r a t i o n { p r i v a t e S e r v i c e A d m i n i s t r a t i o n d e l e g a t e ; p u b l i c A d m i n i s t r a t i o n P r o x y ( S e r v i c e A d m i n i s t r a t i o n d e l e g a t e ) { t h i s . d e l e g a t e = d e l e g a t e ; } p u b l i c void a d m i n i s t r a t e ( i n t v a l u e ) { d e l e g a t e . a d m i n i s t r a t e ( v a l u e ) ; } } p u b l i c c l a s s UsageProxy implements ServiceUsage { p r i v a t e ServiceUsage d e l e g a t e ; p u b l i c UsageProxy ( ServiceUsage d e l e g a t e ) { t h i s . d e l e g a t e = d e l e g a t e ; } p u b l i c void use () { d e l e g a t e . use ( ) ; } }

Oliver Haase Emfra — Proxy 8/14

Implementation

Sample application that creates a ConcreteService, then feeds an administration thread with an AdministrationProxy and a usage thread with a UsageProxy.

p u b l i c c l a s s A p p l i c a t i o n { p u b l i c s t a t i c void main ( S t r i n g [ ] args ) { C o n c r e t e S e r v i c e s e r v i c e = new C o n c r e t e S e r v i c e ( ) ; S e r v i c e A d m i n i s t r a t i o n sa = s e r v i c e . g e t A d m i n i s t r a t i o n P r o x y ( ) ; ServiceUsage su = s e r v i c e . getUsageProxy ( ) ; new Thread (new AdminThread ( sa ) ) . s t a r t ( ) ; new Thread (new UsageThread ( su ) ) . s t a r t ( ) ; }

Oliver Haase Emfra — Proxy 9/14

Implementation

p r i v a t e s t a t i c c l a s s AdminThread implements Runnable { p r i v a t e S e r v i c e A d m i n i s t r a t i o n sa ; p u b l i c AdminThread ( S e r v i c e A d m i n i s t r a t i o n sa ) { t h i s . sa = sa ; } p u b l i c void run () { i n t v a l u e = 0; while ( true ) { sa . a d m i n i s t r a t e(++v a l u e ) ; t r y { Thread . s l e e p ( 5 0 0 0 ) ; } catch ( Exception e ) {} } } }

Oliver Haase Emfra — Proxy 10/14

Implementation

p r i v a t e s t a t i c c l a s s UsageThread implements Runnable { p r i v a t e ServiceUsage su ; p u b l i c UsageThread ( ServiceUsage su ) { t h i s . su = su ; } p u b l i c void run () { while ( true ) { su . use ( ) ; t r y { Thread . s l e e p ( 2 0 0 0 ) ; } catch ( Exception e ) {} } } } }

Oliver Haase Emfra — Proxy 11/14

Implementation

Variant with dynamic proxies: Java allows to create dynamic proxies that implement a set of interfaces specified at run-time.

p u b l i c c l a s s C o n c r e t e S e r v i c e implements S e r v i c e { [ . . . ] p u b l i c S e r v i c e A d m i n i s t r a t i o n g e t A d m i n i s t r a t i o n P r o x y () { I n v o c a t i o n H a n d l e r h a n d l e r = new DelegationHandler ( t h i s ) ; return ( S e r v i c e A d m i n i s t r a t i o n ) Proxy . newProxyInstance ( S e r v i c e A d m i n i s t r a t i o n . c l a s s . g e t C l a s s L o a d e r ( ) , new C l a s s [ ] { S e r v i c e A d m i n i s t r a t i o n . c l a s s } , h a n d l e r ) ; } p u b l i c ServiceUsage getUsageProxy () { I n v o c a t i o n H a n d l e r h a n d l e r = new DelegationHandler ( t h i s ) ; return ( ServiceUsage ) Proxy . newProxyInstance ( ServiceUsage . c l a s s . g e t C l a s s L o a d e r ( ) , new C l a s s [ ] { ServiceUsage . c l a s s } , h a n d l e r ) ; }

Oliver Haase Emfra — Proxy 12/14

Implementation

Class DelegationHandler forwards all incoming calls to delegate

• bject:

p u b l i c c l a s s DelegationHandler implements I n v o c a t i o n H a n d l e r { p r i v a t e Object d e l e g a t e ; p u b l i c DelegationHandler ( Object d e l e g a t e ) { t h i s . d e l e g a t e = d e l e g a t e ; } p u b l i c Object invoke ( Object arg0 , Method arg1 , Object [ ] arg2 ) throws Throwable { return arg1 . invoke ( delegate , arg2 ) ; } }

Oliver Haase Emfra — Proxy 13/14

Implementation

Java 5 and later uses dynamic proxies for Java RMI: When an RMI server object is exported, the runtime system (Java virtual machine) creates a dynamic proxy (RMI stub) that implements the respective remote interface, and forwards all methods calls to the remote server object. This obsoletes the necessity to create stub classes (rmic) beforehand.

Oliver Haase Emfra — Proxy 14/14
