Energy issues of GPU computing clusters Stphane Vialle SUPELEC UMI - - PowerPoint PPT Presentation

▶
energy issues of gpu computing clusters
SMART_READER_LITE
LIVE PREVIEW

Energy issues of GPU computing clusters Stphane Vialle SUPELEC UMI - - PowerPoint PPT Presentation

Nov 04, 2023 281 likes •632 views

AlGorille INRIA Project Team Energy issues of GPU computing clusters Stphane Vialle SUPELEC UMI GT CNRS 2958 & AlGorille INRIA Project Team EJC 19 20/11/2012 Lyon, France What means using a GPU cluster ? Programming a

slide-1
SLIDE 1

Energy issues of GPU computing clusters

Stéphane Vialle SUPELEC– UMI GT‐CNRS 2958 & AlGorille INRIA Project Team EJC 19‐20/11/2012 Lyon, France

AlGorille INRIA Project Team

slide-2
SLIDE 2

Programming a cluster of « CPU+GPU » nodes

  • Implementing message passing + multithreading + vectorization
  • Long and difficult code development and maintenance

How many software engineers can do it ? Computing nodes requiring more electrical power (Watt)

  • CPU + (powerful) GPU dissipate more electrical power than CPU
  • Can lead to improve the electrical network and subscription

 Can generate some extra‐costs !

What means « using a GPU cluster » ?

But we expect :

  • To run faster

and / or

  • To save energy (Watt.Hours)
slide-3
SLIDE 3

1 ‐ First experiment: « hapilly parallel » application

  • Asian option pricer (independant Monte Carlo simulations)
  • Rigorous parallel random number generation

Lokman Abas‐Turki Stephane Vialle Bernard Lapeyre 2008

slide-4
SLIDE 4

Application : « Asian option pricer »: Independent Monte Carlo trajectory computations Coarse grain parallelism on the cluster:

  • Distribution of data on each computing node
  • Local and independent computations on each node
  • Collect of partial results and small final computation

Fine grain parallelism on each node:

  • Local data transfer on GPU memory
  • Local parallel computation on the GPU
  • Local result transfer from the GPU to the CPU memory

 Coarse and fine grain parallel codes can be developed separately (nice!)

1 ‐ Happily parallel application

slide-5
SLIDE 5

1 ‐ Happily parallel application

PC0 Input data files PC1 PC0 PCP‐1 PC1 PC0 PCP‐1

GPU cores

PC1 PC0 PCP‐1 PC1 PC0 PCP‐1 PC1 PC0 PCP‐1 PC0 Coarse grain Coarse grain and fine grain Coarse grain and fine grain Coarse grain and fine grain Coarse grain 1 ‐ Input data reading on P0 2 ‐ Input data broadcast from P0 3 ‐ Parallel and independent RNG initialization 4 ‐ Parallel and independent Monte‐Carlo computations 5 ‐ Parallel and independent partial results computation 6 ‐ Partial results reduction on P0 and final price computation 7 – Print results and perfs

GPU cores GPU cores

Long work to design rigorous parallel random number generation on the GPUs

slide-6
SLIDE 6

1 ‐ Happily parallel application

1E+00 1E+01 1E+02 1E+03 1E+04 1E+05 1 10 100 1000 10000 Total Exec Time(s) Nb of nodes

Asian Pricer on clusters of GPU and CPU

T-1024x1024-1coreCPU T-512x1024-1coreCPU T-512x512-1coreCPU T-1024x1024-1nodeCPU T-512x1024-1nodeCPU T-512x512-1nodeCPU T-1024x1024-1nodeGPU T-512x1024-1nodeGPU T-512x512-1nodeGPU

256 INTEL dual-core nodes 1 CISCO 256-ports switch, Gigabit-eth 16 INTEL dual-core nodes 1 GPU (GeForce 8800 GT) / node 1 DELL 24-ports switch, Gigabit-eth

Comparison to a multi‐core CPU cluster (using all CPU cores): 16 GPU nodes run 2.83 times faster than 256 CPU nodes

slide-7
SLIDE 7

1 ‐ Happily parallel application

Comparison to a multi‐core CPU cluster (using all CPU cores): 16 GPU nodes consume 28.3 times less than 256 CPU nodes

1E+0 1E+1 1E+2 1E+3 1E+4 1 2 4 8 16 32 64 128 256 Consummed Watt.h Nb of nodes

Asian Pricer on clusters of GPU and CPU

W.h-1024x1024-CPU W.h-512x1024-CPU W.h-512x512-CPU W.h-1024x1024-GPU W.h-512x1024-GPU

GPU cluster is 2.83x28.3 = 80.1 times more efficient

slide-8
SLIDE 8

2 – « Real parallel » code experiments: Parallel codes including communications

  • 2D relaxation (frontier exchange)
  • 3D transport PDE solver

Sylvain Contassot‐Vivier Stephane Vialle Thomas Jost Wilfried Kirschenmann 2009

slide-9
SLIDE 9

2 – Parallel codes including comms.

These algorithms remain synchronous and deterministic But coarse and fine grained parallel codes have to be jointly designed  Developments become more complex

… Internode CPU communications Local CPU  GPU data transfers Local GPU computations Local GPU  CPU partial result transfers Local CPU computations (not adapted to GPU processing) Internode CPU communications Local CPU  GPU data transfers …

More synchronization issues between CPU and GPU tasks More complex buffer and indexes management:

One data has a global index, node cpu‐buffer index, node gpu‐buffer index, a fast‐shared‐memory index in a sub‐part of the GPU…

slide-10
SLIDE 10

2 – Parallel codes including comms.

Developments become (really) more complex  Less software engineers can develop and maintain parallel code including communications on a GPU cluster GPU accelerate only some parts of the code GPU requires more data transfer overheads (CPU GPU)  Is it possible to speedup on a GPU cluster ?  Is it possible to speedup enough to save energy ?

slide-11
SLIDE 11

2 – Parallel codes including comms.

1E+0 1E+1 1E+2 1E+3 1E+4 1E+5 1 10 100 Execution time (s) Number of nodes

Pricer ‐ parallel MC

1E+0 1E+1 1E+2 1E+3 1E+4 1 10 100 Energy (Wh) Number of nodes

Pricer – parallel MC

1E+0 1E+1 1E+2 1E+3 1 10 100 Execution time (s) Number of nodes

PDE Solver ‐ Synchronous

1E+0 1E+1 1E+2 1 10 100 Energy (Wh) Number of nodes

PDE Solver ‐ Synchronous

1E+1 1E+2 1E+3 1E+4 1 10 100 Execution time (s) Number of nodes

Jacobi Relaxation

1E+0 1E+1 1E+2 1E+3 1 10 100 Energy (Wh) Number of nodes

Jacobi Relaxation

Monocore‐CPU cluster Multicore‐CPU cluster Manycore‐GPU cluster

slide-12
SLIDE 12

Rmk: Which comparison ? Which reference ?

Number of nodes Jacobi ‐ Gains vs multicore CPU‐cluster SU ncoreGPU vs ncoreCPU‐cluster ED ncoreGPU vs multicoreCPU‐cluster 1 10 Number of nodes 2D Relaxation ‐ Gains vs 1 monocore‐node SU ncore‐GPU vs 1monocore‐node‐CPU EG ncore GPU vs 1monocore‐node‐CPU 1 10 Number of nodes Jacobi Relaxation ‐ Gains vs 1 multicore‐node SU ncore‐GPU vs 1multicore‐node‐CPU EG ncore GPU vs 1monocore‐node‐CPU 1 10

You have a GPU cluster  you have a CPU cluster! You succeed to program a GPU cluster  you can program a CPU cluster! Compare a GPU cluster to a CPU cluster (not to one CPU core…) when possible Comparison will be really different

1 2 3

2 – Parallel codes including comms.

slide-13
SLIDE 13

2 – Parallel codes including comms.

Up to 16 nodes this GPU cluster is more interesting than our CPU cluster, but its interest decreases…

Speedup Energy gain

1E+0 1E+1 1E+2 1 10 100 GPU cluster vs multicore CPU cluster Number of nodes

Jacobi Relaxation

Oops…

1E+0 1E+1 1E+2 1E+3 1 10 100 GPU cluster vs multicore CPU cluster Number of nodes

Pricer – parallel MC

OK

1E+0 1E+1 1E+2 1 10 100 GPU cluster vs multicore CPU cluster Number of nodes

PDE Solver ‐ synchronous

Hum…

Temporal gain (speedup) & Energy Gain

  • f GPU cluster vs CPU cluster:
slide-14
SLIDE 14

2 – Parallel codes including comms.

CPU cluster GPU cluster Computations T‐calc‐CPU If algorithm is adapted to GPU architecture: T‐comput‐GPU << T‐compu‐CPU else: do not use GPUs! Communications T‐comm‐CPU = T‐comm‐MPI T‐comm‐GPU = T‐transfert‐GPUtoCPU + T‐comm‐MPI + T‐transfert‐CPUtoGPU T‐comm‐GPU ≥ T‐comm‐CPU Total time T‐CPUcluster T‐GPUcluster < ? > T‐CPUcluster  For a given pb on a GPU cluster: T‐comm becomes strongly dominant and GPU cluster interest decreases

slide-15
SLIDE 15

3 – Asynchronous parallel code experiments: (asynchronous algorithm & asynchronous implementation)

  • 3D transport PDE solver

Sylvain Contassot‐Vivier Stephane Vialle 2009‐2010

slide-16
SLIDE 16

3 ‐ Async. parallel codes on GPU cluster

Asynchronous algo. provide implicit overlapping of communications and computations, and communications are important into GPU clusters. Asynchronous code should improve execution on GPU clusters specially on heterogeneous GPU cluster BUT :

  • Only some iterative algorithms can be turned into asynchronous

algorithms

  • The convergence detection of the algorithm is more complex

and requires more communications (than with synchronous algo)

  • Some extra iterations are required to achieve the same accuracy.
slide-17
SLIDE 17

3 ‐ Async. parallel codes on GPU cluster

Available synchronous PDE solver on GPU cluster (previous work) Operational asynchronous PDE solver on GPU cluster

  • 2 senior rechearchers in parallel computing
  • 1 year work

The most complex debug we have achieved ! … how to « validate » the code ? Rmk: asynchronous code on GPU cluster has awful complexity

slide-18
SLIDE 18

3 ‐ Async. parallel codes on GPU cluster

Execution time using 2 GPU clusters of Supelec:

  • 17 nodes Xeon dual‐core + GT8800
  • 16 nodes Nehalem quad‐core + GT285

GPUs & synchronous GPUs & asynchronous

T‐exec(s) T‐exec(s) Nb of fast nodes Nb of fast nodes

  • 2 interconnected

Gibagit switches

slide-19
SLIDE 19

3 ‐ Async. parallel codes on GPU cluster

GPU cluster & synchronous vs 1 GPU GPU cluster & asynchronous vs 1 GPU

Speedup vs 1 GPU:

  • asynchronous version achieves more regular speedup
  • asynchronous version achieves better speedup on high nb of nodes
  • Sync. Speedup vs seq.

Nb of fast nodes Nb of fast nodes

  • Sync. Speedup vs seq.
slide-20
SLIDE 20

3 ‐ Async. parallel codes on GPU cluster

GPU cluster & synchronous GPU cluster & asynchronous

Energy consumption:

  • sync. and async. energy consumption curves are (just) different

Nb of fast nodes Nb of fast nodes Energy consumption (W.h) Energy consumption (W.h)

slide-21
SLIDE 21

3 ‐ Async. parallel codes on GPU cluster

GPU cluster & synchronous vs 1 GPU

Energy overhead factor vs 1 GPU (overhead to minimize):

  • overhead curves are (just) « differents »

 no more global attractive solution !

Nb of fast nodes Nb of fast nodes Energy overhead factor Energy overhead factor

GPU cluster & asynchronous vs 1 GPU

slide-22
SLIDE 22

3 ‐ Async. parallel codes on GPU cluster

Speedup

Async vs sync speedup and async vs sync energy gain

  • Can be used to choose the version to run
  • But region frontiers are complex: need a fine model to predict
  • Async. better
  • Async. better

Energy gain

slide-23
SLIDE 23

3 ‐ Async. parallel codes on GPU cluster

Overview of asynchronous code expriments: Can lead to better performances on heterogeneous GPU clusters But:

  • Very hard to develop
  • Difficult to identify when it is better than a synchronous code

 Not the « magical solution » to improve performances

  • n GPU clusters

We are investigating new asynchronous approaches …

slide-24
SLIDE 24

4 – Synchronous parallel application including communications and designed for GPU clusters

  • American option pricer

Lokman Abbas‐Turki Stephane Vialle 2010‐2011‐2012

slide-25
SLIDE 25

4 – Sync. code designed for GPUs

American option pricing:

  • Non linear PDE problem
  • Many solutions does not require too much computations

BUT :

  • Have limited accuracy
  • Are not parallel (bad scaling when parallelized)

Our solution:

  • New mathematic approach

based on Maillavin calculus

  • Use Monte Carlo computation:

we have efficient solution on GPU

  • Design a BSP‐like parallel algorithm:

separated big computing steps and communication steps To get:

  • high quality results
  • GPU efficient code
  • scalable parallel

code on GPU cluster

slide-26
SLIDE 26

4 – Sync. code designed for GPUs

20 40 60 80 100 120 140 160 "5Stk‐16Ktt" "5Stk‐32Ktt" "5Stk‐64Ktt"

GPU vs CPU mono‐node performances

Speedup Energy Gain

Comparison on one node : CPU vs GPU

  • 1 INTEL 4‐core hyperthreaded (« Nehalem »)
  • 1 NVIDIA GTX480 (« Fermi »)

 The parallelization seems well adapted to GPU (it has been designed for this architecture) Parallel CPU and parallel GPU codes

CPU version is parallel but probably not

  • ptimized…
slide-27
SLIDE 27

4 – Sync. code designed for GPUs

2 8 32 128 512 1 2 4 8 16 T‐comput (s) Nb of nodes

Pricer AmerMal ‐ 5Stk

T‐256Ktt‐5Stk T‐128Ktt‐5Stk T‐64Ktt‐5Stk 1 2 4 8 16 32 64 1 2 4 8 16 Energy consumption (W.h) Number of nodes

Pricer AmerMal – 5Stk

256Ktt‐5Stk 128Ktt‐5Stk 64Ktt‐5Stk

Good scalability of parallel code on GPU cluster Energy consumption remains constant when using more nodes And results have high quality ! Missing exepriments on multicore CPU clusters… (long to measure…)

slide-28
SLIDE 28

4 – Sync. code designed for GPUs

After somes years of experience in « option pricing on GPU clusters »

  • Redesign of the mathematic approach
  • Identification of a solution accurate and adapted to GPU clusters
  • Many debug steps, many benchmarks‐perf analysis‐optimization
  • Good results and performances!
  • Still a bottleneck in the code limits the full scalability…

… under improvement.

  • Has required long development times

1‐2 years (part time) 1 mathematician, with strong knowledge in GPGPU 1 computer scientist in parallel computing (and GPGPU)

slide-29
SLIDE 29

5 – Can GPU clusters decrease the energy consumption ?

slide-30
SLIDE 30

5 – GPU cluster energy consumption

Development time Tdev ↗ Electrical Power P (Watt) ↗ Execution Time Te (s) ↘ Flops/Watt ratio ↗ (usually)  Energy consumption (W.h (Joule)) …. ??? In all our experiments: Te decreases  Energy decreases « Te decreases stronger than P increases » But sometimes Speedup and Energy Gain are low (< 5) ! Warning ! Electrical Power increase can require some changes: Improve the electrical network ! Increase of the electrical subscription ! Improve the maximal electrical production … When using GPUs

slide-31
SLIDE 31

5 – GPU cluster energy consumption

Different use‐cases when you add GPUs in a PC cluster:

  • Limited amount of computations to run

(unsaturated machines) During computations : P ↗, Te ↘, Flops/Watt ↗ …… and E ↘ When machine is unused and switched on : P ↗ …… and E ↗ An unused and switched on GPU cluster wastes a lot of energy (under improvement ?)

  • Add GPUs and reduce the nb of nodes: total Flops unchanged

P ↘, Te ↘, Flops/Watt ↗ …… and E ↘ But applications not adapted to GPU will run slowly !

slide-32
SLIDE 32

5 – GPU cluster energy consumption

Different use‐cases when you add GPUs in a PC cluster:

  • Add GPU in each node: increase the total Flops

If unlimited amount of computations to run (saturated machines) P ↗, Te ↘, Flop/Watt ↗ …… but E ↗ Each computation is faster and less consuming But more and more computations are run

slide-33
SLIDE 33

Conclusion

GPU and GPU‐clusters remain complex to program to achieve high performances:

  • Re‐design mathematic solutions
  • Optimize code for GPU clusters
  • Compare to multicore CPU clusters

Add GPUs in a PC cluster increase the electrical power dissipation:

  • Poor usage of GPUs will waste (a lot of) energy

GPU is a « vector co‐processor » with high impact:

  • Can speedup application and reduce the energy consumption

and satisfy users

  • Can be not adapted to a code and can increase the energy

consumption … and make users angry! Analyse the requirements and knowledge of users before to install (actual) GPUs

slide-34
SLIDE 34

Questions ?

AlGorille INRIA Project Team

Energy issues of GPU computing clusters
