Emerging NVM Enabled Storage Architecture: From Evolution to - - PowerPoint PPT Presentation

1

Yiran Chen

Electrical and Computer Engineering University of Pittsburgh Sponsors: NSF, DARPA, AFRL, and HP Labs

Emerging NVM Enabled Storage Architecture:

From Evolution to Revolution.

2

Outline

• Introduction
• Evolution with eNVM:

– On‐chip high speed storage; – Off‐chip secondary storage;

• Revolution with eNVM:

– Memristor‐based neuromorphic accelerator

• Conclusion

3

Conventional Memory Scaling

2012 – 2013 38nm ‐ 32nm M: Stacked MIM P: Planar A: 6F2, bWL G: poly/SiO2 C: Si V: 1.35V 2014 – 2015 29nm ‐ 22nm M: Stacked MIM P: Planar, HKMG A: 6F2, bWL G: HKMG C: Si V: 1.2V 2016 – 2017 22nm ‐ 16nm M: Stacked MIM P: Planar A: 6F2, bBL, LBL, 1T1C(VFET) G: HKMG C: Si V: 1.1V 2018 – 2019 16nm ‐ 14nm M: FBRAM, STT‐RAM, RRAM, PCRAM P: Planar A: 4F2, 1T, 1T1R, 1TMTJ (VFET) G: HKMG C: Si V: ~1V

Burj Khalifa A/R=6

100 20 80 60 40

Aspect Ratio A/R

60 50 40 30 20 11Å 9Å 8Å 7Å 5Å 3Å TOX

Technology Node

1990 2000 2010 101 102 103 104

Mb/Chip

EDO 50 SDRAM 133 DDR1 200-400 DDR2 400-800 DDR3 800-1600

Mbps

Sources: ASML, ITRS, IMEC, Hynix, IBM

Intrinsic difficulty of charge-based com puting and storage!

4

Emerging Nonvolatile Memory

5

Memory Technologies Comparison

ReRAM >10 y <1 1015 None STT‐RAM >10 y 8 1015 None NAND FLASH 10y 4 0.1 ms 1/0.1 ms 105 High None PCRAM >10 y 4 12 ns <50 ns 108 Low None DRAM 4 ms 7‐9 2 ns 1 ns 1016 Low Refresh Power SRAM N 120‐140 0.2 ns 70 ps 1016 Low Leakage Current Data Retention Memory Cell (F2) Read Time Write/Erase Time Number of Rewrites Power Consumption Read/Write Power Consumption

• ther than R/W

N 4 ms 0.1 ms

1/0.1ms

<50 ns Leakage Current Refresh Power High >10 y >10 y

5‐10 ns 5‐10 ns <10 ns <10 ns

5‐10 ns <10 ns <10 ns 5‐10 ns

Low Low

Low Low None None

Source: ITRS ERD workshop presentation by Prof. Y. Chen

6

6

Challenges:

• Identifying the evolutional applications that can

– Easily and seamlessly integrated into the current memory hierarchy and computing platform; – Fully leverage the advantages of emerging NVM; – Not be easily replaced by other alternative technology or architecture.

• Inventing a revolutionary computing and storage

architecture that can

– Offer a high‐performance, power efficient, and scalable computing model; – Provide a truly seamless integration between computing and memory.

7

Outline

• Introduction
• Evolution with eNVM:

– On‐chip high speed storage;

• STT‐RAM based 3D cache for CPU.
• Racetrack based register file for GPU.

– Off‐chip secondary storage;

• Revolution with eNVM:

– Memristor‐based neuromorphic accelerator.

• Conclusion

8

Writing ‘1’

1T‐1MTJ STT‐RAM Schematic

STT‐RAM based 3D cache

Spin‐Transfer Torque Random Access Memory

Source‐line MTJ Reference Layer Free Layer Bit‐line Word‐line

A scalable technology Writing ‘0’

MgO Layer

Magnetic tunneling junction

9

• Pros: Low leakage power, high density.
• Cons: Long write latency and large write power

SRAM vs. MRAM (STT‐RAM)

Area (65nm) 3.66mm2 SRAM 3.30mm2 MRAM Capacity/Bank 128KB 512KB Read latency 2.25ns 2.32ns Write latency 2.26ns 11.02ns Read energy 0.90nJ 0.86nJ Write energy 0.80nJ 5.00nJ Cache configurations Leakage power 2MB (16x128KB) SRAM cache 2.09W 8MB (16x512KB) MRAM cache 0.26W

10

STT‐RAM based 3D cache

• Baseline 3D Architecture

– Core Layer + Cache Layers. – NUCA caches with NOC connections. Layer 1 Cache Controller Core Layer 2 TSV Cache Bank Router

Cache Bank Cache Bank Cache Bank Cache Bank

R R R R

Horizontal Hop Vertical Hop Data Migration

• G. Sun, X. Dong, Y. Xie, J. Li, Y. Chen, HPCA, 2009.

11

STT‐RAM based 3D cache

• Challenges: long write latency of STT‐RAM.
• Solution 1 (S1): Read‐Preemptive Write Buffer.

STT-RAM Caches

Cores

Write Op. Read Op. Read Op. Read Data Read Data

Write Buffer (FIFO)

Write Req. Read Req. Write just begins. Write is alm ost done.

12

STT‐RAM based 3D cache

• Solution S2: SRAM‐MRAM Hybrid L2 Cache

Core Core Core Core

MRAM Bank TSV

Core Core Core Core

SRAM Bank

32-Way STT-RAM 31-Way STT-RAM & 1-Way SRAM

13

STT‐RAM based 3D cache

• Result (S1 & S2):

– Performance is improved by 4.91% compared with STT‐RAM baseline. – Power consumption is reduced by 73.5%.

0.2 0.4 0.6 0.8 1

2M-SRAM-DNUCA 8M-MRAM-DNUCA 8M Hybrid DNUCA

0.2 0.4 0.6 0.8 1 IPC Power

14

Outline

• Introduction
• Evolution with eNVM:

– On‐chip high speed storage;

• STT‐RAM based 3D cache for CPU.
• Racetrack based register file for GPU.

– Off‐chip secondary storage;

• Revolution with eNVM:

– Memristor‐based neuromorphic accelerator.

• Conclusion

15

Racetrack for GPU

• Racetrack cell:

– Two fixed pinning regions: free region, and fix region – Write `0’ – Write `1’ – Read WWL RWL SL BL

Pinning layer Pinning layer Free layer Reference layer

• Racetrack

– Racetrack‐magnetic track – Inject current to move cell – Access port

16

Racetrack for GPU

• Benefits from Racetrack:

– Extremely small cell size;

• Major challenges:

– Shifting caused delay/energy.

• Warp register remapping (WRR)

– 60.0% RF are allocated during the execution – Non‐optimal warp register mapping, max shift distance —8‐cell – WRR, interleaves the warp registers across the access ports, max shift distance—4‐cell

WWL RWL WWL RWL …...

SL BL SL BL SL BL SL BL

Row Decoder Write/Read/Shifter Driver Column Mux Sense Amplifier Arrays Shift Controller

Arbitrator Warp 0 Warp 0

• M. Mao, W. Wen, Y. Zhang, Y. Chen, H. Li, DAC 2014

17

Racetrack for GPU

• Write buffer

– “piggyback‐write” to write back to RF from write buffer; – Rely on the track movement triggered by the read requests; – Positive side‐effect: filter the redundant RF R/W by leveraging RAW and WAW.

1 3 2 4 8 7 9 6 5

To EXE/MEM

18

Racetrack for GPU

• Experiment results:

– Baseline: SRAM‐based register files. – Energy reduction: 59%. – Performance improvement: 4%.

19

Outline

• Introduction
• Evolution with eNVM:

– On‐chip high speed storage; – Secondary storage;

• PCRAM and NAND hybrid SSD;
• Revolution with eNVM:

– Memristor‐based neuromorphic accelerator.

• Conclusion

20

Hybrid SSD

• Memory hierarchy

Off-chip memory 100~300 cycles On-chip memory 1~30 cycles

Page mode ↓ Random access erase-before- write (EBW) ↓ In-place- update (IPU)

Courtesy: Al Fazio (Intel) Solid State Disk (Flash) 25K~2M cycles

PN=0, V

Erase Unit

PN=1, V PN=2, V

…

PN=n, V

X X

21

• One transistor/diode and one GST (GeSbTe).
• In‐place updating (IPU)

PRAM (PCM) Cell

High resistance: ‘0’ Low resistance: ‘1’

Top Electrode GST Substrate

Bottom Electrode

Heater +N Top Electrode GST Substrate

Bottom Electrode

Heater +N

Amorphous Crystalline

22

Hybrid SSD

• Conventional SSD: FLASH.
• Promising candidate: PRAM (Phase change).
• To combine benefits of

both technologies: – Hybrid SSD.

• Two usage:

– Performance; – Reliability.

23

Hybrid SSD: performance enhancement

PN=0, V

Erase Unit 1

PN=1, V PN=2, V

…

PN=n, V

PN=Page Number; V=Valid; I=Invalid

Erase Unit 2

…

PN=0, V

Erase Unit 3

PN=1, V PN=2, V

…

PN=n, V PN=n, I (Empty Pages) PN=2, V PN=2, I PN=n, V

Merge Operation (time consuming)

Erase Unit = 128/ 256KB, Page = 512Bytes ~ 8KB

G.Sun, Y. Joo, Y. Chen, Y. Xie, Y.Chen, H. Li, HPCA, 2010.

24

Hybrid SSD: performance enhancement

… …

Data Region

Data Buffer in Memory Hybrid Architecture Physical View Structural View

… …

Log Region NAND flash PRAM

Erase Unit In-place updating

Sector (512Bytes)

25

Different Log Assignments

Data Region Log Region

Erase Unit

Fixed Assignment

Data Region Log Region

Erase Unit

Organize log pages in group

Data Region Log Region

Erase Unit

Dynamic Assignment

Static log assignment Group log assignment Dynamic log assignment

26

Hybrid SSD: performance enhancement

27

Outline

• Introduction
• Evolution with eNVM:

– On‐chip high speed storage; – Secondary storage;

• Revolution with eNVM:

– Memristor‐based neuromorphic accelerator.

• Conclusion

28

Computing: Present and Future

2000 2010 1990 1000 100

Multi‐core

Clock Frequency (MHz)

New Trend:

• Multi‐core, advanced power management, large on‐chip storage.

Future:

• Heterogeneous system, Brain‐like computing.

Source: CPU DB, Intel Neural Network

2000 2010 1990

10000

Rocket Launch Nuclear Reactor Hot Plate

Power Density (mW/mm2)

1000 100

29 Gray matter White matter Neocortex 6 layers Signals travel within and between layers

Brain – The Most Efficient Computing Machine

Brain:

15–30B neurons Extremely complex

• rgan

4km/mm3 35w

Neuron:

Process signals from

• ther neurons.

Synapse:

Memory Weight signals Neural Network

30

Brain‐like Neuromorphic Circuits

Highly parallel Ultra power efficient Flexible Extremely robust

Real world input Human friendly output

Data friendly

Slow progress in neuoromoprhic hardware implementation

• Lack of efficient synapse design
• Not supportive to mass connection

31

10 20 30 40 50 60 70 300 400 500 600 700 Pulse number Resistance () 10 20 30 40 50 60 70

• 4
• 2

2 4 Voltage (V)

Memristor – Rebirth of Neuromorphic Circuits

• Two terminal, high density
• Non‐volatility
• Analog/multi‐level states
• Natural matrix function
• A MIMO system
• Good combination with memristor

Memristor ↔ Synapse Crossbar ↔ Network

TaN1+x

HP lab, 2012

EI lab, DAC’12

2 3 4 i i+1 n 1 2 3 j-1 j n-1 n 1

EI lab, APL’13 EI lab & HP lab TiN-TaOx device, pulses grows linearly in am plitude

32

Conclusion

• Emerging nonvolatile memory technology (NVM) such as

STT‐RAM, racetrack, PRAM delivers significant improvement for various applications.

• Challenges exist and can be solved by architecture level
• ptimization.
• Innovation of revolutionary architecture which provides

Multi‐order speedup, power efficiency improvement, and hardware cost reduction is promised.
