Electric Vehicle Charging State of the Art

and

Understanding EV Alphabet Soup

Presented By

slide-2
SLIDE 2

What Infrastructure is Required to Charge Electric Vehicles? What Types of Electric Vehicles Are Out on the Road Today? Why Should You, Your Company and Your Facility Care?

slide-3
SLIDE 3

What Exotic Infrastructure is Required to Charge Electric Vehicles?

15 Amp 120 VAC Ground Fault Outlet

slide-4
SLIDE 4

What Exotic Infrastructure is Required to Charge Electric Vehicles?

Every home built since 1971 has several, but maybe not in the right place…

slide-5
SLIDE 5

What Exotic Infrastructure is Required to Charge Electric Vehicles?

20 Amp 120 VAC Outlet with Ground Fault Breaker

slide-6
SLIDE 6

Level 1 (L1) Charging Works with Any Electric Vehicle

  • n the Road Today

Adds 5 Miles of Range per Hour

slide-7
SLIDE 7

Level 1 (L1) Charging

40 Miles in an 8 Hour Workday

slide-8
SLIDE 8

Level 1 (L1) Charging

Inexpensive Outdoor Rated Level 1 Equipment is Available

slide-9
SLIDE 9

What Exotic Infrastructure is Required to Charge Electric Vehicles?

slide-10
SLIDE 10

Level 2 (L2) Charging

slide-11
SLIDE 11

240 VAC 40 Amp Circuit Works with Any Currently Produced Electric Vehicle Adds 15 to 30 Miles of Range per Hour

slide-12
SLIDE 12

Same as an electric clothes dryer circuit

slide-13
SLIDE 13

L2 Standardized Plug AC Line 1 Neutral AC Line 2

slide-14
SLIDE 14

L2 Standardized Plug

Communication with Car Communication with Car

slide-15
SLIDE 15

Why Communicate with the Car?

So this doesn’t happen!

Electric Vehicles refuse to move while plugged in

slide-16
SLIDE 16

Tesla High Power Wall Connector

Mile a Minute Recharging for Tesla Motors Model S and X Charging cost

  • f about 2¢

per minute

slide-17
SLIDE 17

Tesla Roadster Can Use Standard L2 with an Adapter

slide-18
SLIDE 18

Tesla Model S and X Can Use Standard L2 with an Adapter

slide-19
SLIDE 19

Tesla Supercharger

170 Miles of Range in 30 Minutes

slide-20
SLIDE 20

New and Hard to Find?

At Home Depot and Lowe’s

slide-21
SLIDE 21

New and Hard to Find?

Grainger Industrial Supply

slide-22
SLIDE 22

New and Hard to Find?

Amazon. com

slide-23
SLIDE 23

New and Hard to Find?

Best Buy

slide-24
SLIDE 24

New and Hard to Find?

Online Specialty Supplier Metro Plug-In

slide-25
SLIDE 25

All Electrical Equipment Companies Make Them

slide-26
SLIDE 26

All Electrical Equipment Companies Make Them

slide-27
SLIDE 27

All Electrical Equipment Companies Make Them

slide-28
SLIDE 28

All Electrical Equipment Companies Make Them

slide-29
SLIDE 29

DC Fast Charge (DCFC)

slide-30
SLIDE 30

DC Fast Charge (DCFC)

Combination DCFC Units provide both CHAdeMO and SAE connectors to quickly recharge any make of EV which is equipped for DC Charging

slide-31
SLIDE 31

480 VAC 3ɸ Circuit Works with properly equipped Nissan, BMW, Chevy, VW, KIA, Honda and Mitsubishi Vehicles Adds 80+ Miles of Range in ½ Hour

slide-32
SLIDE 32

Just long enough for…

slide-33
SLIDE 33

EVSE HEV PHEV REEV BEV NEV

EV Alphabet Soup

slide-34
SLIDE 34

EVSE Electric Vehicle Supply Equipment

slide-35
SLIDE 35

The “Charger” is in the Car

Speed of charging is negotiated between car and EVSE and is determined by the capacity of both

slide-36
SLIDE 36

Connectors on the Car

slide-37
SLIDE 37

HEV Hybrid Electric Vehicle

slide-38
SLIDE 38

PHEV Plug-In Hybrid Electric Vehicle

slide-39
SLIDE 39

NEV Neighborhood Electric Vehicle

slide-40
SLIDE 40

REEV Range Extended Electric Vehicle

slide-41
SLIDE 41

BEV Battery Electric Vehicle

slide-42
SLIDE 42

BEV Battery Electric Vehicle

slide-43
SLIDE 43

BEV Battery Electric Vehicle

slide-44
SLIDE 44

BEV - Conversions Battery Electric Vehicle

slide-45
SLIDE 45

BEV – New and Unproven? Battery Electric Vehicle

2012 1918

slide-46
SLIDE 46

BEV – Just Small Cars? Battery Electric Vehicle

slide-47
SLIDE 47

BEV – Just Small Cars? Battery Electric Vehicle

slide-48
SLIDE 48

National Security Less Foreign Oil Cleaner Environment Fun to Drive!

slide-49
SLIDE 49

Lower Operating Cost Near Zero Maintenance

slide-50
SLIDE 50

Installation Hints

EV Etiquette Allows Another EV Driver to Unplug Someone Else’s Fully-Charged EV

slide-51
SLIDE 51

Installation Hints

L2 EVSE L2 EVSE L2 EVSE

So…one charging unit can service multiple spaces

slide-52
SLIDE 52

Installation Hints

L2 EVSE L2 EVSE

Place one unit adjacent to ADA accessible space

slide-53
SLIDE 53

Installation Hints

Parking bumpers prevent EVSE damage for curb mounted units…

slide-54
SLIDE 54

Installation Hints

…because you never allow cords to cross walkways and create a tripping hazard

slide-55
SLIDE 55

Installation Hints

Locating between spaces can be a good alternative to front of spaces

slide-56
SLIDE 56

Installation Hints

Installation to the side can avoid cutting pavement

slide-57
SLIDE 57

Installation Hints

Including a 20 Amp 120 VAC

  • utlet

provides backup Level 1 charging

slide-58
SLIDE 58

Installation Hints

Solar carports let vehicles drive on sunlight for true zero emissions

slide-59
SLIDE 59
