Eigenvalues of Graphs Operator Theory and Krein Spaces (dedicated to the memory of Hagen Neidhardt) Samuel Mohr December 20, 2019 Institut fr Mathematik Technische Universitt Ilmenau Gefrdert durch die Deutsche Forschungsgemeinschaft

slide-1
SLIDE 1

Eigenvalues of Graphs

Operator Theory and Krein Spaces (dedicated to the memory of Hagen Neidhardt)

Samuel Mohr December 20, 2019

Institut für Mathematik Technische Universität Ilmenau Gefördert durch die Deutsche Forschungsgemeinschaft (DFG) – Projektnummer 327533333

slide-2
SLIDE 2

Introduction Eigenvalues Spectrum

??

What is a graph? And why am I speaking about graphs?

Samuel Mohr Eigenvalues of Graphs December 20, 2019 2

slide-3
SLIDE 3

Introduction Eigenvalues Spectrum

Graphs

A graph is a combinatorial object consisting of a fjnite set of vertices and links, which connect ver- tices and are called edges.

G V E

Samuel Mohr Eigenvalues of Graphs December 20, 2019 3

slide-4
SLIDE 4

Introduction Eigenvalues Spectrum

Graphs

A graph is a combinatorial object consisting of a fjnite set of vertices and links, which connect ver- tices and are called edges.

G V E

Samuel Mohr Eigenvalues of Graphs December 20, 2019 3

slide-5
SLIDE 5

Introduction Eigenvalues Spectrum

Graphs

A graph is a combinatorial object consisting of a fjnite set of vertices and links, which connect ver- tices and are called edges.

G V E

Samuel Mohr Eigenvalues of Graphs December 20, 2019 3

slide-6
SLIDE 6

Introduction Eigenvalues Spectrum

Graphs

A graph is a combinatorial object consisting of a fjnite set of vertices and links, which connect ver- tices and are called edges.

G V E

Samuel Mohr Eigenvalues of Graphs December 20, 2019 3

slide-7
SLIDE 7

Introduction Eigenvalues Spectrum

Graphs

A graph is a combinatorial object consisting of a fjnite set of vertices and links, which connect ver- tices and are called edges.

G = (V, E)

Samuel Mohr Eigenvalues of Graphs December 20, 2019 3

slide-8
SLIDE 8

Introduction Eigenvalues Spectrum

Graphs

A graph is a combinatorial object consisting of a fjnite set of vertices and links, which connect ver- tices and are called edges.

G = (V, E)

Samuel Mohr Eigenvalues of Graphs December 20, 2019 3

slide-9
SLIDE 9

Introduction Eigenvalues Spectrum

Applications

Algorithms.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 4

slide-10
SLIDE 10

Introduction Eigenvalues Spectrum

Applications

Algorithms.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 4

slide-11
SLIDE 11

Introduction Eigenvalues Spectrum

Applications

Algorithms.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 4

slide-12
SLIDE 12

Introduction Eigenvalues Spectrum

Applications

− → Algorithms.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 4

slide-13
SLIDE 13

Introduction Eigenvalues Spectrum

Theoretical Aspects

Structure, Connectedness, Eigenvalues

Samuel Mohr Eigenvalues of Graphs December 20, 2019 5

slide-14
SLIDE 14

Introduction Eigenvalues Spectrum

Theoretical Aspects

Structure, Connectedness, Eigenvalues

Samuel Mohr Eigenvalues of Graphs December 20, 2019 5

slide-15
SLIDE 15

Introduction Eigenvalues Spectrum

Theoretical Aspects

Structure, Connectedness, Eigenvalues

Samuel Mohr Eigenvalues of Graphs December 20, 2019 5

slide-16
SLIDE 16

Introduction Eigenvalues Spectrum

Defjnition

Let G = (V, E) be a graph, V = {1, 2, . . . , n}. Then AG ∈ Rn×n with AG(x, y) =    1 if {x, y} ∈ E,

  • therwise,

is the adjacency matrix of G. is eigenvalue of G if is eigenvalue of AG.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 6

slide-17
SLIDE 17

Introduction Eigenvalues Spectrum

Defjnition

Let G = (V, E) be a graph, V = {1, 2, . . . , n}. Then AG ∈ Rn×n with AG(x, y) =    1 if {x, y} ∈ E,

  • therwise,

is the adjacency matrix of G. λ is eigenvalue of G if λ is eigenvalue of AG.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 6

slide-18
SLIDE 18

Introduction Eigenvalues Spectrum

Theorem of Perron and Frobenius

Theorem (Perron-Frobenius) Let A ∈ Rn×n

≥0 , n ≥ 2 be symmetric and irreducible and let

λ1(A) ≥ λ2(A) ≥ · · · ≥ λn(A) eigenvalues of A. Then:

1 λ1(A) is positive, has algebraic multiplicity one, and λ1(A) ≥ |λk(A)| for

k ∈ {1, . . . , n}. Furthermore, it is the only eigenvalue that has a eigenvector with only positive entries.

2 λ1(A) = −λn(A) if and only if A looks like

0 B

BT 0

  • r can be transformed by

simultaneous row and column changes of A.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 7

slide-19
SLIDE 19

Introduction Eigenvalues Spectrum

Consequences

Theorem (Perron-Frobenius)

1 λ1(A) is positive, has algebraic multiplicity one, and λ1(A) ≥ |λk(A)| for

k ∈ {1, . . . , n}. Furthermore, it is the only eigenvalue that has a eigenvector with only positive entries. Largest eigenvalue is: positive, multiplicity 1, smaller or equal maximum degree, is k if G is k-regular.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 8

slide-20
SLIDE 20

Introduction Eigenvalues Spectrum

Consequences

Theorem (Perron-Frobenius)

1 λ1(A) is positive, has algebraic multiplicity one, and λ1(A) ≥ |λk(A)| for

k ∈ {1, . . . , n}. Furthermore, it is the only eigenvalue that has a eigenvector with only positive entries. Largest eigenvalue is: positive, multiplicity 1, smaller or equal maximum degree, is k if G is k-regular.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 8

slide-21
SLIDE 21

Introduction Eigenvalues Spectrum

Consequences

Theorem (Perron-Frobenius)

1 λ1(A) is positive, has algebraic multiplicity one, and λ1(A) ≥ |λk(A)| for

k ∈ {1, . . . , n}. Furthermore, it is the only eigenvalue that has a eigenvector with only positive entries. Largest eigenvalue is: positive, multiplicity 1, smaller or equal maximum degree, is k if G is k-regular.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 8

slide-22
SLIDE 22

Introduction Eigenvalues Spectrum

Consequences

Theorem (Perron-Frobenius)

1 λ1(A) is positive, has algebraic multiplicity one, and λ1(A) ≥ |λk(A)| for

k ∈ {1, . . . , n}. Furthermore, it is the only eigenvalue that has a eigenvector with only positive entries. Largest eigenvalue is: positive, multiplicity 1, smaller or equal maximum degree, is k if G is k-regular.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 8

slide-23
SLIDE 23

Introduction Eigenvalues Spectrum

Consequences

Theorem (Perron-Frobenius)

2 λ1(A) = −λn(A) if and only if A looks like

0 B

BT 0

  • r can be transformed by

simultaneous row and column changes of A. If λ1(A) = −λn(A), then: V = A ˙ ∪ B, no edge between any two vertices from A (respectively B), G is bipartite.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 9

slide-24
SLIDE 24

Introduction Eigenvalues Spectrum

Consequences

Theorem (Perron-Frobenius)

2 λ1(A) = −λn(A) if and only if A looks like

0 B

BT 0

  • r can be transformed by

simultaneous row and column changes of A. If λ1(A) = −λn(A), then: V = A ˙ ∪ B, no edge between any two vertices from A (respectively B), G is bipartite.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 9

slide-25
SLIDE 25

Introduction Eigenvalues Spectrum

Consequences

Theorem (Perron-Frobenius)

2 λ1(A) = −λn(A) if and only if A looks like

0 B

BT 0

  • r can be transformed by

simultaneous row and column changes of A. If λ1(A) = −λn(A), then: V = A ˙ ∪ B, no edge between any two vertices from A (respectively B), G is bipartite.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 9

slide-26
SLIDE 26

Introduction Eigenvalues Spectrum

Independence Number

Petersen-Graph: Independence Number G 4. For regular graphs:

  • A. J. Hofgman, unpublished.

G

n 1 n

n and many other bounds … Eigenvalues: 3, 1, and -2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 10

slide-27
SLIDE 27

Introduction Eigenvalues Spectrum

Independence Number

Petersen-Graph: Independence Number G 4. For regular graphs:

  • A. J. Hofgman, unpublished.

G

n 1 n

n and many other bounds … Eigenvalues: 3, 1, and -2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 10

slide-28
SLIDE 28

Introduction Eigenvalues Spectrum

Independence Number

Petersen-Graph: Independence Number G 4. For regular graphs:

  • A. J. Hofgman, unpublished.

G

n 1 n

n and many other bounds … Eigenvalues: 3, 1, and -2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 10

slide-29
SLIDE 29

Introduction Eigenvalues Spectrum

Independence Number

Petersen-Graph: Independence Number α(G) = 4. For regular graphs:

  • A. J. Hofgman, unpublished.

G

n 1 n

n and many other bounds … Eigenvalues: 3, 1, and -2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 10

slide-30
SLIDE 30

Introduction Eigenvalues Spectrum

Independence Number

Petersen-Graph: Independence Number α(G) = 4. For regular graphs:

  • A. J. Hofgman, unpublished.

α(G) ≤ −λn λ1 − λn · n. and many other bounds … Eigenvalues: 3, 1, and -2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 10

slide-31
SLIDE 31

Introduction Eigenvalues Spectrum

Independence Number

Petersen-Graph: Independence Number α(G) = 4. For regular graphs:

  • A. J. Hofgman, unpublished.

α(G) ≤ −λn λ1 − λn · n. and many other bounds … Eigenvalues: 3, 1, and -2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 10

slide-32
SLIDE 32

Introduction Eigenvalues Spectrum

Eigenvalues of Graphs

Observation Eigenvalues of graphs describe its structure: Maximum degree, bipartite?, independence number, many more … Note The choice of 0 (representing equality), 1 (if there is an edge), and 0 (no edge) in AG was rather arbitrary.

  • ther representing matrices of graphs.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 11

slide-33
SLIDE 33

Introduction Eigenvalues Spectrum

Eigenvalues of Graphs

Observation Eigenvalues of graphs describe its structure: Maximum degree, bipartite?, independence number, many more … Note The choice of 0 (representing equality), 1 (if there is an edge), and 0 (no edge) in AG was rather arbitrary. − → other representing matrices of graphs.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 11

slide-34
SLIDE 34

Introduction Eigenvalues Spectrum

Defjnition

The spectrum of a graph G is the spectrum of its adjacency matrix AG, that is, its set of eigenvalues together with their multiplicities.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 12

slide-35
SLIDE 35

Introduction Eigenvalues Spectrum

Examples

Petersen-Graph:

0 1 0 0 1 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0 0 1 1 0 0 1 0 0 0 0 0 0 1 1 0 0 1 0 0 1 0 0 0 1 0 0 0 1 0 1 1 0 0 0 0 0 0 0 1 0 1 1 0 0

Eigenvalues: 3 1 1 1 1 1

5 times

2 2 2 2

4 times

Samuel Mohr Eigenvalues of Graphs December 20, 2019 13

slide-36
SLIDE 36

Introduction Eigenvalues Spectrum

Examples

Petersen-Graph:

     

0 1 0 0 1 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0 0 1 1 0 0 1 0 0 0 0 0 0 1 1 0 0 1 0 0 1 0 0 0 1 0 0 0 1 0 1 1 0 0 0 0 0 0 0 1 0 1 1 0 0

     

Eigenvalues: 3 1 1 1 1 1

5 times

2 2 2 2

4 times

Samuel Mohr Eigenvalues of Graphs December 20, 2019 13

slide-37
SLIDE 37

Introduction Eigenvalues Spectrum

Examples

Petersen-Graph:

     

0 1 0 0 1 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0 0 1 1 0 0 1 0 0 0 0 0 0 1 1 0 0 1 0 0 1 0 0 0 1 0 0 0 1 0 1 1 0 0 0 0 0 0 0 1 0 1 1 0 0

     

Eigenvalues: 3, 1, 1, 1, 1, 1

  • 5 times

, −2, −2, −2, −2

  • 4 times

Samuel Mohr Eigenvalues of Graphs December 20, 2019 13

slide-38
SLIDE 38

Introduction Eigenvalues Spectrum

Examples

Petersen-Graph:

     

0 1 0 0 1 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0 1 1 1 0 0 1 0 0 0 1 0 0 1 1 0 0 1 0 0 1 0 0 0 1 0 0 0 1 0 1 1 0 0 0 0 0 0 0 1 0 1 1 0 0

     

Eigenvalues: 3, 1, 1, 1, 1, 1

  • 5 times

, −2, −2, −2, −2

  • 4 times

Samuel Mohr Eigenvalues of Graphs December 20, 2019 13

slide-39
SLIDE 39

Introduction Eigenvalues Spectrum

Examples

Petersen-Graph:

     

0 1 0 0 1 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0 1 1 1 0 0 1 0 0 0 1 0 0 1 1 0 0 1 0 0 1 0 0 0 1 0 0 0 1 0 1 1 0 0 0 0 0 0 0 1 0 1 1 0 0

     

Eigenvalues: 3.2, 1.3, 1, 1, 1, 0.4

  • 1’s

, −1.6, −2, −2, −2.4

  • 2’s

Samuel Mohr Eigenvalues of Graphs December 20, 2019 13

slide-40
SLIDE 40

Introduction Eigenvalues Spectrum

Examples

Petersen-Graph:

     

0 1 0 0 1 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0 1 1 1 0 0 1 0 0 0 1 0 1 1 1 0 0 1 0 0 1 1 0 0 1 0 0 0 1 0 1 1 0 0 0 0 0 0 0 1 0 1 1 0 0

     

Eigenvalues: 3.2, 1.3, 1, 1, 1, 0.4

  • 1’s

, −1.6, −2, −2, −2.4

  • 2’s

Samuel Mohr Eigenvalues of Graphs December 20, 2019 13

slide-41
SLIDE 41

Introduction Eigenvalues Spectrum

Examples

Petersen-Graph:

     

0 1 0 0 1 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 1 0 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0 1 1 1 0 0 1 0 0 0 1 0 1 1 1 0 0 1 0 0 1 1 0 0 1 0 0 0 1 0 1 1 0 0 0 0 0 0 0 1 0 1 1 0 0

     

Eigenvalues: 3.6, 1.4, 1, 1, 1, 0

  • 1’s

, −1.7, −2, −2, −2.3

  • 2’s

Samuel Mohr Eigenvalues of Graphs December 20, 2019 13

slide-42
SLIDE 42

Introduction Eigenvalues Spectrum

Interlacing

Two sequences of real numbers λ1 ≥ λ2 ≥ · · · ≥ λn and η1 ≥ η2 ≥ · · · ≥ ηm with n ≥ m interlace if λi ≥ ηi ≥ λn−m+i. Theorem (see Haemers – 1995) Let G be a graph and H be obtained from G by removing

  • vertices. Then the spectra of AG and AH interlace.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 14

slide-43
SLIDE 43

Introduction Eigenvalues Spectrum

Interlacing

Two sequences of real numbers λ1 ≥ λ2 ≥ · · · ≥ λn and η1 ≥ η2 ≥ · · · ≥ ηm with n ≥ m interlace if λi ≥ ηi ≥ λn−m+i. Theorem (see Haemers – 1995) Let G be a graph and H be obtained from G by removing

  • vertices. Then the spectra of AG and AH interlace.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 14

slide-44
SLIDE 44

Introduction Eigenvalues Spectrum

??

Is a graph uniquely determined by its spectrum?

Samuel Mohr Eigenvalues of Graphs December 20, 2019 15

slide-45
SLIDE 45

Introduction Eigenvalues Spectrum

Cospectral Graphs

Eigenvalues: −2, 0, 0, 0, 2. Eigenvalues: 2 0 0 0 2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 16

slide-46
SLIDE 46

Introduction Eigenvalues Spectrum

Cospectral Graphs

Eigenvalues: −2, 0, 0, 0, 2. Eigenvalues: −2, 0, 0, 0, 2.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 16

slide-47
SLIDE 47

Introduction Eigenvalues Spectrum

Connected Cospectral Graphs

Eigenvalues: ∼2.7, 1, ∼0.2, −1, −1, ∼−1.9. Eigenvalues: ∼2.7, 1, ∼0.2, −1, −1, ∼−1.9.

Samuel Mohr Eigenvalues of Graphs December 20, 2019 17

slide-48
SLIDE 48

Introduction Eigenvalues Spectrum

Problem

Observation Graphs are not uniquely determined by their spectra. Conjecture (Van Dam, Haemers – 2009) Almost every graph is determined by its spectrum. n 1-4 5 6 7 8 9 10 11 12 ratio 0.0 0.095 0.064 0.105 0.139 0.186 0.213 0.211 0.188

Samuel Mohr Eigenvalues of Graphs December 20, 2019 18

slide-49
SLIDE 49

Introduction Eigenvalues Spectrum

Problem

Observation Graphs are not uniquely determined by their spectra. Conjecture (Van Dam, Haemers – 2009) Almost every graph is determined by its spectrum. n 1-4 5 6 7 8 9 10 11 12 ratio 0.0 0.095 0.064 0.105 0.139 0.186 0.213 0.211 0.188

Samuel Mohr Eigenvalues of Graphs December 20, 2019 18

slide-50
SLIDE 50

Introduction Eigenvalues Spectrum

Problem

Observation Graphs are not uniquely determined by their spectra. Conjecture (Van Dam, Haemers – 2009) Almost every graph is determined by its spectrum. n 1-4 5 6 7 8 9 10 11 12 ratio 0.0 0.095 0.064 0.105 0.139 0.186 0.213 0.211 0.188

Samuel Mohr Eigenvalues of Graphs December 20, 2019 18

slide-51
SLIDE 51

Introduction Eigenvalues Spectrum

!!

Many thanks for listening!

Samuel Mohr Eigenvalues of Graphs December 20, 2019 19
