Efficient Object-Relational Mapping for JAVA and J2EE Applications – or the impact of J2EE on RDB

Marc Stampfli Oracle Software (Switzerland) Ltd.

According to customers about 20-50% percent of the time of developer is used for manual

• bject-relational mapping.

Underestimation

Managing persistence related issues is the most underestimated challenge in enterprise Java today – in terms of complexity, effort and maintenance

Doesn’t JDBC handle these issues?

Agenda

Impedance Mismatch Object Persistence Options J2EE Persistence Requirements J2EE Persistence Framework

Enterprise App. Architecture

Focus of attention

Web Server, Content Server, Distribution Server

JDBC

Java standard for accessing databases JDBC is simply the database connection utilities Java developers need to build upon

rows SQL JDBC

• Connection con =

DriverManager.getConnection(…);

• Statement stmt = con.createStatement();
• stmt.execute("create table JUGSData ("+

"programmer varchar (32),"+"day char (3),"+”cups integer);")

SQLJ

Meta-Standard for accessing databases Pre-compiler to build JDBC Java Code

SQL rows JDBC

1. #sql iterator Iter (double sal, String ename); 2. String ename = 'Smith'; 3. Iter it; ... 4. #sql it = { select ENAME, SAL from EMP where ENAME = :ename };

SQLJ Pre- Compiler

Impedance Mismatch

The differences in relational and object technology is known as the “object-relational impedance mismatch” Challenging problem to address because it requires a combination of relational database and object expertise

Impedance Mismatch

Factor J2EE Relational Databases Logical Data Representation Objects, methods, inheritance Tables, SQL, stored procedures Scale Hundreds of megabytes Gigabytes, terabytes Relationships Memory references Foreign keys Uniqueness Internal object id Primary keys Key Skills Java development,

• bject modeling

SQL, Stored Procedures, data management Tools IDE, Source code management, Object Modeler Schema designer, query manager, performance profilers, database configuration

Object Level Options

Depends on what component architecture is used:

– Entity Beans BMP – Bean Managed Persistence – Entity Beans CMP – Container Managed

Persistence

– Access Java Objects via Persistence Layer

(POJO or J2EE)

Can be off the shelf or “home-grown”

Do you build your O-R Mapping Tool yourself?

Entity Beans - BMP

In BMP, developers write the persistence code themselves Database reads and writes occur in specific methods defined for bean instances The container calls these methods - usually on method or transaction boundaries

ejbLoad() - “load yourself” ejbStore() - “store yourself” ejbCreate() - “create yourself” findBy…() - “find yourself” ejbRemove() - “remove yourself”

Entity Beans - CMP

Persistence is based on information in the deployment descriptors

–

More “automatic” persistence – managed by the Application Server, can be faster than BMP

–

No special persistence code in the bean

–

Description of the persistence done with tools and XML files

Less control, persistence capabilities are limited to the functionality provided.

–

Very difficult to customize or extend CMP features as it is built-in

–

Do have options to plug-in a 3rd party CMP solution on an app server

Object Persistence Layer

Abstracts persistence details from the application layer, supports Java objects/Entity Beans

SQL rows Objects Persistence Layer Objects

• bject-level

querying and creation results are objects results are returned as raw data API uses SQL

• r database

specific calls

J2EE & J2EE & J2EE & J2EE & Web Web Web Web Services Services Services Services

JDBC

• bject creation and

updates through

• bject-level API

Basic J2EE Persistence Checklist

Mappings Object traversal Queries Transactions Optimized database interaction Database Triggers and Cascade Deletes Caching Locking Database features

Mapping

Object model and Schema must be mapped

– True for any persistence approach

Most contentious issue facing designers

– Which classes map to which table(s)? – How are relationships mapped? – What data transformations are required?

Good and Poor Mapping Support

Good mapping support:

–

Domain classes don’t have to be “tables”

–

References should be to objects, not foreign keys

–

Database changes (schema and version) easily handled

Poor mapping support:

–

Classes must exactly mirror tables

–

Middle tier needs to explicitly manage foreign keys

–

Classes are disjoint

–

Change in schema requires extensive application changes

Data and Object Models

Rich, flexible mapping capabilities provide data and object models a degree of independence Otherwise, business object model will force changes to the data schema or vice-versa Often, J2EE component models are nothing more than mirror images of data model – NOT desirable

Simple Object Model

Customer

id: int name: String creditRating: int

Address

id: int city: String zip: String

1:1 Relationship

Typical 1-1 Relationship Schema

CUST

ID NAME A_ID C_RATING

ADDR

ID CITY ZIP

Other possible Schemas…

CUST ID NAME C_RATING C_ID ADDR ID CITY ZIP A_ID CUST_ADDR C_ID CUST ID NAME C_RATE C_ID ADDR ID CITY ZIP CUST ID NAME CITY ZIP C_RATING

Even More Schemas…

CUST ID NAME A_ID ADDR ID CITY ZIP CUST_CREDIT ID C_RATING CUST ID NAME CUST_CREDIT ID C_RATING ADDR ID CITY ZIP C_ID CUST ID NAME ADDR ID CITY ZIP CUST_CREDIT ID C_RATING A_ID CUST ID NAME CUST_CREDIT ID C_RATING ADDR ID CITY ZIP C_ID CUST ID NAME ADDR ID CITY ZIP CUST_CREDIT ID C_RATING A_ID CC_ID

Mapping Summary

Just showed nine valid ways a 1-1 relationship could be represented in a database

– Most persistence layers and application servers

will only support one

Without good support, designs will be forced Imagine the flexibility needed for other mappings like 1-M and M-M

Object Traversal – Lazy Reads

J2EE applications work on the scale of a few hundreds of megabytes Relational databases routinely manage gigabytes and terabytes of data Persistence layer must be able to transparently fetch data “just in time”

Just in Time Reading – Faulting Process

Customer Order Proxy

• 1. Accessing relationship for first

time

• 2. Get related
• bject based on

FK

• 3b. SQL if

not cached

• 3a. Check

Cache

• 4. Plug

result into Proxy Order

Object Traversals

Even with lazy reads, object traversal is not always ideal

– To find a phone number for the manufacturer of a

product that a particular customer bought, may do several queries: Get customer in question Get orders for customer Get parts for order Get manufacturer for part Get address for manufacturer

– Very natural object traversal results in 5

queries to get data that can be done in 1

N+1 Reads Problem

Many persistence layers and application servers have an N+1 reads problem Causes N subsequent queries to fetch related data when a collection is queried for A side effect of the impedance mismatch and poor mapping and querying support in persistence layers

N+1 Reads

Must have solution to minimize queries Need flexibility to reduce to 1 query, 1+1 query or N+1 query where appropriate

– 1 Query when displaying list of customers and

addresses – known as a “Join Read”

– 1+1 Query when displaying list of customers and

user may click button to see addresses – known as a “Batch Read”

– N+1 Query when displaying list of customers but

• nly want to see address for selected customer

Queries

Java developers are not usually SQL experts

– Maintenance and portability become a concern

when schema details hard-coded in application

Allow Java based queries that are translated to SQL and leverage database options

– EJB QL, object-based proprietary queries, query

by example

Queries

Persistence layer handles object queries and converts to SQL SQL issued should be as efficient as written by hand Should utilize other features to optimize

–

Parameter binding, cached statements

Some benefits to dynamically generated SQL :

–

Ability to create minimal update statements

Only save objects and fields that are changed

–

Simple query-by-example capabilities

Query Requirements

Must be able to trace and tune SQL Must be able use ad hoc SQL where necessary Must be able to leverage database abilities

– Outer joins – Nested queries – Stored Procedures – Oracle Hints

Transaction Management

J2EE apps typically support many clients sharing small number of db connections Ideally would like to minimize length of transaction on database

Begin Txn Time Begin Txn Commit Txn Commit Txn

Caching

Any application that caches data, now has to deal with stale data When and how to refresh? Will constant refreshing overload the database? Problem is compounded in a clustered environment App server may want be notified of database changes

Caching

• 4. SQL Query (if needed)
• 1. OO Query
• 5. Results(s)
• 2. Does PK for row

exist in cache?

• 6. NO – Build

bean/object from results Return object results

• 3. YES – Get from

Cache

Locking

J2EE developers want to think of locking at the object level Databases may need to manage locking across many applications Persistence layer or application server must be able to respect and participate in locks at database level

Optimistic Locking

DBA may wish to use version, timestamp and/or last update field to represent optimistic lock

– Java developer may not want this in their

business model

– Persistence layer must be able to abstract this

Must be able to support using any fields including business domain

Pessimistic Locking

Requires careful attention as a JDBC connection is required for duration of pessimistic lock Should support SELECT FOR UPDATE [NOWAIT] semantics

Time Begin Txn Commit Txn Begin Txn Commit Txn Pess Lock

Conclusion

J2EE apps accessing relational databases:

– Don’t need to compromise object/data model – Need to fully understand what is happening at

database level

– Can utilize database features – Do not have to hard code SQL to achieve optimal

database interaction

– Can find solutions that effectively address

persistence challenges and let them focus on J2EE application

TopLink Key Technical Features

TopLink Persistency Layer Framework from Oracle Application Server 10g solves these issues by:

–

Meta-Data Architecture

–

Comprehensive Visual Mapping Workbench

–

Advanced Mapping Support and Flexibility

–

Query Flexibility

–

Just In Time reading

–

Caching

–

Transaction support and integration

–

Locking

–

Performance tuning options

–

SDK

TopLink Runtime Architecture

Data Source TopLink Persistence Manager Cache Query TX

Object Data Conversion Presentation Interface Application Logic

J2EE Server

Business Entities

J2EE Services

JTA

CMP/ BMP

Connection Pools

JDBC

Mappings

Meta-Data Architecture for Object Relational Mapping

Mapping information is kept in XML descriptors and not in the objects Meta-data means OracleAS TopLink is NOT at all intrusive on either the object model or the schema

Employee

firstName lastName address birthDate

Address

E_ID F_NAME L_NAME A_ID B_DATE A_ID CITY STATE ZIP

city state zip

Advanced Mapping Support and Flexibility

Direct to Field, One to One, One to Many, Many to Many

– Any kind of foreign key relationships in Database

supported – including intermediate tables

Object Type, Transformation

– Enumeration (‘Male’-> ‘M’) or conversions (String to

Number)

– User defined transformations

Aggregates, Multiple tables

– Multiple objects/beans per row – Man an object/bean to multiple tables

And many more – Serialized mappings, Direct Collections, Object-Relational Mappings, etc

Mapping Workbench

Lots of mapping tools

• ut there,

however don’t get fleeced by a slick GUI The underlying mapping support is what’s important

Summary

Oracle Application Server 10g – TopLink Persistency Layer solves all the mentioned problems

–

Mapping

–

Queries

–

Transactions

–

Deferred Read Management

–

Locking

–

Caching

TopLink is independent of Database and Application Server Technology

2004 2004

For further Information contact: Marc Ph. Stampfli E-Mail: marc.stampfli@oracle.com Phone: +41 56 483 32 11
