Beyond J2EE 1.4

Peter Tröger Hasso-Plattner-Institute University of Potsdam

Agenda

J2EE Future

JSR Process, EE 5, EJB 3 Sun AppServer 9, JBoss 5, OpenEJB

Dependency Injection & Inversion of Control

Hivemind, Spring, PicoContainer, Plexus, Yan,

Avalon, Tapestry

Object-relational persistence

Hibernate, XMLBeans, Castor

Servlet-based frameworks - Struts Sources: Sun JSR & GlassFish material, Martin

Fowler homepage, different project sites

JSR Process

Java Community Process (JCP) for development of

specifications (since 1995)

Initiation (approved by executive committee) Early draft (for review by the public domain) Public draft (reference implementation, compatibility toolkit) Maintenance (document updates)

Java Specification Request (JSR)

Proposed and final specifications for Java platform Review / approval process

Java EE 5 Platform

Next version of J2EE platform Latest versions of Java technology

Enterprise JavaBeans (EJB) 3.0 (JSR-220) JavaServer Faces (JSF) 1.2 (JSR-252) Servlet 2.5 JavaServer Pages (JSP) 2.1 Java API for Web Services (JAX-WS) 2.0 (JSR-224) Web Services Metadata (JSR-181) Java Architecture for XML Binding (JAXB) 2.0 (JSR-222) Java Persistence 1.0 (JSR-220) Common Annotations 1.0 (JSR-250) Streaming API for XML (StAX) 1.0 (JSR-173)

Java Enterprise System Application Platform Suite

Zur Anzeige wird der QuickTime™ Dekompressor „TIFF (LZW)“ benötigt.

Java EE 5 Major Features

Simplified web service support More web service standards support Simplified EJB development New persistence API Easier web applications with JavaServer Faces Most specs available for review

Spec at Proposed Final Draft state - Q4 2005 Java EE 5 SDK Beta release - Q1 2006 Java EE 5 Final release - Q2 2006

Project GlassFish

Open Source Java EE 5 Application Server Sun AppServer Platform Edition 9

Open access to code and binaries

Integrates with NetBeans, Sun Java Studio

Enterprise, Eclipse

Standard Edition

Advanced security, self-managing, self-healing Clustering, multi-machine administration

Enterprise Edition

Support for high availability

Grizzly HTTP Framework

Highly scalable HTTP path Thousands of connections with few Java threads Uses lower level Java NIO primitives

Easy-to-use, high-performance APIs for socket

communication

Brings non-blocking sockets to the HTTP processing

layer

Integrates with current Apache Tomcat HTTP

Connector architecture (Tomcat 3,4,5)

Replaces Apache Tomcat Coyote HTTP front-end

and thread pool

High-performance buffers and parsing classes

Fast Infoset

Optimized Binary XML transport mechanism -

fast web services

Transparently used by web service

communication stack

TS-7187

GlassFish JBI Integration

Java Business Integration (JBI) standard

JSR 208 SOA-way of Enterprise Application Integration Normalized Message Router OpenESB - Enterprise Service Bus product, out-of-box

support for SOAP and JMS

Java EE web services (EJBs and Servlets) are

automatically enabled in Normalized Message Router

JAXWS communication can be routed in-process to

Normalized Message Router

EJB 3.0

Coordinated in JSR 220 POJO-based programming (Plain Old Java Object)

No more Home interfaces

Backward compatibility Extensive use of annotations, reduced need for deployment

descriptors

Specification of default behavior, reduces configuration overhead Dependency injection with annotations Improved EJB-QL (Update, Delete, Inner / Outer Join, SQL) Manager concept for entity bean POJOs Less checked exceptions Improved performance

• Read-only beans
• Relationship pre-fetching

Annotations as Descriptors

• Only RUNTIME annotations used
• Available in class file, read by runtime, simplifies container development
• Deployment descriptors overwrite annotation configuration
• Annotation for business interface and references
• Business interfaces are optionally generated
• Lifetime management through annotated functions

(@PreDestroy, @PostConstruct)

@Stateless @Remote public class HelloWorldBean { public String getHello() { return „Hello World“; } @PreDestroy cleanUp() { // logic before destruction of the instance }}

EJB 3 Example

@Stateless public class PayrollBean implements Payroll { @Resource DataSource empDB; public void setBenefitsDeduction (int empId, double deduction) { ... Connection conn = empDB.getConnection(); ... } ... }

• @EJB ShoppingCart myCart;

Collection widgets = myCart.startToShop(“widgets”);

EE 5 Web Service Example

@WebService(name=”MySimpleWS”); public class RandomClass { @WebMethod public String sayHello(String s) {...} public void unpublished() {...} }

• @WebServiceRef(

wsdlLocation= ”http://localhost:8080/SayHelloService?WSDL”);) static javaone.SayHelloService wsService; public static void main(String[] args) { javaone.SayHello wsPort = wsService.getHello(); wsPort.sayHello(“FOSS.in Attendees”); }

AOP through Interceptors

public class MyInterceptor { @AroundInvoke public Object myInterceptionMethod( InvocationContext inv) throws Exception { // Code for advice return inv.proceed(); } @Interceptors({„org.example.MyInterceptor"}) public class HelloWorldBean {...}

Java 6 (“Mustang”)

Coordinated in JSR 270 Development snapshots / sources available New bytecode verifier for improved performance JFC / Swing / AWT improvement, Java 2D API,

better internationalization

Java Compiler API (JSR 199) XML and Web Services (XML Signatures, JAX-WS

2.0, JAXB 2.0, JDBC 4.0, JMX 1.3)

Set of improvements for Java 5 features Sources available

Open Source Efforts beyond J2EE 1.4

Huge amount of activities to build alternatives to the

J2EE 1.4 technologies

Interfaces are good abstraction, but where does the

interface implementation class come from ?

Heavyweight complexity Component wiring

as main problem lightweight containers

Component Wiring – The Problem

public interface MovieFinder { List findAll(); class MovieLister { private MovieFinder finder; public MovieLister() { finder = new ColonDelimitedMovieFinder("movies1.txt"); } public Movie[] moviesDirectedBy(String arg) { List allMovies = finder.findAll(); for (Iterator it = allMovies.iterator(); it.hasNext();) { Movie movie = (Movie) it.next(); if (!movie.getDirector().equals(arg)) it.remove(); } return (Movie[]) allMovies.toArray(new Movie[allMovies.size()]); } }

Component Wiring Through Dependency Injection

Assembling of ‚plugin‘-style components

through „Inversion of Control“ (IoC)

Separate assembler object injects an

implementation into the plugin-using component

Prevents tight coupling of specific interface

implementation and interface users

„Dependency Injection“ pattern

Dependency Injection – Constructor Injection

Parameterized constructor of interface user

takes injected implementation

Configuration code about injected objects

In different class (PicoContainer project) In XML file (NanoContainer project)

Client asks IoC framework for instance

public void testWithPico() { MutablePicoContainer pico = configureContainer(); MovieLister lister = (MovieLister)pico.getComponentInstance(MovieLister.class); Movie[] movies = lister.moviesDirectedBy("Sergio Leone"); ...}

PicoContainer Example

class MovieLister... public MovieLister(MovieFinder finder) { this.finder = finder; } class ColonMovieFinder... public ColonMovieFinder(String filename) { this.filename = filename; } private MutablePicoContainer configureContainer() { MutablePicoContainer pico = new DefaultPicoContainer(); Parameter[] finderParams = {new ConstantParameter("movies1.txt")}; pico.registerComponentImplementation( MovieFinder.class, // the interface ColonMovieFinder.class, // the implementation finderParams); pico.registerComponentImplementation(MovieLister.class); return pico; }

Dependency Injection – Setter Injection

Assembler hands dependency instances

through a setter method after instantiation

No atomic setting like with constructor injection Main concept in the Spring framework

public void testWithSpring() throws Exception { ApplicationContext ctx = new FileSystemXmlApplicationContext("spring.xml"); MovieLister lister = (MovieLister) ctx.getBean("MovieLister"); Movie[] movies = lister.moviesDirectedBy("Sergio Leone"); }

Spring Framework Example

class MovieLister... private MovieFinder finder; public void setFinder(MovieFinder finder) { this.finder = finder;} class ColonMovieFinder... public void setFilename(String filename) { this.filename = filename;} <beans> <bean id="MovieLister" class="spring.MovieLister"> <property name="finder"><ref local="MovieFinder"/></property> </bean> <bean id="MovieFinder" class="spring.ColonMovieFinder"> <property name="filename"><value>movies1.txt</value></property> </bean> </beans>

Dependency Injection – Interface Injection

Specific interface for injection of an interface-

implementing instance

Injection-interface is implemented by plugin-

interface user

Used in Apache Avalon project

class IfaceTester { public void testIface() { configureContainer(); MovieLister lister = (MovieLister)container.lookup("MovieLister"); Movie[] movies = lister.moviesDirectedBy("Sergio Leone"); } }

Avalon Example

public interface InjectFinder { void injectFinder(MovieFinder finder); } class MovieLister implements InjectFinder { public void injectFinder(MovieFinder finder) { this.finder = finder; }} public interface InjectFinderFilename { void injectFilename (String filename); } class ColonMovieFinder implements MovieFinder, InjectFinderFilename { public void injectFilename(String filename) { this.filename = filename; }}

Avalon Configuration Example

class Tester { private Container container; private void configureContainer() { container = new Container(); registerComponents(); registerInjectors(); container.start(); } private void registerComponents() { container.registerComponent("MovieLister", MovieLister.class); container.registerComponent("MovieFinder", ColonMovieFinder.class); } private void registerInjectors() { container.registerInjector(InjectFinder.class, container.lookup("MovieFinder")); container.registerInjector(InjectFinderFilename.class, new FinderFilenameInjector()); }

Component Wiring Through Service Locator

One well-known registry object knows how to get

hold of all the objects the application might need

Service Locator Example

class MovieLister { MovieFinder finder = ServiceLocator.movieFinder(); } class ServiceLocator { private static ServiceLocator soleInstance; private MovieFinder movieFinder; public static void load(ServiceLocator arg) { soleInstance = arg; } public ServiceLocator(MovieFinder movieFinder) { this.movieFinder = movieFinder; } public static MovieFinder movieFinder() { return soleInstance.movieFinder; }}

Service Locator Client Example

class Tester { private void configure() { ServiceLocator.load( new ServiceLocator( new ColonMovieFinder("movies1.txt"))); } public void testSimple() { configure(); MovieLister lister = new MovieLister(); Movie[] movies = lister.moviesDirectedBy("Sergio Leone"); } }

Dynamic Service Locator Example

class ServiceLocator { private static ServiceLocator soleInstance; private Map services = new HashMap(); public static void load(ServiceLocator arg) { soleInstance = arg; } public static Object getService(String key){ return soleInstance.services.get(key); } public void loadService (String key, Object service) { services.put(key, service); }

Dynamic Service Locator Client Example

class Tester { private void configure() { ServiceLocator locator = new ServiceLocator(); locator.loadService("MovieFinder", new ColonMovieFinder("movies1.txt")); ServiceLocator.load(locator); } class MovieLister() { MovieFinder finder = (MovieFinder) ServiceLocator.getService("MovieFinder"); }

Service Locator vs. Dependency Injection

Decoupled application code and interface

implementation

Service Locator

Application class asks explicitly for implementation Every plugin depends on a specific locator –

non-planned application usage might be hard

Dependency Injection

Implicit availability of interface implementation Hard to debug Very easy testing (stubs / mocks for implementation)

Other discussions

Constructor vs. setter injection (related to OO principles) Code vs. configuration files

Pico Container

Small container Configuration support through Java objects Preferred mode of constructor injection Nice autowiring

Spring Framework 1.2

Based on J2EE practice book:

Rod Johnson, Expert One-on-One J2EE Design and Development, WROX, October 2002, ISBN: 0-7645-4385-7

Layered Java/J2EE application framework

• Use only parts of it if you like to

Open Source project since 2003

Functionality can be used in any J2EE server, most also in

non-managed environments

Reusable business POJOs, based on layered Spring

architecture features

JavaBeans for application configuration (IoC) Better testability of developed code Strict usage of interface approach Avoid checked exception concept

Spring Framework Features

Lightweight container

• Centralized, automated configuration and plumbing
• POJOs as components

Common abstraction layer for transactions, not tied to J2EE (in

contrast to JTA / EJB)

JDBC abstraction layer with better error handling AOP support for all objects Integration of other technologies (Commons Logging, Hibernate,

JDO)

MVC web application framework Independent from underlying application server Acts as ‚glue code‘ for J2EE APIs and open source frameworks

Spring Feature Stack

Layered Spring Application

Remoting Usage Scenario

POJO Reuse Scenario

Wrap existing POJOs in stateless session EJBs Access and abstraction layer

Spring Packages

Core: bean container functionality, support for

dependency injectiob

Context: resembling of JNDI, supports event

propagation, text messaging and wiring

DAO: JDBC abstraction layer ORM: Integration layers for O/R solutions AOP: Method interceptors, pointcuts Web / Web MVC: Web-oriented integration

features

Spring Lightweight Container

BeanFactory as container

(instantiation, configuration, management)

Multiple implementations (e.g. XmlBeanFactory) Uses configuration data about dependencies Supports different injection paradigms Supports autowiring (by inject property name, by

property type, by constructor argument type)

Supports dependency checking

Resource res = new FileSystemResource("beans.xml"); XmlBeanFactory factory = new XmlBeanFactory(res);

Spring DataSource Example

<beans> <bean id="myDataSource" class="org.apache.commons.dbcp.BasicDataSource" destroy-method="close"> <property name="driverClassName" value="com.mysql.jdbc.Driver" /> <property name="url" value="jdbc:mysql://localhost:3306/mydb" /> <property name="username" value="someone" /> </bean> <bean id="exampleDataAccessObject" class="example.ExampleDataAccessObject"> <property name="dataSource" ref="myDataSource" /> </bean> <bean id="exampleBusinessObject" class="example.ExampleBusinessObject"> <property name="dataAccessObject"> <ref bean="exampleDataAccessObject"/> </property> <property name="exampleParam"><value>10</value></property> </bean> </beans>

Spring DataSource Example

<beans> <bean id="myDataSource" class="org.springframework.jndi.JndiObjectFactoryBean"> <property name="jndiName" value="jdbc/myDataSource" /> </bean> <bean id="exampleDataAccessObject" class="example.ExampleDataAccessObject"> <property name="dataSource" ref="myDataSource" /> </bean> <bean id="exampleBusinessObject" class="example.ExampleBusinessObject"> <property name="dataAccessObject"> <ref bean="exampleDataAccessObject"/> </property> <property name="exampleParam"><value>10</value></property> </bean> </beans>

Spring DataSource Client

public class ExampleBusinessObject implements MyBusinessObject { private ExampleDataAccessObject dao; private int exampleParam; public void setDataAccessObject(ExampleDataAccessObject dao) { this.dao = dao; } public void setExampleParam(int exampleParam) { this.exampleParam = exampleParam; } public void myBusinessMethod() { // do stuff using dao }}

EJB Implementation with Spring

EJBs are hard to test outside the container Solution: Refactor business logic into POJOs behind EJB

facades, including IoC pattern

Spring superclass implements EJB lifecylce methods Still needed to write according ejb-jar.xml

import org.springframework.ejb.support.AbstractStatelessSessionBean; public class MyEJB extends AbstractStatelessSessionBean implements MyBusinessInterface { private MyPOJO myPOJO; protected void onEjbCreate() { this.myPOJO = getBeanFactory().getBean("myPOJO"); } public void myBusinessMethod() { this.myPOJO.invokeMethod(); }}

Jakarta HiveMind

Apache Jakarta project Service and configuration framework

HiveMind services are POJOs Framework covers instantiation and configuration

Supports application development, HiveMind is not

an application server

Service collaboration through dependency injection

microkernel

Conversion of user-defined configuration data into

data objects

Module deployment descriptors parsed by startup

logic, the ‚core‘ of HiveMind

Controlled instantiation and initialization of Java code

HiveMind Details

Zur Anzeige wird der QuickTime™ Dekompressor „TIFF (Unkomprimiert)“ benötigt.

Flexible, loosely-coupled configuration management

and services framework

HiveMind might be used to front EJBs, and therefore

is thread-safe

Dependency injection for

beans or larger components, called modules

Enforces interface usage Strong relation to

Apache Jakarta Tapestry (Howard Lewis Ship)

HiveMind Responsibilities

Code

Obtain a reference to the registry Singleton Know the ID / class type of the service to access Pass the interface class

HiveMind

Find and create the according implementation object Operate in a thread-safe manner Do useful error reporting Support documentation of linked extension points (HiveDoc)

HiveMind Service Referring

private SomeOtherService _otherService; public String myMethod(String param) { if (_otherService == null) _otherService = // Lookup other service . . . _otherService.doSomething(. . .); . . . } private SomeOtherService _otherService; public void setOtherService(SomeOtherService otherService) { _otherService = otherService; } public String myMethod(String param) { _otherService.doSomething(. . .); . . . }

HiveMind Wiring Example (1)

package hivemind.examples; public interface Adder { public int add(int arg0, int arg1); } package hivemind.examples.impl; import hivemind.examples.Adder; public class AdderImpl implements Adder { public int add(int arg0, int arg1) {return arg0 + arg1;} } package hivemind.examples; public interface Calculator extends Adder, Subtracter { }

HiveMind Wiring Example (2)

package hivemind.examples.impl; import hivemind.examples.*; public class CalculatorImpl implements Calculator { private Adder _adder; private Subtracter _subtracter; public void setAdder(Adder adder) { _adder = adder; } public void setSubtracter(Subtracter subtracter) { _subtracter = subtracter; } public int add(int arg0, int arg1) { return _adder.add(arg0, arg1); } public int subtract(int arg0, int arg1) { return _subtracter.subtract(arg0, arg1); } }

HiveMind Wiring Example (3)

<?xml version="1.0"?> <module id="hivemind.examples" version="1.0.0" package="hivemind.examples"> <service-point id="Adder" interface="Adder"> <create-instance class="impl.AdderImpl"/> <interceptor service-id="hivemind.LoggingInterceptor"/> </service-point> <service-point id="Subtracter" interface="Subtracter"> <create-instance class="impl.SubtracterImpl"/> <interceptor service-id="hivemind.LoggingInterceptor"/> </service-point> <service-point id="Calculator" interface="Calculator"> <invoke-factory> <!-- Autowires service properties based on interface! --> <construct class="impl.CalculatorImpl"/> </invoke-factory> <interceptor service-id="hivemind.LoggingInterceptor"/> </service-point> </module>

HiveMind Wiring Example (4)

package hivemind.examples; import org.apache.hivemind.Registry; import org.apache.hivemind.impl.RegistryBuilder; public class Main { public static void main(String[] args) { int arg0 = Integer.parseInt(args[0]); int arg1 = Integer.parseInt(args[1]); Registry registry = RegistryBuilder.constructDefaultRegistry(); Calculator c = (Calculator) registry.getService(Calculator.class); System.out.println("Inputs " + arg0 + " and " + arg1); System.out.println("Add : " + c.add(arg0, arg1)); System.out.println("Subtract: " + c.subtract(arg0, arg1)); } }

HiveMind Logging Interceptor

public String myMethod(String param) { if (LOG.isDebugEnabled()) LOG.debug("myMethod(" + param + ")"); String result = // . . . if (LOG.isDebugEnabled()) LOG.debug("myMethod() returns " + result); return result; } <service-point id="MyService" interface="com.myco.MyServiceInterface"> <create-instance class="com.myco.impl.MyServiceImpl"/> <interceptor service-id="hivemind.LoggingInterceptor"/> </service-point>

O/R Mapping Projects

Object-relational mapping allows OO-view on

tables and relations from databases

Crucial for persistency implementation

Hibernate

Popular open source (LGPL) O/R mapping tool Usable standalone, for POJOs and for EJBs Portable SQL extension as query language (HQL) Mapping definition through XML configuration files,

with own type identifiers

Easier than hand-written SQL/JDBC, more powerful that EJB 2.1

entity beans, over 15 databases supported

Integrated caching and monitoring architecture Usable from servlets or EJB session bean façade Compatible with open source connection pools No backward-compatibility between versions Contributors to JSR 220 specification, implementation in JBoss

EJB3 container

Part of JBoss Enterprise Middleware System

Hibernate Approaches

Top-Down: Start with JavaBeans Bottom-Up: Start with relational schema Middle-Out: Start with mapping definition Meet-In-Middle: Start with JavaBeans and Schema

Using Hibernate Mappings in Applications

SessionFactory: Manages all mappings, configurable

through files

Session: Boundary between database and application Transaction: JDBC, JTA or CORBA transactions,

created from session

try { SessionFactory sf = new Configuration().configure().buildSessionFactory(); } catch (HibernateException e) {…} Session sess = sf.openSession(); Transaction trx = sess.beginTransaction(); Band band = new Band(); band.setName("deCON"); sess.save(band); trx.commit(); sess.close();

Hibernate XML Mapping File

<hibernate-mapping schema="allschools"> <class name="net.allschools.hbn.manual.Comment“ table="COMMENT"> <id name="id" column="ID" type="integer"> <generator class="sequence"> <param name="sequence">allschools.comment_id_seq</param> </generator> </id> <property name="commentDate" column="COMMENT_DATE" type="date" not-null="true" /> <property name="title" column="TITLE" type="string“ not-null="true"/> <property name="text" column="COMMENT_TEXT" type="string" not-null="true"/> <property name="userName" column="USER_NAME" type="string" not-null="true"/> <many-to-one name="release" column="RELEASE_ID“ class="net.allschools.hbn.manual.Release"/> </class> … </hibernate-mapping>

Hibernate Relations

One-to-one

• No foreign key specification
• Cascade definition regarding Update and Delete

Many-to-one / many-to-many

• Needs collection class member in the JavaBean representation

<class name="net.allschools.hbn.manual.Release" table="RELEASE"> <one-to-one name="cover" class="net.allschools.hbn.manual.Image“ cascade="none"/> <set name="comments" cascade="none" lazy="true"> <key column="release_id"/> <one-to-many class="net.allschools.hbn.manual.Comment"/> </set> <set name="bands" table="RELEASE_BANDS" cascade="none" lazy="true"> <key column="RELEASE_ID"/> <many-to-many class="net.allschools.hbn.manual.Band“ column="BAND_ID"/> </set> </class>

Hibernate SessionFactory Configuration

<?xml version='1.0' encoding='utf-8'?> <!DOCTYPE hibernate-configuration PUBLIC "-//Hibernate/Hibernate Configuration DTD 2.0//EN" "http://hibernate.sourceforge.net/hibernate-configuration-2.0.dtd"> <hibernate-configuration> <session-factory name="java:comp/env/hibernate/SessionFactory"> <!-- properties --> <property name="hibernate.connection.driver_class">org.postgresql.Driver</property> <property name="hibernate.connection.url">jdbc:postgresql:allschools</property> <property name="hibernate.connection.username">username</property> <property name="hibernate.connection.password">passwort</property> <property name="hibernate.connection.pool_size">5</property> <property name="dialect">net.sf.hibernate.dialect.PostgreSQLDialect</property> <property name="show_sql">true</property> <property name="use_outer_join">true</property> <!-- mapping files --> <mapping resource="Mappings.hbm.xml"/> </session-factory> </hibernate-configuration>

Hibernate Features

Hibernate Query Language

OO-dialect of SQL – classes, properties,

polymorphism, relational operations, subqueries

Native SQL with pass-through still allowed

Criteria queries (QBC)

Framework for query objects Includes ‘query by example’

Hibernate Query Language

List allAuctions = session.createQuery(“from AuctionItem”).list(); select item from AuctionItem item join item.bids as bid where item.description like “Hibernate%” and bid.amount > 100

XML Beans

Apache XMLBeans project, donated by BEA Binding tool for Java object-view on XML data Major APIs

Strongly-typed access with XMLObject base type XML infoset access through XMLCursor interface XML schema object model acces (SchemaType interface)

XML infoset is FULLY preserved

XML data is still represented in memory

JAXB supports only parts of XML schema No marshalling / demarshalling needed

XMLBeans Steps

Compile schema definition

scomp -out employeeschema.jar employeeschema.xsd

Write code

File xmlFile = new File("c:\employees.xml"); // Bind the instance to the generated XMLBeans types. EmployeesDocument empDoc = EmployeesDocument.Factory.parse(xmlFile); // Get and print pieces of the XML instance. Employees emps = empDoc.getEmployees(); Employee[] empArray = emps.getEmployeeArray(); for (int i = 0; i < empArray.length; i++) { System.out.println(empArray[i]); }

XMLBeans Mapping of Schema Built-In Types

Servlet-based Technology

Apache Jakarta Struts

Application framework for building web applications

• n-top-of J2EE web container

Prebuild components to be assembled to web

applications -> time saving

MVC design pattern as basic approach

Model components are Java classes View components are JSP files

(large support for Struts custom JSP tags)

Controller components are special “action classes” Struts configuration file for assembling

Several forks, confusing amount of sub-projects

Struts View Component

<%@ page contentType="text/html;charset=UTF-8" language="java" %> <%@ taglib uri="/WEB-INF/struts-bean.tld" prefix="bean" %> <%@ taglib uri="/WEB-INF/struts-html.tld" prefix="html" %> <%@ taglib uri="/WEB-INF/struts-logic.tld" prefix="logic" %> <html:html locale="true"> <head><title><bean:message key="hello.jsp.title"/></title><html:base/> </head> <body bgcolor="white"><p> <h2><bean:message key="hello.jsp.page.heading"/></h2> <p><html:errors/><p> <logic:present name="examples.hello" scope="request"> <h2> Hi <bean:write name="examples.hello" property="person" />!<p> </h2> </logic:present> <html:form action="/HelloWorld.do?action=gotName" focus="username" > <bean:message key="hello.jsp.prompt.person"/> <html:text property="person" size="16" maxlength="16"/><br> <html:submit property="submit" value="Submit"/> <html:reset/> </html:form><br> </body> </html:html>

Struts Form Bean

import javax.servlet.http.HttpServletRequest; import org.apache.struts.action.*; public final class HelloForm extends ActionForm { private String person = null; public String getPerson() {return (this.person);} public void setPerson(String person) {this.person = person;} // overriden from ActionForm public void reset(ActionMapping mapping, HttpServletRequest request) { this.person = null;} // overriden from ActionForm public ActionErrors validate(ActionMapping mapping,HttpServletRequest request) { ActionErrors errors = new ActionErrors(); if ((person == null) || (person.length() < 1)) errors.add("person", new ActionError("examples.hello.no.person.error")); return errors; } }

Struts Controller Component

package examples.hello; import javax.servlet.*; import org.apache.struts.action.*; … public final class HelloAction extends Action { public ActionForward execute(ActionMapping mapping, // config file ActionForm form, // form bean HttpServletRequest request, HttpServletResponse response) throws Exception { ActionErrors errors = new ActionErrors(); String person = (String) PropertyUtils.getSimpleProperty(form, "person"); String badPerson = "Atilla the Hun"; if (person.equals(badPerson)) { // business logic errors.add("person", new ActionError("dont.talk.to.atilla", badPerson )); saveErrors(request, errors); return (new ActionForward(mapping.getInput())); } HelloModel hm = new HelloModel(); // interact with model hm.setPerson(person); hm.saveToPersistentStore(); request.setAttribute( Constants.HELLO_KEY, hm); // pass data to view component return (mapping.findForward("SayHello")); // forward control }}

Struts Config File

<?xml version="1.0" encoding="ISO-8859-1" ?> <struts-config> <!-- === Form Bean Definitions === --> <form-beans> <form-bean name="HelloForm“ type="examples.hello.HelloForm"/> </form-beans> <!-- === Action Mapping Definitions === --> <action-mappings> <!-- Say Hello! --> <action path = "/HelloWorld" type = "examples.hello.HelloAction" name = "HelloForm" scope = "request" validate = "true" input = "/hello.jsp"> <forward name="SayHello" path="/hello.jsp" /> </action> </action-mappings> <message-resources parameter="examples.hello.Application"/> </struts-config>
