Marlena Götza, Thilo Steckel, Heinrich Warkentin CLAAS E-Systems

EDC Forum 2017 Big Spatial Data in Agriculture

• 1. CLAAS & GIS Technologies
• 2. Hadoop as a „Big Data“ Ecosystem
• 3. Big Data & GIS Technologies
• 4. Résumé

21.09.2017

Company Presentation CLAAS E-Systems | CLAAS Group

Product Range

Vier Spalten Telehandler Balers Service & Parts Software and systems Combine harvesters Forage harvesters Tractors Forage harvesting machines

21.09.2017

Company Presentation CLAAS E-Systems | Trends and Challenges

Agricultural Engineering in the past

21.09.2017

Company Presentation CLAAS E-Systems | Trends and Challenges

Have we reached our limits?

21.09.2017

Company Presentation CLAAS E-Systems | Trends and Challenges

Precision Agriculture

21.09.2017

GIS in Agriculture

21.09.2017

21.09.2017

• 1. CLAAS & GIS Technologies
• 2. Hadoop as a „Big Data“ Ecosystem
• 3. Big Data & GIS Technologies
• 4. Résumé

Research Project AGATA - Analyse großer Datenmengen in Verarbeitungsprozessen

21.09.2017

Hadoop

21.09.2017

• Core Concepts
• HDFS
• Physical replication of data
• Fault tolerant through redundancy
• MapReduce Framework

Data

09/10/2017

• Machine Data
• GPS position
• Operating data
• Master data
• Field Data
• Polygons
• Documenation

Hadoop

• Good at:
• Storing, processing, querying big data sets
• „batch“ processing of data
• Bad at:
• Processing spatial data
• Handling time and space components
• Visualization of (spatial / temporal) data

21.09.2017

21.09.2017

• 1. CLAAS & GIS Technologies
• 2. Hadoop as a „Big Data“ Ecosystem
• 3. Big Data & GIS Technologies
• 4. Résumé

How can the current big data infrastructure be extended by ESRI technology to support the spatial component of the data in the processing process at CLAAS? Does the use of GIS technologies have an added value for information processing at CLAAS?

21.09.2017

Research cooperation with 52N and ESRI

GIS Tools for Hadoop:

• pen-source
• Esri Geometry API for Java: Java based API
• Spatial Framework for Hadoop: adds User Defined Functions (UDFs)

for spatial queries

• Geoprocessing Tools for Hadoop: connection to ArcGIS Desktop

21.09.2017

Configuration 1: GIS Tools for Hadoop

• calculating the average of selected DGM points
• selecting DEM points that are within a buffer of 5 m

around the GPS point

• assigning the average height to the GPS point

SELECT tm_gps.*, AVG(dgm_dt.dgm_height) as avg_gps_height FROM tm_gps, dgm_dt WHERE ST_Contains( ST_Buffer(ST_Point(tm_gps.gps_long, tm_gps.gps_lat), 0.000045), ST_Point(dgm_dt.dgm_long, testdgm2.dgm_lat)) GROUP BY tm_gps.id, tm_gps.gps_long, tm_gps.gps_lat, tm_gps.gps_height;

21.09.2017

Configuration 1: GIS Tools for Hadoop - Example

enrichment of altitude data Code Explanation

• spatial binning: partitioning space by a grid
• f fixed resolution, aggregation of height

values from the DEM in each cell

• each cell has a unique ID, assigning the

aggregated height values to the grid cells

• determining the Bin-IDs
• joining the machine data to the height

values

CREATE VIEW height_agg_bin AS SELECT bin_id, ST_BinEnvelope(0.0005, bin_id) shape, COUNT(*) count, AVG(dgm_height) height, MAX(dgm_height) max, MIN(dgm_height) min FROM ( SELECT ST_Bin(0.0005, ST_Point(dgm_dt.dgm_long, dgm_dt.dgm_lat)) bin_id, * FROM dgm_dt ) bins GROUP BY bin_id; SELECT * FROM ( SELECT *, ST_BIN(0.0005, ST_Bin(0.0005, ST_Point(gps_long, gps_lat))) as bin_id FROM tm_gps ) t1 LEFT OUTER JOIN height_agg_bin t2 ON (t1.bin_id = t2.bin_id);

21.09.2017

Configuration 1: GIS Tools for Hadoop - Example

enrichment of altitude data: spatial binning Code Explanation

ArcGIS Enterprise Stack

• Hadoop Cluster is integrated as a Big Data File Share
• extension of the Hadoop system with ArcGIS Software
• API for Python to use the ArcGIS Enterprise components in

code scripts

• ArcGIS Pro to operate processes on ArcGIS Enterprise

21.09.2017

Configuration 2: ArcGIS Enterprise

Use Case example using the GeoAnalytics Server

• detection of field boundaries on the basis of GPS points using

GIS technologies

Use Case example Field boundaries

21.09.2017

Step 1: Preprocessing Input data points: GPS position + timestamp Attributes = sensor data

Use Case example Field boundaries

21.09.2017

Use Case example Field boundaries

Step 1: Preprocessing Filtering of non relevant data (street data, U-turns, null values,…)

21.09.2017

Use Case example Field boundaries

Step 2: Reconstruction of field trajectories “Reconstruct Tracks” Tool

21.09.2017

Step 3: Grouping Grouping field tracks to fields by dissolving or rastering and grouping the tracks.

Use Case example Field boundaries

21.09.2017

Step 4: Generating field boundaries Extracting the field polygons by expanding the field tracks to the work width of the machine.

Use Case example Field boundaries

21.09.2017

Known Issues:

• Hadoop is secured by Apache Knox Gateway  workaround required
