Ground/Air Source Heat Pumps

ecoGEO

SLIDE 2

ECOFOREST GEOTERMIA

New company, 2010, Ecoforest Geotermia

Manufacture of ground/air source heat pumps More than 7 years of research and development University of Vigo

SLIDE 3

HEAT PUMPS

Heat pumps, the future energy technology in Europe

► Key technology for the future European Energy Goals European Directive, 20/20/20, 2020 20% renewable energies 20% CO2 emissions reduction 20% systems efficiency increasing 20% systems efficiency increasing

Europ. Direct. 2050, Nearly Net Zero Energy Buildings (nZEB)

► Heat pumps, the key technology for heating and cooling. ► Great cost savings, reduction of the energy consuption up to 80% ► Green technology, reduction of CO2 emissions

SLIDE 4

STANDARD HEAT PUMPS TECHNOLOGY

On/off compressors, NO INVERTER, fixed rotation velocity

The Seasonal Performance Factor (SPF) decreases significantly because the heat

pump can’t adapt to the demand variations and the outlet temperature of the heat pump needs to be higher

A buffer tank and at least one additional shunt group (circulation pump +

mixing valve) are needed increasing considerably the cost and the complexity of mixing valve) are needed increasing considerably the cost and the complexity of the installation

Besides the buffer tank means a loss of efficiency throughout the year, since its

temperature is higher (winter) or lower (summer) than the ambient temperature

SLIDE 5

STANDARD HEAT PUMPS TECHNOLOGY

On/off compressors, NO INVERTER, fixed rotation velocity

ecoGEO Installation Traditional Installation

Additional shunt group

Installation overcost(Buffer tank + shunt group): 1.500 ̴2.500 €

Buffer tank

SLIDE 6

STANDARD HEAT PUMPS TECHNOLOGY

On/off compressors, NO INVERTER, fixed rotation velocity

In many cases an oversizing, and therefore an overcost, of the brine system is

needed since the thermal power needed does not match any commercial value and installing a higher capacity heat pump is required PRACTICAL EXAMPLE PRACTICAL EXAMPLE

Thermal power needed: 11,2 kW Thermal power needed: 11,2 kW Installed power with traditional heat pump (closest commercial value that meets): 13 kW Installed power with ecoGEO heat pump: 11,2 kW Dimensioning of the brine system

1- Installation with traditional heat pump mbrine system = ((13-(13/5))/50)*1000= 208 m 2- Installation with ecoGEO heat pump mbrine system = ((11,2-(11,2/5))/50)*1000= 179 m

mbrine system = ((P-(P/COP))/PEE)*1000 PEE≡ Especific extraction power [W/m]

Cost of the brine system

1- Installation with traditional heat pump Cost= 208 m * 35 €/m= 7.280 € 2- Installation with ecoGEO heat pump Cost= 179 m * 35 €/m= 6.265 €

Overcost in the brine system: 1.015 €

Drilling cost considered : 35 €/m

SLIDE 7

STANDARD HEAT PUMPS TECHNOLOGY

External modules for cooling

Hydraulic inversion
Significant increase in the cost of equipment and installation

(2.500 ̴3.500 €)

Much more complex installations
In many cases brine is also necessary in the heating/cooling circuit

SLIDE 8

STANDARD HEAT PUMPS TECHNOLOGY

External modules for cooling

ecoGEO Installation Traditional Installation

Additional shunt group

Installation overcost(Buffer tank + shunt group + module for cooling): 4.000 ̴6.000 €

Buffer tank External module for cooling

SLIDE 9

STANDARD HEAT PUMPS TECHNOLOGY

Thermostatic expansion valves

Much worse control of the refrigerant flow
As a consequence, bigger overheating degrees bigger electrical

consumption for the compression and worse COP

log P

Thermostatic expansion valve Electronic expansion valve

h Pe 2 Pc 4=4’ 1’ 3=3’ 2´ 1

h2-h1 h2’-h1’ h2’-h1’ > h2-h1 Wcomp’ > Wcomp

COP’ < COP

SLIDE 10

STANDARD HEAT PUMPS TECHNOLOGY

Circulation pumps, fixed velocity and less power

Unable to adapt to demand variations bigger electrical consumption
Higher differences of temperature between the inlet and outlet of the heat

exchangers lower evaporation pressure and higher condensation pressure worse COP

log P

Fixed speed and low power circulation pumps Variable speed and high power circulation pumps

h log P Pe’ 2 Pc’ 4 1’ 3=3’ 2´ 1

h2-h1 h2’-h1’

Fixed speed and low power circulation pumps

Pe Pc 4’

h2’-h1’ > h2-h1 Wcomp’ > Wcomp

COP’ < COP

SLIDE 11

STANDARD HEAT PUMPS TECHNOLOGY

Refrigerant R407C

Much more zeotropic than R410A

the temperature is not constant during evaporation and condensation processes lower efficiency in the heat exchangers worse COP

In case of leakage of refrigerant in the circuit to completely drain and refill

the circuit is necessary the circuit is necessary

SLIDE 12

STANDARD HEAT PUMPS TECHNOLOGY

Only 3-phase power supply for higher power models

Less flexibility
To negotiate a new contract with the electric company is necessary

Big peaks of consumption when the compressor starts Big peaks of consumption when the compressor starts (large starting currents)

Oversized electrical installations
Great effect on the SPF

SLIDE 13

ECOFOREST TECHNOLOGY

Improved technology from the European manufacturers

Inverter technology from Copeland Driver + Scroll compressor 1st and unique European manufacturer

Electronic expansion valve, all models Electronic expansion valve, all models Variable speed circulation pumps, Class A, integrated Micro-PC, control based system Refrigerant R410A Our own control strategies, our own control software 1-Phase or 3-Phase power supply Soft starts

SLIDE 14

ECOFOREST TECHNOLOGY

Main components from well-know manufacturers worldwide

Inverter technology, scroll compressor, from COPELAND Plate heat exchangers, ALFA LAVAL Electronic expansion valve, CAREL Control implementation μPC, CAREL Variable speed pumps Class A, WILO Auxiliary components, DANFOSS Domestic hot water tank and coil, Stainless Steel 316L

SLIDE 15

ecoGEO INVERTER TECHNOLOGY Award winners of the year's best technology in NEW YORK AHR EXPO 2014

SLIDE 16

ecoGEO INVERTER TECHNOLOGY

New Inverter technology from Copeland

Driver + Copeland scroll variable speed compressor
rpm range, from 1800 to 7000
2 driver-compressors, 3 to 12 kW and 5 to 22 kW
Electric power supply, 1-phase, 3-phase
Possibility to limit the thermal power and the

electrical consumption

No need for soft starters, 1800 rpm.
No intensity peaks

SLIDE 17

ecoGEO INVERTER TECHNOLOGY

DHW

4 kW

POOL

8 kW

HEATING

12 kW

COOLING

6,5 kW

ecoGEO Heat Pump Traditional Heat Pump

Adaptation of the heat pump to the installation Adaptation of the installation to the heat pump

VS

Inverter technology allows adapting the power of the heat pump in each of the services

SEVERAL HEAT PUMPS IN ONE

The DIRECT connection to the different services ensures minimum outlet temperatures, maximum efficiency and lower installation costs

SLIDE 18

ecoGEO INVERTER TECHNOLOGY

Cooling of the Inverter by heating system. Our own design

No fan needed, lower electrical consumption
No apertures in the case, lower noise level
Injection of the heat recovered from the Inverter into the heating

system, increase of the SPF system, increase of the SPF

SLIDE 19

ecoGEO TECHNOLOGY

Electronic expansion valve

Controller integrated into μPC, Carel sensors
Accurate and quick control of superheating
Accurate control of mass flow to evaporator
Improvement of evaporator efficiency
Quick response to load changes
Mainly important with inverter
No need for shut-off solenoid valve

SLIDE 20

ecoGEO TECHNOLOGY

Plate heat exchangers

Condenser, asymmetric plates channels
Evaporator, “Equalancer” distribution system

SLIDE 21

ecoGEO TECHNOLOGY

Speed controlled circulation pumps

Speed range, 1400 to 4850 rpm
High Power, 11 mwc
Maximum flow rate, 4500 l/h
Energy efficiency, Class A
Energy efficiency, Class A
Integrated in brine and heating circuits
Control of temperature difference in evaporator (3 ⁰C)

and condenser (5 ⁰C)

SLIDE 22

ecoGEO TECHNOLOGY

μPC based Control system. Our own control strategies

Our own control strategies and software

SLIDE 23

ecoGEO TECHNOLOGY

Simple user interface. Carel screen

User and installer access levels
Multilanguage support

SLIDE 24

ecoGEO TECHNOLOGY

Instrumentation and control

Temperature sensors
Refrigerant suction and discharge
Supply/return brine and heating circuits
Inverter plate and motor wiring
Inverter plate and motor wiring
Pressure sensors
Refrigerant suction and discharge
Brine and heating dircuits
Electric power, Inverter
Compressor torque, maximum torque

SLIDE 25

ecoGEO TECHNOLOGY

Power, COP, SPF and energy counters

Instantaneous
Electric power, measured
Heating/cooling power, calculated
COP
COP
Daily, monthly and yearly energy counter
Electric energy, measured
Heating / cooling energy, calculated
SPF

SLIDE 26

ecoGEO TECHNOLOGY

Compact Unit, “all in one concept”

Integrated brine and heating circulation pumps
Integrated brine and heating expansion vessels
Integrated security valves
Integrated flexible stainless steel hoses
Integrated drainage valves

SLIDE 27

ecoGEO TECHNOLOGY

Quiet, sound insulation, on the case and the compressor

SLIDE 28

ecoGEO TECHNOLOGY

Vibrations protection

Stainless steel hoses

SLIDE 29

ecoGEO – DOMESTIC BRANCH

3 cooling modules

MF1, space heating and DHW
MF2, space heating, DHW and passive cooling
MF3, space heating, DHW and active cooling by reversing the cycle
MF3, space heating, DHW and active cooling by reversing the cycle

SLIDE 30

ecoGEO – DOMESTIC BRANCH

ecoGEO C - Compact 170 l tank ecoGEO B - Basic

SLIDE 31

ecoGEO – DOMESTIC BRANCH

2 heating power ranges

3 to 12 kW
5 to 22 kW

Electrical supply

1 Phase
3 Phase

SLIDE 32

ecoGEO – DOMESTIC BRANCH

Basic 3 - 12 kW

ecoGEO B1 3-12, space heating and DHW ecoGEO B2 3-12, space heating, DHW and passive cooling ecoGEO B3 3-12, space heating, DHW and active cooling

Compact 3 - 12 kW

ecoGEO C1 3-12, heating, DHW with 170 l tank ecoGEO C2 3-12, heating, DHW with 170 l tank and passive cooling ecoGEO C3 3-12, heating, DHW with 170 l tank and active cooling

SLIDE 33

ecoGEO – DOMESTIC BRANCH

Basic 5 - 22 kW

ecoGEO B1 5-22, space heating and DHW ecoGEO B2 5-22, space heating, DHW and passive cooling ecoGEO B3 5-22, space heating, DHW and active cooling

Compact 5 - 22 kW

ecoGEO C1 5-22, heating, DHW with 170 l tank ecoGEO C2 5-22, heating, DHW with 170 l tank and passive cooling ecoGEO C3 5-22, heating, DHW with 170 l tank and active cooling

SLIDE 34

ecoGEO – MF1

MF1 cooling module, space heating and DHW

COMP. 3wV DHW supply Heating Ground return EVAP COND COMP.

EXP. V.

Combi Heating supply DHW return Ground supply Heating return

SLIDE 35

ecoGEO – MF1

MF1 cooling module, space heating and DHW

SLIDE 36

ecoGEO – MF2

MF2 cooling module, space heating, DHW and passive cooling

COMP. 3wV DHW supply Heating supply Ground return

PCHE

EVAP COND

EXP. V.

Combi

supply DHW return Ground supply Heating return

SLIDE 37

ecoGEO – MF2

MF2 cooling module, space heating, DHW and passive cooling

SLIDE 38

ecoGEO – MF3

MF3 cooling module, space heating, DHW and active cooling

Heating and DHW

4wV

COMP. DESR DHW supply DHW

4wV AR

EXP.V. EVAP COND DESR Combi Ground supply Ground return DHW return Heating supply Heating return

SLIDE 39

ecoGEO – MF3

MF3 cooling module, space heating, DHW and active cooling

Active cooling and DHW

4wV

COMP. DESR DHW supply DHW

4wV

EXP.V. DESR Combi Ground supply Ground return DHW return Heating supply Heating return EVAP COND COND EVAP

SLIDE 40

ecoGEO – MF3

MF3 cooling module, space heating, DHW and active cooling Simultaneously Simultaneously production of DHW and heating or cooling

SLIDE 41

ecoGEO – CHW PATENTED PATENTED SYSTEM

DHW Inlet DHW Outlet DHW Inlet DHW Outlet

HEATING + DHW HEATING + DHW COOLING COOLING + + DHW DHW

Water Inlet Water Outlet Brine Inlet Brine Outlet Evaporator Condenser Water Inlet Water Outlet Brine Inlet Brine Outlet Evaporator Condenser

SLIDE 42

ecoGEO – AIT CERTIFICATION

The prestigious AIT (Austrian Institute of Technology) confirmed our heat pumps as the ones with the highest yields in the market of the Inverter and single phase geothermal heat pumps

COP COP COP COP

4,9 4,9

According According to to EN 14511 S0⁰C/W35⁰C EN 14511 S0⁰C/W35⁰C with with single single phase phase power power supply supply, , including including Inverter and Inverter and circulation circulation pumps pumps

SLIDE 43

ecoGEO – HEATING POWER

Heating power 3-12 kW, 30/35 ºC

12 14 16 18 (kW) 0 / -3 5 / 2 10 / 7 2 4 6 8 10 12 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 Potencia calorífica (k rpm

SLIDE 44

ecoGEO – HEATING POWER

Heating power 5-22 kW, 30/35 ºC

25 30 35 W) 0 / -3 5 / 2 10 / 7 5 10 15 20 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 Potencia calorífica (kW) rpm

SLIDE 45

ecoGEO – ELECTRIC POWER

Electric power 3-12 kW, 30/35 ºC

SLIDE 46

ecoGEO – ELECTRIC POWER

Electric power 5-22 kW, 30/35 ºC

SLIDE 47

ecoGEO – COP

COP 3-12 kW, 30/35 ºC

SLIDE 48

ecoGEO – COP

COP 5-22 kW, 30/35 ºC

5,0 6,0 7,0 0,0 1,0 2,0 3,0 4,0 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 COP rpm 0 / -3 5 / 2 10 / 7

SLIDE 49

ecoGEO – INSTALLATIONS

Inverter technology

No buffer tank and no additional shunt groups
Direct connection to the different services
Possibility of adapting the power to each of the demands
Possibility of adapting the power to each of the demands

All in one, “plug and play”

Quick and easy installation

Simple and much cheaper installations

SLIDE 50

ecoGEO – INSTALLATIONS

Geovive showroom

Offices, 160 m2 Underfloor heating ecoGEO C2 3-12

DHW inlet DHW outlet BRINE inlet/outlet Heating inlet/outlet

ecoGEO C2 3-12 Borehole, 150 m

SLIDE 51

ecoGEO – INSTALLATIONS

Private house

260 m2 Heating, 15 kW Cooling, 8 kW Cooling, 8 kW ecoGEO B3 5-22 2 Boreholes 120 m

SLIDE 52

ecoGEO – INSTALLATIONS

Private house

320 m2 Heating, 16 kW Underfloor heating Underfloor heating ecoGEO C1 5-22 2 Boreholes, 120 m Without buffer tank

SLIDE 53

ecoGEO – INSTALLATIONS

Private house

180 m2 Underfloor heating, 10 kW

DHW tank, 500 l

ecoGEO B1 3-12 Without buffer tank

Borehole, 150 m DHW tank, 500 l

SLIDE 54

ecoGEO – INSTALLATIONS

Private house

180 m2 Heating, 10 kW

DHW tank, 300 l

Cooling, 6 kW ecoGEO B3 3-12 Without buffer tank

DHW tank, 300 l

SLIDE 55

ecoGEO – INSTALACIONES

Private house

250 m2 Heating, 12 kW Underfloor heating Underfloor heating ecoGEO C1 3-12 2 boreholes, 100 m With a little 80 l buffer tank in the return of the heating circuit

SLIDE 56

ecoGEO – INSTALACIONES

Private house

260 m2 Heating, 12 kW cooling, 5,5 kW cooling, 5,5 kW Underfloor heating/cooling Fancoils ecoGEO C3 3-12 2 boreholes, 100 m Without buffer tank

SLIDE 57

ecoGEO – INSTALLATIONS

Private house

320 m2 Underfloor heating Cooling Cooling Swimming pool 20 kW ecoGEO B3 5-22 Solar + Heat pump

SLIDE 58

ecoGEO AIR

Compatible with ecoGEO C and ecoGEO B heat pumps

SLIDE 59

ecoGEO AIR

PATENTED DEFROSTING SYSTEM

2 3

Brine from air unit

Patented defrosting system by hot brine that contributes to significantly increase the seasonal performance factor (SPF)

Defrost heat exchanger

1

Internal 3-way defrost valve

2

External 3-way defrost valve

3 Hot brine to air unit

1 2

The stops of the heat pump and the waiting times are completely avoided because it is not necessary to reverse the cycle or to activate electrical resistances External defrost valve prevents the production of cooling in the house during the defrost cycles

SLIDE 60

ecoGEO AIR

HYBRID CONFIGURATION

Possible to combine with rock/ground collector

SLIDE 61

ecoGEO AIR

Axial fan Ziehl-Abegg, with the greatest efficiency and the lowest noise of the market Control of fan speed

SLIDE 62

ecoGEO AIR

Exclusively hydraulic installation Main components of the installation in the indoor unit, which increases its service life Special protections for operation under extreme external conditions Flexible positioning of the Aerothermal Unit Operation down to -15 º C

SLIDE 63

ecoGEO HP – HIGH POWER

SLIDE 64

ecoGEO HP – HIGH POWER

NEW INVERTER TECHNOLOGY BY DANFOSS

SLIDE 65

ecoGEO HP – HIGH POWER

Electronic expansion valve Alfa Laval plate heat exchangers

SLIDE 66

ecoGEO HP – HIGH POWER

Control PCO5+ Our own software and control strategies

SLIDE 67

ecoGEO HP – HIGH POWER

Possibility to drive up to 5 shunt groups Electrical, thermal, COP and SPF energy meters Possibility to connect up to 6 units in cascade Pressure sensors and flow meters in the brine and heating circuits

SLIDE 68

ecoGEO HP – HIGH POWER

3 Heating capacities

12 to 40 kW
15 to 70 kW
25 to 100 kW

3 – phases

ecoGEO HP1 12 – 40 kW ecoGEO HP1 15 – 70 kW ecoGEO HP1 25 – 100 kW

Heating and DHW

COP

4,6 - 5 4,6 - 5 4,6 - 5

Refrigerant R410A

Scroll compressor with Inverter

technology

Electronic expansion valve

SLIDE 69

ecoGEO HP – HEATING POWER

Heating power 12-40 kW, 30/35 ºC

SLIDE 70

ecoGEO HP – HEATING POWER

Heating power 15-70 kW, 30/35 ºC

SLIDE 71

ecoGEO HP – HEATING POWER

Heating power 25-100 kW, 30/35 ºC

SLIDE 72

ecoGEO HP – ELECTRIC POWER

Electric power 12-40 kW, 30/35 ºC

SLIDE 73

ecoGEO HP – ELECTRIC POWER

Electric power 15-70 kW, 30/35 ºC

SLIDE 74

ecoGEO HP – ELECTRIC POWER

Electric power 25-100 kW, 30/35 ºC

SLIDE 75

ecoGEO HP – COP

COP 12-40 kW, 30/35 ºC

SLIDE 76

ecoGEO HP – COP

COP 15-70 kW, 30/35 ºC

SLIDE 77

ecoGEO HP – COP

COP 25-100 kW, 30/35 ºC

SLIDE 78

COMING

THE ENERGY REVOLUTION ecoGEO SOLAR HEAT PUMP

DIRECT CONNECTION!!

SLIDE 79

ecoGEO SOLAR

Electronic module

DIRECT CONNECTION TO PHOTOVOLTAIC PANELS

Heat pump, B1, B2, B3 3-12 / 5-22 Electronic module

SLIDE 80

ecoGEO SOLAR

AUTONOMOUS HEAT PUMPS

HYBRID SYSTEM FOR THERMAL AND ELECTRICAL PRODUCTION

SLIDE 81

ecoGEO SOLAR

Net interconnection Batteries charge Coupled to generator Electric car recharger Touchable colour screen Complete energy management Smart grids

SLIDE 82

ECOFOREST GEOTERMIA

www.ecoforest.es www.ecoforest.es comercial.geotermia@ecoforest.es

Ground/Air Source Heat Pumps

ecoGEO
