Easy Tank Speed Log

2017-05-18 Consilium 2

STW Speed Log with Easy Installation

2017-05-18 Consilium 3

• Based on proven Acoustic Correlation principle
• Easy calibration
• Well proven technology

High Performance Speed Log

2017-05-18 Consilium 4

• Advantages with the Acoustic Correlation principle:
• Not sensitive to temperature or salinity layers
• Not affected by boundary layers

Influence of Currents for Speed Measurement

 vx Weak current Strong current vx Measured speed too far away from the vessel may not reflect the conditions at the vessel

Influence of the Boundary Layer

Strong Calibration always needed

Summary of Sources of Potential Errors

Acoustic logs EM logs Doppler Correlation (SAL) Temp layer Salinity layer Sub-currents Ship motion Air bubbles Boundary layer EMC Anti-Corrosion

2017-05-18 Consilium 8

Easy Tank - Easy to Install

• Few mechanical parts
• Transducer mounting from the inside
• f the hull
• Light weight bottom parts

2017-05-18 Consilium 9

Safe Design

• Pressure tested to 40 bar (400 m)
• Rugged mechanical design
• Water tight cable

2017-05-18 Consilium 10

Easy Tank vs closed Sea Valve

Equally high or higher water integrity level

Space Savings

2017-05-18 Consilium 11

• Small and compact bottom parts
• Acoustic Correlation technology to the price of an EM log

The Easy Tank System

2017-05-18 Consilium 12

Easy Tank Data

• Speed Through Water measurement, STW
• Cable length: 10 m
• Size of transducer: Ø: 168 mm Height: 84 mm
• Weight of transducer incl. cable: 6 kg
• Pressure tested to 40 bar (400 m)
• Approved for both steel and aluminum hull
• ABS type approved
• Patent Pending
