E-Paper – Technology Overview

Release: November 2016

a d ko m . d e Basics of the E-Paper Technology:

1975 Development at the Xerox Palo Alto Research Center 1990 Formation of the MIT Spin off

Operating mode of the E-Paper Technology:

The E INK fluid consists of pellets which contain negatively charged black- and positively charged white flakes. They are enclosed in the sphere. The medium (pellet) is embedded in a light oil. By applying voltage, the flakes can be drawn either to the front- or back

• f the layer / fluid to display the desired content.

a d ko m . d e Construction of an E-Paper:

The structure of an e-paper is clear: Layer 1 is a transparent, waterproof protective foil, which is followed by layer 2 with the actual E INK film. The 3rd layer includes the base substrate, which may consist out of PCB, FPC, PET or glass. A waterproofed protection foil in Layer 4 is finally covering the construction. E-paper, are also named as electrophoretic displays or in short form EPDs, are high-resolution and can in partial addressing of the particles represent several grey shades.

a d ko m . d e Advantages of E-Papers:

• Bi-Stability – Power consumption only on changes of the

display content. Powerless during periods of unchanged representation of the displayed Information.

• Information can be displayed unchanged over a long

period of time.

• Wide viewing angle from all sides
• High Contrast
• High-resolution
• Representation of grey scales
• Very low overall height
• Reflective – good readability without backlighting -

even when exposed to direct sunlight

• Suitable for battery applications.

Available as:

• Graphic glass based E-Paper within standard sizes.

Also as colored E-Paper B/W/R available

• Customized Segment E-Paper
• Flexible, customized Segment E-Paper

Currently valid data on the service life and temperature range: Guaranteed by manufacturer:

• 1.000.000 Refreshes - or
• 5 Years
• ± 0°C up to +50°C

Full Mono- Color chrome Operating temperature Ultra wide temperature Storage temperature UV protection Sunlight readable Viewing angle Bistable display Backlight Thickness display unit Lifetime Refresh time Customization possible ve very g good high volume Specific application criteria available

• dep. on application
• dep. on appl.

higher than other medium high

• 30°C~+85°C
• 40°C~ +105°C
• 20°C~+65°C

E-Paper TFT PMOLED reflective transflective transmissive LCD

• 40°C~ +105°C
• 30°C~+85°C
• 20°C~+70°C
• 10°C~+55°C
• 30°C~+85°C

to be defined 0°C~+50°C

• 25°C~+70°C
• ptional
• ptional

good not available ADKOM™ Elektronik GmbH Segm. IPS TN Segm. Graph. Flex. Graph. Segm. Graph. Segm. Graph.

• ptional
• ptional

a d ko m . d e E-Paper compared to other technologies: Access to E-Paper production via ADKOM:

• leading E-Paper producer with one production lines
• Authorized E INK partner since 2011
• ISO 9001:2008 and ISO/TS 16949:2009 certified

a d ko m . d e Standard sizes graphic E-Paper, base: Q4‘2016

An actual release of our list of the available standard sizes in graphical, glass based E-Papers your will find at: www.adkom.de/en/display-technology/e-paper/grafic-e-paper.html Except of 6.0“, 9,7“ and 13,3“ all size out of own series production from our partner. Thereby:

• better plannability
• better availability
• direct knowledge about changes and EOL notices
• Design-in services
• Development, design and production of controller boards

ADKOM Services around E-Paper:
