SLIDE 1

Innovation Devotion Honesty

E-Lins Technology Co.,Ltd

Mobile Router & Modem (Industrial Class)

SLIDE 2

Innovation Devotion Honesty

E-Lins Technology Co.,Ltd

Factory Inside & Factory Office Corner

SLIDE 3

Product Series Industrial Class Cellular Mobile Router

1. GPRS Router – Back compatible to GSM
2. EDGE Router – Back compatible to GPRS & GSM
3. CDMA Router – Back compatible
4. HSDPA Router – Back compatible to EDGE & GPRS & GSM
5. HSUPA Router – Back compatible to HSDPA & EDGE & GPRS & GSM
6. EV-DO Router – Rev 0 & Rev A. Back compatible to CDMA

Interface: RJ45, RS232 Configuration: VPN, 1 LANs, 1 WAN, Dual Module Dual SIM, WiFi Industrial Class Cellular Mobile Modem

1. GPRS Modem – Back compatible to GSM
2. EDGE Modem – Back compatible to GPRS & GSM
3. CDMA Modem – Back compatible
4. HSDPA Modem – Back compatible to EDGE & GPRS & GSM
5. HSUPA Modem – Back compatible to HSDPA & EDGE & GPRS & GSM
6. EV-DO Modem – Back compatible to CDMA

Interface: RS232 (DB9) or USB

SLIDE 4

Product Series Products Bands:

1. GPRS Series – Dual Band (900/1800Mhz or 850/1900Mhz) or

Quad Band (850/900/1800/1900Mhz)

2. EDGE Series – Quad Band (850/900/1800/1900Mhz)
3. CDMA Series – 800Mhz or 450Mhz or 1900Mhz
4. HSDPA Series – UMTS: 2100Mhz or 2100/1900/850Mhz

EDGE/GPRS/GSM: 850/900/1800/1900Mhz

5. HSDPA Series – UMTS: 2100Mhz or 2100/1900/850Mhz

EDGE/GPRS/GSM: 850/900/1800/1900Mhz

6. EV-DO Series: – 800Mhz or 450Mhz or 1900Mhz

SLIDE 5

EL-H685w HSDPA WiFi Router

Remote Management with SNMP Zero-configuration UPnP support Web based SMS client R&TTE and GCF certified

4. Data speeds

HSDPA 7.2 Mbps Download, HSUPA 2Mbps Upload

5. Interface

LAN Ethernet Interface: 10/100Base T/RJ45 802.11b/g Power interface Reset: R jack Antenna for 3G: 50ohm/SMA/Female UIM/SIM card: 3V Configuration interface: WEB Alarm output interface: TTL

6. Power Supply

Voltage: +5VDC (+7.5~12VDC Optional) Power consumption:

Max. current: 680mA @ +5VDC

Idle: 50mA @ +5VDC

7. Size & Weight

Dimension: 250*140*40mm Weight: 320g

8. Environment

Temperature -10 ~ +60℃ Humidity: 95% (Non-condensing)

Specifications

1. Radio Frequency

HSDPA/UMTS 2100/1900/850MHz GSM/GPRS/EDGE 850/900/1800/1900MHz

2. Parameters

GPRS/EDGE Class 2~10 Code plan: CS1~CS4 Complied with SMG31 bis specifications

3. Function

Support User-friendly Web GUI; Firmware Upgradeable; Traffic & Event Log; Auto-Reconnect; Firewall - NAT, ALG modules, DMZ VPN and Tunneling support Network Services include DHCP, Time, DNS

SLIDE 6

EL-H685w HSDPA WiFi Router

Network Services include DHCP, Time, DNS Remote Management with SNMP Zero-configuration UPnP support Web based SMS client R&TTE and GCF certified

4. Data speeds

7.2 Mbps Download, 384kbps upload; easily upgrade to HSUPA 2Mbps Download

5. Interface

LAN Ethernet Interface: 10/100Base T/RJ45 802.11b/g Power interface Reset: R jack Antenna for 3G: 50ohm/SMA/Female UIM/SIM card: 3V Configuration interface: WEB Alarm output interface: TTL

6. Power Supply

Voltage: +5VDC (+7.5~12VDC Optional) Power consumption:

Max. current: 680mA @ +5VDC

Idle: 50mA @ +5VDC

7. Size & Weight

Dimension: 98*100*23mm(not including antenna) Weight: 320g

8. Environment

Temperature -10 ~ +60℃ Humidity: 95% (Non-condensing)

Specifications

1. Radio Frequency

HSDPA/UMTS 2100/1900/850Mhz GSM/GPRS/EDGE 850/900/1800/1900MHz

2. Parameters

GPRS/EDGE Class 2~10 Code plan: CS1~CS4 Complied with SMG31 bis specifications

3. Function

Support User-friendly Web GUI; Firmware Upgradeable; Traffic & Event Log; Auto-Reconnect; Firewall - NAT, ALG modules, DMZ VPN and Tunneling support

SLIDE 7

EL-EV585w EVDO WiFi Router

3. Data speeds

Forward Link : 2.4 Mbps, Backward Link : 153.6 Kbps

5. Interface

LAN Ethernet Interface: 10/100Base T/RJ45, 802.11 b/g Power interface Reset: R jack Antenna for 3G: 50ohm/SMA/Female UIM/SIM card: 3V Configuration interface: WEB Alarm output interface: TTL

6. Power Supply

Voltage: +5VDC (+7.5~12VDC Optional) Power consumption:

Max. current: 680mA @ +5VDC

Idle: 50mA @ +5VDC

7. Size & Weight

Dimension: 98*100*23mm(not including antenna) Weight: 320g

8. Environment

Temperature -10 ~ +60℃ Humidity: 95% (Non-condensing)

Specifications

1. Radio Frequency

CDMA 1X EV-DO REV A / CDMA 1XRTT CDMA 800/1900 MHz

r Single band 450Mhz or 800Mhz or 1900Mhz
2. Function

Support User-friendly Web GUI; Firmware Upgradeable; Traffic & Event Log; Auto-Reconnect; Firewall - NAT, ALG modules, DMZ VPN and Tunneling support Network Services include DHCP, Time, DNS Remote Management with SNMP Zero-configuration UPnP support Web based SMS client R&TTE and GCF certified

SLIDE 8

EL-E481 EDGE Router

Product Specifications

1. Band

Dual-band GSM900Mhz/,DCS1800Mhz,

r GSM(EGSM)850/900MHz/DCS(GSM)1800/1900MHz
2. Specification

Serial Data rate: 300 to 115, 200 bits/s; Data transmission: EDGE Speed rate: 230.6Kbps~460.8Kbps (maximum) GPRS Speed rate:115.2 kbps

3. Features

Local/remote profiles backup and retrieve Local Local/Remote firmware upgrade Urgent event alarm via SMS Built-in DHCP server Support Support DMZ host, Firewall and NAT Support packet filtering. Support data center communication Transparent data transmission Support radio network data envelope counting Support APN Support multiple protocol conversion, Real-time clock (RTC) Web/Telnet/console management interface ways-on-line, Self-diagnostic and alarm output

4. Interface

Standard RJ-45/RS-232 Standard serial Port(DB-9), Antenna: 50ohm/SMAFemale

5. Configuration interface

WEB/telnet/console

6. Supply voltage range:

5-25VDC

7. SIM interfaces: 3V/1.8V
8. Firewall Speed: 100Mbps
9. Power consumption: Sleep mode 3.5 mA, Speech

mode 300 mA (average), Power down 50 uA

10. Dimensions:

(W*D*H): 59mm *100mm * 23mm Weight : 200 g

11. System Requirements:

Windows Vista, Windows XP, Windows 2000, Internet Explorer 6 CD-ROM Drive

12. Environment:

Working temperature: -20 ~ 60 centigrade degrees, Storage temperature: -30 ~ 85 centigrade degrees, Humidity: < 95% (non-condensing)

SLIDE 9

EL-G285 GPRS Router

Product Specifications

1.Compatible Mobile Networks Dual-band GSM900/1800MHz dual band Or GSM 850/900/1800/1900MHz quad band

2. Specificataion

Serial Data rate: 300 to 115, 200 bits/s Data transmission up to 153.6Kbps

3. Features

Local/remote profiles backup and retrieve Local Local/Remote firmware upgrade Urgent event alarm via SMS Built-in DHCP server Support Support DMZ host Firewall and NAT Support packet filtering. Support data center communication Transparent data transmission Support radio network data envelope counting Support APN Support multiple protocol conversion Real-time clock (RTC) Web/Telnet/console management interface Aways-on-line Self-diagnostic and alarm output

4. Interface

Standard RJ-45/RS-232 Standard serial Port(DB-9) Antenna: 50ohm/SMAFemale

5. Configuration interface

WEB/telnet/console

6. Supply voltage range

5-25VDC

7. SIM interfaces: 3V/1.8V
8. Firewall Speed: 100Mbps
9. Power consumption

Sleep mode 3.5 mA Speech mode 300 mA(average) Power down 50 uA

10. Dimensions: (W*D*H): 59mm *100mm * 23mm

Weight : 200 g

11. System Requirements

Windows Vista, Windows XP, Windows 2000 Internet Explorer 6 CD-ROM Drive

12. Environment

Working temperature: -20 ~ 60 centigrade degrees Storage temperature: -30 ~ 85 centigrade degrees Humidity: < 95% (non-condensing)

SLIDE 10

EL-C385 CDMA Router

Support packet filtering. Support data center communication Transparent data transmission Support radio network data envelope counting Support APN Support multiple protocol conversion Real-time clock (RTC) Web/Telnet/console management interface Aways-on-line, Self-diagnostic and alarm output

4. Interface: RS-232/485 Standard serial Port(DB-9)

Ethernet: 10/100BaseT/RJ45 Antenna: 50ohm/SMA Female

5. Configuration interface: WEB/telnet/console
6. Supply voltage range: 5-25VDC (9V suggested)
7. R-UIM interfaces: 3V/1.8V
8. Lan Speed: 100Mbps
9. Power consumption

Max.: 430mA @ +5VDC Idle: 22mA @+5VDC

10. Dimensions: (W*D*H): 59mm *100mm * 23mm

Weight : 200 g

11. System Requirements: Windows Vista, Windows

XP, Windows 2000 Internet Explorer 6 CD-ROM Drive

Product Specifications

1.Compatible Mobile Networks Dual-band DMA1x 800/1900MHz or Single Band800Mhz or 1900Mhz or 450Mhz

2. Speed

Serial Data rate: 300 to 115, 200 bits/s; Data transmission: CDMA Speed rate:153.6Kbps

3. Features

Local/remote profiles backup and retrieve Local Local/Remote firmware upgrade Urgent event alarm via SMS Built-in DHCP server Support Support DMZ host, Firewall and NAT

SLIDE 11

VPN Router, Multi-Port Router, Dual SIM Router

Product Specifications

1. GPRS/EDGE Band:

Dual-band GSM900Mhz/DCS1800Mhz,

r GSM(EGSM)850/900MHz/DCS(GSM)1800/1900MHz
2. Specificataion

Serial Data rate: 300 to 115, 200 bits/s; Data transmission: EDGE Speed rate: 230.6Kbps~460.8Kbps (maximum) GPRS Speed rate:115.2 kbps CDMA Speed rate:153.6Kbps

3. Built-in VPN

1 WAN 1 LAN, or 1WAN 4 LANs (For multi-port model only) Dual Mode Dual SIM (For Dual Mode Dual SIM model only)

4. Features

Local/remote profiles backup and retrieve Local Local/Remote firmware upgrade Urgent event alarm via SMS Built-in DHCP server Support Support DMZ host, Firewall and NAT Support packet filtering Support data center communication Transparent data transmission Support radio network data envelope counting Support APN Support multiple protocol conversion, Real-time clock (RTC) Web/Telnet/console management interface ways-on-line, Self-diagnostic and alarm output

5. Interface: Standard RJ-45/RS-232 Standard serial

Port(DB-9), Antenna: 50ohm/SMAFemale

6. Configuration interface: WEB/telnet/console
7. Supply voltage range:

5-25VDC

8. SIM interfaces: 3V/1.8V
9. Lan Speed: 100Mbps

SLIDE 12

EL-UH683 USB HSDPA Modem

4. Speed

Console Data transfer Speed: 115200bps Communication Data Speed: Downlink up to 7.2Mbps Uplink up to 385kbps CSD Downlink/Uplink up to 14.4kbps

5. Dimension & Weight

Dimension: 121*74*25mm Weight: 200g

6. Configuration interface: WEB/telnet/console
7. Environment

Work temperature: -30 ~ 80 centigrade degrees Storage temperature: -40 ~ 90 centigrade degrees Humidity: 95% (Non-condensing)

8. Interface

USB 2.0 full speed DB9 Interface (External)

10. Antenna

50ohm/SMA/Female

11. Shell

Steel metal shell: good electromagnetic shield and, heat radiate performance

Product Specifications

1. Radio Frequency

Tri-band HSDPA/UMTS-850/1900/2100 MHZ Quad-band EDGE/GPRS-850/900/1800/1900 MHZ Output Power: Class 4 (2W) @850/900 Class 3 (0.25W) @UMTS Class E2 (0.25W) @ 850/900 Class E2 (0.4W) @1800 Class 1 (1W) @1800/1900 Multi-slot class 10

2. Function

Support voice, SMS, data service TCP stack with IP and UDP protocol

3. input: 5 - 25VDC

SIM card support volt: 3V / 1.8V Power consumption: Off: 50mA Idle: <=2.5mA Minimal Power consumption

SLIDE 13

EL- UEV583 USB EV-DO Modem

4. Speed

Console Data transfer Speed: 115200bps Communication Data Speed: Downlink up to 2.4Mbps Uplink up to 153.2kbps

5. Dimension & Weight

Dimension: 121*74*25mm Weight: 200g

6. Configuration interface: WEB/telnet/console
7. Environment

Work temperature: -30 ~ 80 centigrade degrees Storage temperature: -40 ~ 90 centigrade degrees Humidity: 95% (Non-condensing)

8. Interface

USB 2.0 full speed DB9 Interface (External)

10. Antenna

50ohm/SMA/Female

11. Shell

Steel metal shell: good electromagnetic shield and, heat radiate performance

Product Specifications

1. Radio Frequency

CDMA 1X EV-DO REV A / CDMA 1XRTT CDMA 800/1900 MHz or 450Mhz

2. Function

Support voice, SMS, data service; TCP stack with IP and UDP protocol

3. input: 5 - 25VDC

SIM card support volt: 3V / 1.8V Power consumption: Off: 50mA Idle: <=2.5mA Minimal Power consumption

SLIDE 14

EL-G282 GPRS Modem

4. Speed

Console Data transfer Speed: 115200bps Communication Data Speed: Data speed up to 85.6Kbps (Theoretically) CSD Downlink/Uplink up to 14.4kbps (Experienced)

5. Dimension & Weight

Dimension: 75*50*16mm Weight: 200g

6. Environment

Work temperature: -20 ~ 55 centigrade degrees Storage temperature: -50 ~ 85 centigrade degrees Humidity: 95% (Non-condensing)

7. Interface

USB 2.0 full speed RS232/RS485 DB9 Interface (External)

8. Antenna

50ohm/SMA/Female

9. Shell

Steel metal shell: good electromagnetic shield and, heat radiate performance

Product Specifications

1. Radio Frequency

GSM(EGSM)900MHz/DCS(GSM)1800MHz dual band

r Quad band 850/900/1800/1900Mhz
2. Function

Support voice, SMS, data service; TCP stack with IP and UDP protocol

3. Voltage and Power

Input: 5 - 25VDC SIM card support volt: 3V / 1.8V Power consumption: Sleep mode: 3.5mA Working mode: 300mA (Average) Power down 50 uA GPRS Modem: 360mA (Average)

SLIDE 15

EL-G282 GPRS Modem

4. Speed

Console Data transfer Speed: 115200bps Communication Data Speed: Data speed up to 153kbps

5. Dimension & Weight

Dimension: 75*50*16mm Weight: 200g

6. Environment

Work temperature: -30 ~ 70 centigrade degrees Storage temperature: -50 ~ 85 centigrade degrees Humidity: 95% (Non-condensing)

7. Interface

USB 2.0 full speed RS232/RS485 DB9 Interface (External)

8. Antenna

50ohm/SMA/Female

9. Shell

Steel metal shell: good electromagnetic shield and, heat radiate performance

Product Specifications

1. Radio Frequency

Full TIA/EIA/IS-98A Complicance CDMA2000 1xRTT: CDMA2000 protocol between Mobile & BS Dual band 800/1900Mhz or 450Mhz Control via AT commands

2. Function

Point-to-point MO and MT SMS cell broadcast Text and PDU mode Support voice, SMS, data service

3. Voltage and Power

Input: 5 - 25VDC (9V suggestion) SIM card support volt: 3V / 1.8V

Max. Output power: 0.2W ~ 0.3W

Power consumption: Sleep mode: 5mA up to 1A (Traffic)

SLIDE 16

EL-G181 GSM Modem

4. Speed

Console Data transfer Speed: 115200bps Communication Data Speed: CSD Downlink/Uplink up to 14.4kbps (Experienced) USSD, Non transparent mode, V.110

5. Dimension & Weight

Dimension: 75*50*16mm Weight: 200g

6. Environment

Work temperature: -30 ~ 70 centigrade degrees Storage temperature: -50 ~ 85 centigrade degrees Humidity: 95% (Non-condensing)

7. Interface

USB 2.0 full speed RS232/RS485 DB9 Interface (External)

8. Antenna

50ohm/SMA/Female

9. Shell

Steel metal shell: good electromagnetic shield and, heat radiate performance

Product Specifications

1. Radio Frequency

Dual-band GSM(EGSM)900MHz/DCS(GSM)1800MH Compliant to GSM phase 2/2+ Output Power: Class 4 (2W) EGSM900 Class 1 (1W) GSM1800 Control via AT commands

2. Function

Point-to-point MO and MT SMS cell broadcast Text and PDU mode Support voice, SMS, data service

3. Voltage and Power

Input: 5 - 25VDC (9V suggestion) SIM card support volt: 3V / 1.8V Power consumption: Sleep mode: 3.0mA Idle mode: 10.0mA Working mode: 300mA (Average), 1.8A (Peak) Power down 100 uA
