Direction Générale de l’Aviation Civile

Ministère de la Transition écologique et solidaire

DSNA experience in Arrival sequence service

to Air France and ADP for Orly and CDG airports

EUROCONTROL SWIM Workshop 9-11/12/19

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

AGENDA

Arrival sequence service presentation and implementation Conformance to the SWIM Specifications Experience gained and suggestions improvement 1 2 3

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

PARTNERSHIP

Arrival sequence service

Subscribe to arrival sequence

AF6107 AF6175 AF7381 FR5432 EZY8732 LFPO LFBZ

Customer 1 Subscription: All AF* to LFPO Time Line Time Line Subscription: All flights from LFBO to LFPO Customer 2

LFBO

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

Arrival sequence service

Architecture

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

Arrival sequence service

Service interface protocols

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

Arrival sequence service

Service interface protocols

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

December 2019

• Deployment of the service for Orly and CDG airports
• Technical validation with ADP and Air France

March 2020

• Deployment of AMAN
• Submit to SWIM governance for assessment
• Registry

Mid-2020

• Operational validation with ADP and Air France

Next step

• Add more airports (Nice and Lyon)
• Arrival sequence provided to interested

ANSP and customers

Roadmap

Deployment phases

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

Conformance assessment

Process

Traceability requirements Traceability requirements

ED-254 Arrival sequence service Performance standard DSNA service description describes the implementation made by DSNA

(ISRM) AIRM

Eurocontrol SWIM specification

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

• Validation of the service with service customers and quality of the

service

• Submission to SWIM governance as a candidate SWIM service

Conformance assessment

What’s next?

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

• Added fields

Example: add « calculationPeriod » in the subscriptionResponse to allow the service consumer to monitor the service

• Some mandatory fields are missing in the service payload

Example: EOBT (not present in AMAN data)

• Modification of the XML schema

Conformance assessment

Difference with the standard in our implementation

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

• Mapping AMAN data with AIRM data model
• Data management : ongoing process to analyse data (e.g. confidentiality,
• pen data, trade secrets)

SWIM Governance Use of Information Code of Conduct is helpful

• Security aspects : ongoing process for managing customer certificates

Learning curve – aligned with SWIM common PKI architecture & principles

Feedback

Experience gained

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

• Yellow Profile specification may be too restrictive on some requirements
• protocol versions to use
• Some extensions data entities are rather an additional service:
• in our AMAN component, the strategy is not applicable on one flight but over a

given period.

• Requirements for service monitoring are needed
• Example: timestamp of the arrival sequence

Feedback

Improvement suggestions

Ministère de la Transition écologique et solidaire

Direction Générale de l’Aviation Civile

ANY QUESTIONS ? FEEDBACKS ?

Thank k you for r your r attention ention !
