DRONES

and how they function...

Dromida Verso

“Flip it, fly it, fun!”

Fly like a bird... I wanna fly awayyyyy

What is a Quadcopter Control Board?

Main Purpose: To Stabilize But how?

It takes the signal from the 3 board gyros :

• 1. Roll
• 2. Pitch
• 3. Yaw

What is a “Yaw”?

Is the rotating head of the drone either left or right and is controlled by the throttle stick which is also called the rudder.

What is a Pitch?

Is the movement of the drone forward

• r backward. Push the aileron stick

forward and it goes forward.

What is a Roll?

Confuses most, but it makes the drone fly sidewards. Controlled with the aileron stick moving it left and right.

DRONES

and where they come from...

The first use of Dones began on August 22, 1849 by Austria to Attack Venice. Later in World War I it began surveillance to observe enermy movements. 1896 Samuel P . Langley developed a steam powererd aerodrome that successfully flew along the Potomac River near DC. 1898 Spanish - American War, the U.S military fitted a camera to a kite producing the first aerial reconnaissance photograph Edward M. Sorenson created a radio controlled aircraft in World War II. In Cold War period, drones were used to target in battle field and for collection radioactive data of nuclear tests. During Vietnam War in 1959, drones were then used as spy planes and practice or aerial combat skils.

http://skytango.com/drones-in-movies-7-hollywood-movies-filmed-with-drones/

Drones and Movies

Drone Police?

Drone Port
