Unmanned Aerial Vehicles a.k.a DRONES What are drones? Unmanned Aerial Vehicle (UAV). Informally known as the Drone, it is a flying aircraft with no pilot inside . Can navigate autonomously by onboard computers or by using a

SLIDE 1

a.k.a

DRONES

Unmanned Aerial Vehicles

SLIDE 2

What are drones?

SLIDE 3

Unmanned

Aerial Vehicle (UAV). Informally known as the Drone, it is a flying aircraft with no pilot inside .

Can navigate autonomously by onboard

computers

by using a remote controller in the hands of a pilot on the ground.

SLIDE 4

Types of Drones

SLIDE 5

Multirotors and Planes

SLIDE 6

Types of Multicopter

TriCopter Quadcopter

SLIDE 7

Hexacopter

Octacopter

SLIDE 8

Types of Planes

Fixed wing drone Flapping wing drone

SLIDE 9

The Hybrid

Vtol

SLIDE 10

Different types of motions

Roll
Pitch
Yaw

SLIDE 11

Roll

SLIDE 12

Pitch

SLIDE 13

Yaw

SLIDE 14

How does a drone fly?

Vertical motion
Horizontal motion
Heading

SLIDE 15

SLIDE 16

Benefits of using drones

Low Risk
Low Cost
Long Operational Hours
Pinpoint accuracy
Easy deployment

SLIDE 17

Applications of Drones

SLIDE 18

Application areas

Military
Package delivery
Surveillance
Agriculture
Photography
Disaster management
Image processing
Traffic monitoring

SLIDE 19

How can drones help?

They can give media access to hard‐to‐reach

places

They can save lives
They can support law enforcement
They can contribute to safe infrastructure

maintenance and management

They can streamline agriculture management

SLIDE 20

Companies using drones

SLIDE 21

Amazon’s Prime Air

SLIDE 22

Google’s Project Wing

SLIDE 23
