SLIDE 1
Drip
Automatic faucet dripper to prevent frozen pipes
$400 million
Yearly damages from frozen and burst pipes
Drip Automatic faucet dripper to prevent frozen pipes $400 million - - PowerPoint PPT Presentation
Drip Automatic faucet dripper to prevent frozen pipes $400 million - - PowerPoint PPT Presentation
Drip Automatic faucet dripper to prevent frozen pipes $400 million Yearly damages from frozen and burst pipes Standard faucet controls Solenoid Valve Hot Input Drip bypass Cold Input Customer Needs & Specifications Prevents Saves
SLIDE 2
SLIDE 3
Cold Input Hot Input Drip bypass Solenoid Valve Standard faucet controls
SLIDE 4
Customer Needs & Specifications
Easy Install Seems like regular faucet Prevents Freezing Saves Water
SLIDE 5
Key Questions
- How efficiently can Drip use water?
- How does Drip fit into a faucet?
SLIDE 6
Freezing Experiment
Dry Ice Pump Copper Tubing Ball Valves (water supply) (pipe near exterior wall) (faucet in house)
SLIDE 7
Results
Drip Frequency Volume/Drip
Infrequent Spurt Full Stream Trickle Infrequent Drip Near-Constant Drip Frequent Spurt
SLIDE 8
Integration Mockup
Solenoid Valve Drip Bypass
Front View Rear View
SLIDE 9
Going Forward
- Determine optimal flow conditions
- Further research on installation requirements
- Interview users for cosmetic and operational
preferences
