SLIDE 1
ETH Zurich – Distributed Computing Group
Roger Wattenhofer
Does a Blockchain Need Altruism? Roger Wattenhofer ETH Zurich - - PowerPoint PPT Presentation
Does a Blockchain Need Altruism? Roger Wattenhofer ETH Zurich - - PowerPoint PPT Presentation
Does a Blockchain Need Altruism? Roger Wattenhofer ETH Zurich Distributed Computing Group Do You Trust the Miners? Modeling Distributed Systems A ltruistic R ational C rash B yzantine Modeling Distributed Systems C rash R ational A ltruistic
SLIDE 2
SLIDE 3
SLIDE 4
Byzantine Altruistic Rational Crash
Modeling Distributed Systems
SLIDE 5
Byzantine Altruistic Rational Crash
Who are the Miners?
Modeling Distributed Systems
SLIDE 6
“The system is secure as long as honest nodes collectively control more CPU power than any cooperating group of attacker nodes.”
SLIDE 7
Mining is a Rational Business
SLIDE 8
Mining is a Rational Business
SLIDE 9
2009 2013 2018
Selfish Mining Timeline
2010
SLIDE 10
Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 …
What is Selfish Mining
SLIDE 11
Analysis
Simpler
SLIDE 12
Original Algorithm
SLIDE 13
Somewhat Simpler Algorithm
SLIDE 14
Tx_0 Tx_1 … Tx_0 Tx_1 …
𝑒𝑞 > 𝑒𝑡
SLIDE 15
Somewhat Simpler Algorithm
SLIDE 16
Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 …
𝑒𝑞 = 𝑒𝑡 − 1
SLIDE 17
Somewhat Simpler Algorithm
SLIDE 18
Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 … Tx_0 Tx_1 …
𝑒𝑞 = 𝑒𝑡
SLIDE 19
State Machine (Original & Simpler)
= 1 − 𝛽 𝛽: probability that selfish miner finds a block
SLIDE 20
Stationary Distribution
SLIDE 21
Computation…
SLIDE 22
All 𝛾 Transitions
0 → 0: Block for honest miners 𝑗 + 1 → 𝑗 : Block for selfish miner (for 𝑗 > 2) 2 → 0: Two blocks for selfish miner 1 → 0: Race who wins next block with probability 𝛽 two blocks for selfish miner with probability 𝛾(1 − 𝛿) two blocks for honest miners with probability 𝛾𝛿 one block each
𝛿: probability that honest miners append block to selfish miner’s block (in race)
SLIDE 23
Ratio of Selfish Blocks in Chain
𝛿: probability that honest miners append block to selfish miner’s block (in race)
SLIDE 24
Selfish Miner Share
SLIDE 25
Selfish Miner Share
𝛿 = 0: break even at 𝛽 = 1/3 𝛿 = 0.5: break even at 𝛽 = 1/4 𝛿 = 1: break even at 𝛽 > 0
SLIDE 26
A Blockchain Without Altruism?
[Joint Work with Jakub Sliwinski]
SLIDE 27
Simple Chains Are Too Simple
SLIDE 28
Better: Expose Competition
SLIDE 29
Our Rational Blockchain
SLIDE 30
Always Refer to All Childless Blocks
SLIDE 31
Only One Type of Reference
(Heaviest Reference is Your “Parent”)
SLIDE 32
2 3 4 5 6
Block Ordering is Recursive
1
SLIDE 33
Incentives
SLIDE 34
Why Miners Should Always Refer to All Childless Blocks?
SLIDE 35
Because of our Block Rewards!
SLIDE 36
It’s Somewhat Complicated…
SLIDE 37
Reward = 0.71 Reward = 0.71 Reward = 1
Motivating Block Rewards I
Reward = 1 Reward = 0.34 Reward = 1
SLIDE 38
Reward = 0.72 Reward = 0.45 Reward = 0.91 Reward = 0.69
Motivating Block Rewards II
SLIDE 39
Our Solution
SLIDE 40
1 1
Block Penalty Example
SLIDE 41
1 0.5 0.5
Block Penalty Example
SLIDE 42
1 1 0.66 0.66 0.66 1 0.5 0.5
Block Penalty Example
SLIDE 43
The Penalty Algorithm
SLIDE 44
The Penalty Algorithm
SLIDE 45
The Penalty Algorithm
1 1 1 1 1 1 1 1 0.66 0.66 0.66 0.66 0.66 0.33 0.33
SLIDE 46
Transaction Fees
SLIDE 47
A B fee = 10 A B fee = 10
SLIDE 48
A B fee/2 = 5 A B fee/2 = 5
SLIDE 49
“The system is secure as long as honest nodes collectively control more CPU power than any cooperating group of attacker nodes.”
rational
SLIDE 50
Thank You!
Questions & Comments?
www.disco.ethz.ch Thanks to Jakub Sliwinski
