Docker Security Workshop Goals of this Workshop Understand and - PowerPoint PPT Presentation

Docker Security Workshop Goals of this Workshop Understand and get Understand and get comfortable with Docker comfortable with Linux security technologies security technologies Swarm Mode Security AppArmor Secrets Management seccomp


  1. Security Scanning: Summary Binary level scans pick Official repos/images up statically linked automatically scanned bins Provides Checks against CVE comprehensive bill of databases materials (BOM)

  2. Q&A

  3. Lab Testing Security Scanning

  4. Secure Orchestration by Default With Swarm Mode

  5. Swarm Mode: Overview Native clustering of Docker Hosts Swarm (cluster) • One or more Ma Managers Docker host Docker host Docker host (control plane) Manager Manager Manager • One or more Wo Work rkers rs (data plane) Docker host Docker host Docker host Worker Worker Worker – Run user workloads • Strong default security (out-of-the-box)

  6. Swarm Mode: Client Certificates Every node gets a Client Swarm (cluster) cert that identifies: Docker host Name : Na manager manager1 The node 1 ID : ofcm6bd… ID sha256 :a3ef… Swarm : 3acc2… Role : manager The Swarm that it’s a member of Expires : 2018… Its role in the Swarm

  7. Swarm Mode: Cryptographic Guarantees Swarm Docker host Docker host Na Name : manager1 Na Name : manager manager ID: 3acc2… ID ID : ofcm6bd… manager2 1 2 ID : bd550f… ID sha256 :a3ef… Swarm : 3acc2… sha256 :hxi3… CA Role : manager Swarm : 3acc2… Expires : 2018… Role : manager Expires : 2018… Docker host Docker host Name : worker1 Na Na Name : worker2 ID ID : 237b3e… ID : 5f99ae1… ID worker1 worker2 sha256 :39ock… sha256 :md66c… Swarm : 3acc2… Swarm : 3acc2… Role : worker Role : worker Expires : 2018… Expires : 2018…

  8. Creating a New Swarm $ docker swarm init Raft Consensus Group Swarm initialized: current node (ofcm6bdy5qcrlievawsw9wqfp) is now a manager. Distributed Cluster Store To add a worker to this swarm, run the following command: Docker host docker swarm join \ Manager --token SWMTKN-1- 31fxss83n3puc6bd11wm8vxged2ul94fxfbckjdy0rj37agk C CA CA ko-bz14m6jyeakhzvccs7wnbmmof \ A 172.31.45.44:2377 To add a manager to this swarm, run 'docker swarm join-token manager' and follow the instructions.

  9. Using and External Root CA CA • Swarm supports using external CAs Manager Manager Manager • Pass the --external-ca flag to the docker swarm init command Worker Worker Worker

  10. Adding More Managers $ docker swarm join-token manager Raft Consensus Group To add a manager to this swarm, run the following command: Distributed Cluster Store docker swarm join \ --token SWMTKN-1-31fx-8z0l... \ Docker host Docker host Docker host 172.31.45.44:2377 Manager Manager Manager CA $ docker swarm join \ > --token SWMTKN-1-31fx-8z0l... \ > 172.31.45.44:2377 This node joined a swarm as a manager.

  11. Adding Workers Raft Consensus Group $ docker swarm join-token worker To add a worker to this swarm, run the Distributed Cluster Store following command: Docker host Docker host Docker host docker swarm join \ Manager Manager Manager --token SWMTKN-1-31fx-bz14... \ 172.31.45.44:2377 CA Docker host Docker host Docker host $ docker swarm join \ Worker Worker Worker > --token SWMTKN-1-31fx-bz14... \ > 172.31.45.44:2377 This node joined a swarm as a worker.

  12. Protect your Join Tokens Only approved nodes should be allowed $ docker swarm join \ > --token SWMTKN-1-31fx-bz14... \ to join your Swarm! > 172.31.45.44:2377 To join a Swarm as a manager , a node This node joined a swarm as a worker. must specify the manager join token. Keep it safe! To join a Swarm as a worker , a node must specify the worker join token. Keep it safe! You can rotate join tokens with: $ docker swarm join-token --rotate worker|manager

  13. Swarm Mode: Client Certificates All nodes get a client $ openssl x509 -in certificate /var/lib/docker/swarm/certificates/swarm-node.crt -text O = Swarm ID Certificate: Swarm ID ... Issuer: CN=swarm-ca Node Role OU = Role Node ID Validity Not Before: Mar 9 15:21:00 2017 GMT CN = Node ID Not After : Jun 7 16:21:00 2017 GMT Subject: O=lgz5xj1eqg..., OU=swarm-manager, CN=ofcm6bdy... ... Client certificates are used X509v3 Subject Alternative Name: for mutual authentication DNS:swarm-manager, DNS:ofcm6bdy..., DNS:swarm-ca and encryption. ... -----BEGIN CERTIFICATE----- MIICNDCCAdugAwIBAgIUCoRaj23j4h5 ...

  14. Swarm Mode: Client Certificates Certificate: ... Issuer: CN=swarm-ca Validity Not Before: Mar 9 15:21:00 2017 GMT Not After : Jun 7 16:21:00 2017 GMT Subject: O=lgz5xj1eqg4pcd0bib75i4fhd, OU=swarm-manager, CN=ofcm6bdy5qcrlievawsw9wqfp X509v3 Subject Alternative Name: DNS:swarm-manager, DNS:ofcm6bdy..., DNS:swarm-ca ... $ docker node ls ID HOSTNAME STATUS AVAILABILITY MANAGER STATUS 4ckd17z0uk6fzi0tfwyxbra1g ip-172-31-34-195 Ready Active ofcm6bdy5qcrlievawsw9wqfp * ip-172-31-45-44 Ready Active Leader p73dypqeyeg9p7iab9d0qzns5 ip-172-31-46-1 Ready Active Reachable ubt37ywh3j171f6lpv3n5et4u ip-172-31-43-107 Ready Active Reachable uf7y3ap5qdyrwmxt9upnctxws ip-172-31-46-102 Ready Active

  15. Swarm Info The docker info command $ docker info ... can be used to display Swarm: active NodeID: ofcm6bdy5qcrlievawsw9wqfp Is Manager: true information about the Swarm ClusterID: lgz5xj1eqg4pcd0bib75i4fhd Managers: 3 that a node belongs to. Nodes: 5 Orchestration: Task History Retention Limit: 5 Raft: Snapshot Interval: 10000 Some security related items Number of Old Snapshots to Retain: 0 Heartbeat Tick: 1 Election Tick: 3 are shown in yellow Dispatcher: Heartbeat Period: 5 seconds CA Configuration: Expiry Duration: 3 months Node Address: 172.31.45.44 Manager Addresses: 172.31.43.107:2377 172.31.45.44:2377 172.31.46.1:2377

  16. Simple Certificate Rotation Automatic client certificate rotation Name: manager1 • defaults to 90 days ID (CN): ofcm6bdy5qcrlievawsw9wqfp • Customizable Swarm (O): lgz5xj1eqg4pcd0bib75i4fhd Role (OU): swarm-manager Swarm operates a whitelist of Not before: Mar 9 15:21:00 2017 GMT valid certificates Not after: Jun 7 16:21:00 2017 GMT sha256: hxi3 … Renewal times are randomized to prevent overloading the CA

  17. Certificate Rotation Only client certificates can be rotated* Use the --cert-expiry flag to change the rotation period The following command will build a Swarm that rotates client certificates every 30 days docker swarm init --cert-expiry 720h0m0s The following command updates a Swarm to rotate client certificates every 60 days docker swarm update --cert-expiry 1440h

  18. Docker Swarm: Secure Cluster Store The cluster store is encrypted Raft Consensus Group • Anything stored in the cluster store is encrypted (secrets Distributed Cluster Store etc.) Docker host Docker host Docker host Manager Manager Manager The cluster store is distributed/replicated across all CA managers

  19. Docker Swarm Security: Recap Secure Join Tokens Client Certificates Docke r Swarm Encrypted Cluster Certificate Rotation Store

  20. Docker Swarm: Workload Placement Constraints Limit the nodes that service tasks can run on

  21. Constraints Constraints use the following: Built-in node attributes node.id | node.hostname | node.role | … Built-in Engine labels engine.labels.operatingsystem | … User-define node labels node.labels.zone | node.labels.pcidss …

  22. Constraints: Only Run Tasks on Worker Nodes $ docker service create \ --name svc1 \ --constraint ‘node.role == worker’ \ redis:latest

  23. Constraints: Only Run Tasks on Nodes Running Ubuntu $ docker service create \ --name svc1 \ --constraint ‘engine.labels.operatingsystem == ubuntu 16.04’ \ redis:latest 72

  24. Constraints: User-defined Labels $ docker node update \ --label-add zone=prod1 \ node1 $ docker service create \ --name svc1 \ --constraint ‘node.labels.zone == prod1’ \ redis:latest

  25. Constraints: User-defined Labels $ docker node update \ --label-add zone=prod1 \ node1 $ docker service create \ --name svc1 \ --constraint ‘node.labels.zone != prod1’ \ redis:latest

  26. User-defined Labels Swarm ID: xah78sba9m228… $ docker node update --label-add Manager Manager Manager Simple key/value pairs zone=prod1 zone=prod1 zone=prod2 Worker Worker Worker Great way to organize nodes zone=prod2 zone=prod2 zone=prod1 Only apply within the Swarm

  27. PCI-DSS Example docker service create \ Swarm ID: xah78sba9m228… --name web-fe \ --constraint ‘node.labels.pcidss == yes’ \ mgr1 mgr2 mgr3 --replicas=3 corp1/nginx:hardened pcidss=no pcidss=no pcidss=yes • Single Swarm with 6 nodes wrkr1 wrkr2 wrkr3 • 3 nodes with label pcidss=yes • 3 nodes with label pcidss=no pcidss=yes pcidss=yes pcidss=no • Service deployed with constraint: • node.labels.pcidss == yes • Service tasks can only be scheduled on nodes with label pcidss=yes

  28. Q&A

  29. Lab Building A Secure Swarm

  30. Secure App-centric Networks with Swarm Mode

  31. Background: Networking is Important! Networking is integral to distributed applications But networking is hard, vast, and complex! Goal: Make Docker networking SIMPLE and SECURE!

  32. Docker Networking Architecture Libnetwork (CNM) Native Network Driver Load Balancing Native IPAM Driver Service Discovery Remote Network Driver Network Control Plane Remote IPAM Driver Docker Engine

  33. • Multihost Networking • Aliases • Plugins Libnetwork • DNS Round Robin • IPAM (CNM) LB • Network UX/API 1.7 1.8 1.9 1.10 1.11 1.12 • Secure out-of-the-box Service Distributed • Encrypted distributed KV Discovery DNS store for network config and state • Encrypted control plane • Encrypted data plane • Built-in routing mesh • Overlay…

  34. PCI-DSS Example Swarm Every Swarm gets a distributed Distributed Cluster Store (Network config and state) cluster store • Encrypted by default Manager Manager Manager • Stores network config and CA state Worker Worker Worker All node-to-node communication is secured by mutual TLS

  35. Secure Networking: Container to Container Control Plane Data Plane Encrypted by default Can be easily encrypted • AES (GCM) • --opt encrypted • Keys rotated every 12 • AES (GCM) hours • Keys rotated every 12 hours

  36. Secure Container Networking: Example $ docker network create -d overlay --opt encrypted my-net Control Plane encrypted Data Plane encrypted Config in secure cluster Keys automatically rotated store

  37. Secure Container Networking: Lazy Creation Newly created networks are only created on nodes that need them Nodes that do not need them do not get them (more secure) Reduces network chatter (more secure)

  38. Secure Container Networking: Isolation RethinkDB Internal nginx service RethinkDB RethinkDB my_app Proxy RethinkDB load_balancer_net app_net db_net

  39. Secure Container Networking: Isolation Internal nginx RethinkDB service load_balancer_net db_net my_app RethinkDB Proxy app_net

  40. Secure Container Networking: Isolation Internal nginx RethinkDB service • Micro segmentation • By default, containers can only talk to other containers on the same network my_app RethinkDB Proxy • Service Discovery is network-scoped load_balancer_net app_net db_net – Containers cannot automatically discover services and containers on other networks

  41. Networking Gotcha Starting a container with the --net=host will allow the container to see all networking traffic on the Docker host! $ docker container run --rm -it \ --net=host \ alpine sh Avoid at all costs!

  42. Q&A

  43. Container Native Secrets Management Docker 1.13 Introduced Native Docker Secrets Management

  44. What is a Secret Humans: Applications: Passwords Secrets Plugin API Design Batteries included but removable

  45. The Three Pillars of Docker Security Secrets Infrastructure Usable Security Trusted delivery Independent

  46. Secrets Management: Usable Security Standardized interface for developers Standardized interface for operations teams Us Usable Fits most existing methods of accessing secrets Sec Security Leverages existing security features of Swarm Mode

  47. Secrets Management: Usable Security (Devs) • Compose and services support for secrets • Define services, secrets, networks and volumes in a single file

  48. Secrets Management: Usable Security (Ops) • Integrated secrets and app management in Docker Datacenter • Deploy Compose file directly with no code changes • Add granular access control to secrets and services

  49. Secrets Management: Simplified Workflow (example) Development Test Production environment environment environment /run/secrets/app-sec /run/secrets/app-sec /run/secrets/app-sec Secret: password Secret: Password123 Secret: @e~£.#$$e…

  50. Secrets Management: Trusted Delivery Secrets encrypted at rest in the cluster store Secrets encrypted in-flight over the network Secrets only available to authorized apps/services Secrets never persisted to disk in containers or on nodes

  51. Secrets Management: Trusted Delivery Raft Consensus Group Internal Distributed Store Web Manager Manager Manager UI Worker 1 Worker 2 Worker 3
