Distributed Systems Principles and Paradigms Maarten van Steen VU - PowerPoint PPT Presentation

Distributed Systems Principles and Paradigms Maarten van Steen VU Amsterdam, Dept. Computer Science Room R4.20, steen@cs.vu.nl Chapter 02: Architectures Version: September 3, 2012 Architectures Architectures Architectural styles Software


  1. Distributed Systems Principles and Paradigms Maarten van Steen VU Amsterdam, Dept. Computer Science Room R4.20, steen@cs.vu.nl Chapter 02: Architectures Version: September 3, 2012

  2. Architectures Architectures Architectural styles Software architectures Architectures versus middleware Self-management in distributed systems 2 / 29

  3. Architectures 2.1 Architectural styles Architectural styles Basic idea Organize into logically different components, and distribute those components over the various machines. Layer N Object Object Layer N-1 Object Method call Request� Response� flow flow Object Layer 2 Object Layer 1 (a) (b) (a) Layered style is used for client-server system (b) Object-based style for distributed object systems. 3 / 29

  4. Architectures 2.1 Architectural styles Architectural Styles Observation Decoupling processes in space (“anonymous”) and also time (“asynchronous”) has led to alternative styles. Component Component Component Component Data Publish Subscribe Notification Subscribe delivery delivery Event bus Publish Component Shared (persistent) data space (a) (b) (a) Publish/subscribe [decoupled in space] (b) Shared dataspace [decoupled in space and time] 4 / 29

  5. Architectures 2.2 System Architectures Centralized Architectures Basic Client–Server Model Characteristics: There are processes offering services (servers) There are processes that use services (clients) Clients and servers can be on different machines Clients follow request/reply model wrt to using services Wait for result Client Request Reply Server Provide service Time 5 / 29

  6. Architectures 2.2 System Architectures Application Layering Traditional three-layered view User-interface layer contains units for an application’s user interface Processing layer contains the functions of an application, i.e. without specific data Data layer contains the data that a client wants to manipulate through the application components Observation This layering is found in many distributed information systems, using traditional database technology and accompanying applications. 6 / 29

  7. Architectures 2.2 System Architectures Application Layering User-interface User interface level HTML page containing list Keyword expression HTML generator Processing level Query Ranked list generator of page titles Ranking algorithm Database queries Web page titles with meta-information Data level Database with Web pages 7 / 29

  8. Architectures 2.2 System Architectures Multi-Tiered Architectures Single-tiered: dumb terminal/mainframe configuration Two-tiered: client/single server configuration Three-tiered: each layer on separate machine Traditional two-tiered configurations: Client machine User interface User interface User interface User interface User interface Application Application Application Database User interface Application Application Application Database Database Database Database Database Server machine (a) (b) (c) (d) (e) 8 / 29

  9. Architectures 2.2 System Architectures Decentralized Architectures Observation In the last couple of years we have been seeing a tremendous growth in peer-to-peer systems. Structured P2P: nodes are organized following a specific distributed data structure Unstructured P2P: nodes have randomly selected neighbors Hybrid P2P: some nodes are appointed special functions in a well-organized fashion Note In virtually all cases, we are dealing with overlay networks: data is routed over connections setup between the nodes (cf. application-level multicasting) 9 / 29

  10. Architectures 2.2 System Architectures Structured P2P Systems Basic idea Organize the nodes in a structured overlay network such as a logical ring, or a hypercube, and make specific nodes responsible for services based only on their ID. 0000 0001 1001 1000 0010 0011 1011 1010 0100 1101 0101 1100 0110 0111 1111 1110 Note The system provides an operation LOOKUP(key) that will efficiently route the lookup request to the associated node. 10 / 29

  11. Architectures 2.2 System Architectures Unstructured P2P Systems Essence Many unstructured P2P systems are organized as a random overlay: two nodes are linked with probability p . Observation We can no longer look up information deterministically, but will have to resort to searching: Flooding: node u sends a lookup query to all of its neighbors. A neighbor responds, or forwards (floods) the request. There are many variations: Limited flooding (maximal number of forwarding) Probabilistic flooding (flood only with a certain probability). Random walk: Randomly select a neighbor v . If v has the answer, it replies, otherwise v randomly selects one of its neighbors. Variation: parallel random walk. Works well with replicated data. 11 / 29

  12. Architectures 2.2 System Architectures Superpeers Observation Sometimes it helps to select a few nodes to do specific work: superpeer. Super peer Overlay network of super peers Weak peer Examples Peers maintaining an index (for search) Peers monitoring the state of the network Peers being able to setup connections 12 / 29

  13. Architectures 2.2 System Architectures Hybrid Architectures: Client-server combined with P2P Example Edge-server architectures, which are often used for Content Delivery Networks Client Content provider ISP ISP Core Internet Edge server Enterprise network 13 / 29

  14. Architectures 2.2 System Architectures Hybrid Architectures: C/S with P2P – BitTorrent Client node K out of N nodes Node 1 Lookup(F) Node 2 A BitTorrent� .torrent file� List of nodes� Web page for F storing F Ref. to� Ref. to� file� tracker Web server File server Tracker server Node N Basic idea Once a node has identified where to download a file from, it joins a swarm of downloaders who in parallel get file chunks from the source, but also distribute these chunks amongst each other. 14 / 29

  15. Architectures 2.3 Architectures versus Middleware Architectures versus Middleware Problem In many cases, distributed systems/applications are developed according to a specific architectural style. The chosen style may not be optimal in all cases ⇒ need to (dynamically) adapt the behavior of the middleware. Interceptors Intercept the usual flow of control when invoking a remote object. 15 / 29

  16. Architectures 2.3 Architectures versus Middleware Interceptors Client application Intercepted call B.do_something(value) Application stub Request-level interceptor Nonintercepted call invoke(B, &do_something, value) Object middleware Message-level interceptor send([B, "do_something", value]) Local OS To object B 16 / 29

  17. Architectures 2.4 Self-management in Distributed Systems Self-managing Distributed Systems Observation Distinction between system and software architectures blurs when automatic adaptivity needs to be taken into account: Self-configuration Self-managing Self-healing Self-optimizing Self-* Warning There is a lot of hype going on in this field of autonomic computing. 17 / 29

  18. Architectures 2.4 Self-management in Distributed Systems Feedback Control Model Observation In many cases, self-* systems are organized as a feedback control system. Uncontrollable parameters (disturbance / noise) Initial configuration Corrections Observed output Core of distributed system +/- +/- +/- Reference input Adjustment� Metric� measures estimation Analysis Measured output Adjustment triggers 18 / 29

  19. Architectures 2.4 Self-management in Distributed Systems Example: Globule Globule Collaborative CDN that analyzes traces to decide where replicas of Web content should be placed. Decisions are driven by a general cost model: cost = ( w 1 × m 1 )+( w 2 × m 2 )+ ··· +( w n × m n ) 19 / 29

  20. Architectures 2.4 Self-management in Distributed Systems Example: Globule Client Origin server ISP ISP Core Internet Replica server Enterprise network Client Client Globule origin server collects traces and does what-if analysis by checking what would have happened if page P would have been placed at edge server S . Many strategies are evaluated, and the best one is chosen. 20 / 29

  21. Architectures Extra: Strategy evaluation in Globule An experiment Research question Does it make sense to distribute each Web page according to its own best strategy, instead of applying a single, overall distribution strategy to all Web pages? AS 1 AS 2 AS 3 Client Client Client Client Client Client Client Client Client Edge Edge Edge server server server Client Origin server Clients in an AS of document’s Client unknown AS origin server Client Client Client Client 21 / 29

  22. Architectures Extra: Strategy evaluation in Globule An experiment We collected traces on requests and updates for all Web pages from two different servers (in Amsterdam and Erlangen) For each request, we checked: From which autonomous system it came What the average delay was to that client What the average bandwidth was to the client’s AS (randomly taking 5 clients from that AS) Pages that were requested less than 10 times were removed from the experiment. We replayed the trace file for many different system configurations, and many different distribution scenarios. 22 / 29
