August 2017

Designing the Solution for Electrochemistry

Company Introduction

CE Mark & ISO-Certified Manufacturer

Product Range

• Single Channel Potentiostat/Galvanostat WPG100 series/WPG100HP

ZIVE SP series/ZIVE PP1e

• Multichannel Potentiostat/Galvanostat WMPG1000 series/ ZIVE MP series
• Dual / Bi-Potentiostat

ZIVE BP2 series

• Battery Charge/Discharge Cycler WBCS3000 series
• Fuel Cell Test System Smart series
• Impedance Monitor Zcon/Z# series
• Software ZMAN/IVMAN/LOADRUNNER/SIM4U etc.
• Accessories Faraday cage, Cell, Jig, Fuel cell fixture etc.

Product Range

Applications

• Other Applications
• Coating evaluation
• Heavy metal detection
• Semiconductor
• EDLC
• Membrane
• Bioelectrochemistry
• Material testing

Application

Product Range

Potentiostat/Battery Cycler

Impedance measurement available?

Multichannel WMPG Series

NO YES Potentiostat Battery Test System Electrochemical Workstation

Potentiostat/Battery Test System

ZIVE Series

Single Channel WPG Series WBCS Series Multichannel MP Series Single Channel SP Series Dual/Bi-P’stat BP Series Portable P’stat PP Series

Feature

• Economical price
• 16bit ADC/DAC
• Accurate control & measurement
• 8 current ranges
• Sampling time : >500usec
• Easy-to-control software
• Free software upgrade
• Importing/exporting data file
• For long term experiment
• TCP/IP communication
• Temperature/Auxiliary voltage monitoring available

(option)

• Customized specification available

Standard P’stat/G’stat, WPG100e 10V, 1A control (standard model) High Power P’stat/G’stat, WPG100HP

• Max. ±400A, Max. 4kW

Potentiostat/Galvanostat

Single Channel WPG Series

Potentiostat/Galvanostat

Multichannel WMPG Series

Feature

• Plug-in type module with independent channel operation
• 16bit ADC/DAC
• Accurate control & measurement
• 3 or 5 current ranges depending on models
• High resolution and accuracy in both current control

and measurement(auto/manual selection)

• Sampling time : 10msec
• Easy-to-control software
• Free software upgrade
• Importing/exporting data file
• For long term experiment
• TCP/IP communication
• Temperature/Auxiliary voltage monitoring available (option)
• Customized specification available

Standard Type, WMPG1000

• Voltage range : ±10V(standard)
• Current range : max. ±5A, 5 range
• Max. power per channel : 50Watt

Low Current Type, WMPG1000

• Voltage range : ±10V(standard)
• Current range : max. ±10mA@10V (WMPG1000L)
• max. ±100mA@10V (WMPG1000Le)

5 range

• Max. power per channel : 500mWatt

Potentiostat/Galvanostat

Multichannel WMPG Series

Mid Power Type, WMPG1000M2

• Voltage range : ±10V(standard)
• Current range : max. ±10A, 3 range
• Max. power per channel : 200Watt

High Power Type, WMPG1000HP

• Voltage range : user specification
• Current range : max. ±400A, 1 or 3 ranges
• Max. power per channel : 4kWatt

Potentiostat/Galvanostat

Multichannel WMPG Series

Fixed Specification Model, WMPG1000K8

• Voltage range : ±10V
• Current range : ±1A, 5 range
• 8 channel system, channel expansion is not available.

Fixed Specification Model, WMPG1000LeK8

• Voltage range : ±10V(standard)
• Current range : ±50mA, 5 range
• 8 channel system, channel expansion is not available.

Fixed Specification Model, WMPG1000LK8

• Voltage range : ±10V(standard)
• Current range : ±10mA, 5 range
• 8 channel system, channel expansion is not available.

Battery Test System

WBCS Series

Feature

• Plug-in type module with independent channel operation
• Power supply per 8ch substation
• 4 Probe type true P’stat/G’stat circuit
• Analog feedback circuit for constant
• Voltage & current control
• No switching time between charging and discharging step
• High resolution 16bit ADC/DAC
• Multiple current range (3 ranges, standard)
• Channel expansion up to 128 channels
• MOSFET type bipolar linear circuit
• Unique “fail check” function
• Half cell test available
• TCP/IP communication

Standard Type, WBCS3000S

• Voltage range : ±5V(standard)
• Current range : max. ±5A, 3 range
• Max. power per channel : 50Watt

Low Current Type, WBCS3000L

• Voltage range : ±5V(standard)
• Current range : max. ±10mA@5V (WBCS3000L)
• max. ±100mA@5V (WBCS3000Le)

3 range

• Max. power per channel : 500mWatt

Battery Test System

WBCS Series

Mid Power Type, WBCS3000M2

• Voltage range : ±10V(standard)
• Current range : max. ±12A@5V, 3 range
• Max. power per channel : 200Watt

High Power Type, WBCS3000HP

• Voltage range : user specification
• Current range : max. ±400A, 1 or 3 ranges
• Max. power per channel : 4kWatt

Battery Test System

WBCS Series

Fixed Specification Model, WBCS3000K8

• Voltage range : ±5V
• Current range : ±1A, 5 range
• 8 channel system, channel expansion is not available.

Fixed Specification Model, WBCS3000LeK8

• Voltage range : ±5V(standard)
• Current range : ±100mA, 3 range
• 8 channel system, channel expansion is not available.

Fixed Specification Model, WBCS3000LK8

• Voltage range : ±5V(standard)
• Current range : ±10mA, 3 range
• 8 channel system, channel expansion is not available.

Fuel Cell Test Station

Smart Series

PEM/DM Test System, Smart2

Feature

• Fully integrated compact size
• Suitable for 100Watt PEMFC and DMFC single cell
• Automatic purge gas control
• Temperature measurement and control external anode &

cathode line and cell

• Fully automatic operation by PC control
• Max. 4 channel control by one PC
• Accurate electronic load
• Stoichiometric control is available
• Piston Pump for Methanol flow control
• NafionTM membrane type humidifiers for fuel and oxidant gas
• Various safety functions including watch-dog function
• Powerful software with independent data analysis software

PEM Test System, Smart2PEM DM Test System, Smart2DM

Impedance Monitor

Zcon / Z# Series

Single Channel Impedance Monitor, Zcon

• 2 signal input channel(current and voltage)

and 1 signal output for sinewave

Feature

• For versatile AC impedance experiment using an external

electronic load or a potentiostat/galvanostat

• A flexible frequency generator/analyzer
• Generate various waveforms (e.g. Sinusoidal etc.)
• Designed for spectrum analysis in the electrochemical field
• Simulation and fitting with ZMANTM
• Software controlled function
• Graphic-based user-interface
• Dual real time graph (Bode, Nyquist, etc.) during measurement
• Free analysis using ZMANTM impedance analysis software

without license code

Application

• Fuel cell stack EIS monitoring
• Battery pack EIS monitoring
• General electrochemical study requiring EIS measurement

Multichannel Impedance Monitor, Z#

• 6 signal input channel/1 signal output channel

per set

• analog output as signal generator

a) number of channel : 1 b) max. output : -11.0 to +11.0 V (DC + AC) c) frequency range : 1uHz to 100kHz

Electrochemical Workstation

Common Features

Feature

• Research grade Potentiostat/Galvanostat/ZRA
• Built-in FRA: no other devices needed for impedance measurement
• Supports total 14 EIS techniques including multisine technique
• User can create a scheduled task by using technique menu, sequence editor and batch file
• Internal 295,000 data point storage & continuing experiment regardless of a PC failure.

After the PC is recovered, the data will be transferred automatically.

• Optional power booster available for high current application
• High speed data sampling time
• 50usec/sample in burst mode
• 1msec/sample in normal mode
• 2usec/sample in fast sweep mode
• Supports iR measurement and compensation
• FRA function is to control external electronic load or potentiostat for EIS measurement (except for SP1 & MP1)
• Full software package included as standard: Basic/EIS/Energy/Corrosion/Echem Analysis
• Supports EIS and DC data analysis with ZMAN™ and IVMAN™ Software, respectively
• Channel expansion is available by USB Hub

Electrochemical Workstation

Common Features

W hen com m unication fails w ith a PC

• When communication error occurs between ZIVE product and PC, the data will be stored on the device memory.
• The data will be transferred to the PC after PC is restored.

Electrochemical Workstation

Common Features

System configuration available w ith single channel ZI VE products

Electrochemical Workstation

Common Features

FRA function

• Except for SP1 and MP1
• Supports following techniques;
• FRA potentiostatic EIS
• FRA galvanostatic EIS
• FRA potentiostatic HFR
• FRA galvanostatic HFR
• FRA cable needed

Electronic load Fuel cell Zive Product

Electrochemical Workstation

Common Features

LCD Display

• for ZIVE SP1, SP2, SP5, SP5H, SP5HC, BP2A, BP2C, and 4-housing system MP1

EIS Mode DC Mode

Electrochemical Workstation

Single Channel ZIVE SP Series

ZI VE SP1

• economic model
• voltage range : ±10V, ±1V, ±100mV
• current range : 100nA to 1A, 10 ranges

(1nA & 10nA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 1MHz

ZI VE SP2

• standard model
• voltage range : ±10V, ±1V, ±100mV
• current range : 2nA to 2A, 12 ranges

(20pA & 200pA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 2MHz

Electrochemical Workstation

Single Channel ZIVE SP Series

ZI VE SP5

• high current model
• voltage range : ±10V, ±1V, ±100mV
• current range : 5nA to 5A, 12 ranges

(50pA & 500pA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 1MHz

ZI VE SP5 H

• high voltage, high compliance voltage model
• voltage range : ±40V, ±4V, ±400mV
• current range : 1nA to 1A, 12 ranges

(10pA & 100pA with gain)

• compliance range : ±44V
• frequency range : 10μHz ~ 600kHz

Electrochemical Workstation

Single Channel ZIVE SP / PP1e Series

ZI VE SP5 HC

• high compliance voltage model
• voltage range : ±10V, ±1V, ±100mV
• current range : 1nA to 1A, 12 ranges

(10pA & 100pA with gain)

• compliance range : ±44V
• frequency range : 10μHz ~ 1MHz

ZI VE PP1 e

• portable model
• voltage range : ±10V, ±1V, ±100mV
• current range : 100nA to 1A, 10 ranges

(1nA & 10nA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 1MHz

Electrochemical Workstation

Dual Channel / Bi-Potentiostat ZIVE BP2 Series

ZI VE BP2 A

• dual channel model model
• voltage range : ±10V, ±1V, ±100mV
• current range : 2nA to 2A, 12 ranges

(20pA & 200pA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 2MHz

ZI VE BP2 C

• bi-potentiostat model
• voltage range : ±10V, ±1V, ±100mV
• current range : 2nA to 2A, 12 ranges

(20pA & 200pA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 1MHz

Cell configuration available Cell configuration available

Electrochemical Workstation

Multichannel ZIVE MP Series

ZI VE MP1

• economic model
• voltage range : ±10V, ±1V, ±100mV
• current range : 100nA to 1A, 10 ranges

(1nA & 10nA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 1MHz

ZI VE MP2 A

• standard model
• voltage range : ±10V, ±1V, ±100mV
• current range : 2nA to 2A, 12 ranges

(20pA & 200pA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 2MHz

4ch housing system with LCD display 8ch housing system without LCD display Cell configuration available

Electrochemical Workstation

Multichannel ZIVE MP Series

ZI VE MP2 C

• for multi-working electrode experiment
• voltage range : ±10V, ±1V, ±100mV
• current range : 2nA to 2A, 12 ranges

(20pA & 200pA with gain)

• compliance range : ±12V
• frequency range : 10μHz ~ 1MHz

ZI VE MP5

• high current model
• voltage range : ±10V, ±1V, ±100mV
• current range : 5nA to 5A, 12 ranges

(50pA & 500pA with gain)

• compliance range : ±10V
• frequency range : 10μHz ~ 1MHz

Cell configuration available

Electrochemical Workstation

Multichannel ZIVE MP Series

ZI VE MP5 H

• high voltage, high compliance voltage model
• voltage range : ±40V, ±4V, ±400mV
• current range : 1nA to 1A, 12 ranges

(10pA & 100pA with gain)

• compliance range : ±44V
• frequency range : 10μHz ~ 600kHz

ZI VE MP5 HC

• high compliance voltage model
• voltage range : ±10V, ±1V, ±100mV
• current range : 1nA to 1A, 12 ranges

(10pA & 100pA with gain)

• compliance range : ±44V
• frequency range : 10μHz ~ 1MkHz

Electrochemical Workstation

Smart Manager(SM) Software

• Software packages included
• Basic techniques
• Energy software package (BAT)
• EIS software package (EIS)
• Electrochemical analysis software package(EAS)
• Corrosion software package (COR)
• Supports fourteen(14) EIS techniques
• Current interrupt iR measurement/iR compensation
• Pulse charge/discharge test available
• Bipolar pulse capability
• High speed data sampling time
• 50usec/sample in burst mode
• 1msec/sample in normal mode
• 2usec/sample in fast sweep mode
• Free software package

Electrochemical Workstation

Smart Manager(SM) Software

• User friendly software
• Universal graphic (DC/EIS/Cycle)
• Experiment can be scheduled by following three methods
• Technique menu
• Sequence file editor : User can easily create sequences beginning from simple structures right up to

complex measurement procedures.

• Bath file : User can make a batch file by combining technique file and sequence file.
• BCO(button click operation) function : Click icon for the system operation
• Fail function
• Safety limit setting
• New file creation during experiment
• Bipolar pulse capability
• Sine wave control available

Data editor About New sequence Open schedule file Device utility Save sequence file as Technique function Batch function Single channel monitor Multichannel monitor Multichannel real time graph Simple monitor View DC/EIS/Cycle graph Graph properties Strip chart

Electrochemical Workstation

Smart Manager(SM) Software

Techniques Sequence File Editor Batch File Editor

How to Make a Schedule File

Basic Techniques EIS Software Package Energy Software Package Corrosion Software Package Echem Analysis Software Package Technique File + Sequence File

Electrochemical Workstation

Smart Manager(SM) Software

Techniques

Electrochemical Workstation

Smart Manager(SM) Software

• Basic techniques
• 1. Potentiostatic
• 2. Galvanostatic
• 3. Double step potentiostatic
• 4. Double step galvanostatic
• 5. OCP measurement
• 6. Potential sweep
• 7. Current sweep
• 8. Cyclic voltammetry
• 9. Fast potential sweep
• 10. Potentiostatic Ru measurement
• 11. Galvanostatic Ru measurement

CV curve of potassium ferricyanide(K3Fe(CN)6) in KNO3

Electrochemical Workstation

Smart Manager(SM) Software

• EIS software package(EIS)
• 1. Potentiostatic EIS
• 2. Galvanostatic EIS
• 3. Pseudo galvanostatic EIS
• 4. OCP EIS
• 5. Potentiodynamic PEIS
• 6. Galvanodynamic GEIS
• 7. Potentiodynamic HFR
• 8. Galvanodynamic HFR
• 9. Potentiostatic HFR monitor
• 10. Galvanostatic HFR monitor
• 11. Multisine potentiostatic EIS
• 12. Multisine galvanostatic EIS
• 13. Intermittent potentiostatic EIS
• 14. Intermittent galvanostatic EIS

Coin cell intermittent PEIS 3D Nyquist plot by ZMAN Potentiostatic EIS of a coin cell, Nyquist plot

Electrochemical Workstation

Smart Manager(SM) Software

• Energy software package(BAT)
• 1. Battery test technique
• CC/CC test for cycle life test of NiCd or NiMH battery
• Discharging test
• EVS(Electrochemical voltage spectroscopy)
• Variable scan rate CV
• Potentiostatic IV curve
• Galvanostatic IV curve
• Steadystate CV
• GITT
• PITT
• 2. Pulse mode is available for GSM & CDMA profile.

Pulse shape profile can be created by user’s demand.

• 3. Control mode
• Charge: CC, CC-CV, pulse, sine wave
• Discharge: CC, CP, CR, pulse, sine wave
• 4. Cutoff condition
• time, voltage, current, power, temperature, auxV etc.

C-rate charge/discharge of a coin cell

Electrochemical Workstation

Smart Manager(SM) Software

• Electrochemical analysis software package(EAS)
• 1. Step techniques
• CA(Chronoamperometry)
• CC(Chronocoulometry)
• CP(Chronopotentiometry)
• 2. Sweep techniques
• LSV(Linear sweep voltammetry)
• SDV(Sampled DC voltammetry)
• Fast CV
• Fast LSV
• 3. Pulsed techniques
• DPV(Differential pulse voltammetry)
• SWV(Square wave voltammetry)
• DPA(Diff. pulse amperometry)
• NPV(Normal pulsed voltammetry)
• RNPV(Reverse normal pulse voltammetry)
• DNPV(Differential normal pulse voltammetry)

Chronoamperometry experiment Differential pulse voltammetry

Electrochemical Workstation

Smart Manager(SM) Software

• Corrosion software package(COR)
• 1. Tafel(Tafel experiment)
• 2. Rp(Polarization resistance)
• 3. RpEc trend
• 4. PDYN(Potentiodynamic)
• 5. CYPOL(Cyclic polarization resistance)
• 6. GDYN(Galvanodynamic)
• 7. Reactivation
• 8. Galvanic corrosion
• 9. Potentiostatic ECN
• 10. Galvanostatic ECN
• 11. ZRA mode ECN

Tafel experiment Tafel analysis in IVMAN

Electrochemical Workstation

Smart Manager(SM) Software

Sequence File Editor

Tree View Sequence Cut-off Condition Sampling Condition

Electrochemical Workstation

Smart Manager(SM) Software

• Control parameter

Electrochemical Workstation

Common Features – SM Software

Batch File Editor

• In batch file operation, sequence files and/or technique files will be executed sequentiall0y.
• Cycling(looping) mode is available.
• Each sequence file or technique file is editable.

Click here for more detailed information on SM Software

How to Make a Quotation

WMPG / WBCS System

WMPG System WBCS System Start-Up Kit

• Includes SI software
• LAN communication

Substation

• 8 channel substation – basic unit
• Stackable for channel expansion
• Rack mount type is available from 32 channel system

with standard specification if required Plug-in Module

• Selectable depending on required channel specification
• Should be included as many as number of channels

required Cell Cable

• Standard length : 1.5 meter

Options

(if required)

• battery jig, aux voltage measurement module,

temperature/voltage monitoring system, thermocouple, etc.

• WPG System comes with a cell cable as standard.

How to Make a Quotation

ZIVE SP / BP / PP Series

ZIVE SP / BP / PP Series SP / BP / PP System

• Cell cable and SM software are included

Options

• ZRA and FRA cable
• for SP2, SP5, and BP2A/BP2C
• supplied with SP1 and PP1 as standard
• Power Booster
• Battery pack for PP1e system
• Battery jig, thermocouple, etc.

How to Make a Quotation

ZIVE MP Series

ZIVE MP Series MP System

• SM software are included
• Should be selected depending on number of channels
• rdered.

Cell Cable

• Should be ordered depending on number of channels.

Options

• Aux, ZRA and FRA cable
• for MP2, MP5, and MP2A/MP2C
• supplied with MP1
• Power Booster
• Battery pack for PP1e system
• Battery jig, thermocouple, etc.

Other Software

• EIS data analysis software

3D plot Tafel initial fitting CV simulation

ZMAN I VMAN SI M4 U

• DC data analysis software
• Simulation software for

cyclic voltammetry License code is needed to analyze the data obtained by using 3rd party’s instruments.

Other Software

• Dynaload control software

Virtual control panel Fuel mixing software for DM fuel cell

LoadRunner Solution Mixer

• Ismatec pump control software

Accessories

Pow er Booster

• for high current application
• modular type design
• EIS capability

ZB1 with ZIVE SP2

Cell Voltage/ Tem p. Monitoring System

• for battery pack potential / temperature measurement
• corrosion potential measurement, etc.

cX816: 8 ch temperature input & 16 ch voltage input Rack type Click here for Accessory brochure

Accessories

Battery Jig

• for cylindrical cell and/or coin cell
• 2- or 4- contact point
• gap between contact pin is fixed or adjustable
• for WBCS or ZIVE series

CCJ8F2

Pouch Cell Jig

• PPJ series
• pull down contact type
• 4 contact point type (Kelvin probe)
• APJ series
• alligator clip contact type
• for WBCS series

UCJ1 CCJ4F2 two stage PPJ4 APJ64

Accessories

Coin Cell Holder

• for 2016, 2025, 2032 coin cell
• CCH2 / CCH2L : for WBCS series
• CCH3 : for ZIVE SP1, SP2, MP1, MP2, and BP2 model

CCH3 for ZIVE system

Multiplexer

• for multiple cell operation
• for ZIVE SP2, SP5, BP2, MP2, and MP5
• Part No. : MUX8B

CCH2 For WBCS system MUX8B

Accessories

Faraday Cage

• designed to block out external EMI noise
• size
• overall : 300x398x300mm(WxHxD)
• window : 100x300mm(WxH)

Black Box

• designed for photo- and spectro-electrochemical

experiments

• Part No. & size
• BB1 : 603x300x330mm(WxDxH)
• BB1S : 297x245x250mm(WxDxH)

Farad2 BB1 BB1S

Accessories

Fuel Cell Hardw are Fixture

• for PEM and DM fuel cell
• max. operating temperature : 120˚C or 180˚C
• active area : 5, 9, 25, 50, 100cm²
• components

serpentine flow pattern, cartridge heater(2), current collector(2), cell graphite(2), end plate(2), connector

• thermal jacket is available as an option.
• MEA is not included.

SCFC with cartridge heater

MEA

• active area : 25cm² (5x5cm)
• reactants : hydrogen/oxygen or air
• Pt charge anode/cathode : 0.2/0.4mg/cm²
• gas diffusion layers included, hot bonded to MEA
• Part No.
• 2 pcs/pk : MEA2
• 5 pcs/pk : MEA5
• 10 pcs/pk : MEA10

MEA

Accessories

Mem brane Conductivity Cell

• designed to measure ionic conductivity by

simply loading a membrane into cell hardware

• 2 or 4 electrode measurement
• material
• cell body : PEEK
• wire : platinum
• Part No. : MCC

Through-Plane Conductivity Jig

• designed to measure through-plane conductivity of

membranes

• 2 electrode measurement
• suitable for ion exchange membrane test
• Part No. : MCJ1

MCC MCC with fuel cell hardware fixture MCJ

Accessories

Photo Echem Cell Kit

• designed to characterize electrode material

under lighting condition

• for 2- or 3- electrode test
• gas tight cell
• attachments are interchangeable between cells
• chemically resistant PEEK cell body
• coiled Pt wire as a counter electrode is included
• Part No.
• standard type : PCELL1
• two optical window type : PCELL2
• specimen holder type : PCELL3

PCELL1 PCEEL2 PCEEL1 PCELL3

Accessories

Corrosion Cell

• standard or water-jacketed type
• doesn’t include electrodes
• optional items : flat specimen holder, thermometer
• Part No. :

200ml volume : CCK02 / WCCK02 500ml volume : CCK05 / WCCK05 1 liter volume : CCK1 / WCCK1

(cell components may vary depending on model.)

WCCK1, water-jacketed type

Flat Cell Kit

• for flat specimen samples
• two opening area
• doesn’t include a reference electrode
• detachable counter electrode(graphite plate) is

included

• Part No. :

standard type : FCK2 water-jacket type : WFCK2 FCK2, standard type

Accessories

Plate Cell Kit

• designed to evaluate plate material such as

metal, semi-conducting plate, etc.

• sample size : width: >15mm,

thickness: 0.1~10mm

• doesn’t include electrodes
• Part No. : PTC1

WCCK1, water-jacketed type

Plate Cell Kit

• for coated plate test
• doesn’t include electrodes
• Part No. :
• 5ml volume : PTC015
• 55ml volume : PTC2
• sample size :
• PTC015 : 29x29mm or more, >3mm thickness
• PTC2 : 60x60mm or more, >7mm thickness

PTC2 PTC015

Accessories

H-Type Cell

• for membrane or permeation foil test
• membrane, graphite rod, reference electrode,

flag type Pt counter electrode, and flat specimen holder are not included

• Part No. :

100ml volume/each : HCELL01 200ml volume/each : HCELL02 500ml volume/each : HCELL05 1 liter volume/each : HCELL1

(cell components may vary depending on model.)

HCELL1

Electrode Holder & Glass Vial

• hole size : 4, 1.6mm to 10mm dia.
• three screws to adjust the hole size
• material : Teflon
• Part No. :
• electrode holder : UEH1
• glass vial : 20ml vial, GV20

50ml vial, GV50 100ml vial, GV100 200ml vial, GV200 HCELL01 UEH1

with optional electrodes and a glass vial

HCELL01S Glass Vial, GV series

Accessories

Flat Specim en Holder

• disk specimen holder
• glass tube diameter : 6.3mm
• sample thickness : 0.3~5.8mm
• Part No.

1) FSH2

• active area : 11.28mm dia.
• sample size : 15.5mm~22mm dia.

2) FSH15

• active area : 15mm dia.
• sample size : 18.5mm~25mm dia.

FSH2

Duck-billed Specim en Holder

• Cu rod with Au or Cu plated duck-billed clip
• Part No.
• Au plated : CUAU
• Cu plated : CUCU

Accessories

Pt Plate/ Mesh Electrode

• made up with a supporting rod with a suitable

sized piece of Pt foil or Pt mesh at the end.

• thickness : 0.2mm
• Part No.
• PFL1 : 1cm² active area
• PFL4 : 4cm² active area
• PFL5 : 5cm² active area
• PFL9 : 9cm² active area
• PFL16 : 16cm² active area
• PFL25 : 25cm² active area

* Part No. with suffix ‘M’ means mesh type electrode. e.g. : PFL16M

PFL25

Pt Gauze Electrode

• for bulk electrolysis experiment
• 50 mesh, 0.5mm dia. Pt
• dimensions
• electrode : 40mm dia. X 50mm height
• connecting Pt wire : 1mm dia. X 50mm long
• Part No. : PGE

Plate or mesh type PGE

Contact
